2Features
TI CC3200 ARM Cortex M4 Processor with WIFI support
Arduino UNO Size and Pin Out
Support ArduCAM Standard Camera Interface and MT9D111 Camera Module
Onboard JTAG/SWD Debugger
Support Energia and Code Composer Studio Development Environment
Applications Microcontroller Subsystem:
ARM Cortex-M4 Core at 80 MHz
256KB RAM, 1MB serial flash memory with file system for user
Hardware Crypto Engine for Advanced Fast Security, Including AES, DES,
3DES, SHA2 MD5, CRC and Checksum
Up to 27 individually programmable, multiplexed GPIO pins, including a fast
parallel camera interface, I2S, SD/MMC, UART, SPI, I2C, and four-channel
ADC.
Wi-Fi Network Processor Subsystem:
Dedicated ARM MCU, completely offloads Wi-Fi and Internet Protocols from
the Application Microcontroller
802.11 b/g/n Radio
WPA2 Personal and Enterprise Security
Station, Access Point, and Wi-Fi Direct Modes
Powerful Crypto Engine for Fast, Secure Wi-Fi and Internet Connections with
256-Bit AES Encryption for TLS and SSL connections
SmartConfig Technology, AP Mode and WPS2 for easy and flexible Wi-Fi
provisioning
The power-management subsystem includes integrated DC-DC converters
supporting a wide range of supply voltages. This subsystem enables low-power
consumption modes, such as the hibernate with RTC mode requiring less than 7
μA of current
