Ion Rx

Installation & Owner’s

Manual

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Table of Contents

Ion Rx, Megatouch, Ion, Mega-Lease, Mega-Link, MegaNet, MegaWeb, TournaMAXX and TournaCHAMP are

registered trademarks of AMI.

Reproductionofthismanual,inanyformorbyanymeans,isstrictlyforbiddenwithout the written permission of AMI.

Site Preparation .............................p. 1

Setting up your

Megatouch Game .......................... p. 1

Game Description..........................p. 1-2

General Care

and Maintenance ...........................p. 3-4

Touchscreen Calibration ...........p. 3

Monitor

Adjustment Procedure ..............p. 3

General Circuit Board

Handling Information ..................p. 3-4

Cleaningthe Cabinet .................p. 4

Cleaning the Touchscreen

Monitor .......................................p. 4

Cleaning the Fans and

Vents .........................................p. 4

Watchdog Timer ........................p. 4

Power Cord Security ................p. 4

Optional Rx Cover .....................p. 4

Rx Optional Marquee

Installation Instructions..............p. 5

Software Update Cable ............ p. 6

Megatouch Ion Software

Operator Setup Screens

Flowchart.........................................p. 7-8

Main Menu.......................................p. 9-10

Credits/Pricing Menu ................... p. 11-15

Quick Price Setup......................p. 11

Coin-InMenu..............................p. 12

Coinless Coin Op Menu .............p. 13-14

Rental Mode ...............................p. 14

Freeplay Mode...........................p. 15

Games Menu .................................. p. 15

Game Setup ...............................p. 15

Hi Scores Menu..............................p. 16

View/Clear Hi Scores ...............p. 16

Books Menu....................................p. 16-18

Books Display............................p. 16-17

CashSettlement ........................p. 17-18

System Menu ................................. p. 19

Diagnostics Menu..........................p. 20-21

Hard Drive Self Diagnostics ......p. 21

Network Menu ...............................p. 22-28

Hardware Setup........................p. 22-23

Connection Wizard ....................p. 24-26

AMI Jukebox Mega-Link Setup..p. 27-28

Local Tournament Mode..............p. 29-33

Credit Card Menu ..........................p. 34

Vault Credits ..............................p. 34

Setup Operator Cards...............p. 34

Presentation Menu .......................p. 35

Operator Ad Screens................p. 35

SidebarPromotion .....................p. 35

Sales Enabler Videos................p. 35

Promotion Menu............................p. 36-37

MyMerit .....................................p. 36

Merit Money ...............................p. 37

PromoCredits ............................p. 37

MegaNet Menu ...............................p. 38-40

Megatouch Ion Rx Hardware

DIP Switch Settings .......................p. 41

Troubleshooting ............................p. 42-44

Parts List and Illustrations

Game Illustrations ......................p. 45-46

Replacement Parts List .............p. 47

Connection Diagrams ................p. 48-50

Warranty and Software License

Agreements

Warranty............................................p. 51

Software License Agreement...........p. 52-57

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

MEGATOUCH ION RX OWNER’S MANUAL PM0721-09

Site Preparation

IndeterminingthelocationforyourMegatouch

Ionvideo game, consideration must be given

toasuitable, grounded electricaloutlet.Since

the game is a computerized device, it should

have a separate circuit, if at all possible. If a

separate circuit is not available, care should

betaken to providea clean andconstant volt-

age.As a basic guideline, never connect the

unit to a circuit that also supplies power to

freezers,coolersorotherhighpowerconsum-

ingandelectricalnoisegeneratingequipment.

Place the game in a location where nothing

willinterferewith properventilation.Thegame

should not be exposed to any dripping or

splashing liquids. Objects filled with liquid

should not be placed on the unit.

Setting up your Megatouch Game

1. After removing the game from the car-

ton, attach the power cord to the back

of the game near the ON/OFF switch.

Plugthegameintoastandard,grounded

AC outlet.

