ASROCK FM2A88X-ITX Bedienungsanleitung

User Manual

Version 1.1

Published September 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Contents

1. Introduction ................................................................ 1

1.1 Package Contents ..................................................................... 1

 1.2 Specications............................................................................. 2

1.3 Unique Features ........................................................................ 6

1.4 WiFi-802.11n Module and ASRock WiFi 2.4/5GHz Antenna ..... 11

1.5 Motherboard Layout ................................................................. 13

1.6 I/O Panel .................................................................................. 15

2. Installation .................................................................. 17

Pre-installation Precautions ................................................................ 17

2.1 CPU Installation ......................................................................... 18

2.2 Installation of CPU Fan and Heatsink ...................................... 19

2.3 Installation of Memory Modules (DIMM) .................................... 20

2.4 Expansion Slots (PCI Express Slots)......................................... 22

2.5 Jumpers Setup........................................................................... 23

2.6 Onboard Headers and Connectors ....................................... 24

2.7 Dual Graphics Operation Guide ................................................ 28

2.8 Using the HDMI-In Port ............................................................. 30

3. Software and Utilities Operation............................... 33

3.1 Installing Drivers ........................................................................ 33

3.2 A-Tuning .................................................................................... 34

3.3 Qualcomm®Atheros®Security Wake On Internet Technology .. 38

3.4 Start8 ......................................................................................... 45

4. UEFI SETUP UTILITY.................................................. 48

4.1 Introduction ................................................................................ 48

4.1.1 UEFI Menu Bar................................................................ 48

4.1.2 Navigation Keys............................................................... 49

4.2 Main Screen............................................................................... 49

4.3 OC Tweaker Screen................................................................... 50

4.4 Advanced Screen ...................................................................... 53

  4.4.1 CPUConguration........................................................... 54

  4.4.2 NorthBridgeConguration .............................................. 55

  4.4.3 SouthBridgeConguration ............................................. 56

  4.4.4 StorageConguration...................................................... 57

  4.4.5 ACPIConguration.......................................................... 58

  4.4.6 USBConguration........................................................... 60

4.4.7 Trusted Computing .......................................................... 61

4.5 Tool ............................................................................................ 62

4.6 Hardware Health Event Monitoring Screen ............................... 65

4.7 Boot Screen ............................................................................... 66

4.8 Security Screen ......................................................................... 68

4.9 Exit Screen ................................................................................ 69

1. Introduction

Thank you for purchasing ASRock FM2A88X-ITX+ motherboard, a reliable moth-

erboard produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

softwareandutilities.Chapter4containsthecongurationguideoftheBIOSsetup.

 Because the motherboard specications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice.Incaseanymodicationsofthismanualoccur,theupdatedver-

sion will be available on ASRock website without further notice. You may

ndthelatestVGAcardsand CPUsupportlistsonASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

ourwebsiteforspecicinformationaboutthemodelyouareusing.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock FM2A88X-ITX+ Motherboard (Mini-ITX Form Factor)

ASRock FM2A88X-ITX+ Quick Installation Guide

ASRock FM2A88X-ITX+ Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x ASRock WiFi 2.4/5GHz Antenna

2 x SMA Wi-Fi Antenna Cables

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows®8 / 8 64-bit / 7 / 7 64-bit, it is

recommendedtosettheBIOSoptioninStorageCongurationtoAHCI

mode.

1.2 Specications

Platform - Mini-ITX Form Factor

- Premium Gold Capacitor design (100% Japan-made high-

quality conductive polymer capacitors)

A-Style - Home Cloud

- HDMI-In

CPU - Supports Socket FM2+ 95W / FM2 100W processors

- 4 + 2 Power Phase design

Chipset - AMD A88X (Bolton-D4)

Memory - Dual Channel DDR3 Memory Technology

- 2 x DDR3 DIMM Slots

- Supports DDR3 2400+(OC)/2133/1866/1600/1333/1066

non-ECC, un-buffered memory (see CAUTION 1)

- Max. capacity of system memory: 32GB (see CAUTION 2)

- Supports Intel®ExtremeMemoryProle(XMP)1.3/1.2

 -SupportsAMDMemoryProle(AMP)

Expansion Slot - 1 x PCI Express 3.0 x16 Slot (PCIE1 @ x16 mode)

* PCIE 3.0 is only supported with FM2+ CPU. With FM2

CPU, it only supports PCIE 2.0.

- 1 x Half/Full (mSATA) mini-PCI Express Slot

- Supports AMD Dual Graphics

Graphics - Integrated AMD Radeon HD 8000/7000 series graphics in

A-series APU

- DirectX 11.1, Pixel Shader 5.6 with FM2+ CPU. DirectX 11,

Pixel Shader 5.0 with FM2 CPU.

