ASROCK X99 WS Bedienungsanleitung

X99 WSX99 WS

Version 1.0

Published August 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 9

Chapter 2 Installation 11

2.1 Installing the CPU 12

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installation of Memory Modules (DIMM) 16

2.4 Expansion Slots (PCI Express Slots) 18

2.5 Jumpers Setup 20

2.6 Onboard Headers and Connectors 21

2.7 Smart Switches 26

2.8 Dr. Debug 27

2.9 SLITM , 3-Way SLITM , 4-Way SLITM and Quad SLITM Operation

Guide 29

2.9.1 Installing Two SLITM-Ready Graphics Cards 29

2.9.2 Installing Three SLITM-Ready Graphics Cards 31

2.9.3 Installing Four SLITM-Ready Graphics Cards 33

2.9.4 Driver Installation and Setup 35

2.10 CrossFireXTM, 3-Way CrossFireXTM, 4-Way CrossFireXTM and

Quad CrossFireXTM Operation Guide 36

2.10.1 Installing Two CrossFireXTM-Ready Graphics Cards 36

2.10.2 Installing Three CrossFireXTM-Ready Graphics Cards 37

2.10.3 Installing Four CrossFireXTM-Ready Graphics Cards 38

2.10.4 Driver Installation and Setup 39

2.11 M.2_SSD (NGFF) Module Installation Guide 40

2.12 HDD Saver Cable Installation Guide 43

2.13 Dual LAN and Teaming Operation Guide 44

Chapter 3 Software and Utilities Operation 45

3.1 Installing Drivers 45

3.2 A-Tuning 46

3.3 ASRock APP Shop 52

3.3.1 UI Overview 52

3.3.2 Apps 53

3.3.3 BIOS & Drivers 56

3.3.4 Setting 57

3.4 Start8 58

Chapter 4 UEFI SETUP UTILITY 61

4.1 Introduction 61

4.1.1 UEFI Menu Bar 61

4.1.2 Navigation Keys 62

4.2 Main Screen 63

4.3 OC Tweaker Screen 64

4.4 Advanced Screen 72

4.4.1 CPU Conguration 73

4.4.2 Chipset Conguration 75

4.4.3 Storage Conguration 77

4.4.4 Super IO Conguration 78

4.4.5 ACPI Conguration 79

4.4.6 USB Conguration 80

4.4.7 Trusted Computing 81

4.5 Tools 82

4.6 Hardware Health Event Monitoring Screen 86

4.7 Security Screen 88

4.8 Boot Screen 89

4.9 Exit Screen 92

•

English

X99 WS

Chapter 1 Introduction

ank you for purchasing ASRock X99 WS motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality

and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock X99 WS Motherboard (EATX Form Factor)

• ASRock X99 WS Quick Installation Guide

• ASRock X99 WS Support CD

• 1 x I/O Panel Shield

• 2 x ASRock SLI_Bridge Cards

• 1 x ASRock SLI_Bridge_3S Card

• 1 x ASRock 3-Way SLI Bridge Card

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x HDD Saver Cable

• 1 x Screw for Ultra M.2 Socket

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • EATX Form Factor

• 2oz Copper PCB

• High Density Glass Fabric PCB

CPU • Supports Intel® CoreTM i7 and Xeon® E5-1600/2600 v3

Processor Family for the LGA 2011-3 Socket, up to 18 Cores

and 160W

• Digi Power design

• 12 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

• Supports Untied Overclocking Technology

Chipset • Intel® X99

Memory • Quad Channel DDR4 Memory Technology

• 8 x DDR4 DIMM Slots

• Supports DDR4 3000+(OC)*/2933+(OC)/2800(OC)/2400

(OC)/2133/1866/1600/1333/1066 non-ECC, un-buered

memory

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

• Supports non-ECC RDIMM (Registered DIMM)

• Supports DDR4 ECC, un-buered memory/RDIMM with

Intel® Xeon® processors E5 series in the LGA 2011-3 Socket

• Max. capacity of system memory: 128GB (see CAUTION)

• Supports Intel® Extreme Memory Prole (XMP) 2.0

• 15 Gold Contact in DIMM Slots

Expansion

Slot

• 5 x PCI Express 3.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE4/

PCIE6: single at x16 (PCIE1); dual at x16 (PCIE1) / x16

(PCIE4); triple at x8 (PCIE1) / x8 (PCIE2) / x16 (PCIE4);

quad at x8 (PCIE1) / x8 (PCIE2) / x8 (PCIE4) / x8 (PCIE6))

* If you install CPU with 28 lanes, PCIE1/PCIE2/PCIE3/PCIE4

will run at x16/x0/x4/x8 or x8/x8/x4/x8, and PCIE6 will be

disabled.

* If M.2 PCI Express module is installed, PCIE3 slot will be

disabled.

