ASROCK A620M-HDVP Bedienungsanleitung

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re

welcome to visit ASRock’s website at http://www.asrock.com; or you may contact

your dealer for further information. For technical questions, please submit a

support request form at https://event.asrock.com/tsd.asp

ASRock Incorporation

e-mail: info@asrock.com.tw

ASRock EUROPE B.V.

e-mail: sa[email protected]

ASRock America, Inc.

e-mail: sa[email protected]

Scan the QR code to view more manuals and documents.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 5

1.4 I/O Panel 7

1.5 Block Diagram 8

Chapter 2 Installation 9

2.1 Installing the CPU 10

2.2 Installing the CPU Fan and Heatsink 13

2.3 Installing Memory Modules (DIMM) 21

2.4 Connecting the Front Panel Header 23

2.5 Installing the I/O Panel Shield 24

2.6 Installing the Motherboard 25

2.7 Installing SATA Drives 26

2.8 Installing a Graphics Card 28

2.9 Connecting Peripheral Devices 30

2.10 Connecting the Power Connectors 31

2.11 Power On 32

2.12 Jumpers Setup 33

2.13 Onboard Headers and Connectors 34

2.14 M.2 SSD Module Installation Guide (M2_1 and M2_2) 42

English

A620M-HDVP

Chapter 1 Introduction

ank you for purchasing ASRock A620M-HDVP motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

• ASRock A620M-HDVP Motherboard (Micro ATX Form Factor)

• ASRock A620M-HDVP User Manual

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

CPU • Supports AMD Socket AM5 RyzenTM 8000 and 7000 Series

Processors*

* Please refer to CPU Support List on ASRock's website for more

information. (http://www.asrock.com/)

Chipset • AMD A620

Memory • Dual Channel DDR5 Memory Technology

• 2 x DDR5 DIMM Slots

• Supports DDR5 ECC/non-ECC, un-buered memory up to

7200+(OC)*

• Max. capacity of system memory: 96GB

• Supports Extreme Memory Prole (XMP) and EXTended

Proles for Overclocking (EXPO) memory modules

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

Expansion

Slot

CPU:

• 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*

Chipset:

• 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)*

• 1 x PCI Slot

* Supports NVMe SSD as boot disks

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Graphics • Integrated AMD RDNATM graphics (Actual support may

vary by CPU)

• 1 x HDMI 2.0 TMDS/FRL 6G Compatible, supports HDR,

HDCP 2.3 and max. resolution up to 4K 60Hz

• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP

2.3 and max. resolution up to 4K 120Hz

• 1 x DVI-D, supports max. resolution up to Full HD

(1920x1200) 60Hz

• 1 x D-Sub, supports max. resolution up to Full HD

(1920x1080) 60Hz

English

A620M-HDVP

Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)

LAN • Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111H

USB CPU:

• 4 x USB 3.2 Gen1 Type-A (Rear)

Chipset:

• 1 x USB 3.2 Gen2 Type-C (Rear)

• 1 x USB 3.2 Gen2 Type-A (Rear)

• 2 x USB 3.2 Gen1 Type-A (Front)

• 4 x USB 2.0 (Front)

* All USB ports support ESD Protection

Rear Panel

I/O

• 1 x PS/2 Mouse Port

• 1 x PS/2 Keyboard Port

• 1 x Serial Port: COM2

• 1 x D-Sub Port

• 1 x DVI-D Port

• 1 x HDMI Port

• 1 x DisplayPort 1.4

• 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)

• 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)

• 4 x USB 3.2 Gen1 Type-A Ports

• 1 x RJ-45 LAN Port

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage CPU:

• 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280

PCIe Gen4x4 (64 Gb/s) mode*

• 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280

PCIe Gen4x4 (64 Gb/s) mode*

Chipset:

• 4 x SATA3 6.0 Gb/s Connectors

* Supports NVMe SSD as boot disks

English

RAID • Supports RAID 0, RAID 1 and RAID 10 for SATA storage

devices

• Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe

storage devices*

* Requires additional M.2 NVMe expansion cards to support

RAID 10

Connector • 1 x Print Port Header

• 1 x SPI TPM Header

• 1 x COM Port Header

• 1 x Chassis Intrusion and Speaker Header

• 1 x CPU Fan Connector (4-pin)*

• 1 x Chassis Fan Connector (4-pin)**

• 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan

Speed Control)***

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

* CPU_FAN1 supports the fan power up to 1A (12W).

** CHA_FAN2 supports the fan power up to 1A (12W).

*** CHA_FAN1/WP support the fan power up to 2A (24W).

*** CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in

use.

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

OS • Microso® Windows® 10 64-bit / 11 64-bit

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may aect your system’s stability, or

even cause damage to the components and devices of your system. It should be done

at your own risk and expense. We are not responsible for possible damage caused by

overclocking.

* For detailed product information, please visit our website: http://www.asrock.com

English

A620M-HDVP

1.3 Motherboard Layout

ATXPWR1

PCIE1

USB 3.2 Gen2

T: USB32_5

B: USB32_TC1

HDLED RESET

PLED PWRBTN

CPU_FAN1

ATX12V1

Top:

RJ-45

AMD

A620

DDR5_B1 (64 bit, 288-pin module)

DDR5_A1 (64 bit, 288-pin module)

CMOS

Battery

AUDIO

CODEC

M2_1

Top:

LINE IN

Center:

FRONT

Bottom:

MIC IN

DP1

PCIE2

CHA_FAN1/WP

CHA_FAN2

14 1316

PCIE3

A620M-HDVP

SATA3_3

SATA3_2

SATA3_1

SATA3_0

PCI1

M2_2

P 2

Mouse

COM2

VGA1

DVI1

USB 3.2 Gen1:

USB32_1

USB32_2

USB32_3

USB32_4

HDMI1

SUPER

I/O

USB32_6_7

PANEL1

SPK_CI1

CLRCMOS1

USB_3_4

USB_1_2

COM1

HD_AUDIO1

SPI_TPM_J1

BIOS

ROM

LPT1

P 2

Keyboard

LAN

Chip

RoHS

English

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 CPU Fan Connector (CPU_FAN1)

3 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)

4 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)

5 ATX Power Connector (ATXPWR1)

6USB 3.2 Gen1 Header (USB32_6_7)

7 SPI TPM Header (SPI_TPM_J1)

8SATA3 Connector (SATA3_2)

9SATA3 Connector (SATA3_3)

10 SATA3 Connector (SATA3_0)

11 SATA3 Connector (SATA3_1)

12 System Panel Header (PANEL1)

13 Clear CMOS Jumper (CLRCMOS1)

14 Chassis Intrusion and Speaker Header (SPK_CI1)

15 USB 2.0 Header (USB_3_4)

16 USB 2.0 Header (USB_1_2)

17 Chassis Fan Connector (CHA_FAN2)

18 Print Port Header (LPT1)

19 COM Port Header (COM1)

20 Front Panel Audio Header (HD_AUDIO1)
