GENOAD8UD-2T

GENOAD8UD-2T/X550

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack GENOAD8UD-2T / GENOAD8UD-2T/X550

motherboard, a reliable motherboard produced under ASRock Rack’s consistently stringent

quality control. It delivers excellent performance with robust design conforming to ASRock

Rack’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-by-step

guide to the hardware installation. Chapter 3 and 4 contains the conguration guide to BIOS

setup and information of the Sofware Support.

1.1 Package Contents

• ASRock Rack GENOAD8UD-2T/GENOAD8UD-2T/X550 Motherboard

(Deep Micro-ATX Form Factor: 10.4-in x 10.5-in)

• Quick Installation Guide

• 1 x MCIO X8 to 8 SATA +8P Cable (63cm)

• 1 x ATX 4P to 24P Power Cable (8cm)

• 2 x Screws for M.2 Sockets

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

2 3

English

1.2 Specications

GENOAD8UD-2T / GENOAD8UD-2T/X550

MB Physical Status

Form Factor Deep Micro-ATX

Dimension 10.4" x 10.5" (264.16 x 266.7 mm)

Processor System

CPU Supports AMD EPYC GENOA processors

Socket 1 Socket SP5 (LGA 6096)

ermal Design

Power (TDP)

400W

Chipset System on Chip

System Memory

Supported DIMM

Quantity

8 DIMM slots (1DPC)

Supported Type Supports DDR5 288-pin RDIMM, RDIMM-3DS

Max. Capacity per

DIMM

RDIMM: 64GB (2R)

RDIMM-3DS: 512GB (2S8Rx4)

Max. Frequency 4800MHz

Voltage 1.1V

Note Memory capacity, frequency, and voltage support is to be validated

Expansion Slot

Slot 6 PCIe5.0 x16

Slot 5 PCIe5.0 x16

Slot 4 PCIe5.0 x16

Slot 3 PCIe5.0 x16

Other PCIe Expansion Connectors

M.2 2 M-key (PCIe5.0 x4); support 2280/2260/2242/2230 form

factor

MCIO 2 MCIO (PCIe5.0 x8)

2 MCIO (PCIe5.0 x8 or 8 SATA 6Gb/s)

1 MCIO (PCIe5.0 x4)

Storage

CPU Built-in Storage AMD EPYC GENOA (16 SATA 6Gb/s):

2 MCIO

Ethernet

Additional Ethernet

Controller

GENOAD8UD-2T:

Intel® X710-AT2: 2 RJ45 (10GbE)

GENOAD8UD-2T/X550:

Intel® X550-AT2: 2 RJ45 (10GbE)

USB

Controller/Hub AMD EPYC GENOA

GENOAD8UD-2T

GENOAD8UD-2T/X550

2 3

English

Connectors/Headers External:

2 Type-A (USB3.2 Gen1)

Internal:

1 header (19-pin, 2 USB3.2 Gen1)

Graphics

Controller ASPEED AST2600

VRAM DDR4 512MB

Security

TPM 1 (13-pin, SPI)

Rear Panel I/O

UID Button/LED 1 UID button w/ LED

VGA Port 1 DB15 (VGA)

USB 2 Type-A (USB3.2 Gen1)

RJ45 2 RJ45 (10GbE), 1 dedicated IPMI

Hardware Monitor

Temperature CPU, MB, TR1 Temperature sensing

Fan CPU/Rear/Front Fan Tachomete

CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

CPU/Rear/Front Fan Multi-Speed Control

Voltage VCORE, VCCSA, VCCM, 3V, 5V, 12V, +BAT, 3VSB, 5VSB,

VCCIO, +2.5V_VPP

Server Management

BMC Controller ASPEED AST2600

IPMI Dedicated

GLAN

1 Realtek RTL8211F for dedicated management GLAN

System BIOS

Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM

Features ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance

wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)

Other Internal Connectors/Headers

PSU connector 1 (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 3 (8-

pin, ATX 12V) support 12V DC-in

Other Power

Connector

1 (6-pin) for HDD power

Auxiliary Panel

Header

1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2

activity LED, locate, SMBus

System Panel 1 (9-pin): power switch, reset switch, system power LED,

HDD activity LED

NMI Header 1

COM Header 1

Speaker Header 1 (4-pin)

Fan Header 6 (6-pin)

ermal Sensor

Header

4 5

English

TPM Header 1 (13-pin, SPI)

SGPIO Header 2

HSBP 1

SMbus Header 1

PMbus Header 1

IPMB Header 1

Clear CMOS 1 (contact pads)

LED Indicators

Standby Power LED 1 (5VSB)

Fan Fail LED 6

BMC Heartbeat LED 1

Support OS

OS Microso® Windows®:

- Server 2016 (64bit)

- Server 2019 (64bit)

- Server 2022 (64 bit)

Linux®:

- RedHat Enterprise Linux Server 8.3 (64 bit) / 8.4 (64 bit)

- CentOs 8.3 (64 bit) / 8.4 (64 bit)

- SUSE SLES 15.2 (64 bit) / 12.5 (64 bit)

- UBuntu 21.04 (64 bit) / 20.04.3 (64 bit) / 18.04.5 (64 bit)

Hypervisor:

- VMWare® ESXi 6.7.0 u3 / vSphere 6.7.0 u3

- VMWare® ESXi 7.0 U1 / vSphere 7.0 U1

- VMWare® ESXi 7.0 U2a / vSphere 7.0 U2b

- CITRIX Hypervisor 8.2.0

*Please refer to our website for the latest OS support list.

Environment

Temperature Operation temperature: 10°C ~ 35°C (50 - 95 degF) / Non

operation temperature: -40°C ~ 70°C (-40 - 158degF)

Humidity Non operation humidity: 20% ~ 90% ( Non condensing)

is motherboard supports Wake from on Board LAN. To use this function, please make

sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager

> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is

enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard

LAN1&2 can wake up S5 under OS.

If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-

dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it

will pass the WHQL tests.

NOTE: Please refer to our website for the latest specications.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ASROCK Rack Hauptplatine Handbücher

ASROCK Rack

ASROCK Rack ALTRAD8UD-1L Bedienungsanleitung

ASROCK Rack

ASROCK Rack X570D4U-2L2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack ROME2D16-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack EPYC3451D4I2-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack EP2C612D16NM Bedienungsanleitung

ASROCK Rack

ASROCK Rack C422 WSI/IPMI Bedienungsanleitung

ASROCK Rack

ASROCK Rack C2550D4I Bedienungsanleitung

ASROCK Rack

ASROCK Rack E3C236D4HM-2L+ Bedienungsanleitung

ASROCK Rack

ASROCK Rack X570D4U Bedienungsanleitung

ASROCK Rack

ASROCK Rack 1U2S-B650 Bedienungsanleitung

ASROCK Rack

ASROCK Rack E3C256D4U-2L2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack E3C246D4I-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack SP2C621D16-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack EP2C612D16HM Bedienungsanleitung

ASROCK Rack

ASROCK Rack EPC612D4I Bedienungsanleitung

ASROCK Rack

ASROCK Rack E3C256D4ID-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack EP2C621D16HM-AB Bedienungsanleitung

ASROCK Rack

ASROCK Rack SPC741D8M3-2T/X550 Bedienungsanleitung

ASROCK Rack

ASROCK Rack X570D4I-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack C236 WSI Bedienungsanleitung

ASROCK Rack

ASROCK Rack EPYC3251D4I-2T Bedienungsanleitung

ASROCK Rack

ASROCK Rack C236 WS Bedienungsanleitung

ASROCK Rack

ASROCK Rack EP2C621D12 WS Bedienungsanleitung

ASROCK Rack

ASROCK Rack WC422D8A-2T Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
