Walker – User Manual
(3/2/2015)
CONTROLS
LED Indicator
For Magstripe
Card Reading
For EMV Card Reading
Micro USB Port for
Charging & Operation
3.5mm Audio Jack
Lanyard Hole
SPECIFICATIONS
Power & Battery
Charging
Software Support
Battery Life
Light Indicator
Communication Channel
Built-in Lithium Polymer Rechargeable Battery,
125 mAH, 3.7V
Via Micro USB to computer system or power
adapter. Charge for 2 hours for full charge
Android 2.1 or above, IOS 6.0 or above,
Windows Phone 8, Windows XP or above
Approximately 100 EMV transactions
Micro USB
In The Box Walker, USB cable, User manual
Light ON
Light Flashing
• Green – Battery Full Charge
• Red – Charging
• Green – During Transaction
• Red – Low battery during transaction
INSTRUCTIONS
Step 1
Charge Walker using the enclosed cable
You can connect Walker to a computer or use a power adapter (not included).
A full charge will be obtained in 2 hours.
Step 2
Download and install the merchant payment application on your smartphone or tablet
Step 3
Plug Walker into the audio jack of your smartphone or tablet. You may need to remove the protective case from
your phone or tablet if it prevents Walker from being properly plugged into the audio jack.
Step 4
Open/launch the payment application
Step 5
You may need to maximize the media volume or other audio settings on your phone
Computer /
Power Adapter
Step 6
Swipe or insert the card when prompted by your payment application
Insert
** Leave the card in Walker until the payment application prompts you
to remove the card.
WARRANTY
Walker has a six month warranty for manufacturing defects. The warranty is void if the serial number has been
tampered with or removed.
Please contact your merchant services provider for support.
Swipe
Remove and reconnect Walker.
Remove any protective sleeve or case from your smartphone or tablet.
Contact your merchant services provider to make sure your smartphone or
tablet is supported.
Charge Walker if necessary.
Device does not work with your
phone or tablet
Problem Recommendations
Device cannot read your card
successfully Check the card slots for any obstructions.
Make sure the magstripe or chip is facing the right direction.
Swipe the card with a consistent, smooth speed.
Don’t remove a chip card until prompted by your payment application.
TROUBLESHOOTING
376 Victoria Ave. Suite 418
Montreal, Quebec,
QC H3Z 1C3, Canada
