ASROCK TRX40 CREATOR Bedienungsanleitung

Version 1.0

Published October 2019

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

CE Warning

is device complies with directive 2014/53/EU issued by the Commision of the European

Community.

is equipment complies with EU radiation exposure limits set forth for an uncontrolled

environment.

is equipment should be installed and operated with minimum distance 20cm between

the radiator & your body.

Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

Radio transmit power per transceiver type

Function Frequency Maximum Output Power (EIRP)

WiFi

2400-2483.5 MHz 18.5 + / -1.5 dbm

5150-5250 MHz 21.5 + / -1.5 dbm

5250-5350 MHz 18.5 + / -1.5 dbm (no TPC)

21.5 + / -1.5 dbm (TPC)

5470-5725 MHz 25.5 + / -1.5 dbm (no TPC)

28.5 + / -1.5 dbm (TPC)

Bluetooth 2400-2483.5 MHz 8.5 + / -1.5 dbm

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 7

1.4 I/O Panel 9

1.5 WiFi-802.11ax Module and ASRock WiFi 2.4/5 GHz

Antenna 11

1.6 USB 3.2 Gen2 x2 Module 12

Chapter 2 Installation 13

2.1 Installing the CPU 14

2.2 Installing the CPU Liquid Cooler 18

2.3 Installation of Memory Modules (DIMM) 20

2.4 Expansion Slots (PCI Express Slots) 22

2.5 Onboard Headers and Connectors 23

2.6 Smart Switches 29

2.7 Dr. Debug 31

2.8 SLITM, 3-Way SLITM and 4-Way SLITM Operation Guide 37

2.8.1 Installing Two SLITM-Ready Graphics Cards 37

2.8.2 Installing Three SLITM-Ready Graphics Cards 39

2.8.3 Installing Four SLITM-Ready Graphics Cards 41

2.8.4 Driver Installation and Setup 43

2.9 CrossFireXTM, 3-Way CrossFireXTM and 4-Way CrossFireXTM

Operation Guide 44

2.9.1 Installing Two CrossFireXTM-Ready Graphics Cards 44

2.9.2 Installing Three CrossFireXTM-Ready Graphics Cards 45

2.9.3 Installing Four CrossFireXTM-Ready Graphics Cards 46

2.9.4 Driver Installation and Setup 47

2.10 M.2_SSD (NGFF) Module Installation Guide (M2_1 and M2_2) 48

2.11 M.2_SSD (NGFF) Module Installation Guide (M2_3) 51

Chapter 3 Software and Utilities Operation 54

3.1 Installing Drivers 54

3.2 ASRock Motherboard Utility (A-Tuning) 55

3.2.1 Installing ASRock Motherboard Utility (A-Tuning) 55

3.2.2 Using ASRock Motherboard Utility (A-Tuning) 55

3.3 ASRock Live Update & APP Shop 58

3.3.1 UI Overview 58

3.3.2 Apps 59

3.3.3 BIOS & Drivers 62

3.3.4 Setting 63

3.4 ASRock Polychrome SYNC 64

Chapter 4 UEFI SETUP UTILITY 67

4.1 Introduction 67

4.1.1 UEFI Menu Bar 67

4.1.2 Navigation Keys 68

4.2 Main Screen 69

4.3 OC Tweaker Screen 70

4.4 Advanced Screen 74

4.4.1 CPU Conguration 75

4.4.2 Onboard Devices Conguration 76

4.4.3 Storage Conguration 78

4.4.4 ACPI Conguration 79

4.4.5 Trusted Computing 80

4.4.6 AMD CBS 81

4.4.7 AMD PBS 82

4.4.8 AMD Overclocking 83

4.5 Tools 84

4.6 Hardware Health Event Monitoring Screen 86

4.7 Security Screen 89

4.8 Boot Screen 90

4.9 Exit Screen 92

English

TRX40 Creator

Chapter 1 Introduction

ank you for purchasing ASRock TRX40 Creator motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock TRX40 Creator Motherboard (ATX Form Factor)

• ASRock TRX40 Creator Quick Installation Guide

• ASRock TRX40 Creator Support CD

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x ASRock SLI_HB_Bridge_3S Card (Optional)

• 1 x ASRock WiFi 2.4/5 GHz Antenna (Optional)

• 3 x Screws for M.2 Sockets (Optional)

• 3 x Standos for M.2 Sockets (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• 8 Layer PCB

• 2oz Copper PCB

CPU • Supports AMD Socket sTRX4

• Intersil Digital PWM

• 8 Power Phase design

• Supports ASRock Hyper BCLK Engine II

Chipset • AMD TRX40

Memory • Quad Channel DDR4 Memory Technology

• 8 x DDR4 DIMM Slots

• Supports DDR4 4666(OC)+/4600(OC)/4533(OC)/4466

(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133

(OC)/4000 (OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/

3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-

buered memory (U-DIMM)

• Max. capacity of system memory: 256GB

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 4 x PCI Express 4.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE4:

single at x16 (PCIE1); dual at x16 (PCIE1) / x16 (PCIE3);

triple at x16 (PCIE1) / x16 (PCIE3) / x8 (PCIE4); quad at x16

(PCIE1) / x8 (PCIE2) / x16 (PCIE3) / x8 (PCIE4))

* Supports NVMe SSD as boot disks

• Supports AMD 4-Way CrossFireXTM, 3-Way CrossFireXTM

and CrossFireXTM

• Supports NVIDIA® 4-Way SLITM, 3-Way SLITM and SLITM

• Support NVIDIA® SLITM with NVIDIA® Quadro graphics

cards

• Supports NVIDIA® NVLinkTM with dual NVIDIA® GeForce®

RTX series graphics cards**

** NVIDIA NVLink Bridge does not come with the package.

Please purchase it from NVIDIA® if necessary.

• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-

802.11ax module (on the rear I/O)

• 15μ Gold Contact in VGA PCIe Slots (PCIE1 and PCIE3)

English

TRX40 Creator

Audio • 7.1 CH HD Audio (Realtek ALC4050H+ALC1220)

• Premium Blu-ray Audio support

• Supports Surge Protection

• Supports Purity SoundTM 4

- Nichicon Fine Gold Series Audio Caps

- NE5532 Premium Headset Amplier for Front Panel

Audio Connector (Supports up to 600 Ohm headsets)

- Pure Power-In

- Direct Drive Technology

- PCB Isolate Shielding

- Impedance Sensing on Front Out port

- Individual PCB Layers for R/L Audio Channel

- Gold Audio Jacks

- 15μ Gold Audio Connector

• Supports DTS Connect

LAN 1 x 10 Gigabit LAN 100/1000/2500/5000/10000 Mb/s

(AQUANTIA® AQC107):

• Supports Lightning/ESD Protection

• Supports PXE

1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon

RTL8125AG):

• Supports Dragon 2.5G LAN Soware

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and

Streaming Modes

- User Customized Priority Control

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE
