OPERATING INSTRUCTIONS
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATION
LINE CORD SAFETY TIPS
1. Never pull or yank on the cord or the appliance.
2. To insert plug, grasp it firmly and guide it into outlet.
3. To disconnect appliance, grasp plug and remove it from outlet.
4. Before each use, inspect the line cord for cuts and/or abrasion marks. If any
are found, this indicates that the appliance should be serviced and the line
cord replaced. The line cord may be replaced by qualified service personnel.
5. Never wrap the cord tightly around the appliance, as this could place undue
stress on the cord where it enters the appliance and cause it to fray
and break.
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE, OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
HOW TO USE
Power Indicator Light
Carrying Handle
Grille
Guards
THERMOSTAT Switch
(MIN/MAX)
Cord; keep loosely coiled when
not in use (not shown)
Caution Light
Function Switch
OFF/FAN ONLY/I (1300W)/II (1500W)
CARE AND CLEANING
This appliance is for HOUSEHOLD USE ONLY. It may be plugged into any AC
electrical outlet (ordinary household current). Do not use any other type of outlet.
SPECIAL ATTENTION:
The use of an extension cord is not recommended. However, if it is absolutely
necessary, be sure that the cord is (1) No. 14 AWG minimum size and rated no
less than 1500 watts; (2) UL Listed; (3) as short as possible (long cords can
overheat, as well as trip circuit breakers); (4) not used for operating more than
one appliance at a time.
REMEMBER: Portable electric heaters are designed for space heating or as a
supplementary heat source. They are not intended to be the main source of heat.
CHOOSING A LOCATION FOR HEATER/FAN
• Place Heater on a flat, stable surface, such as a floor, tabletop, shelf or desk
in a location where the airflow through the inlet and exhaust openings are not
obstructed.
• Keep all combustible materials such as furniture, pillows, bedding, paper,
clothes and curtains at least 3 feet away from heater.
• Do not use in wet or moist locations; example, bathrooms or laundry areas,
or in areas where paint or other flammable or volatile liquids are used
or stored.
CAUTION
Be sure that no other appliances are plugged into the same circuit with this
Heater/Fan. A circuit overload could occur.
TO USE
1. Make sure the function switch is OFF.
2. Plug in and turn the unit on. The red power indicator light illuminates.
3. If you prefer to operate the fan without heat, turn the function switch to FAN
ONLY and turn the THERMOSTAT switch clockwise until the fan begins to
operate. The heat will not operate in this mode.
4. If you would like heat, select either 1300W (Low) or 1500W (Hi).
5. Turn the THERMOSTAT switch clockwise to the MAX setting to activate
the Heater/Fan.
6. Once the desired room temperature is reached, turn the THERMOSTAT switch
counterclockwise until the fan cycles off. The heat will now cycle On/Off and
maintain a comfort level.
This appliance is permanently lubricated and will not require additional lubrication for the
life of the unit. It contains no user serviceable parts. Refer service to qualified service
personnel.
SPECIAL NOTE:
Before unplugging unit, turn to the Off position.
TO CLEAN: Always unplug and disconnect the cord from the electrical outlet when
cleaning your Heater. Allow Heater to cool completely before attempting to clean.
Accumulated dust may be removed from the Heater with a soft cloth or vacuum cleaner
using the dusting brush attachment. Interior dust can often be removed by using a
vacuum cleaner in its blower mode with a crevice attachment.
Heater may also be cleaned with a cloth that has been moistened with a solution of mild
detergent and water. Dry the Heater casing thoroughly with a soft, dry cloth before
operating the unit.
CAUTION: DO NOT immerse Heater in water or allow water to drip into the interior of the
Heater, as this could create an electric shock hazard.
TO STORE: When storing Heater during the off season, be sure to store it in a dry area
neatly. Neatly wrap the power cord. The power cord should not be in contact with sharp
edges, and it should not be compressed by heavy objects.
SPECIAL FEATURES
SAFETY AUTO SHUT-OFF AND SAFETY CAUTION LIGHT: This Heater/Fan is equipped with
a safety auto shut-off, plus a safety thermal fuse and caution light. If the unit experiences
excessive heat, the safety auto shut-off will cycle the Heater/Fan off, and the caution
light goes on. If this occurs, turn the unit off immediately and check for any objects that
may be restricting airflow through the heater/fan. If the caution light continues to glow,
do not operate Heater/Fan. A cool-down period of several minutes may be required
before the Heater/Fan resumes normal operation. The safety auto-shut off device is
designed to operate if the heater is tipped over, front or back, and the airflow is blocked.
POWER INDICATOR LIGHT: To show that unit is switched on and operating, this
Heater/Fan is equipped with a power indicator light that illuminates whenever the heater
is plugged in and the function switch is turned on in any position. It continues to glow
even if the thermostat has cycled and the heating elements are off.
MAXIMUM CONTINUOUS HEAT: Turn the THERMOSTAT switch clockwise to the MAX
position and the function switch to the 1500-watt setting.
GRILLE GUARDS:
The grille guards on the front of the unit protect the safety grille from impact if unit falls
forward or tips over.
SAFETY TIP-OVER AUTOMATIC SHUT-OFF:
As an additional safety feature, this Heater shuts off automatically when unit is tipped
over under certain conditions. If it is tilted either forward or backward, the Heater ceases
to operate, and the caution light is activated. In addition, the power indicator light
remains lit to show that the unit is plugged in and switched on. The caution light remains
on until the unit is switched off and unplugged. Once the unit is returned to a level
position, plugged in and switched on again, normal operation resumes.
