Archos 501353 Bedienungsanleitung
1
www
1
English
RegisteR youR pRoduct!
VERSION 1.0 - P/N: 109302
www.archos.com/register
Dear Customer,
Thank you for choosing this ARCHOS product. We hope that you will enjoy using it and that it will give you satisfaction for many
years to come. Once you unpack your ARCHOS product, we recommend that you take a few minutes to register it
(www.archos.com/register).This will allow you to get access to ARCHOS technical support (www.archos.com/support).
If you have questions related to the use of Windows®, you can display the Windows® Help by clicking on the Start menu (at the bot-
tom left of the screen), then Help and Support.
Wishing you the best multimedia experience,
The ARCHOS Team.
Please note that your device’s appearance may be slightly different than presented in this User Guide.
User_Guide_1_Archos_9_PN109302_v1_book.indd 1 31/01/2011 15:05:56
2
▲
!
English
iMpoRtANt sAFety Notes
Carefully read and follow the Safety Notices as failure to comply with these could lead to serious injury or in some cases death.
Electrical Device Warning
Your device and its charger/adapter are electrical devices, therefore :
Do not expose the ARCHOS 9, cords, or adapter/charger to rain, moisture, water, or use in humid areas.-
Avoid using near spillable liquids such as drinks.-
Do not pinch, bend, or put heavy or sharp objects on its electrical cord.-
Connect only peripherals and accessories that are expressly designed for the standardized connectors of the ARCHOS 9.-
Use only a charger/adapter that are specically certied for the ARCHOS 9.-
If using an extension cord, use a minimum cable diameter of AWG n°26-
Shutdown and unplug from the adapter/charger before changing a part in the device.-
Unplug from the wall during a storm.-
General Treatment Advice
Your device has delicate components inside and should be treated carefully, therefore:
Do not handle the ARCHOS 9 roughly or subject it to falls, pressure, shock, or violent movement.-
Do not use or leave the ARCHOS 9 on soft surface such as a bed or cushion which could help the device build up heat.-
If your ARCHOS 9 is very cold or has been stored in a very cold environment, do not use it right away. Let it adjust to the room-
temperature gradually, before turning it on.
If the device emits a strange oder, produces extra-ordinary heat, or makes strange noises, stop using the device, remove battery-
from device, and contact an ARCHOS service representative.
Do not use the device while driving a car or doing any other activities in which loss of concentration could lead to potential-
harm to self or others.
User_Guide_1_Archos_9_PN109302_v1_book.indd 2 31/01/2011 15:05:56
3
English
Health warnings
Using an electronic device such as the ARCHOS 9 can lead to health problems if used inappropriately, therefore:
Allow a break from continued usage of at least 10 minutes per hour.-
Maintain enough light in the room (equivalent to that required for reading)-
When using headphones, do not listen to loud levels of music or sound for extended periods. Stop using headphones if you hear-
ringing or buzzing in your ears.
Use only on a table top and where hands and wrists can comfortably access the keyboard. If you are doing much typing, keep-
your wrists straight and give your hands a periodic rest.
Adjust your seat and table’s height appropriately. Using your device while lying or in any position other than sitting at a desk-
could cause musculoskeletal problems and is strongly discouraged.
Be aware that being equipped with wi capabilities, it will send and receive radio waves and that medical devices such as -
pacemakers may be sensitive to the generation of radio frequencies created by this device. Check with the maker of your medical
equipment to make sure such interference is tolerable by the equipment.
If connecting a 3G or similar transmitting device (ex: 3G USB stick) to allow connections to the internet via wireless telephone-
networks, your exposure to radio frequencies is increased. Inform yourself of the Specic Absorption Rate level for the device and
what it means and what health risks are involved.
Please read other important safety information at the back of this guide.
User_Guide_1_Archos_9_PN109302_v1_book.indd 3 31/01/2011 15:05:56
4
?
English
Questions about Windows®?
If you have questions related to the use of Windows®, you can display the Windows® Help by clicking on the Start
menu (at the bottom left of the screen), then Help and Support.
Contact our Technical Support Team
Visit www.archos.com/support to contact ARCHOS technical support.You will need to register your product before
contacting ARCHOS Technical Support.
FAQs
See the Frequently Asked Questions section on www.archos.com/faq
Need HeLp?
Here are some ways to nd the information you may need:
User_Guide_1_Archos_9_PN109302_v1_book.indd 4 31/01/2011 15:05:57
5
English
box coNteNts*
* Please note: actual box contents may vary and are subject to change without prior notice.
The box includes the following items:
The Power cord & adapter
The ARCHOS 9
Stylus
To be inserted in the back of
the product.
Removable Battery
Recovery DVD
User_Guide_1_Archos_9_PN109302_v1_book.indd 5 31/01/2011 15:06:01
6
1
2
3
4
5
6
7
8
9
7
89
23
6
5
4
1
1
English
Loudspeakers
Webcam: the LED indicator next to it turns on when the webcam is on.
“A” button Press once: this button is the equivalent of pressing “Ctrl+Alt+Del” on a regular
keyboard. Hold this button and press the Mouse buttons to activate (on) or deactivate (off)
the WiFi and Bluetooth connections.
