ART+SOUND CLMN8 Bedienungsanleitung

CLMN8

OPERATIONS

MANUAL

WARRANTY CONDITIONS

2 years of warranty from the manufacturing date.

The warranty is limited to repair or exchange of the

defective material insofar this is a consequence of

normal use and the device has not been damaged.

ArtSound is not responsible for any other costs

deriving from the defect (e.g. transport). For any

details, we refer to the general conditions of sale.

TECHNICAL SPECIFICATIONS

• range : <60m2

• 2-way/broadband system 8+1

• driver, neodymium-magnet :

2” polypropylene cone

• tweeter, neodymium-magnet : 1” soft dome

• magnetic shielded

• max. power (100V) : 6 -15-30 W

• max. power (8Ω) : 40-180 W

• sensibility : 91dB

• frequency range : 120Hz - 20kHz

• dimensions (h x w x d) : 578 x 70 x 75mm

• weight / piece : 2.23 kg

• housing : aluminium

• black / white

• suspension : multi-directional bracket

Dear customer, thank you and congratulations on

the purchase of your speakers(s). If you read the

following instructions and keep them, you will be

able to enjoy them for a long time!

SAFETY INSTRUCTIONS

• A CLMN8 cannot swim. Please keep it away

from water and all types of moisture.

• Ensure that your ampliﬁer is disconnected while

connecting your speaker(s).

• Power cables and audio cables had best be

kept away from the speaker cables as much as

possible.

• Ensure that your ampliﬁer is disconnected while

connecting your speaker(s).

• Ensure that the total capacity of all speakers is

lower than that of the amp.

• Assemble the CLMN8 only using the included

bracket and ﬁtting screws.

• People only have one set of ears, treat them

carefully. Prolonged exposure to a high volume

may cause damage.

• When in doubt about the positioning or the use

of the speakers, ask help from an audio expert

in advance.

3 x

4 x

INSTALLATION

34 mm

50 mm

92 mm

6 mm

1 2

B B

1- Deduplicate the bracket. 2- Assemble part A of the bracket to the wall by

use of screws.

3- Assemble part B of the bracket to the speaker

4- Connect the speaker cable [+/-] via the

connecting terminal and select the desired

capacity (in a 100 V environment or 8 Ohm in

case of residential use).

ROOD

ROUGE

RED

ZWART

NOIR

BLACK

30W

15W

8Ω

Kwww.artsound.be

EArtsound.audio

Qartsoundaudio

House of Music nv

Ronse, Belgium

¼+32 9 380 81 80

º [email protected]

7- Extended speaker position

Untighten both screws, position the speaker

and ﬁxate it.

5- Turn speaker to left or right

Untighten the screw at the bottom, turn the

speaker and ﬁxate it.

6- Aligning the speaker vertically

Untighten the screw, direct the speaker and

ﬁxate it.

56C

YOU ARE ABOUT TO ENJOY IT!
