AMGOO am83 Bedienungsanleitung
User Manual
Model Name: AM83
Brand Name:AMGOO
FCC ID:UOSAM83
Contents
Safety and Precaution........................1
Instruction to Accessories ..............1
Key Instruction ..............................2
Icon Instruction..............................4
Begin to Use ........................................5
Install SIM Card and Battery.........5
Charge the Battery .........................5
Power the phone on/off..................6
Memory Card.................................6
USB Data Cables...........................6
Basic Function ....................................6
Call.................................................6
Text Input.......................................7
Function of Functional List...............8
Call center......................................8
Multimedia...................................10
Phonebook ...................................14
User profiles.................................15
Messaging....................................16
Organizer......................................18
Settings.........................................20
Fun&Games.................................22
Services........................................22
Safety and Precaution
You should read the following information carefully before using the phone
in order to use it safely and effectively.
Power the phone on safely
Do not use the phone at the location where the phone is prohibited using or
the phone can cause the disturbance or risks.
Disturbance
The mobile communication can be subject to the radio disturbance, thus
affecting its performance.
Accessories and batteries
Please use the batteries and adapter designed by our company, or
otherwise resulting in explosion.
User’s Manual for GSM/GPRS Digital Mobile Phone
This Manual is correct in the contents when it is published, however Amgoo
reserves the right to modify the technical specifications without other
notification. Some contents in the Manual are possibly distinguished from
the real phone and will be different according to the installed software, SIM
cards and service providers
Instruction to Accessories
Please confirm the intact articles as follows are all in the package. Please
contact with the local distributer in case of the missed ones.
A Phone
An adapter
z Battery
z USB data c
Remarks: AMGOO reserves the right to change or upgrade the product without
any prior notice
2
Key Instruction
Picture Key Description(Under Standby
Mode)
LSK Enter in functional list ( Main
menu).
RSK Enter in the contact list in
phonebook.
Send1 Enter in list window of SIM1/
SIM2call logs.
Send2 Enter in list window of SIM1/
SIM2 call logs.
FM Enter in FM
END
Press to terminate a call or
refuse a call.
Press and hold to power the
phone off (or power the phone
on under power-off mode).
OK Enter in the dialing interface
UP
Enter in Shortcuts
Press and hold to turn on/off
flashlight
down Enter in Alarm
Left Enter in User profiles
Right Enter in Add new contact
3
previou
s song
Press to switch to a p revious
song with cursor.
Press and hold: go
backwards
play/pa
use Press to play or pause playing
next
song
Press to switch to a next song
with cursor.
Press and hold: go forwards
1
Press to enter in dialing window
and input number 1.
Press and hold to dial t he voice
mailbox number.
0,2~9
Press to enter in the dialing window
and input nu mbers 0, 2~9. Press
and hold: a. directly dial the phone
number at per tinent position when
the quickly-dialing and inputting
function is opened;
b. Press to enter in d ialing and
inputting window alike when the
quickly-dialing and inputting
function is closed.
*
Press to enter in dialing and
inputting window and input symbol
*.
Press and hold to switch amid
symbols “*”, “+”, “P” and “W”.
4
#
Press to enter in dialing and
inputting window and input symbol
“#”.
Press and hold to switch amid
Mute/General Modes.
Keyboard lock mode LSK+# Combination, Lock or unlock
keyboard
Icon Instruction
Icon Description
Indicate the network signal strength for SIM card 1.
Indicate the network signal strength for SIM card 2.
Indicate the current battery capacity for battery
Indicate that there is an unread SMS in SIM card 1.
Indicate that there is an unread SMS in SIM card 2.
Indicate that there is a missed call in SIM card 1.
Indicate that there is a missed call in SIM card 2.
Indicate that the current profile mode is the General mode.
Indicate that the current profile mode is the Silent mode.
5
Indicate that the current profile mode is the Meeting mode.
Indicate that the current profile mode is t he Power saving
mode.
Indicate that the current profile mode is the Outdoor mode.
Indicate that the current profile mode is the My style mode.
Indicate that the current alarm clock is set as activated.
Indicate that the current playing music.
Indicate the current keypad-locked state.
Begin to Use
Install SIM Card and Battery
Please be sur e to disconnect the phone with the adapter before
disassembling the battery.
This version is a dual-card dual-standby phone which can be inserted with
2 SIM cards. You should be careful to use, insert and disassemble the SIM
card because the contact of the SIM card is easy to be scraped or bent to
damage.
Charge the Battery
The phone will release the warning tone displaying the insufficient battery
capacity with the indication of the empty battery icon when the battery
capacity is lower. Under this case, the phone will power off automatically
when the battery capacity is too lower. Please charge the battery.
Not charging: If the phone power is supplied by the battery 1 in default, the
battery 2 will be automatically switched to till the battery 1 is used up (i.e.
6
the battery 1 is a main power supply).
Charging: Firstly the battery supplied is charged, after charged fully,
the other battery is switched to for charging and supplies.(after the adapter
is taken out, return to a state of no charging, namely, the battery 1 supplies
in default).
Power the phone on/off
Press and hold [End] to power the phone on under the power-off state
Press and hold [End] to power the phone off under the power-on state.
Memory Card
The phone supports the T-Flash card (otherwise purchased), which
is a multimedia memory card used to multiple the memory of the phone.
USB Data Cables
This version supports the USB interface. You can connect your phone with
the PC via the USB&data cable, copy ing or moving the files amid the
phone and PC, or browsing the images, record files and video files saved
in the phone via the PC.
The phone pops up window with 3 modes at your choice: Mass storage , W
eb cam and COMPort.
Basic Function
Call
The phone will select the main network automatically after powered on if it
is located within the coverage of the main network. The phone can use
other network, called as roaming.
Dial
You can dial with several ways as follows:
Input the phone nu mber (should affix the international/national/regional
code or district code if necessary) and then press [Send1/Send2] under
the standby mode.
Press [Send1/Send2] to dial a phone number listed in the recent call
log under the standby mode.
Press and hold numeric keys [2]-[9] to dial the sho rtcut phone
number set on the numeric keys under the standby mode.
7
The phone supports dialing the international emergency phone
number, such as 112 and 911 etc.
Answer Incoming Call
You can perform as follows when there is an incoming call:
Press [Send1/Send2] to receive the incoming call. You can use the
earphone to answer the call when the generic earphone.
Press [End] to decline an incoming call.
View Missed Incoming Call
The quantity of missed incoming calls will display on the screen under the
standby mode if there are missed incoming calls.
Function During Call
You can use many functions during the call process.
Option During call
Press <Option> to use the following options:
Hold single call: temporarily hold the current call.
End single call: end the current call.
New Call: call the opposite party to build a Call to Many.
Phonebook: enter in the phonebook menu.
Call history: view the information of the missed, dialed or answered
calls in SIM card 1 or 2.
Messaging: enter in the SMS menu.
Sound recorder: record the current call.
Mute: open or close the mute mode.
DTMF: open or close the DTMF function during the call.
Launch or Close Hand-free Function
Press <H-free>/<H-Held> to open or close the hand free function.
Text Input
Use Keypad
Change Text Input Method
Press [#] key to select the desired input methods:
Smart ABC, Smart abc,Multitap ABC, Multitap abc, Smart FR, Smart
fr,Multitap FR, Multitap fr, Multitap PT, Multitap pt, Multitap ID, Multitap id,
