ASROCK IMB-157 Bedienungsanleitung

IMB-157

User Manual

Version 1.0

Published May 2017

Version 1.0

Published May 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

CAUTION:

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Contents

1 Introduction ....................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Specications................................................................. 6

1.3 Motherboard Layout....................................................... 8

1.4 I/O Panel........................................................................ 10

2 Installation ......................................................... 11

2.1 Screw Holes................................................................... 11

2.2 Pre-installation Precautions ........................................... 11

2.3 Installation of Memory Modules (SO-DIMM).................. 12

2.4 Expansion Slot............................................................... 13

2.5 Jumpers Setup............................................................... 14

2.6 Onboard Headers and Connectors................................ 17

3 UEFI SETUP UTILITY......................................... 23

3.1 Introduction .................................................................... 23

3.1.1 UEFI Menu Bar .................................................... 23

3.1.2 Navigation Keys ................................................... 24

3.2 Main Screen................................................................... 24

3.3 Advanced Screen........................................................... 25

3.3.1 CPU Conguration ............................................... 26

3.3.2 Chipset Conguration........................................... 27

3.3.3 Storage Conguration .......................................... 28

3.3.4 Super IO Conguration ........................................ 29

3.3.5 ACPI Conguration............................................... 31

3.3.6 USB Conguration ............................................... 32

3.4 Hardware Health Event Monitoring Screen ................... 33

3.5 Security Screen ............................................................. 34

3.6 Boot Screen ................................................................... 35

3.7 Exit Screen .................................................................... 37

4 Software Support .............................................. 38

4.1 Install Operating System................................................ 38

4.2 Support CD Information ................................................. 38

4.2.1 Running Support CD............................................ 38

4.2.2 Drivers Menu........................................................ 38

4.2.3 Utilities Menu........................................................ 38

4.2.4 Contact Information.............................................. 38

Chapter 1: Introduction

Thank you for purchasing ASRock IMB-157 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock IMB-157 Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock IMB-157 Driver CD

ASRock IMB-157 Jumper Setting Instruction

1 x I/O Panel Shield

1.2 Specications

Form

Factor Dimensions Mini-ITX (6.7-in x 6.7-in)

Processor

System

CPU BGA1296 for Intel®Apollo Lake SoC

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L2 Cache (By CPU)

L3 Cache (By CPU)

Chipset N/A

BIOS UEFI

Expansion

Slot

PCIe 1 x PCIe x1 slot

Mini-PCIe 1 (full/half size) with PCIe x1 and USB 2.0

(Shared)

mSATA 0

M.2

1 x M.2 (KEY M, 2242/2260) with SATA III signal

for SSD

1 x M.2 (KEY E, 2230) with PCIe x1 and USB 2.0

(Shared) for Wireless

Memory

Technology Dual Channel DDR3L 1867 MHz

Max. 16GB

Socket 2 x SO-DIMM

Graphics

Controller Intel®HD Graphics

VRAM Shared Memory

VGA Supports Max resolution up to 1920 x 1200

DVI No

LVDS Supports Max resolution up to 1920 x

1200@60Hz

HDMI Supports HDMI, Max resolution up to 3840 x

2160@30Hz

DisplayPort No

MultiDisplay Yes (Triple Display)

Ethernet

Ethernet 10/100/1000 Mbps

Controller 2 x Realtek RTL8111G

Connector 2 x RJ-45

SATA

Max Data

Transfer

Rate

SATA3 (6.0Gb/s)

Rear I/O

VGA 1

DVI 0

HDMI 1

DisplayPort 0

Ethernet 2

USB 4 x USB 3.0

Audio 2 (Mic-in, Line-out)

Serial 0

PS/2 1

Internal

Connector

USB 4 x USB 2.0 (2 x 2.54 pitch header)

LVDS/

Inverter 1/1

eDP 1 (shared with LVDS)

VGA 1

Serial 6 x COM (COM1and COM2 with

RS232/422/485 support)

SATA 1

mPCIe 1

Parallel 1 (shared with GPIO)

mSATA 0

PS/2 0

GPIO 8-bit 8 x GPI + 8 x GPO (shared with LPT

header)

SATA PWR

Output Con 1

Speaker

Header 1

Watchdog

Timer

Output Output from super I/O to drag RESETCON#

Interval 256 Segments, 0,1,2…255 Sec/Min

Power

Requirements

Input PWR +12V or +19V~+24V DC-In (DC Jack / 4-pin

ATX PWR Con)

Power On

AT/ATX Supported

-AT : Directly PWR on as power input ready

-ATX : Press button to PWR on after power

input ready

Environment Temperature 0ºC – 60ºC

1.3 Motherboard Layout

Mic In

AUDIO

CODEC

BUZZ1

BIOS

Chip

USB2_6_7

HD_AUDIO1

IMB-157

BUZZ2

SATA3_1

CPU_FAN1

PCIE1

DC_JACK1

mini-PCIe

LPC1

PS2_KB_MS1

VGA2

CLRMOS1

SPEAKER1

LAN1

VGA1

Line Out

HDMI1

BLT_VOL1

HDLED RESET

PLED PWRBTN

PANEL1

Ci1

SATA_PWR1

USB6_S_MPCIE1

BLT_PWR1

PNL_PWR1

BKT_PWR1

Industrial

SPDIF1

DDR3_A1 (Support DDR3L Only)

