ASRock Industrial NUC-1335UE/D4 Bedienungsanleitung

NUC-1360P/D4

NUC-1340P/D4

NUC-1365UE/D4

NUC-1335UE/D4

NUC-1315UE/D4

NUC-1315U/D4

User Manual

Version 1.2

Updated April 19, 2023

Version 1.0

Published December 30, 2022

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRockInd Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRockInd. ASRockInd assumes no responsibility

for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRockInd does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRockInd, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRockInd has been advised of the possibility of such damages arising

from any defect or error in the documentation or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in

California, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/

hazardouswaste/perchlorate”

ASRockInd Website: http://www.asrockind.com

e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

CAUTION:

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 4

1.4 I/O Panel 5

1.5 Block Diagram 6

Chapter 2 Installation 7

2.1 Screw Holes 7

2.2 Pre-installation Precautions 7

2.3 Installation of Memory Modules 8

2.4 Expansion Slots 9

2.5 Onboard Headers and Connectors 10

2.6 Installation of ROM Socket 13

Chapter 3 UEFI SETUP UTILITY 14

3.1 Introduction 14

3.1.1 Entering BIOS Setup 14

3.1.2 UEFI Menu Bar 15

3.1.3 Navigation Keys 16

3.2 Main Screen (Advanced Mode) 17

3.3 Advanced Screen 18

3.3.1 CPU Conguration 19

3.3.2 Chipset Conguration 22

3.3.3 Storage Conguration 24

3.3.4 Super IO Conguration 26

3.3.5 AMT Conguration 27

3.3.6 ACPI Conguration 29

3.3.7 USB Conguration 30

3.3.8 Trusted Computing 31

3.4 Hardware Health Event Monitoring Screen 33

3.5 Security Screen 34

3.6 Boot Screen 35

3.7 Exit Screen 37

NUC 1300/D4 Series

Chapter 1 Introduction

Thank you for purchasing ASRockInd NUC-1360P/D4 / NUC-1340P/D4 / NUC-

1365UE/D4 / NUC-1335UE/D4 / NUC-1315UE/D4 / NUC-1315U/D4 motherboard,

a reliable motherboard produced under ASRockInd’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to ASRock-

Ind’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-

step guide to the hardware installation. Chapter 3 contains the conguration guide to

BIOS setup.

Because the motherboard specications and the BIOS soware might be updated, the

content of this manual will be subject to change without notice. In case any modica-

tions of this manual occur, the updated version will be available on ASRockInd website

without further notice. You may nd the latest CPU support lists on ASRockIndind

website as well.

ASRockIndind website https://www.asrockind.com/

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

https://www.asrockind.com/support/index.asp

1.1 Package Contents

ASRockInd NUC-1360P/D4 / NUC-1340P/D4 / NUC-1365UE/D4 / NUC-1335UE/

D4 / NUC-1315UE/D4 / NUC-1315U/D4 Motherboard (NUC (4.09-in x 4.02-in x

1.5-in, 10.4 cm x 10.2 cm x 3.8 cm)

1.2 Specications

Form

Factor Dimensions NUC (4.09-in x 4.02-in x 1.5-in, 10.4 cm x 10.2 cm x 3.8

cm)

Processor

System

CPU

Intel® 13th Gen (Raptor Lake-P) Core™ Processors

NUC-1360P/D4 (i7-1360P, 4P+8E)

NUC-1340P/D4 (i5-1340P, 4P+8E)

NUC-1365UE/D4 (i7-1365UE, 2P+8E)

NUC-1335UE/D4 (i5-1335UE, 2P+8E)

NUC-1315UE/D4 (i3-1315UE, 2P+4E)

NUC-1315U/D4 (i3-1315U, 2P+4E)

Chipset MCP

BIOS AMI SPI 256 Mbit

Expansion

Slot M.2 1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0 and CNVi

for Wireless

Memory

Technology Dual Channel DDR4 3200 MHz

Capacity 64GB (32 GB per DIMM)

Socket 2 x 260-pin SO-DIMM

Graphics

Controller Intel® Iris® Xe Graphics for i7/i5 CPU

Intel® UHD Graphics for i3 CPU

HDMI HDMI 2.0b

Max resolution up to 4096x2160@60Hz

DisplayPort DisplayPort 1.4a, DP++

Max resolution up to 4096x2160@60Hz

Multi

Display Max 4 display (Included 2 outputs from Type-C)

