DISHWASHER QUICK START GUIDE: ZIM656PH

Dear Customer,

This Quick Start Guide is enclosed

with detailed dishwasher Operating

Instructions. Before using the

appliance carefully read the Operating

Instructions, especially guidelines for

safe use.

Before plugging your dishwasher

into the mains power, remove the

safety packaging. Do not start the

dishwasher before it is properly set up.

Turn on the appliance1

Open the dishwasher door, press the on/o󰘯

button. Power indicator will be on

Dispense detergent2

Press the latch to open the detergent dispenser.

Add detergent to the dispenser.

Check the special salt

level

Add special salt to the dispenser when the

corresponding indicator on the control panel

comes on.

Load the dishes

Remove food leftovers from the dishes

Place the dishes in the baskets according to loading

guidelines.

It is recommended to load the lower basket 󰘰rst, then

the upper basket.

Select the wash programme

Open the door, press the Power button

Choose a program, the response light will turn on.

Then close the door, the dishwasher will start its

cycle.

IO-DWS-2624 (EN) 10.2020./1

Start your dishwasher

Open the dishwasher door.

The dishwasher will start a wash programme.

Turn o󰘯 the appliance

Turn the appliance o󰘯 using the On/O󰘯 button.

Remove dishes from the

appliance

When the dishwasher is o󰘯, open the door and wait

about 15 minutes before removing the dishes. This

will also facilitate the drying process. Hot dishes are

more susceptible to cracking.

Features and components

Spray arms

Cutlery basket

Upper basket

Inner tube

Lower basket

Salt container

Detergent dispenser

Mugs and cups shelves

Main 󰘰lter

Water supply hose connection

Water drain hose

Regulator

NOTE:

Figures are for illustrative purposes only Individual models may vary.

Lower spray arm

Filter assembly

Inner pipe

Salt container

Dispenser

Cutlery basket Lower basket

Upper basket

Cup rack Upper spray

arm

TABLE OF WASH PROGRAMMES: ZIM656PH

Standard programme This is a reference program for research institutes. Tests according to EN

50242.

 Thisprogrammeissuitableforwashingnormallysoiledtableware.Thisisthemoste󰀨ectivepro-

gramme taking into account the total energy and water consumption for this kind of tableware.

** Programmeduration,energyandwaterconsumptionvaluegiveninthetablehavebeendeter-

minedunderlaboratoryconditions.Actualvaluescanvary.

ITEM Programme name

The

default

tempera-

ture

[°C]

Type of soil Amount of

detergent

Duration

[min.] *

Power

consumption

[kWh] *

Water

consumption

[litres] *

**ECO

Self-Cleaning

Soil level

With the Sanitize option selected, the water tem-

peratureisincreasedto70˚Cforhightemperature

sanitization.

Intensivesoil 5g / 25g

(1 or 2 items)

Pre-wash

50°C Dry

Light soil 30g

(1 item)

Wash 50°C Rinse 45°C

Rinse

Lightly soiled glass-ware and porcelain

Light soil 30g

(1 item)

Wash 55°C Rinse Dry

Pre-wash

45°C Wash 70°C

Type of cycle

A shorter wash for lightly soiled loads that do not need

drying.

Thisprogramprovidesane󰀨ectivecleaningofthe

dishwasher itself. Light soil

Hygiene

Wash 70°C Rinse 70°C

Dry

5g / 25g

(1 or 2 items)

Rinse

1 hour For normally soiled loads that need quick wash.

Rinse 50°C

Rinse 70°C Dry

Rapid Light soil 15g

(1 item)

Wash

40°C

Rinse 40°C Rinse 55°C

Rinse

70°

40°

70°

50°

55°

200 1.772 19.0

60 0.853 11.4

210 0.808 11.0

145 1.241 14.9

30 0.781 11.0

For lightly soiled crockery and glass.

50°

Glass 120 0.902 15.0

Light soil 5g / 25g

(1 or 2 items)

Rinse

Pre-wash

40°C Wash 50°C Rinse 50°C Dry

DISHWASHER QUICK START GUIDE: ZIM656PH

Dear Customer,

This Quick Start Guide is enclosed

with detailed dishwasher Operating

Instructions. Before using the

appliance carefully read the Operating

Instructions, especially guidelines for

safe use.

Before plugging your dishwasher

into the mains power, remove the

safety packaging. Do not start the

dishwasher before it is properly set up.

Turn on the appliance1

Open the dishwasher door, press the on/o󰘯

button. Power indicator will be on

Dispense detergent2

Press the latch to open the detergent dispenser.

Add detergent to the dispenser.

Check the special salt

level

Add special salt to the dispenser when the

corresponding indicator on the control panel

comes on.

Load the dishes

Remove food leftovers from the dishes

Place the dishes in the baskets according to loading

guidelines.

It is recommended to load the lower basket 󰘰rst, then

the upper basket.

Select the wash programme

Open the door, press the Power button

Choose a program, the response light will turn on.

Then close the door, the dishwasher will start its

cycle.

Start your dishwasher

Open the dishwasher door.

The dishwasher will start a wash programme.

Turn o󰘯 the appliance

Turn the appliance o󰘯 using the On/O󰘯 button.

Remove dishes from the

appliance

When the dishwasher is o󰘯, open the door and wait

about 15 minutes before removing the dishes. This

will also facilitate the drying process. Hot dishes are

more susceptible to cracking.

Features and components

Spray arms

Cutlery basket

Upper basket

Inner tube

Lower basket

Salt container

Detergent dispenser

Mugs and cups shelves

Main 󰘰lter

Water supply hose connection

Water drain hose

Regulator

NOTE:

Figures are for illustrative purposes only Individual models may vary.

Lower spray arm

Filter assembly

Inner pipe

Salt container

Dispenser

Cutlery basket Lower basket

Upper basket

Cup rack Upper spray

arm

TABLE OF WASH PROGRAMMES: ZIM656PH

Standard programme This is a reference program for research institutes. Tests according to EN

60436.

 Thisprogrammeissuitableforwashingnormallysoiledtableware.Thisisthemoste󰀨ectivepro-

gramme taking into account the total energy and water consumption for this kind of tableware.

Programmeduration,energyandwaterconsumptionvaluegiveninthetablehavebeendeter-

minedunderlaboratoryconditions.Actualvaluescanvary.

ITEM Programme name

The

default

tempera-

ture

[°C]

Type of soil Amount of

detergent

Duration

[min.] *

Power

consumption

[kWh] *

Water

consumption

[litres] *

**ECO

Self-Cleaning

Soil level

With the Sanitize option selected, the water tem-

peratureisincreasedto70˚Cforhightemperature

sanitization.

Intensivesoil 4g / 16g

(1 or 2 items)

Pre-wash

50°C Dry

Light soil 20g

(1 item)

Wash 50°C Rinse 45°C

Rinse

Lightly soiled glass-ware and porcelain

Light soil 20g

(1 item)

Wash 55°C Rinse Dry

Pre-wash

45°C Wash 70°C

Type of cycle

A shorter wash for lightly soiled loads that do not need

drying.

Thisprogramprovidesane󰀨ectivecleaningofthe

dishwasher itself. Light soil

Hygiene

Wash 70°C Rinse 70°C

Dry

4g / 16g

(1 or 2 items)

Rinse

1 hour For normally soiled loads that need quick wash.

Rinse 50°C

Rinse 70°C Dry

Rapid Light soil 12g

(1 item)

Wash

40°C

Rinse 40°C Rinse 55°C

Rinse

70°

40°

70°

50°

55°

200 1.772 19.0

60 0.853 11.4

210 0.824 11.0

145 1.241 14.9

30 0.781 11.0

For lightly soiled crockery and glass.

50°

Glass 120 0.902 15.0

Light soil 4g / 16g

(1 or 2 items)

Rinse

Pre-wash

40°C Wash 50°C Rinse 50°C Dry