DDR3_B1 (Support DDR3L Only)

M.2 KEY M

USB 3.0

T: USB3

B: USB2

USB 3.0

T: USB1

B: USB0

LAN2

LVDS 1

BLT_PWM1

LPT_GPIO1

CHA_FAN1

CI2

COM1

JGPIO_SET1

BL1

BL2

TO_UPS1

FROM_UPS1

USB3_PWR0_1

USB3_PWR2_3

USB2_PWR6_7

USB2_PWR4_5

USB2_4_5

PWR_JP1

JGPIO_PWR1

PWR_COM1

PWR_COM2

PWR_COM3

PWR_COM4

PWR_COM5

PWR_COM6

COM2

COM3

COM4

COM5

COM6

CLRMOS2

M.2 KEY E

USB4_S_M2E1

1 : 2-pin UPS Module Power Input Connector

2 : USB Power Setting Jumpers

(USB3_PWR0_1 (For

USB3_0_1

))

(USB3_PWR2_3 (For

USB3_2_3

))

3 : ATX Power Connector (Input +12V & +19V~+24V)

4 : SATA Power Output Connector

5 : SATA3 Connector (SATA3_1)

6 : BL1, BL2

7 :

LVDS Panel Connector

* eDP Connector (on the Backside of PCB)

8 : BLT_PWM1

9 : Backlight Volume Control (BLT_VOL1)

10 :

Backlight Power Connector (BLT_PWR1)

11 : USB2.0 Connectors (USB2_4_5, USB2_6_7)

12 : Panel Power Selection (LCD_VCC) (PNL_PWR1)

13 : Backlight Power Select (LCD_BLT_VCC) (BKT_PWR1)

14 :

System Panel Header

15 : USB4_S_M2E1

16 : Internal COM Port Headers

COM1, 2 (RS232/422/485)

COM3, 4, 5, 6 (RS232)

17 : Printer Port / GPIO Header (LPT_GPIO1)

18 : Digital Input / Output Default Value Setting (JGPIO_SET1)

19 : Digital Input / Output Power Select (JGPIOPWR) (JGPIO_PWR1)

20 : COM Port Pin9 PWR Setting Jumpers

PWR_COM1 ~ 6 (For COM Port1 ~ 6)

21 :

4-Pin CPU FAN Connector (+12V)

22 :

4-Pin Chassis FAN Connector (+12V)

23 : Chassis Intrusion Headers (CI1, Cl2)

24 : LPC Header

25 : ATX/AT Mode Select

26 : SPDIF Header

27 :

Front Panel Audio Header

28 : 3W Audio AMP Output Wafer

29 : Clear CMOS Jumper

30 : Clear CMOS Header

31 :

PS2 Keyboard/Mouse Header

32 : USB6_S_MPCIE1

33 : Buzzer

34 : VGA Header

35 : USB Power Setting Jumpers

(USB2_PWR4_5 (For

USB2_4_5

))

(USB2_PWR6_7 (For

USB2_6_7 and PS2_KB_MS1

))

1.4 I/O Panel

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN Port LED Indications

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

1 DC Jack

2 HDMI Port (HDMI1)

3 USB 3.0 Ports (USB3_0_1)

4 USB 3.0 Ports (USB3_2_3)

5 VGA Port (VGA1)

6 LAN RJ-45 Port (LAN1)*

7 LAN RJ-45 Port (LAN2)*

8 Line out (Green)

9 Microphone (Pink)

ACT/LINK

LED

SPEED

LED

LAN Port

124

358

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK Rack MT-C224 Bedienungsanleitung

ASROCK

ASROCK H61M-DPS Bedienungsanleitung

ASROCK

ASROCK 1U4LW Series Bedienungsanleitung

ASROCK

ASROCK Z68 PRO3-M - ANNEXE 671 Bedienungsanleitung

ASROCK

ASROCK IMB-1000D Bedienungsanleitung

ASROCK

ASROCK H410M/ac Bedienungsanleitung

ASROCK

ASROCK 880GMH USB3 R2.0 Bedienungsanleitung

ASROCK

ASROCK 775XFIRE-ESATA2 - 02-2006 Bedienungsanleitung

ASROCK

ASROCK B85M Pro3 Bedienungsanleitung

ASROCK

ASROCK 890GM Pro3 R2.0 Bedienungsanleitung

ASROCK

ASROCK FM2A55M-DGS Bedienungsanleitung

ASROCK

ASROCK P45R2000 Bedienungsanleitung

ASROCK

ASROCK H87 Pro4 Bedienungsanleitung

ASROCK

ASROCK AD425PV3 Bedienungsanleitung

ASROCK

ASROCK K7UPGRADE-880 Bedienungsanleitung

ASROCK

ASROCK Z590M-ITX/ax Bedienungsanleitung

ASROCK

ASROCK H61DE-S3 Bedienungsanleitung

ASROCK

ASROCK H310D4-P1 Bedienungsanleitung

ASROCK

ASROCK X58 EXTREME6 - Bedienungsanleitung

ASROCK

ASROCK AM1H-ITX Bedienungsanleitung

ASROCK

ASROCK H81M-HG4 Bedienungsanleitung

ASROCK

ASROCK X99 X99 Extreme3 Bedienungsanleitung

ASROCK

ASROCK 990FX EXTREME3 Bedienungsanleitung

ASROCK

ASROCK X570 PHANTOM GAMING 4 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