Keyboard button Press once: display/hide the virtual keyboard. Hold this button and press
the Mouse buttons to increase/decrease the screen brightness.
Mouse buttons: the top one acts as a mouse’s left button and the bottom one acts as a
mouse’s right button.
Built-in microphone
Power Button: press once to turn the device on.
In the event that the device cannot be shutdown via the
Start
menu >
Shutdown
item (at the bottom left of the
screen), you can press and hold the Power button until the ARCHOS shuts down.
Mousepad: to move the cursor that appears on the screen.
Battery latch: slide it to remove the battery located at the back of the product.
ARcHos 9 descRiptioN
User_Guide_1_Archos_9_PN109302_v1_book.indd 6 31/01/2011 15:06:05
7
1
6
2
3
4
5
8
7
9
1
2
3
4
5
6
10
7
8
9
10
English
ARcHos 9 descRiptioN
Headphone jack
USB Port: to connect USB devices to your ARCHOS, such as a keyboard, a mouse, etc.
Power indicator: turns on when the device is on. Blinks when the device is in standby.
Charging indicator: Light on: battery charging / blinking: battery charged
Hard drive indicator: blinks when the hard drive is active (playing/transferring les)
Power connector:to connect the supplied power cable.
Adjustable-length Leg stand
Removable battery: to remove it, slide the bat-
tery latch, on the right side of the device.
Stylus holder
Extension port: to connect the optional ARCHOS
Port Replicator accessory.
User_Guide_1_Archos_9_PN109302_v1_book.indd 7 31/01/2011 15:06:09
8
EUR
US
UK
▲
!
1
2
3
English
Before using your ARCHOS for the rst time, completely charge the battery!
Installing and Charging the Battery
Slide the battery into the battery slot, on the back of the product and then gently push the battery until it clicks into place.
Connect the supplied power cable to the ARCHOS Power connector and to a wall outlet.The battery will start charging.
Turning the ARCHOS on
To turn the ARCHOS on, press the Power button .The Power status indicator, on the left side of the device, will turn on. During the
installation wizard, use the Ease of access on-screen icon to bring up the Windows® keyboard whenever you need to type in text.
In the event that the device cannot be shutdown via the
Start
menu >
Shutdown
item (at the bottom left of the screen), you can press and hold the Power
button until the ARCHOS shuts down.
The Charging indicator (on the left side of the device) is on while the battery is charg-
ing. When the battery is fully charged the indicator will blink.
stARtiNg up
User_Guide_1_Archos_9_PN109302_v1_book.indd 8 31/01/2011 15:06:12
9
English
toucHscReeN & MousepAd tips
The mousepad and mouse buttons
The mousepad functions like a laptop touchpad. Simply drag your nger on its surface to move the on-screen cursor. •
To display pop-up info boxes (for example, when you want to see a le’s attributes), you will need to use the mousepad to •
move the cursor over an item without clicking on it.
The two buttons, on the left side of the device act like a mouse’s left and right buttons.•
The touchscreen
The screen of your ARCHOS is entirely tactile. To select an item, tap on it. To open it, tap it twice.To drag an item or select an
area, simply slide your nger on the screen. Holding your nger at a specic position is the equivalent of a mouse’s right-click.
To congure the touchscreen, open up the eGalaxTouch program (from the desktop).This will allow you to:
recalibrate your screen (• Tools tab) in case the cursor doesn’t align with your nger.
activate/deactivate the• auto right click (Settings tab > Options). This option allows you to make a right-click when you keep your
nger held down on the screen.
adjust the• Double Click area parameter (Settings tab) in case an item doesn’t always open when you tap twice on it.
adjust the sensitivity area of the screen’s edges (• Edge compensation tab) in case it is difcult to slide scroll bars on the edges of
the screen.
User_Guide_1_Archos_9_PN109302_v1_book.indd 9 31/01/2011 15:06:12
10
English
coNNectiNg to tHe iNteRNet
WiFi Connection
Make sure you know your WiFi network’s name (which you usually define when you set up your modem) as well as its security key (of the type WEP or WPA).
Each WiFi network (school, home, café) has a different name and key.
Make sure that your WiFi module is turned on by holding on the “A” button and pressing on the top mouse button (on the left side of the device).
To make the initial connection, click on the WiFi icon in the system tray (in the bottom right corner of the screen), and you will see all the WiFi
networks detected by the ARCHOS.
Select your WiFi network, and click on Connect.You might need to type the security key which can be found in the documentation that came with your
modem (or which was defined by the person who set up the WiFi modem).Then click on Ok.
In the system tray (in the bottom right corner of the screen), the icon indicates that there is an active WiFi connection. The icon indicates that
there is no connection but a WiFi hot spot has been detected. You can click on these items at anytime in order to connect or disconnect from the Internet.
It is also suggested that you use the combination “A” button and the lower mouse button to turn off the WiFi module when not connected to the Internet
in order to save battery power.
User_Guide_1_Archos_9_PN109302_v1_book.indd 10 31/01/2011 15:06:12