- Max. shared memory 2GB

 -ThreeVGAoutputoptions:D-Sub,DVI-DandHDMIPorts

- Supports Triple Monitor

- Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

 -SupportsDual-linkDVI-Dwithmax.resolutionupto

2560x1600 @ 60Hz

- Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI

monitor is required) (see CAUTION 3)

- Supports Blu-ray Stereoscopic 3D with HDMI Port

 -SupportsAMDSteadyVideoTM 2.0: New video post

processing capability for automatic jitter reduction on

home/online video

 -SupportsHDCPwithDVI-DandHDMIPorts

 -SupportsFullHD1080pBlu-ray(BD)playbackwithDVI-D

and HDMI Ports

Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1150

Audio Codec)

- Premium Blu-ray Audio support

- TI®NE5532PremiumHeadsetAmplier(Supportsupto600

ohm headsets)

- Supports DTS Connect

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Qualcomm®Atheros®AR8171

- Supports Qualcomm®Atheros®Security Wake On Internet

Technology

- Supports Wake-On-LAN

 -SupportsEnergyEfcientEthernet802.3az

- Supports PXE

Wireless LAN - Supports IEEE 802.11a/b/g/n

- Supports Dual-Band (2.4/5 GHz)

- Supports High speed wireless connection up to 300Mbps

- 2 antennas to support 2 (Transmit) x 2 (Receive) MIMO

Technology

- Supports Bluetooth 4.0 Class II

Rear Panel I/O - 2 x Antenna Ports

- 1 x PS/2 Mouse/Keyboard Port

- 1 x D-Sub Port

 -1xDVI-DPort

- 1 x HDMI-Out Port

- 1 x HDMI-In Port

- 1 x Optical SPDIF Out Port

- 4 x USB 2.0 Ports

- 1 x eSATA Connector

- 2 x USB 3.0 Ports (AMD A88X (Bolton-D4))

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jacks: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone

Storage - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug

- 1 x mSATA 6.0 Gb/s Connector (Solid-State Drive

connector), supports NCQ and AHCI

Connector - 1 x Chassis Intrusion Header

- 1 x TPM Header

- 1 x CPU Fan Connector (4-pin)

- 1 x Chassis Fan Connector (4-pin)

- 1 x 24 pin ATX Power Connector

 -1x4pin12VPowerConnector

- 1 x Front Panel Audio Connector

- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

- 1 x USB 3.0 Header by AMD A88X (Bolton-D4)

(Supports 2 USB 3.0 ports)

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 compliance wake up events

- Supports jumperfree

- SMBIOS 2.3.1 support

 -DRAM,VDDP,VDDRVoltagemulti-adjustment

Support CD -Drivers,Utilities,AntiVirusSoftware(TrialVersion),

CyberLink MediaEspresso 6.5 Trial, Google Chrome

Browser and Toolbar, Start8 (30 days trial)

Hardware - CPU temperature sensing

Monitor - Chassis temperature sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU/Chassis Quiet Fan

- CPU/Chassis Fan multi-speed control

- CASE OPEN detection

 -Voltagemonitoring:+12V,+5V,+3.3V,Vcore

OS - Microsoft® Windows®8.1 32-bit / 8.1 64-bit / 8 32-bit /

8 64-bit / 7 32-bit / 7 64-bit / XP 32-bit

Certications - FCC, CE, WHQL

- ErP/EuP ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

overclocking.

CAUTION!

1. Whether 2400/2133/1866/1600MHz memory speed is support-

ed depends on the CPU you adopt. If you want to adopt DDR3

2400/2133/1866/1600 memory module on this motherboard,

please refer to the memory support list on our website for the

compatible memory modules.

ASRock website http://www.asrock.com

2. Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage un-

der Windows®8 / 7. For Windows®64-bit OS with 64-bit CPU,

there is no such limitation. You can use ASRock XFast RAM to

utilize the memory that Windows®cannot use.

3. xvYCC and Deep Color are only supported under Windows®8

64-bit / 8 / 7 64-bit / 7. Deep Color mode will be enabled only

if the display supports 12bpc in EDID. HBR is supported under

Windows®8 64-bit / 8 / 7 64-bit / 7.

Andere Handbücher für FM2A88X-ITX

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK ALIVENF5-ESATA2 R3.0 Bedienungsanleitung

ASROCK

ASROCK X99E-ITX/ac Bedienungsanleitung

ASROCK

ASROCK H310CM-ITX/ac Bedienungsanleitung

ASROCK

ASROCK IMB-130 Gebrauchsanweisung

ASROCK

ASROCK H410M-H/M.2 SE Bedienungsanleitung

ASROCK

ASROCK Z170 Extreme7+ Bedienungsanleitung

ASROCK

ASROCK P4 COMBO Bedienungsanleitung

ASROCK

ASROCK P55 DELUXE - V1.1 Bedienungsanleitung

ASROCK

ASROCK P55 DELUXE - V1.1 Bedienungsanleitung

ASROCK

ASROCK H55M PRO Bedienungsanleitung

ASROCK

ASROCK Fatal1ty H87 Performance Series Bedienerhandbuch

ASROCK

ASROCK H470M Bedienungsanleitung

ASROCK

ASROCK 880GMH-LE USB3 - NOTICE 2 Bedienungsanleitung

ASROCK

ASROCK PRO Series Bedienungsanleitung

ASROCK

ASROCK EPYC3251D4I-2T Bedienungsanleitung

ASROCK

ASROCK B550 Phantom Gaming-ITX/ax Bedienungsanleitung

ASROCK

ASROCK M3A790GXH/USB3 Bedienungsanleitung

ASROCK

ASROCK M3A770DE - V1.0 Bedienungsanleitung

ASROCK

ASROCK IMB-X1233-WV Bedienungsanleitung

ASROCK

ASROCK 880GM PRO3 Bedienungsanleitung

ASROCK

ASROCK A55M-VS Bedienungsanleitung

ASROCK

ASROCK IMB-X1314 Bedienungsanleitung

ASROCK

ASROCK A785GM Bedienungsanleitung

ASROCK

ASROCK Z390M-STX MXM Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
