Argo MILO PLUS Bedienungsanleitung

V 11/18

PORTABLE AIR CONDITIONER (LOCAL)

MILO PLUS

OPERATING INSTRUCTIONS

Read the instructions carefully before operating the appliance or carrying out maintenance work.

Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or

damage. Store these instructions in a safe place for future reference.

V 11/18

The Refrigerant R290

•To realize the function of the air conditioner unit, a special refrigerant circulates in the

system. The refrigerant is the fluoride R290 = 3 GWP (Global warming potential). This

refrigerant is flammable and inodorous. It canlead to explosions under certain conditions,

however the flammability of this refrigerant is very low and it can be ignited only by fire.

•Compared to other common refrigerants, R290 is a non-polluting refrigerant with no harm

to the ozonosphere and a no effect upon the greenhouse effect. R290 has very good

thermodynamic features which lead to a really high energy efficiency. The units therefore

need less filling.

Warning:

Do not try to accelerate the defrosting process or to clean the appliance in different ways other

than those recommended by the manufacturer. Should repair be necessary, contact your

nearest authorized Argoclima Service Centre. Any repairs carried out by unqualified personnel

may be dangerous. The appliance has to be stored in a room that doesn’t have any continuously

operating ignition sources. (for example: open flames, an operating gas appliance or an

operating electric heater.) Do not pierce or burn.

Appliance has to be installed, operated and stored in a room with a floor area larger than 15 m2.

For repairs, strictly follow manufacturer’s instructions only for appliances filled with R290

flammable gas. Be aware that refrigerants do not have any odour.

Appliance filled with flammable gas R290.

Before installing and using the appliance, read the owner’s manual.

Before repairing the appliance, read the service manual.

V 11/18

GENERAL OPERATING AND SAFETY INSTRUCTIONS

•This appliance is a local air conditioner designed for domestic use.

•Only use this air-conditioner as described in this manual.

•Ensure that the required voltage and frequency (220-240V/50 Hz)

match the available power source.

•Fuse style T3.15AH250V, the electricity passing through the fuse

cannot be above 3.15A.

•This appliance can be used by children aged from 8 years and above

and people with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Children shall not play with the appliance.

•Cleaning and user maintenance shall not be made by children

without supervision.

•Ensure that the electricity system is able to deliver the operating

current required by the air conditioner, in addition to that normally

absorbed by other appliances (household appliances, lighting

system, etc.). Please refer to the maximum power input data

indicated on the air conditioner's data plate.

•Connection to the electricity grid must take place in accordance with

current installation standards.

•Ensure that the automatic switches and system protection valves are

able to withstand a start-up current of 6A (normally for less than 1

second).

•The system socket must always be fitted with an efficient earth

connection.

•Make sure that the plug is fully inserted. Do not use multiple

adapters. Do not touch the plug with wet hands. Make sure that the

plug is clean.

V 11/18

•Do not use the plug as a means by which to start/stop the air

conditioner: use the ON/OFF button on the remote control or on the

control panel.

•Do not install the air conditioner in rooms where it may receive water

splashes (e.g. laundry rooms).

•This air conditioner can be used by children of 8 years of age or older,

and by persons with reduced physical, sensory and mental abilities

or who lack the necessary know-how and experience to operate it, if

under the supervision or instruction of a person responsible for their

safety, so that they are fully aware of the attendant risks.

•Before moving or cleaning the device, ensure that it is unplugged

from the socket.

•Do not move the air conditioner while it is operating; first turn the

appliance off, check for any condensate build-up and empty it if

necessary.

•To turn the appliance off, set the remote control to OFF and remove

the plug from the socket. Pull on the plug only. Do not pull the cord.

•Do not use the appliance if the cord or plug are damaged. If the

power supply cord is damaged, it must be replaced by the

manufacturer, dealer or a similarly qualified person so as to avoid

any safety risks.

•Keep the unit away from fire, possible fire sources, inflammable or

explosive objects.

•Do not leave the unit unattended while it’s operating, turn the unit off

and unplug it.

•If drainage hose is used, the ambient temperature musnt’t be lower

than 0°C. It can cause water leakage to the air conditioner.

•Do not splash or pour water on the air conditioner

V 11/18

PRECAUTION!

•Do not insert any objects into the air conditioner: this is very

dangerous as the fan turns at high speed.