• 1 x PCI Express 2.0 x16 slot (PCIE5: x4 mode)

English

X99 WS

• Supports AMD Quad CrossFireXTM, 4-Way CrossFireXTM,

3-Way CrossFireXTM and CrossFireXTM

• Supports NVIDIA® Quad SLITM, 4-Way SLITM, 3-Way SLITM

and SLITM

* If you install CPU with 28 lanes, 4-Way CrossFireXTM and

4-Way SLITM are not supported.

• 15 Gold Contact in VGA PCIe Slot (PCIE1 and PCIE4)

Audio • 7.1 CH HD Audio with Content Protection (Realtek

ALC1150 Audio Codec)

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• Supports Purity SoundTM 2

- Nichicon Fine Gold Series Audio Caps

- 115dB SNR DAC with Dierential Amplier

- TI® NE5532 Premium Headset Amplier (Supports up to

600 Ohms headsets)

- Direct Drive Technology

- EMI Shielding Cover

- PCB Isolate Shielding

• Supports DTS Connect

LAN • 1 x Intel® I217LM (Gigabit LAN PHY 10/100/1000 Mb/s)

• 1 x Intel® I210AT (Gigabit LAN 10/100/1000 Mb/s)

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports Dual LAN with Teaming

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 1 x Optical SPDIF Out Port

• 1 x eSATA Connector

• 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

LED)

English

• 1 x Clear CMOS Switch

• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /

Front Speaker / Microphone

Storage • 10 x SATA3 6.0 Gb/s Connectors, support RAID (RAID

0, RAID 1, RAID 5, RAID 10 and Intel Rapid Storage 13),

NCQ, AHCI, Hot Plug and ASRock HDD Saver Technology

(S_SATA3_3 connector is shared with the eSATA port)

(S_SATA3_2 connector is shared with Ultra M.2 Socket)

* RAID is supported on SATA3_0 ~ SATA3_5 ports only.

• 1 x eSATA Connector, supports NCQ, AHCI and Hot Plug

• 1 x Ultra M.2 Socket, supports M.2 SATA3 6.0 Gb/s module

and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)

Connector • 2 x COM Port Headers

• 1 x TPM Header

• 1 x Power LED Header

• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin) (Smart Fan

Speed Control)

• 1 x Power Fan Connector (3-pin)

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector (Hi-Density Power Connec-

tor)

• 1 x HDD Saver Connector

• 2 x PCIe Power Connectors

• 1 x Front Panel Audio Connector

• 1 x underbolt AIC Connector

• 2 x USB 2.0 Headers (support 4 USB 2.0 ports) (Supports

ESD Protection (ASRock Full Spike Protection))

• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports

ESD Protection (ASRock Full Spike Protection))

• 1 x Dr. Debug with LED

• 1 x Power Switch with LED

• 1 x Reset Switch with LED

• 1 x BIOS Selection Switch

Andere Handbücher für X99 WS

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK P43R1600TWINS - V1.0 Bedienungsanleitung

ASROCK

ASROCK B85M-HDS Bedienungsanleitung

ASROCK

ASROCK Z87 Extreme6 Bedienungsanleitung

ASROCK

ASROCK G31M-VS2 - V1.1 Bedienungsanleitung

ASROCK

ASROCK K8 COMBO-Z Bedienungsanleitung

ASROCK

ASROCK G-Pro Series Bedienungsanleitung

ASROCK

ASROCK Z390 Taichi Ultimate Bedienungsanleitung

ASROCK

ASROCK H61M-PS4 Bedienungsanleitung

ASROCK

ASROCK 970 Pro Bedienungsanleitung

ASROCK

ASROCK H61M-DPS Bedienungsanleitung

ASROCK

ASROCK IMB-1314 Bedienungsanleitung

ASROCK

ASROCK GE PRO-HT R3.0 Bedienungsanleitung

ASROCK

ASROCK A785GMH128M Bedienungsanleitung

ASROCK

ASROCK Z170M-PIO2 Bedienungsanleitung

ASROCK

ASROCK FM2A78M-ITX+ Bedienungsanleitung

ASROCK

ASROCK 2CORE1066-2.13G - V1.0 Bedienungsanleitung

ASROCK

ASROCK K10N78D Bedienungsanleitung

ASROCK

ASROCK H610M-ITX/ac Bedienungsanleitung

ASROCK

ASROCK B660M Pro RS/AX Bedienungsanleitung

ASROCK

ASROCK H110M-HDV R3.0 Bedienungsanleitung

ASROCK

ASROCK AM5D4ID-2I/BCM Bedienungsanleitung

ASROCK

ASROCK P45DE3 Bedienungsanleitung

ASROCK

ASROCK P65iCafe Bedienungsanleitung

ASROCK

ASROCK Z790 Steel Legend WiFi Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
