ASROCK K7V88 Bedienungsanleitung

K7V88

User Manual

Version 1.0

Published March 2004

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identification or explanation and to the owners’ benefit, without intent to infringe.

Disclaimer:

Specifications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or fitness for a particular purpose.

In no event shall ASRock, its directors, officers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of profits, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

ASRock Website: http://www.asrock.com

Contents

1. Introduction .................................................. 5

1.1 Package Contents .......................................................... 5

1.2 Specifications ................................................................ 6

1.3 Motherboard Layout ...................................................... 8

1.4 ASRock I/O PlusTM ................................................................................................. 9

2. Installation .................................................... 10

Pre-installation Precautions ................................................... 10

2.1 CPU Installation .............................................................. 11

2.2 Installation of CPU Fan and Heatsink ............................ 11

2.3 Installation of Memory Modules (DIMM)......................... 12

2.4 Expansion Slots (PCI and AGP Slots) ........................... 14

2.5 Jumpers Setup .............................................................. 15

2.6 Onboard Headers and Connectors .............................. 17

2.7 Serial ATA (SATA) Hard Disks Installation ..................... 20

2.8 Hot Plug and Hot Swap Functions for SATA HDDs....... 20

2.9 Making An SATA Driver Diskette .................................... 21

3. BIOS SETUP UTILITY ......................................... 22

3.1 Introduction .................................................................... 22

3.1.1 BIOS Menu Bar .................................................... 22

3.1.2 Navigation Keys ................................................... 23

3.2 Main Screen................................................................... 23

3.3 Advanced Screen ......................................................... 24

3.3.1 CPU Configuration................................................ 24

3.3.2 Chipset Configuration .......................................... 25

3.3.3 ACPI Configuration ............................................... 27

3.3.4 IDE Configuration ................................................. 28

3.3.5 PCIPnP Configuration ........................................... 30

3.3.6 Floppy Configuration ........................................... 30

3.3.7 Super IO Configuration ........................................ 31

3.3.8 USB Configuration ............................................... 32

3.4 Hardware Health Event Monitoring Screen .................. 33

3.5 Boot Screen................................................................... 33

3.5.1 Boot Settings Configuration.................................. 34

3.5.2 Boot Device Priority............................................... 34

3.6 Security Screen ............................................................ 35

3.7 Exit Screen .................................................................... 36

4. Software Support.......................................... 37

4.1 Install Operating System ............................................... 37

4.2 Support CD Information ................................................. 37

4.2.1 Running Support CD ............................................ 37

4.2.2 Drivers Menu ........................................................ 37

4.2.3 Utilities Menu ........................................................ 37

4.2.4 ASRock “PC-DIY Live Demo” Program ................. 37

4.2.5 Contact Information .............................................. 37

1. Introduction

Thank you for purchasing ASRock K7V88 motherboard, a reliable motherboard pro-

duced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-

step guide to the hardware installation. Chapter 3 and 4 contain the configuration

guide to BIOS setup and information of the Support CD.

Because the motherboard specifications and the BIOS software might be

updated, the content of this manual will be subject to change without

notice. In case any modifications of this manual occur, the updated

version will be available on ASRock website without further notice. You

may find the latest memory and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

1.1 Package Contents

ASRock K7V88 Motherboard

(ATX Form Factor: 12.0-in x 8.0-in, 30.5 cm x 20.3 cm)

ASRock K7V88 Quick Installation Guide

ASRock K7V88 Support CD

One 80-conductor Ultra ATA 66/100/133 IDE Ribbon Cable

One Ribbon Cable for a 3.5-in Floppy Drive

One Serial ATA (SATA) Data Cable

One Serial ATA (SATA) HDD Power Cable(Optional)

One ASRock I/O PlusTM Shield

1.2 Specifications

Platform: ATX Form Factor: 12.0-in x 8.0-in, 30.5 cm x 20.3 cm

CPU: Supports Socket A (462 pins) for

AMD AthlonTM / AthlonTM XP / DuronTM processor

Chipsets: North Bridge:

VIA KT880, FSB @ 400 MHz

South Bridge:

VIA VT8237, supports USB 2.0, ATA 133, SATA 1.5Gb/s

Memory: 4 DDRDIMM Slots: DDR1, DDR2,DDR3, and DDR4

Support PC3200 (DDR400) / PC2700 (DDR333) /

PC2100 (DDR266), Max. 4GB

Dual Channel Memory Technology support (see CAUTION 1)