•Ensure that air circulates freely around the unit. Do not cover

the air intake and delivery grilles with drapes or any other

means.

WARNING!

•The air conditioner must be positioned at least 50 cm from the wall

or any other obstacles, on a flat and stable surface so as to avoid

water leaks.

•The air conditioner is fitted with a system for protecting the

compressor from overload. This means that the compressor

only starts 3 minutes after its previous stoppage.

•Please wait at least 3 minutes before starting the unit. This helps

prevent the compressor from being damaged.

WARNING!

In the event of an anomaly, switch the appliance off and unplug

it from the socket. Do not dismantle or attempt to repair or modify

the product. In the event of a malfunction, contact the service

centre directly.

WARNING!

•Do not expose the air conditioner to direct sunlight, as the

colour of the materials may change; moreover, the appliance

may overheat causing the protection mechanism to intervene

and switch the appliance off.

•Do not use insecticides, oils, detergents or spray paints near

the appliance; do not use aggressive chemical detergents to

clean the casing: this may damage the finish and colour.

•Close all open windows to maximise air conditioning efficiency.

V 11/18

The manufacturer will not be held liable if safety and accident

prevention rules are not observed.

V 11/18

DESCRIZIONE DELL’APPARECCHIO

FRONT VIEW

REAR VIEW

1) CONTROL PANEL AND FUNCTION BUTTONS

WITHOUT REMOTE CONTROL

2) VERTICAL FINS AND AIR INTAKE

3) WHEELS

4) CORD CABLE CLAMP

5) POWER CORD

6) AIR FILTER

7) AIR FILTER

8) AIR EXPULSION HOSE

9) JOINT

10) END FITTING FOR WINDOW

11) REMOTE CONTROL

Min/max operating limits (internal temperature)

Cooling: 16 °C DB / 35 °C DB

Dehumidification: 16 °C DB / 35 °C DB

Cooling mode room temperature adjustment range: 16 °C DB / 30 °C DB

V 11/18

PRE-OPERATING CHECKS AND OPERATIONS

The following space must be maintained to ensure the operating efficiency of the portable air conditioner.

APPLIANCE START-UP

Open the packaging and remove the box from above. Remove the product and the other elements supplied

(illustrated in the box below).

LCD remote control

Type AAA batteries for the

remote control

Round fitting for window (1) to

be positioned between the end

of the tube and the end fitting

for the window

End fitting for window,

supplied into 2 parts (2)

Flat fitting for positioning

between the air discharge

outlet and the hose

Hose

Drain hose

Cord winder

Drainage pipe

Screws

Window unit kit (3 pcs)

(A+B+C)

Round fitting for window unit, to be

positioned between the end of the

tube and the window unit (A)

Window unit (B)

Cap (C)

Position the product vertically on a flat and stable surface, as close as possible to a window and at least 50 cm from walls

or other nearby obstacles.

(1)

V 11/18

INSTALLATION OF CORD WINDER HOOKS

Install the cord winder hooks to the back of the unit using the

screws, as shown in the figure.

The hooks must be positioned facing upwards and

downwards.

When the appliance is not being used, wind the power

cord around the hooks.

Wind the cord around the hook.

USE WITH END FITTING FOR WINDOW

Connect the flat fitting to the hose, extend the hose as far as

necessary for reaching the outside and it connect to the back

of the air conditioner.

Next, slide the flat fitting downwards into the grooves (A)

and secure it with the hook (B).

The upward-facing side of the flat fitting is marked "TOP".

Connect the round window fitting (1) to the end of the hose

then the end fitting for the window (2), previously obtained by

joining parts A and B

Open the windows and lock one of the two leaves with the

handle.

Place the end fitting against the fixed leaf of the window,

and draw the other leaf towards it.

1. Hook

2. Screw

V 11/18

USE WITH WINDOW UNIT KIT

1. To make the hole in the glass it is advisable to take

the porthole kit accessory to the glazier.

2. Insert the window unit into the window.

3. Insert the round fitting into the retractable flexible pipe and

insert the latter with its round fitting into the window unit

without the plug..

4. Insert the round fitting onto the flexible pipe.

5.Insert the flat fitting onto the hose.

6. Slide the flat fitting downwards into the grooves (A) and

secure it with the hook (B).

The upward-facing side of the flat fitting is marked "TOP".

7. The outlet must be between 40 cm and 130 cm above the ground. Avoid tight curves or bends in the flexible hose.