2. Turn the power switch at the back of

the game to ON and wait for it to go

throughitsboot-upsequence.Thegame

will display the Main Menu Screen.

3. The machine has been preset at the

factory and should not need to be ad-

justed, however it is recommended that

the screen be calibrated (see

Touchscreen Calibration) and the

coin and/or bill acceptor(s) be tested.

4. There are many custom settings avail-

ablefor the game.Tocustomize the set-

tings, follow the software instructions in

this manual.

Game Description

The Rx model has one lock located on the

back of the unit. To open the unit, unlock this

lock and lift the front bezel from the rear of

the system. It comes equipped with a coin

mechand/orbillacceptor.Thismodelalsohas

couplersinstalledintherearofthegame.These

areused for future hardware upgradeswhich

includelinking and modemcapabilities. Each

game comes equipped with a wireless USB

adapter that can be used to wirelessly link

twoIongames together.Withtheadditionof a

wirelessrouter, the game(s)can also connect

tothe Internet. The Linksys 802.11G router is

recommended.Formoreinformation,seeCon-

nection Wizard.

All of the major components of the Rx sys-

tem are located inside the cabinet, which

can be opened by unlocking a single lock.

Thesecomponents include themotherboard,

LCD monitor, I/O board, power supply, hard

drive, coin box, and bill acceptor. On the I/O

board (see Figure 34) there are SETUP and

CALIBRATE buttons. Pressing the SETUP

buttonwillbring you totheMain Menu Screen

(see Figure 1). From this screen you can

then adjust the operator options to best suit

yourparticular needs. For calibration instruc-

tions, please see the next section of this

manual.

IMPORTANTNOTICE

While the Megatouch Rx is weather-resistant and designed to channel water away from

internal electronic components, it is not weatherproof. It is recommended that the Rx be

placed in a protected environment out of direct rain and sunlight, such as under a canopy

or awning. If the game does get wet, please turn it off and allow it to dry completely before

continuing play.

When placed outdoors this unit should be properly grounded by using a GFCI (ground fault

circuit interrupter) outlet. Additionally, all extension cords used should be heavy-duty and

rated for outdoor use.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

PM0721-09 MEGATOUCH ION RX OWNER’S MANUAL 2

This model features a widescreen LCD with

an electronic sidebar that provides space

for displaying images, advertisements, and

in-game information. The electronic sidebar

feature allows you to create customized

sidebar images to display during idle mode.

These images can be imported using a USB

pen at the game, or they can be remotely

sent to the game through the Remote Op-

erator Web Site. For more information, see

Sidebar Promotion in this manual, or re-

fer to your Remote Operator Web Site.

Web Marquee Creator

The Web Marquee Creator allows you to go

online to create your own customized mar-

quee for the Rx, which can then be printed

from any computer connected to a printer.

These custom marquees can be used to ad-

vertiseanything you wish to promote. Simply

go to www.meritgames.com/creator.asp and

follow the instructions. This marquee will be

printed out, then folded in half to fit the mar-

queeholder, which canbe attachedtothe top

of your Rx unit. If you wish to install this op-

tionalmarqueeholder, pleasesee the section

“RxOptionalMarqueeInstallationInstructions”

later in this manual.

Credit Card Reader

The game also features a built-in credit card

reader. To enable the credit card reader, you

must connect the game to a broadband

Internet connection, call into the MegaNet

server, and select a rate plan on your Re-

mote Operator Web Site. Credit card func-

tionality requires a broadband Internet con-

nection and a MegaNet subscription.

NOTE: If a Megatouch unit that accepts

credit cards is moved between the U.S. and

Canada, Customer Service must be noti-

fied 2 business days before activating the

credit card feature in the new country. Fail-

ure to notify Customer Service will put the

operator in violation of card processing

regulations, for which the operator assumes

full responsibility. Furthermore, players who

pay by credit card in the new country will be

surprised with currency exchange fees,

which will likely lead them to call their credit

card companies, dispute the charge, and

obtain a charge reversal. The net result will

be a credit card payment refund to the play-

ers, which will hurt revenue.

