ASROCK OC FORMULA X299 Bedienungsanleitung

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock X299 OC

Formula o cerca il tuo prodotto tra le migliori offerte di Schede Madri

Version 1.0

Published August 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 8

1.4 I/O Panel 11

Chapter 2 Installation 13

2.1 Installing the CPU 14

2.2 Installing the CPU Fan and Heatsink 17

2.3 Installing the Motherboard Backplate 18

2.4 Installation of Memory Modules (DIMM) 20

2.5 Expansion Slots (PCI Express Slots) 22

2.6 Jumpers Setup 24

2.7 Onboard Headers and Connectors 26

2.8 Smart Switches 32

2.9 Dr. Debug 35

2.10 Post Status Checker 37

2.11 SLITM , 3-Way SLITM , 4-Way SLITM and Quad SLITM Operation

Guide 38

2.11.1 Installing Two SLITM-Ready Graphics Cards 38

2.11.2 Installing Three SLITM-Ready Graphics Cards 40

2.11.3 Installing Four SLITM-Ready Graphics Cards 42

2.11.4 Driver Installation and Setup 44

2.12 CrossFireXTM, 3-Way CrossFireXTM, 4-Way CrossFireXTM and

Quad CrossFireXTM Operation Guide 45

2.12.1 Installing Two CrossFireXTM-Ready Graphics Cards 45

2.12.2 Installing Three CrossFireXTM-Ready Graphics Cards 46

2.12.3 Installing Four CrossFireXTM-Ready Graphics Cards 48

2.12.4 Driver Installation and Setup 49

2.13 M.2_SSD (NGFF) Module Installation Guide 50

Chapter 3 Software and Utilities Operation 54

3.1 Installing Drivers 54

3.2 Formula Drive 55

3.3 ASRock Live Update & APP Shop 58

3.3.1 UI Overview 58

3.3.2 Apps 59

3.3.3 BIOS & Drivers 62

3.3.4 Setting 63

3.4 ASRock RGB LED 64

Chapter 4 UEFI SETUP UTILITY 66

4.1 Introduction 66

4.2 EZ Mode 67

4.3 Advanced Mode 68

4.3.1 UEFI Menu Bar 68

4.3.2 Navigation Keys 69

4.4 Main Screen 70

4.5 OC Tweaker Screen 71

4.6 Advanced Screen 85

4.6.1 CPU Conguration 86

4.6.2 Chipset Conguration 88

4.6.3 Storage Conguration 90

4.6.4 Intel® Thunderbolt™ 92

4.6.5 Super IO Conguration 93

4.6.6 ACPI Conguration 94

4.6.7 USB Conguration 95

4.6.8 Trusted Computing 96

4.7 Tools 97

4.8 Hardware Health Event Monitoring Screen 100

4.9 Security Screen 103

4.10 Boot Screen 104

4.11 Exit Screen 106

English

X299 OC Formula

Chapter 1 Introduction

ank you for purchasing ASRock X299 OC Formula motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock X299 OC Formula Motherboard (ATX Form Factor)

• ASRock X299 OC Formula Quick Installation Guide

• ASRock X299 OC Formula Support CD

• 1 x I/O Panel Shield

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x ASRock 3-Way SLI-3S1S Bridge Card (Optional)

• 1 x ASRock 3-Way SLI Bridge Card (Optional)

• 1 x ASRock 4-Way SLI-S111 Bridge Card (Optional)

• 1 x ASRock SLI_HB_Bridge_3S Card (Optional)

• 1 x Motherboard Backplate (Optional)

• 2 x Screws for M.2 Sockets (Optional)

• 1 x Jumper Cap for BIOS B Select Jumper (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• 8 Layer PCB

• 2oz Copper PCB

CPU • Supports Intel® CoreTM X-Series Processor Family for the

LGA 2066 Socket

• Digi Power design

• 13 Power Phase design

• Supports Intel® Turbo Boost Max Technology 3.0

* Please note that the 4-Core processors only support Intel®

Turbo Boost Technology 2.0.

• Supports ASRock Hyper BCLK Engine III

Chipset • Intel® X299

Memory • Quad Channel DDR4 Memory Technology

• 4 x DDR4 DIMM Slots

• Supports DDR4 4600+(OC)*/4500(OC)/4400(OC)/4266

(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/

3600(OC)/3200(OC)/2933(OC)/2800(OC)/2666/2400/2133

non-ECC, un-buered memory

* e maximum memory frequency supported may vary by

processor type.

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

• Max. capacity of system memory: 64GB

• Supports Intel® Extreme Memory Prole (XMP) 2.0

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 5 x PCI Express 3.0 x16 Slots*

* If you install CPU with 44 lanes, PCIE1/PCIE3/PCIE4/PCIE5/

PCIE7 will run at x16/x0/x0/x16/x8 or x8/x8/x8/x8/x8.

* If you install CPU with 28 lanes, PCIE1/PCIE3/PCIE4/PCIE5/

PCIE7 will run at x16/x0/x0/x8/x4 or x8/x8/x0/x8/x4.

