ASROCK Z77E-ITX Bedienungsanleitung

Z77E-ITX

User Manual

Version 1.0

Published March 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identiﬁcation or explanation and to the owners’ beneﬁt, without intent to infringe.

Disclaimer:

Speciﬁcations and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or ﬁtness for a particular purpose.

In no event shall ASRock, its directors, ofﬁcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of proﬁts, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction......................................................... 7

1.1 Package Contents ......................................................... 7

1.2 Speciﬁcations................................................................. 8

1.3 Motherboard Layout....................................................... 13

1.4 I/OPanel ...................................................................... 15

1.5 WiFi-802.11n Module and ASRock WiFi 2.4GHz

Antenna ........................................................................ 17

2 Installation........................................................... 18

2.1 Screw Holes................................................................... 18

2.2 Pre-installation Precautions ......................................... 18

2.3 CPU Installation............................................................. 19

2.4 Installation of Heatsink and CPU fan............................. 21

2.5 Installation of Memory Modules (DIMM)........................ 22

2.6 Expansion Slots (PCI Express Slots)................................. 23

2.7 Dual Monitor and Surround Display Features................ 24

2.8 ASRock Smart Remote Installation Guide..................... 27

2.9 Jumpers Setup .......................................................... 29

2.10 Onboard Headers and Connectors ............................ 30

2.11 Serial ATA (SATA) / Serial ATA2 (SATA2) / Serial ATA3

(SATA3) Hard Disks Installation ................................. 34

2.12 Hot Plug and Hot Swap Functions for SATA / SATA2 /

SATA3 HDDs ................................................................. 34

2.13 SATA / SATA2 / SATA3 HDD Hot Plug Feature and

Operation Guide ........................................................ 35

2.14 Driver Installation Guide ............................................ 37

2.15 Installing Windows®7 / 7 64-bit With RAID Functions

....................................................................................... 37

2.16 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit Without RAID Functions ................... 38

2.16.1 Installing Windows®XP / XP 64-bit Without RAID

Functions............................................................ 38

2.16.2 Installing Windows®7 / 7 64-bit / VistaTM /

VistaTM 64-bit Without RAID Functions............... 38

3 UEFI SETUP UTILITY ................................................. 39

3.1 Introduction.................................................................... 39

3.1.1 UEFI Menu Bar .................................................... 39

3.1.2 Navigation Keys................................................... 40

3.2 Main Screen................................................................... 40

3.3 OC Tweaker Screen ...................................................... 41

3.4 Advanced Screen........................................................... 46

3.4.1 CPU Conﬁguration............................................... 47

3.4.2 North Bridge Conﬁguration................................... 49

3.4.3 South Bridge Conﬁguration.................................. 50

3.4.4 Storage Conﬁguration.......................................... 51

3.4.5 Intel(R) Rapid Start Technology........................... 52

3.4.6 Intel(R) Smart Connect Technology..................... 53

3.4.7 Super IO Conﬁguration ........................................ 54

3.4.8 ACPI Conﬁguration............................................... 55

3.4.9 USB Conﬁguration ............................................... 56

3.5 Hardware Health Event Monitoring Screen ................... 57

3.6 Boot Screen................................................................... 58

3.7 Security Screen ............................................................. 59

3.8 Exit Screen .................................................................... 60

4 Software Support................................................. 61

4.1 Install Operating System................................................ 61

4.2 Support CD Information................................................. 61

4.2.1 Running Support CD............................................ 61

4.2.2 Drivers Menu........................................................ 61

4.2.3 Utilities Menu........................................................ 61

4.2.4 Contact Information.............................................. 61

Chapter 1: Introduction

Thank you for purchasing ASRock Z77E-ITX motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conﬁgura-

tion guide to BIOS setup and information of the Support CD.