Mounting the Rx to a Countertop

In addition to the U-bolt located on the rear

of the system, the Rx can also be secured

in a location by mounting it to a countertop

withthe provided bolt, nut, and washers.

To do this, open the Rx and remove the

powersupply.Thiswill giveyou access to the

hole in the center of the Rx’s base, which the

securingbolt will run through.

Position the Rx where you would like it to be

mounted on the countertop, then use the

hole in the center of the game to mark the

drilling location on the countertop. Move the

Rx out of the way, and drill a hole in the

countertop to accept the bolt. Place the Rx

back over the hole and secure it in place

with the bolt, nut, and washers. One washer

should rest inside the hole on the bottom of

theRx’sbase,while theothershouldbeplaced

on the bolt on the underside of the coutertop

and secured in place with the provided nut.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

MEGATOUCH ION RX OWNER’S MANUAL PM0721-093

General Care and Maintenance

NOTE: THIS GAME MUST ONLY BE SER-

VICEDBYQUALIFIED SERVICE PERSON-

NEL.

CAUTION: THERE ARE HIGH-VOLTAGE

PARTS IN THIS GAME. BE CAREFUL

WHEN SERVICING THE INSIDE OF THE

GAME. THE GAME SHOULD ALWAYS BE

UNPLUGGED BEFORE SERVICING.

Touchscreen Calibration

IMPORTANT: You should only touch the

game with your finger during calibra-

tion (don’t lean or touch anywhere else

on the game) and keep your finger as

outstretched as possible, with your

palm and other fingers away from the

screen (so the rest of your hand

doesn’t affect calibration).

•Pressthe“Calib”button on theI/Oboard

(see Figure 34).

•Touch the center of the first cross that

appears and hold it there for 2 sec-

onds. Once you release your

finger, a second cross will appear.

•Touch the center of the second cross

that appears on the screen and hold it

there for 2 seconds.

•Once the second cross is touched and

released, another cross will appear on

the screen. To test the calibration of

the screen, touch the cross with your

finger and slowly drag your finger

around the screen. The cross should

follow your movement.

•Touch the EXIT button.

The game will prompt you to go through the

same steps two more times.

Monitor Adjustment Procedure

The vertical/horizontal controls and bright-

ness/contrast controls are located on the

OSD board, which is located on the back of

the monitor. Pressing the button labeled

Menu on the OSD board will show the on-

screen display on the monitor. Use the Left

andRight buttons tomove through themenu.

Touch Menu again to select the option you

want to change. Use the Left and Right but-

tons to change the option, then select Menu

again to deselect the option. Auto will auto-

matically adjust the size and brightness.

Touchthe Exit buttontoexit.Adjust the moni-

tor controls until the screen looks as sug-

gested in the following steps.

1. Set the game to the Checkerz game

screen.

2. Adjust the vertical and horizontal size

and vertical and horizontal position to

make sure that the game screen fills

the monitor screen and that the game

screen is centered.

3. Adjust the brightness and contrast con-

trols until the top sets of checkers are

a rich red and the bottom set are a dark

gray. The feet on the “Checkerz”

character should be white. (Adjusting

the brightness and contrast can also

correct for a lack of sharpness.)

NOTE: If you are experiencing an issue

where your screen seems to be slightly

shifted, repeat the screen calibration

process, pressing “Auto” on the OSD

board when each new calibration

screen appears BEFORE you calibrate

the screen for that resolution.

General Circuit Board Handling

Information

Before handling any boards, observe the

following procedures:

•Prevent Electro-Static Discharge by:

1. Storing the boards in the anti-

static bags in which they are

shipped.

2. Removing any static charge

from your body before handling

the boards.

3. Using a ground strap when

handling the boards.

•When plugging in connectors to the

board, make sure the connector is

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

PM0721-09 MEGATOUCH ION RX OWNER’S MANUAL 4

inserted straight onto the header and

that the connector covers all header

pins.

