Emergency telephone

Operating Instructions

BIGTEL 49 PLUS

Contents

1 Safety Information 4. . . . . . . . . . . . . . . .

2 Putting the Telephone into Operation 5. . .

3 Operating Elements 7. . . . . . . . . . . . . . .

4 Operating the Telephone 8. . . . . . . . . . .

5 Telephoning 9. . . . . . . . . . . . . . . . . . . .

6 Private Branch Exchanges /

Suppl. Services 11. . . . . . . . . . . . . . . .

7 Menu Structure 12. . . . . . . . . . . . . . . . . .

8 Phone Book 13. . . . . . . . . . . . . . . . . . . .

9 Calls List / CID 14. . . . . . . . . . . . . . . . . .

10 Emergency Call 15. . . . . . . . . . . . . . . . .

11 If Problems Occur 16. . . . . . . . . . . . . . . .

12 Maintenance / Guarantee 17. . . . . . . . . . .

13 Index 18. . . . . . . . . . . . . . . . . . . . . . . . .

Safety Information

1 Safety Information

Please read this operating instruction manual thoroughly.

Intended use

The telephone is suitable for telephoning within a public telephone net-

work system. Any other use is considered unintended use. Unauthorised

modification or reconstruction is not permitted. Under no circumstances

open the device or complete any repair work yourself.

Installation location

Prevent excessive exposure to smoke, dust, vibration, chemicals, mois-

ture, heat and direct sunlight.

Power adapter plug (option)

Caution: No power adapter plug is enclosed with the product.

Only use an original power adapter plug which can be ordered

from out Service Hotline.

Hearing aid compatibility

Using the premium receiver, the telephone is perfectly compatible with

most popular hearing aids on the market. However, due to the wide range

of hearing aids available, there is no guarantee that the telephone will

function problem−free with every model.

Caution: This telephone is capable of producing very volume le-

vels when the amplifier is switched on and the volume control is

set to maximum. Extreme caution should be taken if the handset

is to be shared between users with normal hearing and those with

hearing impairment.

Disposal

You are obliged to dispose of consumable goods properly in ac-

cordance with the applicable legal regulations. The adjacent sym-

bol on the telephone indicates that electrical and electronic appa-

ratus and batteries no longer required must be disposed of

separate from domestic waste.

Electrical and electronic devices must be disposed of at suit-

able collection points provided by the public waste authorities.

Batteries must be disposed of at the point of sale or at the ap-

propriate collection points provided by the public waste authori-

ties.

Packaging materials must be disposed of according to local reg-

ulations.

Putting the Telephone into Operation

2 Putting the Telephone into Operation

Safety notes

Caution: It is essential to read the safety information in Chapter

1 before preparing the telephone for use.

Checking the contents of the package

The package contains:

Content BIGTEL 49 PLUS

Base unit 1

Premium receiver 1

Coil cable for the receiver 1

Telephone connection cable 1

Batteries AA 1.5 V 4

Wall−mounting bracket 1

Operating manual 1

Connecting the telephone

Connect the telephone as illustrated in the diagram. Only use the tele-

phone connection line supplied because the equipment may not function if

another telephone connection line is used.

Power adapter

plug (option)

Receiver connection

Telephone line socket

The full range of telephone functions can only be used when the

batteries are correctly inserted and are not empty.

It is also possible to use the optional power adapter plug instead

of batteries.

Device type: BIGTEL 49 PLUS (9 V DC, 200 mA).

Putting the Telephone into Operation

Inserting the batteries

Insert the batteries in the open

battery compartment.

Only use batteries of the type

AA 1.5 V. Pay attention to the

correct polarity. Close the

battery compartment cover.

The full range of telephone functions can only be used when the

batteries are correctly inserted and are not empty.

Caution: Always ensure that the telephone is not connected to

the telephone socket and/or power socket (option) when inser-

ting or replacing batteries.

When the batteries are empty, the icon appears in the display.

Replace the batteries.

