IMB-A160

User Manual

Version 1.0

Published October 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction ................................................................ 5

1.1 Package Contents.......................................................... 5

1.2 Specications ................................................................. 6

1.3 Unique Features............................................................. 9

1.4 Motherboard Layout ..................................................... 10

1.5 I/O Panel ...................................................................... 12

2. Installation .................................................................. 13

2.1 Installing Memory Modules (DIMM) ............................... 14

2.2 Expansion Slots (PCI Express Slots) ............................. 15

2.3 Installing SATA Hard Disks............................................. 16

2.4 Power Connectors.......................................................... 17

2.5 Installing the System Panel............................................ 18

2.6 Onboard Headers and Connectors ................................ 19

2.7 Jumpers Setup ............................................................... 24

2.8 Operating System Setup ................................................ 26

2.8.1 Installing Windows®8 / 8 64-bit / 7 / 7 64-bit /

VistaTM / VistaTM 64-bit / XP / XP 64-bit Without

RAID...................................................................... 26

2.8.2 Installing Windows®8 64-bit / 7 64-bit / VistaTM

64-bit on a HDD Larger than 2 terabytes .............. 27

2.8.3 Installing Windows®8 / 8 64-bit / 7 / 7 64-bit /

VistaTM / VistaTM 64-bit with RAID .......................... 28

2.9 Installing Drivers............................................................. 29

2.10 Hot Plug and Hot Swap for Hard Disk Drives................. 30

3. UEFI SETUP UTILITY.................................................. 34

3.1 Introduction .................................................................... 34

3.1.1 UEFI Menu Bar ..................................................... 34

3.1.2 Navigation Keys .................................................... 35

3.2 Main Screen ................................................................... 36

3.3 Advanced Screen........................................................... 37

3.3.1 CPU Conguration ............................................... 38

3.3.2 North Bridge Conguration................................... 39

3.3.3 South Bridge Conguration .................................. 40

3.3.4 Storage Conguration .......................................... 41

3.3.5 Super IO Conguration ........................................ 42

3.3.6 ACPI Conguration............................................... 43

3.3.7 USB Conguration ............................................... 45

3.3.8 Trusted Computing............................................... 46

3.4 Hardware Health Event Monitoring Screen.................... 47

3.5 Boot Screen ................................................................... 48

3.6 Security Screen.............................................................. 49

3.7 Exit Screen..................................................................... 50

1. Introduction

Thank you for purchasing ASRock IMB-A160 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality con-

trol. It delivers excellent performance with robust design conforming to AS-

Rock’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contains the introduction of the mother-

board and step-by-step hardware installation guide. Chapter 3 and 4 con-

tains the conguration guide of BIOS setup and information of the Support

CD.

Because the motherboard specications and the BIOS software

might be updated, the content of this manual will be subject to

change without notice. In case any modications of this manual

occur, the updated version will be available on ASRock’s web-

site without further notice. You may nd the latest VGA cards

and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com

If you require technical support related to this motherboard,

please visit our website for specic information about the model

you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock IMB-A160 Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock IMB-A160 Quick Installation Guide

ASRock IMB-A160 Support CD

2 x Serial ATA (SATA) Data Cables

1 x Serial ATA (SATA) HDD Power Cables

1 x I/O Panel Shield

1.2 Specications

Platform - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0

- All Solid Capacitor design (100% Japan-made high

quality Conductive Polymer Capacitors)

CPU - Supports AMD Embedded G-Series APU T56N/T48E/

T40E

- Supports AMD Virtualization Technology

Chipset - AMD A50M/A55E Controller Hub

Memory - Single Channel DDR3 memory technology

- 2 x 204-pin DDR3 SO-DIMM slots

- T56N supports DDR3 1333/1066 MHz SDRAM,

T48E/T40E supports DDR3 1066 MHz SDRAM

- Max. capacity of system memory: 8GB

(see CAUTION 1)

Expansion Slots - 1 x PCI Express 2.0 x4 slot (PCIE1: x4 mode)

- 1 x Mini-PCI Express slot (Half size)

Graphics - AMD Radeon HD 6320 with T56N, AMD Radeon HD

6250 with T48E/T40E

- Supports Pixel Shader 5.0, DirectX 11

- Max. shared memory 256MB

- Three VGA Output options: D-Sub, LVDS and HDMI

- Supports D-Sub with max. resolution up to 2560x

1600 @ 60Hz for T56N or 1920x1200 for T48E/T40E

- Supports 2-CH/24bits LVDS with max. resolution up

to 1920x1200 @ 60Hz (Optional)

- Supports HDMI 1.3a Technology with max. resolution

up to 1920x1200 @ 60Hz (Optional)

Audio - 2 CH Audio (Realtek ALC662 Audio Codec)

LAN - 2 x Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake On LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports Dual LAN

- Supports PXE

Rear Panel I/O - 1 x PS/2 Mouse/Keyboard Port

- 1 x D-Sub Port

- 2 x HDMI Ports (Optional)

- 2 x Serial Ports (RS-232/422/485)

- 6 x Ready-to-Use USB 2.0 Ports

- 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and

SPEED LED)

- HD Audio Jacks: Line Out / MIC In

SATA3 - 4 x SATA3 6.0 Gb/s connectors, support RAID (RAID

0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and

Hot Plug (Raid is not supported by AMD A50M)

Connectors - 4 x SATA3 6.0 Gb/s connectors

- 4 x COM port headers

- 1 x LVDS header (Optional)

- 1 x Printer port

- 1 x Mini SATA slot

- 1 x TPM header

- 1 x CPU Fan connector (1 x 4-pin)

- 1 x Chassis Fan connector (1 x 3-pin)

- 4 pin 12V power connector

- SATA power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

- 1 x Vertical Type A USB

BIOS Feature - 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

Support CD - Drivers

Hardware - CPU/Chassis Temperature Sensing

Monitor - CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft®Windows®8 / 8 64-bit / 7 / 7 64-bit / VistaTM

/ VistaTM 64-bit / XP / XP 64-bit compliant

Certications - FCC, CE, WHQL

CAUTION!

1. Due to the operating system’s limitation, the actual memory

size of the reservation for system usage under Windows®32-

bit operating systems may be less than 4GB. Windows®64-bit

operating systems have no such limitation. You can use ASRock

XFast RAM to utilize the memory that Windows®cannot use.

WARNING

Please realize that there is a certain risk involved with over-

clocking, including adjusting the setting in the BIOS, applying

Untied Overclocking Technology, or using third-party overclock-

ing tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your

system. It should be done at your own risk and expense. We are

not responsible for possible damage caused by overclocking.

* For detailed product information, please visit our website:

http://www.asrock.com

1.3 Unique Features

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded

in Flash ROM. This convenient BIOS update tool allows

you to update system BIOS without entering operating

systems rst like MS-DOS or Windows®. With this util-

ity, you can press the <F6> key during the POST or the

<F2> key to enter into the BIOS setup menu to access

ASRock Instant Flash. Just launch this tool and save

the new BIOS le to your USB ash drive, oppy disk or

hard drive, then you can update your BIOS only in a few

clicks without preparing an additional oppy diskette or

other complicated ash utility. Please be noted that the

USB ash drive or hard drive must use FAT32/16/12 le

system.

ASRock Crashless BIOS

ASRock Crashless BIOS allows users to update their

BIOS without fear of failing. If power loss occurs during

the BIOS update process, ASRock Crashless BIOS will

automatically finish the BIOS update procedure after

regaining power. Please note that BIOS files need to

be placed in the root directory of your USB disk. Only

USB2.0 ports support this feature.

1.4 Motherboard Layout

1 mini SATA Slot (M_SATA1)

2* LVDS Connector (LVDS1)

3* Backlight Power Jumper (BKT_PWR1)

4* Inverter Power Control Header (BLT_PWR2)

5* Panel Power Jumper (PNL_PWR1)

6* Backlight & Amp Volume Control Header (BLT_VOL1)

7 CPU Fan Connector (CPU_FAN1)

8 CPU

9 AMD A50M/A55E Chipset

10 4-pin ATX 12V Power Connector

11 2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_A2, Black)

12 Printer Port (LPT1)

13 SATA Power Connector (JPWR1)

DDR3_A1

DDR3_A2

LVDS1

USB 2.0

T: USB1

B: USB0

PS2

Keyboard

/Mouse

COM1

VGA1

COM2

HDMI2

HDMI1

RJ-45

USB 2.0

T: USB3

B: USB2

RJ-45

USB 2.0

T: USB5

B: USB4

Top:

Line In

Center:

Line Out

Bottom:

Mic In

PCIE1

AUDIO

CODEC

LAN

ATX12V1

BUZZ1

CMOS

Battery

CPU_FAN1

LPT1

CLRCOMOS1

32Mb

BIOS

PANEL1

HDLED RESET

PLED PWRBTN

SATA3_1

SATA3_2

SATA3 _3

SATA3_4

CHA_FAN1

JPWR1

Designed in Taipei

BLT_VOL1

BLT_PWR2

SPEAKER_OUT1

COM4

COM3

COM5

COM6

USB_6_7

USB_8_9

USB_10_11

USB12

D IO1

HD_AUDIO1

BKT_PWR1

PNL_PWR1

SET_CM2

SET_CM1

SET_CM4

SET_CM3

MINI_PCIE1

M_SATA1

IMB-A160

13456

34 27

278 9 10 11

2528

29 30 31

PWR_JP1

Super

I/O

TPM1

Andere Handbücher für IMB-A160

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK AM1H-M Bedienungsanleitung

ASROCK

ASROCK 4X4-4800U Bedienungsanleitung

ASROCK

ASROCK Rack E3C224D4M-16RE Bedienungsanleitung

ASROCK

ASROCK EPC621D6U Bedienungsanleitung

ASROCK

ASROCK Z790 Series Bedienungsanleitung

ASROCK

ASROCK WOLFDALE1333-D667 Bedienungsanleitung

ASROCK

ASROCK AM2NF3-VSTA Bedienungsanleitung

ASROCK

ASROCK Z590 Phantom Gaming 4/ac Bedienungsanleitung

ASROCK

ASROCK P4FSB1333-650 - Bedienungsanleitung

ASROCK

ASROCK Z97 Pro3 Bedienungsanleitung

ASROCK

ASROCK B85 Pro4 Bedienungsanleitung

ASROCK

ASROCK B360M-HDV Bedienungsanleitung

ASROCK

ASROCK IMB-380-D Bedienungsanleitung

ASROCK

ASROCK B250M DASH Bedienungsanleitung

ASROCK

ASROCK Fatal1ty Z68 Professional Gen3 Bedienungsanleitung

ASROCK

ASROCK CONROE945PL-GLAN Bedienungsanleitung

ASROCK

ASROCK EP2C612D16SM Bedienungsanleitung

ASROCK

ASROCK P4I45PE-C Bedienungsanleitung

ASROCK

ASROCK N68-VGS3 UCC - Bedienungsanleitung

ASROCK

ASROCK G-Pro Series Bedienungsanleitung

ASROCK

ASROCK G41M-VGS3 Bedienungsanleitung

ASROCK

ASROCK H61M-HP4 Bedienungsanleitung

ASROCK

ASROCK Z87 Extreme6 Bedienungsanleitung

ASROCK

ASROCK 4CoreN73PV-HD720p R1.0 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
