ASROCK FM2A75 Pro4 Bedienungsanleitung

FM2A75 Pro4

User Manual

Version 1.0

Published August 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction ................................................................ 5

1.1 Package Contents ..................................................................... 5

1.2 Specications ............................................................................. 6

1.3 Unique Features ........................................................................ 10

1.4 Motherboard Layout ................................................................. 14

1.5 I/O Panel .................................................................................. 15

2. Installation .................................................................. 17

Pre-installation Precautions ................................................................ 17

2.1 CPU Installation ......................................................................... 18

2.2 Installation of CPU Fan and Heatsink ...................................... 18

2.3 Installation of Memory Modules (DIMM) .................................... 19

2.4 Expansion Slots (PCI and PCI Express Slots) ........................... 21

2.5 CrossFireXTM and Quad CrossFireXTM Operation Guide ............ 22

2.6 Dual Graphics Operation Guide ................................................ 26

2.7 Dual Monitor and Surround Display Features ........................... 28

2.8 ASRock Smart Remote Installation Guide ................................. 31

2.9 Jumpers Setup ........................................................................... 33

2.10 Onboard Headers and Connectors ....................................... 34

2.11 Smart Switches .......................................................................... 39

2.12 Dr. Debug .............................................................................. 40

2.13 Serial ATA3 (SATA3) Hard Disks Installation ......................... 44

2.14 Hot Plug and Hot Swap Functions for SATA3 HDDs ................. 44

2.15 SATA3 HDD Hot Plug and Hot SwapFeature and Operation

Operation Guide ........................................................................ 45

2.16 Driver Installation Guide ............................................................ 47

2.17 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

With RAID Functions ................................................................. 47

2.18 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

Without RAID Functions ............................................................ 48

3. UEFI SETUP UTILITY .................................................. 49

3.1 Introduction ................................................................................ 49

3.1.1 UEFI Menu Bar ................................................................ 49

3.1.2 Navigation Keys ............................................................... 50

3.2 Main Screen ............................................................................... 50

3.3 OC Tweaker Screen................................................................... 51

3.4 Advanced Screen ...................................................................... 55

3.4.1 CPU Conguration ........................................................... 56

3.4.2 North Bridge Conguration .............................................. 57

3.4.3 South Bridge Conguration ............................................. 58

3.4.4 Storage Conguration ...................................................... 59

3.4.5 Super IO Conguration .................................................... 60

3.4.6 ACPI Conguration .......................................................... 61

3.4.7 USB Conguration ........................................................... 63

3.4.8 Network Conguration ..................................................... 64

3.5 Tool ............................................................................................ 65

3.6 Hardware Health Event Monitoring Screen ............................... 67

3.7 Boot Screen ............................................................................... 69

3.8 Security Screen ......................................................................... 71

3.9 Exit Screen ................................................................................ 73

4. Software Support ....................................................... 74

4.1 Install Operating System ............................................................ 74

4.2 Support CD Information ............................................................. 74

4.2.1 Running Support CD ....................................................... 74

4.2.2 Drivers Menu ................................................................... 74

4.2.3 Utilities Menu ................................................................... 74

4.2.4 Contact Information ......................................................... 74

1. Introduction

Thank you for purchasing ASRock FM2A75 Pro4 motherboard, a reliable mother-

board produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modications of this manual occur, the updated ver-

sion will be available on ASRock website without further notice. You may

nd the latest VGA cards and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock FM2A75 Pro4 Motherboard

(ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm)

ASRock FM2A75 Pro4 Quick Installation Guide

ASRock FM2A75 Pro4 Support CD

4 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode.

1.2 Specications

Platform - ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm

- All Solid Capacitor design

CPU - Support for Socket FM2 100W processors

- 4 + 2 Power Phase Design

- Supports AMD’s Cool ‘n’ QuietTM Technology

- UMI-Link GEN2

Chipset - AMD A75 FCH (Hudson-D3)

Memory - Dual Channel DDR3 Memory Technology

- 4 x DDR3 DIMM slots

- Support DDR3 2600+(OC)/2400(OC)/2133(OC)/1866/1600/

1333/1066/800 non-ECC, un-buffered memory

(see CAUTION 1)

* 2600+ is only supported with two DIMMs

- Max. capacity of system memory: 64GB (see CAUTION 2)

- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2

- Supports AMD Memory Prole (AMP)

Expansion Slot - 2 x PCI Express 2.0 x16 slots

(PCIE2 @ x16 mode; PCIE4 @ x4 mode)

- 2 x PCI Express 2.0 x1 slots

- 3 x PCI slots

- Supports AMD Quad CrossFireXTM, CrossFireXTM and Dual

Graphics

Graphics - AMD Radeon HD 7000 graphics

- DirectX 11, Pixel Shader 5.0

- Max. shared memory 2GB

- Three VGA Output options: D-Sub, DVI-D and HDMI

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports Dual-link DVI with max. resolution up to

2560x1600 @ 75Hz

- Supports D-Sub with max. resolution up to 1920x1600 @

60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required) (see CAUTION 3)

- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a

- Supports AMD Steady VideoTM: New video post processing

capability for automatic jutter reduction on home/online

video

- Supports HDCP function with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI and HDMI ports

Audio - 7.1 CH HD Audio with Content Protection

(Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

- Supports THX TruStudioTM

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse/Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 1 x Optical SPDIF Out Port

- 2 x Ready-to-Use USB 2.0 Ports

- 1 x eSATA3 Connector

- 6 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone

SATA3 - 5 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and “Hot Plug” functions

USB 3.0 - 2 x Rear USB 3.0 ports by AMD A75 FCH (Hudson-D3),

support USB 1.1/2.0/3.0 up to 5Gb/s

- 4 x Rear USB 3.0 ports by Etron EJ188, support

USB 1.1/2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by

AMD A75 FCH (Hudson-D3), supports USB 1.1/2.0/3.0 up

to 5Gb/s

Connector - 5 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)

- 3 x Chassis Fan connectors (1 x 4-pin, 2 x 3-pin)

- 1 x Power Fan connector (3-pin)

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

- 1 x Dr. Debug (7-Segment Debug LED)

- 1 x Power Switch with LED

- 1 x Reset Switch with LED

- 1 x Clear CMOS Switch with LED

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, VDDP, VDDR, SB Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

compliant

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

overclocking.

CAUTION!

1. Whether 2600/2400/2133/1866/1600MHz memory speed is

supported depends on the CPU you adopt. If you want to adopt

DDR3 2600/2400/2133/1866/1600 memory module on this

motherboard, please refer to the memory support list on our

website for the compatible memory modules.

ASRock website http://www.asrock.com

2. Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage

under Windows® 7 / VistaTM. For Windows® 64-bit OS with 64-

bit CPU, there is no such limitation. You can use ASRock XFast

RAM to utilize the memory that Windows® cannot use.

3. xvYCC and Deep Color are only supported under Windows® 7

64-bit / 7. Deep Color mode will be enabled only if the display

supports 12bpc in EDID. HBR is supported under Windows® 7

64-bit / 7 / VistaTM 64-bit / VistaTM.

1.3 Unique Features

ASRock Extreme Tuning Utility (AXTU)

ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to

ne-tune different system functions in a user-friendly interface,

which includes Hardware Monitor, Fan Control, Overclocking,

OC DNA, IES and XFast RAM. In Hardware Monitor, it shows

the major readings of your system. In Fan Control, it shows the

fan speed and temperature for you to adjust. In Overclocking,

you are allowed to overclock CPU frequency for optimal system

performance. In OC DNA, you can save your OC settings as

a prole and share it with your friends. Your friends then can

load the OC prole to their own system to get the same OC set-

tings. In IES (Intelligent Energy Saver), the voltage regulator

can reduce the number of output phases to improve efciency

when the CPU cores are idle without sacricing computing per-

formance. In XFast RAM, it fully utilizes the memory space that

cannot be used under Windows® OS 32-bit CPU.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more efcient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows®

to shorten boot up time. By calling S3 and S4 at specic timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows® desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems rst like MS-

DOS or Windows®. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS le to your USB ash drive, oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional oppy diskette or other compli-

cated ash utility. Please be noted that the USB ash drive or

hard drive must use FAT32/16/12 le system.

Andere Handbücher für FM2A75 Pro4

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK P75 Pro3 Bedienungsanleitung

ASROCK

ASROCK IMB-158 Bedienungsanleitung

ASROCK

ASROCK B660M-ITX/eDP Bedienungsanleitung

ASROCK

ASROCK Z77M Bedienungsanleitung

ASROCK

ASROCK H91M-XT PLUS Bedienungsanleitung

ASROCK

ASROCK B550M Steel Legend Bedienungsanleitung

ASROCK

ASROCK CONROE1333-GLAN - V1.0 Bedienungsanleitung

ASROCK

ASROCK A75 Extreme6 Bedienungsanleitung

ASROCK

ASROCK B450 Steel Legend Bedienungsanleitung

ASROCK

ASROCK 775Twins-HDTV Bedienungsanleitung

ASROCK

ASROCK B85M-ITX Bedienungsanleitung

ASROCK

ASROCK IMB-A1301 Service-Handbuch

ASROCK

ASROCK PE PRO Bedienungsanleitung

ASROCK

ASROCK FM2A68M-HD+ Bedienungsanleitung

ASROCK

ASROCK A75 Extreme6 Bedienungsanleitung

ASROCK

ASROCK 2Core1066-2.13G Bedienungsanleitung

ASROCK

ASROCK X570 PHANTOM GAMING 4 Bedienungsanleitung

ASROCK

ASROCK P67 Extreme4 Gen3 Bedienungsanleitung

ASROCK

ASROCK A770DE Bedienungsanleitung

ASROCK

ASROCK N100M Bedienungsanleitung

ASROCK

ASROCK B760M-HDV/M.2 Bedienungsanleitung

ASROCK

ASROCK K8NF3-VSTA Bedienungsanleitung

ASROCK

ASROCK IMB-140 Bedienungsanleitung

ASROCK

ASROCK Z68 EXTREME4 - ANNEXE 541 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
