Archos S3 Platinum Bedienungsanleitung
1
EN
Table of contents
For more information, please consult the
FAQs on www.archos.com. Make sure to read
them before considering any product return.
Your deal may be no big deal. As we are often
updating and improving our products, your
device’s software may have a slightly dierent
appearance or modied functionality than
presented in this Quick Start Guide.
Package contents........................................................
Description of the phone.........................................
Assembling....................................................................
Getting started.............................................................
Through the wizard....................................................
3G & WiFi connection.................................................
Google account & Contacts.....................................
Troubleshooting...........................................................
2
3
6
8
9
10
12
14
ARCHOS_53_Platinum_book_quick.indd 1 23/04/2013 18:14:51
2
Package Contents
Check your product box for the following items:
-ARCHOS 53 Platinum
-Battery
-Headset
-Micro SIM adaptor
-USB cable
-Charger
-Quick start guide
-Warranty Legal & Safety notices
The items supplied with your device and
available accessories may vary depending on
your region or service provider.
The supplied items are designed only for your
device and may not be compatible with other
devices.
Unapproved accessories may cause your device
to malfunction.
ARCHOS_53_Platinum_book_quick.indd 2 23/04/2013 18:14:52
3
scale 1:1 mm
05-04-2013
last modification:
NEW
Rev O
AC53PL
CONFIDENTIAL
DRAWING
5
21
4
3
EN
1Webcam
Loudspeaker
Volume buttons
Microphone
ON/OFF button
2
3
4
5
Description of the phone
ARCHOS_53_Platinum_book_quick.indd 3 23/04/2013 18:14:53
4
10
67
scale 1:1 mm
05-04-2013
last modification:
NEW
Rev O
AC53PL
CONFIDENTIAL
DRAWING
scale 1:1 mm
05-04-2013
last modification:
NEW
Rev O
AC53PL
CONFIDENTIAL
DRAWING
8 9
Description of the phone
Micro-USB port
Headset jack
Camera
Flashlight
Loudspeaker
6
9
8
7
10
ARCHOS_53_Platinum_book_quick.indd 4 23/04/2013 18:14:54
5
11 13
12
EN
Menu button: open the list of options available
on the current screen.
Home button: short press to return to the
Home screen; press and hold to open the list of
recent applications.
Back button: return to the previous screen.
Description of the phone
Menu button
Home button/Recent apps
Back button
13
12
11
ARCHOS_53_Platinum_book_quick.indd 5 23/04/2013 18:14:55
6
Assembling
1. Use the notch to remove the back cover.
Do not bend or twist the back cover
excessively. Doing so may damage the cover.
2. To insert your 3G SIM card, slide it facing
downwards in the 2G/3G slot (slot 1). To insert
your standard SIM card, slide it facing downwards
in the 2G slot (slot 2).
3. To insert a Memory card, push upwards
the memory card slot and lift the cover. Place
the Memory card. Close the cover and push it
downwards.
4. Align the battery’s 4 contact points with those
of the phone and gently press the battery down
into place.
5. Replace the battery cover clicking it back into
position.
Before using your device for the first time,
charge completely its battery.
ARCHOS_53_Platinum_book_quick.indd 6 23/04/2013 18:14:55
7
Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position
Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position
Slot1Slot2
EN
Assembling
ARCHOS_53_Platinum_book_quick.indd 7 23/04/2013 18:14:56
8
Turn ON
If you are turning on your device for the rst
time, follow the on-screen instructions to set
up your device. You must sign in to Google or
create a Google account to use applications
that interact with the Google server.
1. Press and hold the ON/OFF button to turn on
the device.
When you turn on your device, a PIN code may
be requested.
2. Type the PIN code supplied with your SIM card.
Beware of typing a wrong PIN code.
3. Select‘OK’.
Turn OFF
To turn o your device, press and hold the ON/
OFF button, and then select Power o > OK.
Getting started
ARCHOS_53_Platinum_book_quick.indd 8 23/04/2013 18:14:56
9
EN
Tip:
Your device turns off the touch screen when
you do not use it for a specified period. To turn
on the screen, press the ON/OFF button.
Getting started
Through the wizard
The rst time you start up your ARCHOS, the
installation wizard will help you set up your
device:
-Language
-Date & time
-WiFi connection
-Location service options
-3rd party apps
ARCHOS_53_Platinum_book_quick.indd 9 23/04/2013 18:14:57
10
3G connection
With your 3G SIM card, you can connect to the
Internet without setting.
The ARCHOS will only have signal if you are in
an area covered by your 3G provider’s 3G or
EDGE network.
When connected to the 3G network, the 3G
icon is displayed in the status bar.
To be able to access Internet, the mobile data
icon must be activated.
Drag down the status bar and touch the mobile
data icon to activate it.
3G & WiFi connection
ARCHOS_53_Platinum_book_quick.indd 10 23/04/2013 18:14:57
