American Standard LIBERATION Bedienungsanleitung

OWNER’S

MANUAL

Congratulations!

You are now the owner of a walk-in bath from the

most trusted name in plumbing.

We know you have a choice in which walk-in bath

you have in your home and want to welcome you

to the Liberation by American Standard family.

We feel honored that you have chosen Liberation

by American Standard to supply and install your

walk-in bath. We specialize in providing the safest

bathing experience without sacriﬁcing luxury.

Your satisfaction is our guarantee.

Should you have any questions regarding your

walk-in bath, please do not hesitate to contact

our customer support center at

855.225.2183

Thank you for your purchase. Your Liberation

by American Standard walk-in bath is a true

investment in your health and peace of mind.

Table of Contents

Liberation Walk-In Bath 4

Control Panel Functions 6

Open & Close Walk-In Bath Door 7

Quick Drain® 8

Self Cleaning Sanitary System 9

RevitaJet™ Whole Body Hydrotherapy 10

Chromatherapy 14

Aromatherapy 15

Important Safety Instructions 16

Cleaning and Maintenance 18

Exclusive Limited Lifetime Warranty 19

Trouble Shooting 20

Liberation

Walk-In Bath

Liberation

Walk-In Bath

Construction

1. 100% Premium Cast Acrylic Material

2. Freestanding Metal Support

3. Patented, Leak Proof Door System

4. Quick Drain® Fast Water Removal System

5. Premium Faucet with Hand Shower

6. Textured Bath Floor

7. Low Threshold

8. 17” Chair Height Seat

9. Built-In Chrome Grab Bar

10. Easy Access Panel

RevitaJet™ Whole Body Hydrotherapy

Other Innovative Features

11. Deluxe Upper Body Massage

12. Ultimate Leg Therapy

13. Legs-Only Therapy Diverter

14. Ultra Foot Massage

15. Wrist and Hand Massage

16. Variable Speed Heater Blower and Whirlpool Pump

17. Chromatherapy Lights - Including Integrated Lights

in 6 Water Jets

18. Aromatherapy

19. In-line Heater

20. Self-Cleaning Sanitary System

Control Panel

Functions

Lights: There are 7 light

options that are available with

the Liberation walk-in bath.

Push the button to select the

desired color. The last setting

will scroll through each color

automatically.

Drain: If your walk-in bath is

equipped with the Quick Drain®,

open the traditional drain

system (turn the overﬂow) and

then press the Drain button to

activate the drain. When the

water falls below the suction

guard, press the button again

to turn oﬀ. The Quick Drain® will

automatically shut oﬀ after 3

minutes as a safety feature.

Jets: Push this button once to

activate the water jets. If the

leg valve is turned oﬀ, all of the

jets will expel water. Once the

leg valve is turned on, only the

lower jets will expel water. Push

once more to turn oﬀ.

Air: Push this button once to

activate the heated blower

at high speed. To adjust the

speed to medium or low, push

and hold the button. Push

again to turn the air jets oﬀ.

Control Panel Operation

Open & Close

Walk-In Bath Door

To enter your Liberation walk-in bath, reach into the inside of the bath

and pull the handle until it is vertical with the side of the bath. Push

the door open and enter carefully. To close the door securely, simply

close the door and place the lever in the down position. Do not apply

excessive pressure when placing the handle in the close position. Fill

the bath above the highest jet before activating the whirlpool pump (if

equipped). Do not put weight on the door when entering and exiting the

walk-in bath. It is recommended to leave the door in the open position

when the walk-in bath is not in use.

Open

How to Open and Close the Door

Cable Driven Drain

Quick Drain® Operation

The Quick Drain® drains water from your tub

quickly. This patent-pending system comes

equipped with a pump, safety suction and

on/oﬀ electronic control that allows you to

activate the drain with the touch of a button.

Quick Drain® is not a standard feature on the

soaker bath.

To operate the Quick Drain®, turn the Cable

Driven Drain clockwise to open and then

press the Quick Drain® on/oﬀ switch to

activate the drain. When the water falls below

the suction guard, press the on/oﬀ switch to

turn the drain system oﬀ.

Cable Driven Drain Operation

To open and close the

Cable Driven Drain,

turn clockwise and

counterclockwise to

open and close.

Quick Drain®

On/Oﬀ Button for

Jet Model

Quick Drain® On/Oﬀ

Button for the Soaker

model

Quick Drain®

Suction Guard

is located at the

base of the seat

Eliminate the Maintenance

Say “good-bye” to the maintenance needed to enjoy a clean whirlpool

system. Included with jet and dual massage systems, Ozone is the most

eﬀective cleaning system available for bathing environments today.

A study by the EPA through West Virginia University states that:

• Ozone is more eﬀective than chlorine in destroying bacteria and

viruses.

• Ozone is pure Oxygen (O2) with an extra Oxygen atom (O3)

• Because of the extra atom, after Ozone destroys disease-causing

microorganisms, it reverts back to pure Oxygen (O2). Therefore,

it doesn’t leave any harmful residue behind.

Approved by the NSF, FDA and EPA and required in all commercial bathing

environments, this safe and eﬀective sanitation system automatically

oxidizes and eliminates disease-causing microorganisms in the bath

when the whirlpool system is activated. Bleach is not necessary or

recommended when cleaning the walk-in bath. The Ozone Disinfection

System requires no user participation. Turn on the whirlpool system,

and ozone bubbles are automatically

injected into water.

All Ozone Generators are equipped

with a preset vacuum switch which

will not turn on if the pump is not

running with water ﬂowing through

the whirlpool system. The Ozone

Generator includes an exclusive

High Limit Switch and will not false

trip from tap water. If your whirlpool

is equipped with adjustable jets,

or other ﬂow control systems, the

pre-set vacuum may not activate

the generator. To assure proper

operation, all jets may need to be

fully open with the pump operating

at or near maximum ﬂow.

Ozone Disinfection System

Self Cleaning

Sanitary System

RevitaJet™Whole

Body Hydrotherapy

The treatment of illness and injury through the use of water; both hot

and cold. The four most popular ailments people use hydrotherapy to

treat are: arthritis, lower back pain, insomnia and diabetes.

Arthritis

Warm water treatments help by dilating blood

vessels in the body, relieving pain and easing the

tension in muscles.

Lower Back Pain

Studies have shown that people who use

hydrotherapy experience marked reductions in

pain and use fewer pharmaceuticals to control

their pain.

Insomnia Warm baths have been shown to improve both

the ability to fall asleep and the quality of sleep.

Diabetes

In a study published by the New England Journal

of Medicine, people with Type 2 Diabetes soaked

in hot tubs for 30 minutes a day, 6 days a week.

Doctors noticed that the patients had an easier

time controlling their weight and plasma glucose

levels.

Whirlpool: Push this button once to activate the

water jets. If the legs-only valve is open, all of the

jets will operate. Once the legs-only valve is closed,

only the lower jets will operate. Push once more to

turn oﬀ.

Air System: Push this button once to activate the

heated blower at high speed. Push again to adjust

the speed to medium, low and one last time to turn

the air jets oﬀ. If you push and hold the button, the

air blower will turn on high and gradually lower in

speed.

Source: Petrofsky; Nance
