T342 Users Manual
3
Table of Contents
Table of Contents
The Deluxe Home Theater Experience
T342 Features 8
T342 Specifications 9
Getting Started
Make Sure You Have the Following Items 13
Front Panel Description 15
Rear Panel Description 16
Display Window Description 17
Remote Control Description 18
Prepare the Remote Control 19
What Type of Video Connection Do You Have? 20
Video Connection 22
What Type of Audio Connection Do You Have? 26
Audio Connection 28
Radio Tuner Antenna Connection 37
4Customer Service 1 626 968 6860
Basic Operations
Playing a DVD 40
Front Panel Buttons 41
Remote Control Buttons 43
Care for Your Discs 51
Setting Up the System Preferences
Navigating the Setup Menu 61
General Setup 62
Audio Setup 64
Video Setup 77
Preference Setup 80
Special Operations
Playing MP3's 55
Viewing Images (JPEG's) 57
PlayingProgressive Scan 59
Password Setup
Exit Setup
83
85
Table of Contents
5
Appendix (Definitions of Keywords) 87
Tr oubleshooting Guide 91
Safety Instructions 93
Legal Notifications
Copyright 99
FCC 100
Warranty Information 103
Getting Started
The Deluxe Home Theater Experience
7
The T342 Deluxe Home Theater Experience brings the clarity and quality of
the movie theater home to you. The picture quality of DVD combined with
the multi-channel surround sound of the T342 will enable you to fully enjoy
the Home Theater experience.
The T342 System gives you a complete Home Theater package, combining an
advanced DVD player with a Stereo receiver and tuner that can support the
most advanced Dolby Digital sound that is only available through DVD
technology.
8Customer Service 1 626 968 6860
T342 Features
DVD Player / Receiver with Expanded Functions
Blue Light VFD Display
Digital AM / FM Stereo Tuner with 40 Memory Presets
125 watts total system power
1 Auxiliary A/V Input for Additional Components
Advanced Surround Sound
Dolby Digital Surround Decoding
Digital Sound Processing
Diversified EQ Sound Effects
Expanded Video Features
Built-In Screensaver
3-Level DVD Zoom
Active Full-Screen Function of Widescreen DVDs
Composite, S-Video, and Component Video Outputs
Digital Audio Input & Output
Full-Function Remote Control
DVD Player-Palys DVDs, VCDs, CDs, CD-R/RWs, Mp3s, JPEGs
9
The Deluxe Home Theater Experience
T342 Specifications
Built-in Dolby Digital
Dolby Digital Decoding
Dolby & DTS SPDIF DigitaI output
Dolby down-mix dual channel
Multi format Disk Supporting
CD, MP3
DVD,VCD,SVCD
CD-R,CD-RW
Kodak Picture CD (JPEG)
Audio Advantage
192K, 24bit
E.Q. Genie (7 modes to select)
Diversify Sound effect
10 Customer Service 1 626 968 6860
Video Decompression
MPEG-2, MPEG-1
10-bit video decoding
PAL,NTSC TV system playback
Screen aspect ratio selectable (4:3 and 16:9)
Smart Content editor
Multi-angled view
8 Languages for OSD (8-bit On Screen Display)
Multilingual dialog up to 8 tracks and 32 subtitles
Advanced Progressive Scan
Video Inputs / Outputs
Composite video input / output (AV)
S-video output
Component output
Audio Inputs / Outputs
Optical SPDIF Output (1)
AUX Stereo Input / Output (1)