IDE: IDE1: ATA 133 / Ultra DMA Mode 6

IDE2: ATA 133 / Ultra DMA Mode 6

Support up to 4 IDE devices

Serial ATA: 2 SATA connectors

Support 1.5Gb/s data transfer rate

Floppy Port: Supports up to 2 floppy disk drives

Audio: 5.1 channels AC’97 Audio

LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN

Hardware Monitor: CPU temperature sensing (ASRock U-COP)

Chassis temperature sensing

CPU overheat shutdown to protect CPU life

(ASRock U-COP)(see CAUTION 2)

CPU fan tachometer

Chassis fan tachometer

Voltage monitoring: +12V, +5V, +3V, Vcore

PCI slots: 5 slots with PCI Specification 2.3

AGP slot: 1 AGP slot, supports 1.5V, 8X/4X AGP card (see CAUTION 3)

USB 2.0: 8 USB 2.0 ports:

include 6 ready-to-use USB 2.0 ports on the rear panel,

plus one on-board header supporting 2 extra USB 2.0 ports

(see CAUTION 4)

ASRock I/O PlusTM:1 PS/2 mouse port, 1 PS/2 keyboard port,

1 serial port: COM1,

1 parallel port: ECP/EPP support,

6 ready-to-use USB 2.0 ports,

1 RJ 45 port,

Audio Jack: Line In / Line Out / Microphone

BIOS: AMI BIOS

Supports “Plug and Play”

ACPI 1.1 compliance wake up events

SMBIOS 2.3.1 support

CPU frequency stepless control

(only for advanced users’ reference, see CAUTION 5)

OS: Microsoft®Windows®98SE / ME / 2000 / XP compliant

CAUTION!

1. This motherboard supports Dual Channel Memory Technology. Before you

implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 12 for proper installation.

2. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal

grease between the CPU and the heatsink when you install the PC system.

3. Do NOT use a 3.3V AGP card on the AGP slot of this motherboard!

It may cause permanent damage!

4. Power Management for USB 2.0 works fine under Microsoft®Windows® XP

SP1 / 2000 SP4. It may not work properly under Microsoft®Windows® 98 /

ME. Please refer to Microsoft®official document at

http://www.microsoft.com/whdc/hwdev/bus/USB/USB2support.mspx

5. Although this motherboard offers stepless control, it is not recommended

to perform over clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

CPU. The CPU host frequency of this motherboard is determined by the

jumper-setting. To perform over-clocking, you must set the FSB jumper

according to your AMD CPU before you use the “Manual” option as the

FSB setting in BIOS setup. Please check page 22 for details.

1.3 Motherboard Layout

1 PS2_USB_PWR1 Jumper 17 Floppy Connector (FLOPPY1)

2 CPU Fan Connector (CPU_FAN1) 18 Chassis Fan Connector (CHA_FAN1)

3 CPU Multiplier Jumper (J1) 19 Power LED Header (PWR_LED1)

4 CPU Socket 20 System Panel Header (PANEL1)

5 North Bridge Controller 21 Chassis Speaker Header (SPEAKER 1)

6 ATX 12V Connector (ATX12V1) 22 USB 2.0 Header (USB67, Blue)

7 2 x 184-pin DDR DIMM Slots 23 Clear CMOS Jumper (CLRCMOS2)

(Dual Channel A: DDR1, DDR3; Blue) 24 Infrared Module Header (IR1)

8 2 x 184-pin DDR DIMM Slots 25 Game Port Connector (GAME1)

(Dual Channel B: DDR2, DDR4; Black) 26 Flash Memory

9 FSB Select Jumper (FSB_SEL0) 27 5 x PCI Slots (PCI1- 5)

10 FSB Select Jumper (FSB_SEL1) 28 Front Panel Audio Header (AUDIO1)

11 AGP Slot (1.5V_AGP1) 29 JR1 Jumper

12 Secondary IDE Connector (IDE2, Black) 30 JL1 Jumper

13 Primary IDE Connector (IDE1, Blue) 31 ATX Power Connector (ATXPWR1)

14 South Bridge Controller 32 Internal Audio Connector: AUX1 (White)

15 Secondary Serial ATA Connector (SATA2) 33 Internal Audio Connector: CD1 (Black)

16 Primary Serial ATA Connector (SATA1) 34 Shared USB 2.0 Header (USB45, Blue)

PS2_USB_PWR1

SOCKET 462

CPU_FAN1

ATX12V1

DDR1 (64/72 bit, 184-pin module)