* If you install CPU with 16 lanes, PCIE1/PCIE3/PCIE4/PCIE5/

PCIE7 will run at x16/x0/x0/x0/x4 or x8/x0/x0/x8/x4.

English

X299 OC Formula

* Please note that the 3-Way SLITM conguration varies

depending on processor type.

* Supports NVMe SSD as boot disks

• 1 x PCI Express 3.0 x4 Slot (PCIE6: x4 mode) (Flexible

PCIe)**

** If you install CPU with 28 lanes or 16 lanes, PCIE6 will be

disabled.

• 1 x PCI Express 2.0 x1 Slot

• Supports AMD Quad CrossFireXTM, 4-Way CrossFireXTM,

3-Way CrossFireXTM and CrossFireXTM***

*** 4-Way CrossFireXTM is only supported with CPU with 44

lanes or 28 lanes.

• Supports NVIDIA® Quad SLITM, 4-Way SLITM, 3-Way SLITM

and SLITM****

**** 3-Way SLITM is only supported with CPU with 44 lanes or

28 lanes; 4-Way SLITM is only supported with CPU with 44 lanes.

• 15μ Gold Contact in VGA PCIe Slot (PCIE1 and PCIE5)

Audio • 7.1 CH HD Audio with Content Protection (Realtek

ALC1220 Audio Codec)

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• Supports Purity SoundTM 4

- Nichicon Fine Gold Series Audio Caps

- 120dB SNR DAC with Dierential Amplier

- NE5532 Premium Headset Amplier for Front Panel

Audio Connector (Supports up to 600 Ohm headsets)

- Pure Power-In

- Direct Drive Technology

- PCB Isolate Shielding

- Impedance Sensing on Line Out port

- Individual PCB Layers for R/L Audio Channel

- Gold Audio Jacks

- 15μ Gold Audio Connector

• Supports DTS Connect

LAN • Gigabit LAN 10/100/1000 Mb/s

• 1 x Giga PHY Intel® I219V, 1 x GigaLAN Intel® I211AT

English

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 1 x Optical SPDIF Out Port

• 2 x USB 2.0 Ports (Supports ESD Protection)

• 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ASMedia ASM3142)

(Supports ESD Protection)

• 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ASMedia ASM3142)

(Supports ESD Protection)

* Ultra USB Power is supported on USB3_34 ports.

* ACPI wake-up function is not supported on USB3_34 ports.

• 4 x USB 3.1 Gen1 Ports (Supports ESD Protection)

• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

LED)

• 1 x BIOS Flashback Button

• 1 x Clear CMOS Button

• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /

Front Speaker / Microphone (Gold Audio Jacks)

Storage • 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology

15 and Intel Smart Response Technology), NCQ, AHCI and

Hot Plug*

* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will

be disabled.

* If M2_2 is occupied by a SATA-type M.2 device, SATA3_5 will

be disabled.

• 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061,

support NCQ, AHCI and Hot Plug

• 2 x Ultra M.2 Sockets (M2_1 and M2_2), support M Key

type 2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module

and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**

** Supports Intel® OptaneTM Technology

** Supports NVMe SSD as boot disks

** Supports ASRock U.2 Kit

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK 990FX EXTREME3 Bedienungsanleitung

ASROCK

ASROCK A520M-HVS Bedienungsanleitung

ASROCK

ASROCK IMB-156J Bedienungsanleitung

ASROCK

ASROCK 890GMH-USB3 - V1.0 Bedienungsanleitung

ASROCK

ASROCK Vig103M Bedienungsanleitung

ASROCK

ASROCK E35LM1 R2.0 Bedienungsanleitung

ASROCK

ASROCK B450 Steel Legend Bedienungsanleitung

ASROCK

ASROCK H61M-VG3 Bedienungsanleitung

ASROCK

ASROCK Fatal1ty B360M Performance Bedienungsanleitung

ASROCK

ASROCK A75iCafe Bedienungsanleitung

ASROCK

ASROCK P45DE - V1.0 Bedienungsanleitung

ASROCK

ASROCK GENOA2D24G-2L+ Bedienungsanleitung

ASROCK

ASROCK B75M-DGS R2.0 Bedienungsanleitung

ASROCK

ASROCK H81TM-ITX R2.0 Bedienungsanleitung

ASROCK

ASROCK X99 Extreme6/3.1 Bedienungsanleitung

ASROCK

ASROCK Z97M Pro4 Bedienungsanleitung

ASROCK

ASROCK X48TURBOTWINS-WIFI Bedienungsanleitung

ASROCK

ASROCK IMB-195-D Bedienungsanleitung

ASROCK

ASROCK W790 WS Bedienungsanleitung

ASROCK

ASROCK H310M-HG4 Bedienungsanleitung

ASROCK

ASROCK H71M-DGS Bedienungsanleitung

ASROCK

ASROCK P67 PRO3 - Bedienungsanleitung

ASROCK

ASROCK A75 Pro4-M Bedienungsanleitung

ASROCK

ASROCK G41M-GS3 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
