Associated Electrics RC82 Bedienungsanleitung

:: Introduction

:: Other Helpful Items

Associated Electrics, Inc.

26021 Commercentre Dr.

Lake Forest, CA 92630

http://www.TeamAssociated.com · http://www.RC10.com · http://twitter.com/Team_Associated · http://bit.ly/AEonFacebook

Customer Service

Tel: 949.544.7500

Fax: 949.544.7501

Thank you for purchasing this Team Associated product. This manual contains instructions and tips for building and maintaining

your new RC8.2 RTR. Please take a moment to read through it an familiarize yourself with these steps as they will help you to

understand each component’s function and show you some tips for getting the most out of your RC8.2 RTR. We are continually

changing and improving our designs; therefore, actual parts may appear slightly different than the illustrations.

Tools included with your vehicle:

• 1.5mm and 2.0mm L wrenches

• 2.5mm ball nose wrench

• Stamped turnbuckle wrench, 5mm & 5.5mm

• Shock tool, upper and lower pieces (#89358)

• 10mm clutch nut wrench (#7976)

• 5 in 1 wrench, 17mm, 10mm, 8mm, 7mm, 5.5mm

• Glow igniter (#7994) (requires 1 D sized battery)

• Fuel bottle 400cc (#1749)

• Glow plug (#MC59)

Your RC8.2 RS RTR kit comes ready to run.

However there are some things that are necessary to complete the kit.

• Transmitter batteries (6 AA) (#302, 303 recommended)

• Receiver batteries (4 AA) (#302, 303 recommended)

-OR-

• 4.8-7.4v rechargeable receiver battery pack

• either flat (#613) or hump (#612) style NiMh battery

• either 1600mAh LiPo (#630), 2100mAh LiPo (#631),

• -OR- 1700 LiFe (#638) battery (recommended)

• Additional Glow plugs (#MC59) • Glow igniter battery (1 D)

• Model car fuel (20%-30% nitro recommended)

• Silicone Shock Fluid / Differential Fluid (Refer to catalog for complete listings)

• Body Scissors (AE Part # 1737) • Wire cutters • Soldering Iron • FT Threadlock (#1596)

• FT Hex Wrenches (AE Part # 1541, 1655) • Starter box (#1750 recommended) • FT Turnbuckle Wrench (#89240)

• FT Nut Drivers (AE Part #1561, 1663-1668) • Calipers or a Precision Ruler • Green Slime shock lube (AE Part # 1105)

• Needle nose pliers • Hobby knife • Reamer/hole punch • Ride Height Gauge (#1449 recommended)

:: Items Included :: Additional Items Needed

:: RC8.2 RS RTR Platform Features :: RC8 Platform Features

RC8.2 RS RTR Features:

• Powerful Reedy .21VS engine with pull start and

Team Associated 2-chamber tuned exhaust

• XP 2.4Ghz radio system with digital high torque

XP DS1510MG metal gear steering servo and water resistant

receiver box

• 16mm Big Bore 6061 aluminum shock bodies and caps with

rubber shock boots

• Low center of gravity 3mm thick 7075 aluminum shock

towers

• Black hard-anodized 7075 aluminum chassis with keyed

lower suspension plates

• Updated RC8.2 racing suspension geometry

• Aluminum steering knuckles for improved durability

• Choice of two factory finished RC8 bodies

• Lightweight and durable drivetrain

• Upgraded Dual bell-crank steering rack for reduced

bump-steer

• 4.30:1 ratio gearboxes

• 43T diff ring and 10T pinion for increased punch and

durability over conventional buggy ratio gearboxes

• Brakes

• Brake cam stops ensure brakes aren’t dragging while on

throttle.

• 2 piece Center diff housing split vertically for easy diff

removal and maintenance

• Caster blocks adjust 14, 16, or 18 degrees with molded

inserts

• Low profile elliptical 2-stage air filter

• PTFE clutch shim and easy to build design

• Adjustable with 0.9mm, 1.0 mm, and 1.1 mm springs

(only 1.0mm included)

• Fuel tank

• Easily removeable fuel tank only 2 body clips for easy

cleaning

3/13

24-25.........Shocks Install

25-29.........Radio Tray Assembly

29-32.........Fuel Tank, Air Filter, and Engine

Assembly

33................Wheel, Tires, and Body

Assembly

34-36.........TechTips

37-49.........Catalog

49................Contact Info

49-50.........Notes

51.................Setup Sheet “Kit Setup”

52................1:1 Hardware “Fold Out

53................Setup Sheet “Blank”

54................Back Cover

:: Table of Contents

:: Notes

This symbols indicates

a special note or

instruction in the manual.