•Donot connect any peripheral device to

the board if the power is still connected

to the peripheral, or if power is already

applied to the board.

CAUTION: Be extremely careful when re-

placing the lithium battery on the

motherboard. There is a danger of explo-

sion if the battery on the motherboard is in-

correctly replaced. Only replace the battery

with the same type recommended by the

manufacturer. Dispose of used batteries ac-

cording to the manufacturer’s instructions.

Cleaning the Cabinet

•The cabinet should be cleaned with a

damp cloth and mild detergent. Always

apply the cleaner to the cloth and not

directly on the game. Liquids could en-

ter the cabinet and damage electronics

inside.

Cleaning the Touchscreen Monitor

•The touchscreen glass should be

cleaned with a damp cloth and isopro-

pyl alcohol or a non-ammonia cleanser.

Do not use any abrasive or vinegar-

based cleansers, as they will damage

the touchscreen glass.

NOTE: DO NOT USE ANY ABRASIVE

SOLVENTS, ACID OR VINEGAR-BASED

CLEANSERS ON THE MONITOR OR

DECALS.OVER TIME, SUCH CLEANSERS

COULD HARM THE TOUCHSCREEN AND

ERASE THE DECALS. BE CAREFUL NOT

TO USE COMMERCIAL CLEANERS CON-

TAININGANY OF THESE SUBSTANCES.

Cleaning the Fans and Vents

•The fans and vents should be cleaned

of any dust and grime on a regular

basis to ensure proper ventilation of

the game.

•To ensure proper operation of the

game, it is important that all fans are

operating correctly and that the airflow

is unobstructed. Make sure nothing is

placed inside the cabinet or next to the

fan vents that would inhibit the flow of

air. Also, if any fans are not operating,

it is important that they be replaced.

Watchdog Timer

This game has been equipped with a feature

that allows it to automatically reboot if it en-

counters a problem. The watchdog timer will

reboot the machine within 5 minutes after a

failure,allowing the gameto automatically re-

setitself if a problemarises without needinga

technicianpresent.

Power Cord Security

Use the provided tie wrap to secure the

power cord to the U-bolt on the back of the

game (see Figure 33 at the rear of this

manual).

This will prevent unnecessary strain or ac-

cidental removal of the cord if the game is

turned or moved.

NOTE:Make sure thatthe plug is fully seated

in the game after attaching it to the U-bolt.

Optional Rx Cover

ThereisanoptionalvinylcoverfortheRx(part

number: HW0339-01) that can be ordered

throughyourdistributor.Thiscovercanbeused

to better protect your Rx while not in use.

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

MEGATOUCH ION RX OWNER’S MANUAL PM0721-09

Rx Optional Marquee Installation Instructions

CAUTION

WHILE THE RX MARQUEE IS OPTIONAL, DUE TO THE STRONG ADHESIVE USED TO

SECURE IT, ONCE IT IS INSTALLED, IT IS NOT MEANT TO BE REMOVED.

The marquee should never be used as a handle when servicing the game, as it was not

designed for this purpose. When used inappropriately in this fashion, the marquee

could break, causing the bezel to slam down and thereby damaging the system.

The monitor bezel should always be opened by using the handle on the rear of the

coin/bill acceptor.

Before you begin installation:

Line up the marquee as shown in FigureA. The right side of the marquee (looking from

the front) should be even with the front of the plastic on the coin/bill acceptor, and the

frontbase ofthe marquee should be even across the front of the monitor bezel. Thisstep

is just so you can see how the marquee should fit without using any adhesive. You may

also find it helpful to use a pencil and draw and very light line on the top of the bezel to

mark the rear of the marquee. You can then follow this guideline when you permanently

secure the marquee to the bezel.

COIN/BILL

ACCEPTOR

MONITOR

Marquee Installation:

1. Remove the two strips covering the two pieces of tape on the bottom of the

marquee.

2. Carefully line up the marquee on top of the bezel. Follow any guidelines you have

drawn for yourself, or refer to Figure 1 for placement.

3. Press down on the base of the marquee to ensure that the adhesive has fully bonded

with the bezel.

FIGUREA-RX MARQUEE PLACEMENT(SIDEVIEW)

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

PM0721-09 MEGATOUCH ION RX OWNER’S MANUAL

Software Update Cable

Discs have been provided with your game in the event that you need to reinstall the

software at any time. The included SATAupdate cable may be required for software updates

dependingonthe type of SATADVD drive youhave.It is needed foruse with internal SATADVD

drives,so make sure tokeep the cablefor any futuredisc-installed software upgrades.It should

be connected to the game as shown in the figure below.

Connecting a SATA DVD Drive

•Turn off and unplug the game.

•Unlock and open the cabinet by lifting the bezel from the rear of the unit.

•Locate the unconnected end of the software upgrade power cable, routed near the

hard drive (see figure below for reference). Connect this cable to the SATApower cable

input on the back of your SATADVD drive.

•Connect the SATA data cable (either the one that came with your external DVD drive,

or the provided cable that came with the game) to the software upgrade data port

inside the game (see figure below). Connect the other end of this cable to the SATAdata

cableinput on the back of your DVDdrive (referto figure below).

•Plug in and turn on the game and continue with the software update as normal. When

finished, we recommend that you keep the provided SATA data cable connected to

your DVD drive and only connect it to the update port inside the game during updates.

SOFTWARE UPGRADE

DATA PORT

PROVIDED SATA DATA CABLE

(FOR USE WITH INTERNAL

SATA DVD DRIVES)

SATA DATA

CABLE INPUT

SATA POWER

CABLE INPUT

SOFTWARE UPGRADE POWER CABLE

(LOCATED INSIDE THE GAME,

ROUTED NEAR HARD DRIVE)

REAR VIEW OF

SATA DVD DRIVE

FIGUREB- INTERNALVIEW OFMEGATOUCHRX

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

MEGATOUCH ION RX OWNER’S MANUAL PM0721-09

Credits/Pricing

Games

Hi Scores

Books

System

Diagnostics

Tournament

Network

Credit Card

Presentation

Promotion

MegaNet Books Display

Cash Settlement Setup

Cash Settlement Collection

Set Time

Security Setup

Volume Control

Set 6 Star PIN

Data Transfer

Options

AMI Setup

System

Books

Enable 6 Stars

Default Language

Player selectable language

Language buttons have flags

Show games unavailable in current language

Enable theft deterrent

Enable Educational Attract Mode

Enable Attract Mode Sounds

Tournament Mode

Show prize pools on Main Menu

Enable TouchTunes

Enable TouchTunes Hi-Resolution Mode

Enable AMI

Enable Light Show

Cash Settlement Collection

Revenue Details/Cash Out

Fee Details

Clear/Complete Collection

Options

Security Setup

Enter Security PIN

Options

Auto Clear

Hi Scores

No Names in

Hi Scores

(game list)