Audio Interface Realtek ALC233/ALC256, High Denition Audio

Ethernet

Controller/

Speed

NUC-1365UE/D4, NUC-1335UE/D4, NUC-1360P/D4,

NUC-1340P/D4:

Intel® I226LM with 10/100/1000/2500 Mbps, supports

vPro

NUC-1315U(E)/D4:

Intel® I226LM with 10/100/1000/2500 Mbps

Controller 2 x RJ-45

Rear I/O

HDMI 1 x HDMI 2.0b

DisplayPort 1 x DP 1.4a

Ethernet 2 x 2.5 Gigabit LAN

USB 2 x USB 3.2 Gen2 (Type A)

DC Jack 1

NUC 1300/D4 Series

Front I/O USB

2 x USB 3.2 Gen2 (Type A)

1 x USB4/underbolt™4 (5V/3A, supports

DP1.4a display output)

*For underbolt support, please refer to

support list.

1 x USB 3.2 Gen2 (Type-C, 5V/3A, supports

DP1.4a display output)

Audio 1 (headphone & microphone jack)

Internal

Connector

USB 2 x USB 2.0 (1 x 2.00 pitch header)

COM 1 x COM(RS-232/RS-422/RS-485)

TPM TPM 2.0 onboard IC

Storage M.2

1 x M.2 (KEY M, 2242/2260/2280) with PCIe

Gen4 x4 for SSD

*M.2 Key M 2280(Supported by bracket)

SATA 1 x SATA3.0 (6.0 Gb/s)

Watchdog

Timer

Output From Super I/O to drag RESETCON#

Interval 256 Segments, 0, 1, 2, ...255 Sec

Power

Requirements

Input PWR 12V~19V DC-In Jack

Power On

AT/ATX Supported

- AT : Directly PWR on as power input ready

- ATX : Press button to PWR on aer power

input ready

Environment

Operating

Temp -20ºC ~ 70ºC

Storage Temp -40ºC ~ 85ºC

Operating

Humidity 5% ~ 90%

Storage

Humidity 5% ~ 90%

1.3 Motherboard Layout

AUDIO1

DC_JACK1

SATA3_0

Industrial

LAN1

COM1

HDLED

PLED PWRBTN

PANEL1

DDR4_B1 (Support DDR4 Only)

DDR4_A1 (Support DDR4 Only)

USB2_7_8

LAN2

BIOS

ROM

RESET

HDMI_DP_1:

Bottom: HDMI

Top: DP

USB3_1_2

(USB3.2 Gen2):

Bottom: USB3_1

Top: USB3_2

USB3_3_4

(USB3.2 Gen2):

Bottom: USB3_3

Top: USB3_4

TC_UD1 (Type C):

USB3/DP

JP1

M2_E1

M.2 SSD (M2_M1)

75 74

2 1

74 75

TC_T0(Ty pe C):

USB4 /

Thunderbolt 4

1 :

M.2 Key-M Socket (M2_M1)

2 :

M.2 Key-E Socket (M2_E1)

3 : USB 2.0 Connector (USB2_7_8)

4 : COM Port Header (COM1)(RS-232/422/485)

5 : SATA3 Connectors (SATA3_0)

6 : JP1

7 : System Panel Header (PANEL1)

Back Side :

Power Button (PWR_BTN1)

Fan Connector (FAN1)

Battery Connector (BAT1)

ESPI Connector (ESPI)

NUC 1300/D4 Series

1.4 I/O Panel

1 USB3/DP Type-C Port (TC_UD1)

2 USB 3.2 Gen2 Ports (USB3_3_4)

3 USB4/underbolt™4 Type-C Port

(TC_T0)

4 Audio Jack (AUDIO1)

5 RJ-45 LAN Port (LAN1)*

6 RJ-45 LAN Port (LAN2)*

7 HDMI Port (HDMI1)

8 DisplayPort (DP1)

9 USB 3.2 Gen2 Ports (USB3_1_2)

10 DC-in Jack (DC_IN1)

Front I/O :

Rear I/O :

ACT/LINK

LED

SPEED

LED

LAN1 Port

SPEED LED

Status Description

O 10Mbps connection

Orange 100Mbps/1Gbps connection

Green 2.5Gbps connection

Activity/Link LED

Status Description

O No Link

Blinking Data Activity

On Link

* ere are two LED on the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN1 Port LED Indications
