ASROCK X600-ITX Bedienungsanleitung

Version 1.0

Published August 2023

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 5

1.4 Front Panel 8

1.5 Rear Panel 9

Chapter 2 Installation 10

2.1 Installing the CPU 11

2.2 Installing the CPU Fan and Heatsink 14

2.3 Installing Memory Modules (DIMM) 16

2.4 Expansion Slot (PCIe Slot) 18

2.5 Jumpers Setup 19

2.6 Onboard Headers and Connectors 20

2.7 Smart Button 23

2.8 M.2 WiFi/BT Module Installation Guide 25

2.9 M.2 SSD Module Installation Guide 27

Chapter 3 Auto Driver Installer 29

Chapter 4 UEFI SETUP UTILITY 30

4.1 Introduction 30

4.1.1 UEFI Menu Bar 30

4.1.2 Navigation Keys 31

4.2 Main Screen 32

4.3 OC Tweaker Screen 33

4.4 Advanced Screen 36

4.4.1 CPU Conguration 37

4.4.2 PCI Conguration 38

4.4.3 Onboard Devices Conguration 39

4.4.4 Storage Conguration 40

4.4.5 ACPI Conguration 41

4.6.6 USB Conguration 43

4.4.7 Trusted Computing 44

4.6.8 AMD CBS 46

4.6.9 AMD PBS 47

3.4.10 AMD Overclocking 48

4.5 Tools 49

4.6 Hardware Health Event Monitoring Screen 50

4.7 Security Screen 52

4.8 Boot Screen 53

4.9 Exit Screen 55

X600-ITX

English

Chapter 1 Introduction

ank you for purchasing X600-ITX motherboard. In this documentation, Chapter

1 and 2 contains the introduction of the motherboard and step-by-step installation

guides. Chapter 3 contains the operation guide of the soware and utilities. Chapter

4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• X600-ITX Motherboard (Deep mini-ITX Form Factor)

• 1 x I/O Panel Shield

• 2 x SATA Cables (Optional)

• 2 x Screws for M.2 Sockets (M2*2) (Optional)

• 1 x Screw for WiFi Module (M2*2) (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice.

English

1.2 Specications

Platform • Deep mini-ITX Form Factor

• Solid Capacitor design

CPU • Supports AMD Socket AM5 RyzenTM 7000 Series Processors

• Supports CPU up to 65W

• 6+2 Power Phase design

Chipset • AMD X600

Memory • Dual Channel DDR5 Memory Technology

• 4 x DDR5 DIMM Slots

• Supports DDR5 ECC/non-ECC, un-buered memory up to

7200+(OC)*

• Max. capacity of system memory: 192GB

• Supports Extreme Memory Prole (XMP) and EXTended

Proles for Overclocking (EXPO) memory modules

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

Expansion

Slot

CPU:

• 1 x PCIe 4.0 x16 Slot, supports x16 mode*

* Supports NVMe SSD as boot disks

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

Graphics • Integrated AMD RDNATM 2 graphics (Actual support may

vary by CPU)

• ree graphics output options: 1x HDMI, 2 x DisplayPort 1.4

• Supports Triple Monitor

• 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR,

HDCP 2.3 and max. resolution up to 4K 120Hz

• 2 x DisplayPort 1.4 with DSC (compressed), support HDCP

2.3 and max. resolution up to 4K 120Hz

X600-ITX

English

Audio • Realtek ALC897 Audio Codec

LAN • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s

• Dragon RTL8125BG

• Supports Dragon 2.5G LAN Soware

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and

Streaming Modes

- User Customized Priority Control

Front

Panel I/O

• 1 x Headphone/Headset Jack

• 2 x USB 3.2 Gen1 Type-A Ports

• 1 x USB 3.2 Gen1 Type-C Port

• 2 x USB 2.0 Ports

Rear Panel

I/O

• 1 x HDMI Port

• 2 x DisplayPort 1.4

• 2 x USB 3.2 Gen1 Ports

• 2 x USB 2.0 Ports

• 1 x RJ-45 LAN Port

• 1 x BIOS Flashback Button

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage CPU:

• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280

PCIe Gen5x4 (128 Gb/s) mode*

• 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280

PCIe Gen4x4 (64 Gb/s) mode*

ASMedia ASM1061:

• 2 x SATA3 6.0 Gb/s Connectors

* Supports NVMe SSD as boot disks

English

RAID • Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe stor-

age devices*

* Requires additional M.2 NVMe expansion cards to support

RAID 10

Connector • 1 x Chassis Intrusion Header

• 1 x CPU Fan Connector

* e CPU Fan Connector supports the CPU fan of maximum 1A

(12W) fan power.

• 1 x Chassis Fan Connector (4-pin)

* e Chassis Fan Connector supports the chassis fan of maxi-

mum 1A (12W) fan power.

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Header

• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

Hardware

Monitor

• CPU, Chassis Temperature Sensing

• CPU, Chassis Fan Tachometer

• CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by

CPU temperature)

• CPU, Chassis Fan Multi-Speed Control

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 10 64-bit

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

X600-ITX

English

1.3 Motherboard Layout

USB 3.2 Gen1

USB3_TC_1

Headphone

/ Headset

CPU_FAN1

RoHS

DDR5_A2 (64 bit, 288-pin module)

DDR5_A1 (64 bit, 288-pin module)

DDR5_B2 (64 bit, 288-pin module)

DDR5_B1 (64 bit, 288-pin module)

SATA3_A2SATA3_A1

CHA_

FAN1

PANEL1

HDLED RESET

PLED PWRBTN

ATX12V1

M.2 WiFi

M.2 PCIe SSD

PCIE1

USB 3. 2 Gen1

T: USB3_1

B: USB3_2

USB 2.0

T: USB_1

B: USB_2

USB 2.0

T: USB_3

B: USB_4

RJ-45

USB 3.2 Gen 1

USB3 34_

USB_5_6

CLRCMOS1

ATXPWR1

X600-ITX

BIOS

_FB1

HDMI

Top:

LINE IN

Center:

FRONT

Bottom:

MIC IN

DP_2

DP_1

CI1

Top Side View