Setting the time and date

The time and date are set via the menu. Refer to Page 12 for the se-

quence of menu option selections necessary.

Private branch exchanges

The information on Page 11 explains how to install your telephone in a pri-

vate branch exchange.

Wall installation

The telephone can also be installed on a wall. You require two screws in

order to fix the telephone on a wall.

Feed the guide tabs (1) on the wall−mounting bracket (2) in the slots (3) on

the rear side of the telephone. Slide the wall bracket (2) 10 mm upwards

until it audibly snaps into place.

Warning: Ensure that there are no cables or pipes etc. under

the surface of the wall where you want to drill the holes.

Drill two holes whose distance apart corresponds to the bracket to be

used, insert the screws and allow them to project 5 mm from the wall.

Position the telephone on the bracket, fit the screws in the slots and slide

the telephone downwards a little.

Turn the receiver hook (4) in the receiver cradle 180° so that the receiver

can be hooked in.

Operating Elements

3 Operating Elements

Telephone

1 Call back button

2 One−touch dialling

button M1

(emergency call number 1)

3 Delete

4 One−touch dialling

button M2

(emergency call number 2)

5 Scroll upwards

6 Quick dial button

7 Scroll downwards

8 Calls list (CID1) /

Cancel2

9 New call indication

10 Phone book

11 Save number button

12 R button

13 Redial button

14 LED, telephone is

ringing

15 LED, handsfree mode

16 Handsfree mode button

17 Receiver +40 dB boost

button

18 Volume boost on LED

19 Control knob,

receiver volume

(hidden under premium

handset)

20 Ringing volume"

slide control

21 Tone" slide control

22 Handsfree volume"

slide control

The buttons in this operating manual are depicted with a uniform contour.

Variations in the symbols on the telephone buttons compared to those

depicted here are possible.

21CID: Connection Identification = Displays the number of a caller.

2Each process is automatically cancelled if no input is made

within a period of 60 seconds or if the CID button is pressed.

Operating the Telephone

4 Operating the Telephone

Display and explanation of operation sequences

Enter digits or letters

Press the button depicted briefly

2 x Press the button depicted twice, briefly

2 sec Press the button depicted for

2 seconds

Press and hold Press and hold the button depicted

Release Release the button depicted

 Telephone rings

Lift the receiver

Replace the receiver on−hook

TextText flashes in the display

GERMAN or Text or icon in the display

Icons and texts in the display

Icon Description

On: Replace the batteries.

14:45 Display of the time.

19/09 Display of the date.

The phone book is open Page 13.

CID The calls list is open Page 14.

NEW The entry in the calls list is new Page 14.

01 Position number in the call list.

TOTAL:

There are XX entries in the call list.

NEW:

There are XX new entries in the call list.

Creating phone book entries − example

The example in Creating phone book entries explains how to navigate

and make entries in the phone book. Proceed as in this example for all the

settings.

Creating phone book entries

Open the phone book

, SAVE? Activate the saving process and

confirm it

, Enter the phone number

(max. 22 digits) and confirm it

, Enter the name (max. 16 letters)

and confirm it

SAVED Entry is saved

Telephoning

5 Telephoning

Taking a call

, or Take the call

Ending a call

or End the call

Making a call

Enter the phone number

(max. 22 digits)

Following incorrect input, press to

delete the last digit

or or Dial the number

It is also possible to lift the receiver first to obtain the dialling tone.

The digits in the phone number then entered are dialled imme-

diately. It is not possible to correct wrong digits individually using

this dialling procedure.

Redialling

Your telephone stores the last phone number dialled.

or , Redial the last phone number dialled

Calling back missed calls

The telephone stores the numbers of the last 32 calls received in a calls

list.

or Select an entry

or Dial the number

Dialling phone numbers from the phone book

There must be phone numbers stored in the phone book Page 13.

Open the phone book

or Select an entry

or Dial the number

One−touch dialling

The quick dial buttons M1 or M2 can be used for normal quick dial num-

bers or as a memory location for automatic emergency call dialling. Phone

numbers must have been stored as quick dial numbers. Page 15.

or Press the required quick dial button

or or Dial the number

Quick dialling

It is possible to store 10 phone numbers so that they are dialled simply by

pressing three buttons (quick dialling).

Programming quick dial buttons

Press the Save number button

, Enter the phone number

(max. 22 digits) and confirm it

, Enter the name (max. 16 letters)

and confirm it

Enter the memory location number

(e.g. in this case, memory location 0)

Making calls using the quick dial buttons

or Lift the receiver or handsfree

Press the quick dial button

Enter the memory location number

(e.g. in this case, memory location 0)

The phone number stored is automatically dialled.

Adjusting the receiver volume

The receiver volume can be adjusted when the +40 dB volume boost but-

ton is activated.

Adjust the volume with the control knob

Telephoning

Increasing the receiver volume on +40 dB.

The receiver volume can be increased by pressing the left−hand side of

the loudspeaker key marked +40 dB

Increasing the volume on + 40 dB

Tone control

The tone of the receiver can be adjusted using the corresponding slide

control on the right−hand side of the housing.

Adjust the tone using the slide control

Tone adjustment is only possible when the receiver volume

+40 dB boost button is on.

Ringing volume

The ringing volume can be adjusted using the corresponding slide control

on the right−hand side of the housing.

Adjust the volume using the slide

control

Talk time display

The duration of a call is displayed in minutes and seconds during the call.

Handsfree

Use this function to listen to the caller via the loudspeaker.

Switch on handsfree mode

Deactivate handsfree mode

Adjusting the handsfree volume

The handsfree volume can be adjusted using the corresponding slide con-

trol on the right−hand side of the housing.

Adjust the volume using the slide

control

Inhaltsverzeichnis

Andere Amplicomms Telefon Handbücher

Amplicomms

Amplicomms bigtel 50 alarm plus Bedienungsanleitung

Amplicomms

Amplicomms powertel 46 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 711 Voice Bedienungsanleitung

Amplicomms

Amplicomms bigtel 1480 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 700 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 480 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 96 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 30 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 48 Plus Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 60 plus Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 196 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 2880 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 96 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 1500 Bedienungsanleitung

Amplicomms

Amplicomms POWERTEL 92 Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 1880 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 48 Plus Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 90 Bedienungsanleitung

Amplicomms

Amplicomms BIGTEL 48 Bedienungsanleitung

Amplicomms

Amplicomms bigtel 50 alarm plus Bedienungsanleitung

Amplicomms

Amplicomms BigTel 40plus Bedienungsanleitung

Amplicomms

Amplicomms BigTel 40plus Bedienungsanleitung

Amplicomms

Amplicomms bigtel 50 alarm plus Bedienungsanleitung

Amplicomms

Amplicomms PowerTel 58plus Bedienungsanleitung

Beliebte Telefon Handbücher anderer Marken

GE 2-9480 Bedienungsanleitung

Geemarc

Geemarc PHOTOPHONE 155 Bedienungsanleitung

D-Link

D-Link DWR-720/PW Bedienungsanleitung

Interquartz

Interquartz Gemini IQ333 Bedienungsanleitung

SSS Siedle

SSS Siedle HT 840-0 Bedienungsanleitung

Motorola

Motorola TITANIUM Bedienungsanleitung

Panasonic

Panasonic ICX Bedienungsanleitung

LG H870DS Bedienungsanleitung

Samsung

Samsung GT-I9500 Bedienungsanleitung

AT&T

AT&T Trimline 205 Bedienungsanleitung

Selta

Selta zenyth 600 Bedienungsanleitung

Doro

Doro AFTI 20 Bedienungsanleitung

UNIQCELL

UNIQCELL A1 Bedienungsanleitung

Panasonic

Panasonic KX Series Bedienungsanleitung

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Bedienungsanleitung

BT Decor 425 Bedienungsanleitung

NEC

NEC SV8500 Bedienungsanleitung

Teledex

Teledex PEARL Bedienungsanleitung