Because the motherboard speciﬁcations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modiﬁcations of this manual occur, the updated version

will be available on ASRock website without further notice. You may ﬁnd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speciﬁc information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock Z77E-ITX Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock Z77E-ITX Quick Installation Guide

ASRock Z77E-ITX Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x ASRock WiFi 2.4GHz Antenna (Optional)

1 x DVI-to-D-Sub Converter (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-

bit, it is recommended to set the BIOS option in Storage Conﬁguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

1.2 Specifications

Platform - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm

- Premium Gold Capacitor design (100% Japan-made

high-quality Conductive Polymer Capacitors)

CPU - Supports 3rd and 2nd Generation Intel®CoreTM i7 / i5 / i3 in

LGA1155 Package

- Digi Power Design

- 6 + 2 Power Phase Design

- Supports Intel®Turbo Boost 2.0 Technology

- Supports Intel®K-Series unlocked CPU

- Supports Hyper-Threading Technology (see CAUTION 1)

- Supports Intel®Rapid Start Technology and Smart Connect

Technology with Intel®Ivy Bridge CPU

Chipset - Intel®Z77

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)

- 2 x DDR3 DIMM slots

- Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/

1600/1333/1066 non-ECC, un-buffered memory

- Max. capacity of system memory: 16GB (see CAUTION 3)

- Supports Intel®Extreme Memory Proﬁle (XMP)1.3/1.2

Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)

(see CAUTION 4)

* PCIE 3.0 is only supported with Intel®Ivy Bridge CPU. With

Intel®Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x mini-PCI Express slot: For WiFi module

Graphics * Intel®HD Graphics Built-in Visuals and the VGAoutputs can

be supported only with processors which are GPU

integrated.

- Supports Intel®HD Graphics Built-in Visuals: Intel®Quick

Sync Video 2.0, Intel®InTruTM 3D, Intel®Clear Video HD

Technology, Intel®InsiderTM, Intel®HD Graphics 2500/4000

- Pixel Shader 5.0, DirectX 11 with Intel®Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel®Sandy Bridge

CPU.

- Max. shared memory 1760MB (see CAUTION 5)

- Multi VGA Output options: DVI, HDMI, DisplayPort and

D-Sub with the bundled DVI-to-D-Sub Converter

(see CAUTION 6)

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports DVI with max. resolution up to 1920x1200 @ 60Hz

- Supports DisplayPort with max. resolution up to 2560x1600

@ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required) (see CAUTION 7)

- Supports HDCP function with DVI, HDMI and DisplayPort

ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI, HDMI and DisplayPort ports

Audio - 7.1 CH HD Audio with Content Protection

(Realtek ALC898 Audio Codec)

- Premium Blu-ray audio support

- Supports THX TruStudioTM

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Broadcom BCM57781

- Supports Wake-On-LAN

- Supports Energy Efﬁcient Ethernet 802.3az

- Supports PXE

Wireless LAN WiFi-802.11n module

- 300Mbps IEEE 802.11n / 54Mbps IEEE 802.11g /

11Mbps IEEE 802.11b

- Supports Station mode (Infrastructure mode and Ad-hoc

mode)

Rear Panel I/O I/O Panel

- 2 x Antenna Ports

- 1 x PS/2 Mouse/Keyboard Port

- 1 x DVI-I Port

- 1 x HDMI Port

- 1 x DisplayPort

- 1 x Optical SPDIF Out Port

- 2 x Ready-to-Use USB 2.0 Ports

- 1 x eSATA2 Connector

- 4 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone (see CAUTION 8)

SATA3 - 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and Hot Plug

functions

USB3.0 - 2 x Rear USB 3.0 ports by Intel®Z77, support USB 1.0/2.0/3.0

up to 5Gb/s

- 2 x Rear USB 3.0 ports by ASMedia ASM1042, support USB

1.0/2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by

Intel®Z77, supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 2 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and Hot Plug

functions

- 1 x mSATA 3.0 Gb/s connector (Solid-State Drive

connector), supports RAID (RAID 0, RAID 1, RAID 5, RAID

10, Intel Rapid Storage and Intel Smart Response

Technology), NCQ, AHCI functions and Full-size mini-PCI

Express modules

- 2 x SATA3 6.0Gb/s connectors

- 1 x CIR header

- CPU/Chassis FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature - 64MbAMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU Core, IGPU, DRAM, VCCSA Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

Multimedia Suite - OEM

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 9)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 10)

- ASRock APP Charger (see CAUTION 11)

- ASRock SmartView (see CAUTION 12)

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your system. It should be

done at your own risk and expense. We are not responsible for possible damage

caused by overclocking.