DDR2 (64/72 bit, 184-pin module)

DDR3 (64/72 bit, 184-pin module)

DDR4 (64/72 bit, 184-pin module)

IDE1

IDE2

1.5V_AGP1

VIA

VT8237

FLOPPY1

CMOS

Battery

VIA

KT880

Chipset

Super

I/O

2MB

BIOS

GAME1

IR1

USB67

CHA_FAN1

SATA2

SATA1

CLRCMOS2

PAN EL 1

HDLED RESET

PLED PWRBTN

SPEAKER1

PCI 2

PCI 3

PCI 4

PCI 5

PCI 1

ATA133

5.1 CH

FSB400

K7V88

USB2.0

DDR400

Audio

CODEC

LAN

PHY

AUDIO1

JR1 JL1

AUX1

CD1

USB45

PWR_LED1

PARALLEL PORT

COM1

PS2

Mouse

PS2

Keyboard

USB 2.0

T: US B 2

B: USB3

USB 2.0

T: US B 0

B: USB1

Top:

RJ-45

Top:

Line In

Center:

Line Out

Bottom:

Mic In

USB 2.0

T: US B 4

B: USB5

20.3cm (8.0 in)

30.5cm (12.0 in)

FSB_SEL0

FSB_SEL1

6457312

24 23 20

2122

ATXPWR1

SATA

AGP 8X

Dual Channel

1.4 ASRock I/O PlusTM

1 Parallel Port 7 2 x USB 2.0 Ports (USB0, USB1)

2 RJ-45 Port 8 2 x USB 2.0 Ports (USB2, USB3)

3 Line In (Light Blue) 9 Serial Port: COM1

4 Line Out (Lime) 10 PS/2 Keyboard Port (Purple)

5 Microphone (Pink) 11 PS/2 Mouse Port (Green)

6 2 x Shared USB 2.0 Ports (USB4, USB5)

8910

2. Installation

K7V88 is an ATX form factor (12.0-in x 8.0-in, 30.5 cm x 20.3 cm) motherboard.

Before you install the motherboard, study the configuration of your chassis to en-

sure that the motherboard fits into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard

components or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any

component.

2. To avoid damaging the motherboard components due to static

electricity, NEVER place your motherboard directly on the carpet or

the like. Also remember to use a grounded wrist strap or touch a

safety grounded object before you handle components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded anti-

static pad or in the bag that comes with the component.

Before you install or remove any component, ensure that the power

is switched off or the power cord is detached from the power

supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK M810LR Bedienungsanleitung

ASROCK

ASROCK Fatal1ty X99M Killer Series Bedienungsanleitung

ASROCK

ASROCK PRO BTC+ Series Bedienungsanleitung

ASROCK

ASROCK X399M Taichi Bedienungsanleitung

ASROCK

ASROCK H81M-ITX Bedienungsanleitung

ASROCK

ASROCK IMB-A180-H Bedienungsanleitung

ASROCK

ASROCK IMB-A182 Bedienungsanleitung

ASROCK

ASROCK Z690 Steel Legend/D5 Bedienungsanleitung

ASROCK

ASROCK ALIVENF7G-HD720P - V2.0 V5.0 Bedienungsanleitung

ASROCK

ASROCK H61M-DGS Bedienungsanleitung

ASROCK

ASROCK N3150DC-ITX Bedienungsanleitung

ASROCK

ASROCK B460TM-ITX Bedienungsanleitung

ASROCK

ASROCK Fatal1ty Z68 Professional Gen3 Bedienungsanleitung

ASROCK

ASROCK M3A790GMH 128M - V1.0 Bedienungsanleitung

ASROCK

ASROCK AB350 Pro4 Bedienungsanleitung

ASROCK

ASROCK Z68 Extreme4 Gen3 Bedienungsanleitung

ASROCK

ASROCK 880G Pro3 Bedienungsanleitung

ASROCK

ASROCK N68C-S Bedienungsanleitung

ASROCK

ASROCK H310CM-HDV/M.2 Bedienungsanleitung

ASROCK

ASROCK P45TS-R Bedienungsanleitung

ASROCK

ASROCK 4CORE1600TWINS-P35 - V1.0 Bedienungsanleitung

ASROCK

ASROCK H61DEL Bedienungsanleitung

ASROCK

ASROCK N68-S3 UCC - Bedienungsanleitung

ASROCK

ASROCK B460M Pro4/ac Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
