Amana AMAW27S Bedienungsanleitung
WINE COOLER
Model No.:AMAW27S
CUSTOMER SERVICE NUMBER
In the U.S. 1-855-666-4477
KEEP THIS NUMBER FOR FUTURE REFERENCE!
Warrantor: Zhongshan Galanz Consumer
Electric Appliances Co., Ltd, Guangdong 528429
To ensure proper use of this appliance and for your safety, please read
the following instructions completely before operating this appliance.
by Galanz-Zhongshan Galanz Consumer Electric Appliances Co., Ltd.,
Guangdong, China. Limited warranty provided by manufacturer.
®/TM 2018 . Amana All rights reserved. Manufactured under license
C
AMAW25S2MS
1
TABLE OF CONTENTS
WINE COOLER SAFETY
Reversing the door.......................................................................
11
Wine cooler safety ...................................................................... 1
Important safety instructions...................................................... 11
Important grounding instructions............................................... 2
Installation instructions............................................................... 3
Operating instructions................................................................. 6
Parts and features........................................................................ 7
Specifications............................................................................... 8
Cleaning....................................................................................... 9
Power Failure...............................................................................10
Vacation and ............................................................moving care 10
Troubleshooting tips....................................................................13
Assistance....................................................................................15
Warranty......................................................................................15
Location requirements................................................................... 3
When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of explosion fire, electrical shock, and/or injury to
persons, including the following:
Read all instructions before using the appliance.
1.This appliance must be grounded. Connect only to properly grounded outlet.
See Important Grounding Instructions on page 2 and page 3.
2.Install or locate this wine cooler only in accordance with the provided
Installation Instructions.
3.To protect against electric shock, do not place cord, plug, or wine cooler in
water or other liquid.
4.The refrigerant of this product is R600a, which isflammable. Make sure not to
damage the cooling system during the transportation and installation.
Please note that servicing shall be done by factory authorized service
personnel, so as to minimize the risk of possible ignition due to incorrect parts
or improper service.
5.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your
appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you
and others.
All safety messages will follow the safety alert symbol and either the
These words mean:
word”DANGER” or “WARNING.”
You can be killed or seriously injured if you don’t
immediately follow instructions.
You can be killed or seriously injured if you don’t
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to
the chance of injury, and tell you what can happen reduce if the instructions
are not followed.
–
2 3
Before you throw away your old wine cooler:
1.Take off the doors.
2.Leave the shelf racks in place so that children may not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants, which under federal law must be
removed prior to product disposal. If you are getting rid of an old wine cooler
product, check with a qualified disposal company for instructions.
IMPORTANT GROUNDING INSTRUCTIONS
This appliance must be grounded due to the event of an electrical short circuit.
This appliance is equipped with a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is properly installed and
grounded.
1.Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood or if
doubt exists as to whether the appliance is properly
grounded.
LOCATION REQUIREMENTS
Keep flammable materials and vapors,such as
gasoline,away from wine cooler .
54
wine cooler
wine cooler
wine cooler
4
4
wine cooler
left right
WINE STORAGE
1. The maximum capacity of AMAW27S/AMAW25S2MS is 25 wine bottles (750ml).
2. To achieve the maximun capacity, place 9 bottles in the first rack as shown
below in Figure A, place 5 bottles in the next 2 racks as shown below in Figure B.
3. Next, place 3 bottles sideways in the bottom 2 racks as shown below in Figure C.
4. Store wine in sealed bottles only.
C
PARTS AND FEATURES
1.Glass Door
2.Shelf Racks (4)
4.Base Rack
5.Leveling Leg
AMAW27S/AMAW25S2MS
3.Temperature Knob
1
5
2
3
4
4.For red wine the suggested temperature range is 53 °F-61 . °F
wine cooler
5.Reducing the frequency of door opening can lower power consumption.
For white wine the suggested temperature range is 43 °F-50 . °F
Dial settings from 1 - 4.
Dial setting from 4 - 7.
wine cooler
76
wine cooler
page 2
Please see the above image which shows you five popular dimensions of wine
bottles.
The maximum capacity is based on “Typical Bordeaux” bottle dimension.
If storing larger bottles, the capacity will be reduced.
Bottle Sizes and Storage Capacity
LARGE
CALIFORNIA
RED
TYPICAL
PINOT
NOIR
TYPICAL
BORDEAUX
TYPICAL
RIESLING
CHAMPAGNE/
SPARKLING
3" 3-1/8" 2-3/4" 2-3/4" 3-3/4"
9-1/2"
7-1/2" 8-1/2" 6-1/2" 7"
12-1/4"
13"
11-3/4"
11-7/8"
12-7/8"
AMAW27S
AMAW25S2MS
Use nonflammable cleaner .
98
SPECIFICATIONS
Model
Climate class
Electric shock protection type
Capacity (cu.ft)
Voltage (V)
Frequency (Hz)
Current (A)
Voice [dB(A)]
Refrigerant
Net weight (lbs)
Interior temperature ( )F
Dimension (in )inches
Width
Depth
Height
N
I
2.7
120
60
R600a/0.81oz
48.51
18.89
18.70
24.68
<42
0.82
0.95
39~64
Energy Consumption (kw.h/24h)
1110
POWER FAILURE
When a power failure occurs, the wine cooler can normally store for several wine
hours. Do not put additional into th
wine e appliance during a power failure, and do
not open door. Disconnect the plug from the outlet, and reconnect when the
power has been restored.
VACATION AND MOVING CARE
AMAW27S/AMAW25S2MS
1
2
3
8
7
5
6
4
1312
wine cooler
TROUBLESHOOTING TIPS
wine cooler
wine cooler
wine bottle
do
Assistance
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If
you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you only use factory
specified replacement parts. Factory specified replacement parts will fit right and
work right because they are made with the same precision used to build every
new wine cooler.
To locate factory specified replacement parts in your area, call us
or your nearest designated service center.
In the U.S.A.
toll free: 1-855-666-4477.
Limited Warranty
This warranty applies to products purchased and used in the U.S. This is the
only express warranty for this product and is in lieu of any other warranty.
This product is warranted to be free from defects in material and workmanship
for a period of one (1) year from the date of original purchase, except as noted
below. During this period, we will repair or replace this product at our option.
This warranty extends only to the original consumer purchaser and does not
cover a defect resulting from abuse, misuse, neglect including failure to clean
product regularly in accordance with manufacturer's instructions, use for
commercial purposes, or any use not in conformity with the printed directions.
This warranty is provided by Galanz-Zhongshan Galanz Consumer Electric
Appliances Co.,Ltd.
(see lnstallation instructions)
wine cooler
wine cooler
wine cooler
wine bottles
wine cooler
wine cooler
1514
If you have a claim under this warranty, please call our CUSTOMER SERVICE
NUMBER. For faster service please have model number and serial number
ready for operator to assist you.
We exclude all claims for special, incidental, and consequential damages caused
by breach of express or implied warranty. All liability is limited to the amount
of the purchase price. Every implied warranty, including any statutory
warranty of merchantability or fitness for a particular purpose, is
disclaimed except to the extent prohibited by law, in which case such
warranty is limited to the duration of this written warranty. This
warranty gives you specific legal rights. You may have other legal rights that
vary depending on where you live. Some states do not allow limitations on
implied warranties or special, incidental, or consequential damages, so the
foregoing limitations may not apply to you.
1716