- ASRock XFast USB (see CAUTION 13)

- ASRock XFast LAN (see CAUTION 14)

- ASRock XFast RAM (see CAUTION 15)

- ASRock Crashless BIOS (see CAUTION 16)

- ASRock OMG (Online Management Guard)

(see CAUTION 17)

- ASRock Internet Flash (see CAUTION 18)

- Lucid Virtu Universal MVP (see CAUTION 19)

* Lucid Virtu Universal MVP can be supported only with

processors which are GPU integrated.

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 20)

- ASRock U-COP (see CAUTION 21)

- Boot Failure Guard (B.F.G.)

- Good Night LED

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-

Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft®Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit /

XP / XP 64-bit compliant (see CAUTION 22)

Certiﬁcations - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 23)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. About the settings of “Hyper Threading Technology”, please check page

47.

2. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 22 for proper installation.

3. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®7 /

VistaTM / XP. For Windows®OS with 64-bit CPU, there is no such limita-

tion. You can use ASRock XFast RAM to utilize the memory that Win-

dows®cannot use.

4. Only PCIE1 slot supports Gen 3 speed. To run the PCI Express in Gen

3 speed, please install an Ivy Bridge CPU. If you install a Sandy Bridge

CPU, the PCI Express will run only at PCI Express Gen 2 speed.

5. The maximum shared memory size is deﬁned by the chipset vendor and

is subject to change. Please check Intel®website for the latest informa-

tion.

6. You can choose to use two of the three monitors only. DVI, HDMI and

DisplayPort monitors cannot be enabled at the same time. Besides, with

the DVI-to-HDMI adapter, the DVI port can support the same features as

HDMI port.

7. xvYCC and Deep Color are only supported under Windows®7 64-bit /

7. Deep Color mode will be enabled only if the display supports 12bpc

in EDID. HBR is supported under Windows®7 64-bit / 7 / VistaTM 64-bit /

VistaTM.

8. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 15

for proper connection.

9. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune dif-

ferent system functions in a user-friendly interface, which includes Hard-

ware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hardware

Monitor, it shows the major readings of your system. In Fan Control, it

shows the fan speed and temperature for you to adjust. In Overclocking,

you are allowed to overclock CPU frequency for optimal system per-

formance. In OC DNA, you can save your OC settings as a proﬁle and

share it with your friends. Your friends then can load the OC proﬁle to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve efﬁciency when the CPU cores are idle without sacriﬁcing

computing performance. Please visit our website for the operation proce-

dures of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

10. ASRock Instant Flash is a BIOS ﬂash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

Andere Handbücher für Z77E-ITX

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK IMB-R1000 Bedienungsanleitung

ASROCK

ASROCK H81 Pro BTC Bedienungsanleitung

ASROCK

ASROCK 880GXHU3/128M Bedienungsanleitung

ASROCK

ASROCK P55 EXTREME4 - Bedienungsanleitung

ASROCK

ASROCK M3A785GM-LE/128M Bedienungsanleitung

ASROCK

ASROCK 939Dual-VSTA Bedienungsanleitung

ASROCK

ASROCK Z390 Steel Legend Bedienungsanleitung

ASROCK

ASROCK Z97 Extreme6/ac Bedienungsanleitung

ASROCK

ASROCK Q270 Pro BTC+ Bedienungsanleitung

ASROCK

ASROCK AD425PV Bedienungsanleitung

ASROCK

ASROCK K7VM2 Bedienungsanleitung

ASROCK

ASROCK Z68 EXTREME4 - ANNEXE 541 Bedienungsanleitung

ASROCK

ASROCK 2CORE1066-2.13G - V1.0 Bedienungsanleitung

ASROCK

ASROCK Z87iCafe4 Bedienungsanleitung

ASROCK

ASROCK C246 WS Bedienungsanleitung

ASROCK

ASROCK B760M PC LIGHTNING Bedienungsanleitung

ASROCK

ASROCK ATW-HC2260 Bedienungsanleitung

ASROCK

ASROCK K10N78FULLHD-HSLI - R2.0 Bedienungsanleitung

ASROCK

ASROCK Z97 Anniversary Bedienungsanleitung

ASROCK

ASROCK AM2NF4G-SATA2 Bedienungsanleitung

ASROCK

ASROCK CML-HDV/M.2 TPM Bedienungsanleitung

ASROCK

ASROCK K7VT4A PRO Bedienungsanleitung

ASROCK

ASROCK ALIVEXFIRE-ESATA2 R3.0_987 - Bedienungsanleitung

ASROCK

ASROCK H55M-GE Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