Clear All Games

View/Clear High

Scores

Games

Main Menu

Hi Scores

View/Clear

High Scores

Options

Game Setup

Options

Quick Price Setup

Coin-In

Value of Credit

Credit Card Pricing

Pay Per Time

Coinless Coin Op

Clear Credits

Free Credits

Options

Credits/Pricing

Puzzles

Cards

Erotic

Strategy

Mega-Link

New Games

Action

Quiz & Word

Enable

All Games

Factory Default

Games

Price Display

Freeplay Enabled

Enable Coinless Coin Op

Enable Rental Mode

Game Setup

Options

Enable erotic games

Allow game continue

Show deck cards

Allow bonus replay

Enable easy mode

Continuous bonus round

Linked games enabled

Photo Hunt hints

Trivia rounds/bonus

Show correct answer in Trivia, Power Trivia

and Snap Shot

Enable free gamein Solitaire

Split column move in Power Solitaire

Enable free gamein Power Solitaire

Category same for all in Power Trivia

Enable consolation question in Power Trivia

Face up cards, player selectable in Tri Towers

Checkerz Rules

Enable Kids Club category

Enable Premium Erotic Ad Screen in Idle

Force Slow Senior Game Play

Sticker Book Timer Options

Disable Questionable Content

Options

Clear All

Clear One

Individual Game

Price/Credits

Cost to continue

Default Games

Clear One

Clear All

Enable All Games

Operator Setup Screens Flowchart

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

PM0721-09 MEGATOUCH ION RX OWNER’S MANUAL

Credit Card

Functionality Test

Credit Card Pricing

Setup Operator Cards

Vault Credits

Options Add/Edit Billboard

Set Start/End Date

Remove Billboard

Remove All Billboards

Enable Premium Erotic

Enable MegaWeb

Enable Operator Website

Enable Hot Topics

Price/Credits

Default Games

Clear One

Clear All

Enable All Games

Access Sales Enabler Videos

Manage Sidebar Images

Import Sidebars

Sidebar Promotion

MegaNet

Premium Erotic

Operator Web Access

MegaWeb

Hot Topics

Options Options

Operator Ad Screens

Sidebar Promotion

Options

Presentation

My Merit

Merit Money

Promo Credits

Options

Promotion

Hot Topics

Options

Enable My Merit

Enable Merit Money

Enable Promo Credits

Start Time

End Time

Idle Time

Number of Free Credits

View Player Data

Show Game Play Frequency

Show Player Hi Scores

Backup/Restore

Start Time

End Time

Free Game Limit

Set PIN

Options

Promo Credits

My Merit

Merit Money

Operator Ad Screens

Enable Credit Card Functionality

Pulse Hard Meter For Credit Card Purchases

Network Options

Dial-Up Options

Tournamaxx Options

Network Options

Tournament

Set Up Tournament

Clear Winners

Reset All

Credit Card

Wireless Ethernet

Wired Ethernet

Dial-Up

Connection Log

Location Info

Connection Wizard

Connection Diagnostics

Network Options

Connect to MegaNet

Network

Options

Diagnostics

Video Test

I/O Test

Touchscreen Calibration

Touchscreen Test

Checksum Test

System Info

Verify Databases

Hard Drive Self Diagnostics

View System Log

Clear Tournamaxx Databases

Tournamaxx Options

Network Options

Set MegaNet Server

Set MegaNet ID

Set Update Time

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere AMI Entertainment Spielkonsole Handbücher

AMI Entertainment

AMI Entertainment Megatouch Ion eVo Betriebsanleitung

Beliebte Spielkonsole Handbücher anderer Marken

Atari

Atari 2600 Bedienungsanleitung

PLAYNETIC

PLAYNETIC GameNetic Bedienungsanleitung

Sony

Sony SCPH-50008 Bedienungsanleitung

Nintendo

Nintendo Starlight Fun Center Bedienungsanleitung

Saitek

Saitek Alchemist Plus Bedienungsanleitung

Sears

Sears Tele-Games 637.99743 Bedienungsanleitung

AYANEO

AYANEO 2 Bedienungsanleitung

Sony

Sony PlayStation 3 (Uncharted: Drake's Fortune Limited Edition... Bedienungsanleitung

Mattel

Mattel My Meebas N2214 Bedienungsanleitung

Entex

Entex PacMan2 Bedienungsanleitung

Sega

Sega 32X Bedienungsanleitung

Saitek

Saitek Cougar Bedienungsanleitung

View-Master

View-Master Interactive Vision Verdrahtungsschema

Sony

Sony SCPH-35003 GT Bedienungsanleitung

Sony

Sony PSP go Bedienungsanleitung

Sony

Sony PSVITA Bedienungsanleitung

Excalibur

Excalibur ABC Wide 333 Bedienungsanleitung

Microsoft

Microsoft XBOX Betriebsanleitung
