REPAIR MANUAL
Pages:
1 - 33
The information included in this Ariston Repair Manual may change without notice. Please see our web site
www.usservicenet.com for updates, corrections or additions.
PRODUCT: DISHWASHER
MODEL: L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
REPAIR MANUAL
Page: i
This Repair Manual is intended for persons having electrical and mechanical training and a level of knowledge
of these subjects generally considered acceptable in the Appliance Service Industry. Ariston cannot be
responsible, nor assumes any liability for injury or damages of any kind arising from the use or misuse of
the information contained in this Repair Manual.
If you have any questions regarding the proper diagnosis, repair or operation of any Ariston Appliance, please
contact the Ariston Customer Care Center or your Service Representative.
SERVICING SAFEGAURDS:
To avoid personal injury and/or property damage, it is important that safe servicing practices be observed at all times. Examples of
safe service practices are listed below but are not limited to the following:
1) Never attempt a product repair if you have any doubts as to your ability to complete the repair in a safe and
satisfactory manner.
2) Before servicing or removing an appliance:
- Disconnect power to the appliance.
- Turn off the gas / LP supply.
- Turn off the water supply.
3) Never interfere with the proper operation of any safety device.
4) Use only genuine factory replacement parts as substitutions may interfere with compliances to home safety codes or standards.
5) It is extremely important that all safety ground connections be reestablished prior to the completion of the service call. Failure to
do so will result in a hazardous condition being created.
6) Prior to returning the appliance back into active service, ensure the following:
- All electrical connections are correct and secure.
- Electrical leads are properly dressed and secured away from sharp edges, high temperature components and moving parts.
- All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from metal parts or panels.
- All safety grounds (both internal and external) are correctly and securely connected.
- All access panels are properly and securely reassembled.
SAFE SERVICE PRACTICES
REPAIR MANUAL
Page: ii
Page
1. Model and Serial Number Location ................................................................................................ 1
2. Rack Rollers - Upper & Lower........................................................................................................ 2
3. Upper Spray Arm............................................................................................................................2
4. Lower Spray Arm............................................................................................................................3
5. Outer Door Panel............................................................................................................................ 4
6. Control Panel..................................................................................................................................5
7. Outer Door Skin..............................................................................................................................6
8. Soap Dispenser and Water Temperature NTC............................................................................... 7
9. Door Spring Adjustment and Door Latch........................................................................................7
10. Kick Plate ....................................................................................................................................... 8
11. Door Extension............................................................................................................................... 9
12. Water Valve.................................................................................................................................. 10
13. Float Switch and Pressure Switch................................................................................................ 11
14. Lower Component Access - Base Pane Removal........................................................................ 12
15. Lower Components...................................................................................................................... 13
16. Drain Motor................................................................................................................................... 14
17. Main Motor and Pump.................................................................................................................. 15
18. Heater Assembly.......................................................................................................................... 17
19. Turbidity Sensor (LI 670 / LI 700 Models Only)............................................................................................ 18
20. Water Softener............................................................................................................................. 19
TABLE OF CONTENTS
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
REPAIR MANUAL
Page: iii
Page
21. High Pressure Switch................................................................................................................... 20
22. Fan Motor (LL 65 / LI 700 Models Only) ...................................................................................................... 20
23. Water Inlet and Turbine................................................................................................................ 21
24. Fault Codes.................................................................................................................................. 22
25. Schematics................................................................................................................................... 23
TABLE OF CONTENTS Cont.
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
REPAIR MANUAL
Page: iv
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
This Dishwasher Repair Manual uses the LI 700 S model for all repair instructions and demonstrations. The
technical similarities between the LI 700 S and the other LI , L and LL models will allow the repair techniques
described and demonstrated to be applied without difficulty to the other models not shown.
LI 700 S LL 64 S
REPAIR MANUAL
Page: 1
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
1. MODEL and SERIAL NUMBER LOCATION
• The Model and Serial Number Tag is located on the right side of the Inner Door Panel (Fig. 1-1). The Model shown is a LI 700 S
with a Serial Number of 407292454 (Fig. 1-2).
Note: Numbers located to the left of the nine (9) digit Serial Number are not required on the Warranty Claim Form.
Fig. 1-1
Fig. 1-2
REPAIR MANUAL
Page: 2
3. UPPER SPRAYARM
• To remove the Upper Spray Arm (Fig. 3-1) gently grasp the Locking Ring with a Channel Locks and turn Counter-Clockwise
(Fig. 3-2); note the Tab and Slot locking configuration (Fig. 3-3).
TECH NOTE: When Replacing the Spray Arm make sure that it is tightened completely onto the Locking Ring.
Fig. 3-1 Fig. 3-2 Fig. 3-3
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
2. RACK ROLLERS - Upper & Lower
• The Lower Rack Roller Assemblies are held in place using three (3) tension clips (Fig 2-4). Grasping the Roller Assembly and
applying downward force will disengage the Roller Assembly from the Rack.
Fig. 2-1 Fig. 2-2 Fig. 2-3
• The Upper Rack can be removed by releasing the Rail Clip and sliding the
Rack out from the Rail (Fig. 2-1). If the Upper Rack Roller Assembly must be
replaced (Fig 4-2) first remove the Side Panel (see Section 22) and then
remove the four (4) 8mm bolts that mount the Roller Assembly to the Tank.
• Once the Upper Rack has been removed, the Rack Roller Wheels can be
replaced by gently prying the Hub Clips inward with a small screwdriver and
then moving the Roller Wheel out and off the Hub (Fig. 2-3).
Fig. 4-4
REPAIR MANUAL
Page: 3
4. LOWER SPRAYARM
• To remove the Lower Spray Arm (Fig. 4-1) hold the Spray Arm Locking Ring with a Channel Locks and then turn the Spray Arm
Clockwise (Fig. 4-2). The Locking Ring Assembly can also be removed by rotating it Counter-Clockwise; note the Tab and Slot
locking configuration (Fig. 4-3).
TECH NOTE: When Replacing the Spray Arm make sure that it is tightened completely onto the Locking Ring.
Fig. 4-3
Fig. 4-1
Fig. 4-2
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
REPAIR MANUAL
Page: 4
5. OUTER DOOR PANEL
Fig. 5-2
Fig. 5-1
B
B B
A A
• The Outer Door is held in place using four (4) Phillips screws (Fig. 5-1). Screw “A” is a
single screw located on the bottom left and right corners of the Inner Door Panel. Screw
“B” is just below the Phillips screw that holds the Outer Door Skin (Fig. 5-2).
• With the four (4) screws removed raise the Door to an upright position and then slide
the Outer Door Panel down and out from the Alignment Channel (Fig. 5-3).
• When replacing the Outer Door insert the Alignment Pin into the Channel and then raise
the Door Panel up until it is even with the top of the Control Panel (Fig. 5-4).
TECH NOTE: To prevent damage to the Outer Door, Alignment Pins, or Channel, make
sure to support the weight of the Door as you remove or replace it.
Fig. 5-3
Fig. 5-4
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
REPAIR MANUAL
Page: 5
6. CONTROL PANEL
Fig. 6-1
Fig. 6-2
Fig. 6-3
• To remove the Control Panel (Fig. 6-1), remove the six (6) Phillips Control Panel screws from the Inner Door Panel (Fig 6-2). With
the screws removed the Control Panel will lay forward and is now accessible for repair (Fig. 6-3).
TECH NOTE: The Outer Door must be removed first (see Section 5) before removing the Control Panel Screws.
L 63 / LL 64 / LL 65
LI 640 / LI 670 / LI 700