!There is a 1:1 hardware foldout page in the back

of the manual. To check the size of a part, line

up your hardare with the correct drawing until

you find the exact size. Each part in the foldout

has a number assigned to it for ordering

replacement parts.

1....................Cover

2....................Introduction

3....................Table of Contents

4-5...............Front and Rear Diff Assembly

6-7................Center Diff Assembly

7-8...............Steering, Servo, and Rear

Camber Links Assembly

8-10.............Shocks Assembly

10.................Chassis Assembly

10-12..........Steering Assembly

12-13..........Front Geaerbox Assembly

14-17..........Front Suspension Assembly

17-19.........Rear Gearbox Assembly

19-22.........Rear Suspension Assembly

22-23.........Center Bulkhead Assembly

Associated Electrics, Inc.

26021 Commercentre Dr.

Lake Forest, CA 92630

http://www.TeamAssociated.com · http://www.RC10.com · http://twitter.com/Team_Associated · http://bit.ly/AEonFacebook

Customer Service

Tel: 949.544.7500

Fax: 949.544.7501

:: Front/Rear Differential Assembly

:: Front/Rear Differential Assembly (cont.)

89120

Diff

outdrive

89120

Sun gear

89120

Spider

gear

assembly

25236

8x16mm

bearing

89496

Diff

outdrive

16mm

89121

Diff

O-Ring

89115

Diff

housing

Align pin with

groove in sun gear

#6588

black grease

89120

Diff

washer

89121

Diff

O-Ring

#6588

black grease

:: Front/Rear Differential Assembly (cont.)

89120

Diff

outdrive

89116

Diff

gasket

25236

8x16mm

bearing

89113

Diff ring

gear

89121

Diff

O-Ring 89121

Diff

O-Ring

89496

Diff

outdrive

16mm

#6588

black grease

#6588

black grease

#6588

black grease

89120

Diff

washer

89208

3x14mm

fhcs

Diff fluid

5,000cst

#5453

Tighten screws

evenly and firmly.

Thin Gasket

Fill with diff fluid to

top of gears.

Build

front and

rear diffs!

Align pin with

groove in sun gear

89120

Sun gear

:: Center Differential Assembly

:: Center Differential Assembly (cont.)

Align pin with

groove in sun gear

89120

Sun gear

89115

Diff

housing

25236

8x16mm

bearing

89121

Diff

O-Ring

89496

Diff

outdrive

16mm

89120

Diff

washer

89121

Diff

O-Ring

89110

Spur gear

(46T)

89496

Diff

outdrive

16mm

25236

8x16mm

bearing

89121

Diff

O-Ring

#6588

black grease

#6588

black grease

#6588

black grease

89120

Diff

outdrive

89120

Spider

gear

assembly

:: Center Differential Assembly (cont.)

:: Steering Turnbuckle Assembly

Align pin with

groove in sun gear

89120

Sun gear

89116

Diff gasket

#6588

black grease

89120

Diff

outdrive

89120

Diff

washer

89121

Diff

O-Ring

89208

3x14mm

fhcs

Tighten screws

evenly and firmly.

Fill with diff fluid to

top of gears.

Diff fluid

5,000cst

#5453

89074

Steering

eyelet

89075

Steering

ballstud

17.8mm

89268

42mm steel

turnbuckle

Build right

and left

sides!

:: Servo Link Assembly

:: Rear Camber Link Assembly

:: Shock Assembly

89076

Camber

ball joints

89076

Camber

pivot balls

89076

Camber

rod end

89269

38mm steel

turnbuckle x2

Build right

and left

sides!

7.7mm

89358

Lower

shock tool

89066

Shock

O-rings

89352

Spacer

89358

Lower

Use the lower shock tool

to load the two o-rings

and spacer for easy

lubing and installation

into the shock body

Shock

fluid

89580

16x29mm

RTR shock

body (front)

89582

16x38mm

RTR shock

body (rear)

89078

Straight

eyelet

89267

32mm steel

turnbuckle

7.5mm 89078

balljoint

:: Shock Assembly - (cont.)

89335

Shock

cap

89396

Shock

collar

89351

Shock

bladder

Some residual shock

fluid may appear from

your first few runs

around the shock cap

as a result of bleeding.

Bladder Installation

As you install the shock cap with the bladder, it will force

out any extra fluid. If you install the cap with the shaft

fully extended, you are running FULL REBOUND.

To run less rebound, unthread the cap 1-2 turns and

compress the shaft to the desired position and

re-tighten the cap with the shaft compressed.

Start with no rebound.

A B C

89065

Shock

rod end

Short boots for

front shocks.

Long boots for

rear shocks.

89556

RC8.2

shock boot

(front shown)

89065

Shock rod

end ball

Fill to top with

shock fluid:

Front: 40wt

#5423

Rear 30 wt

#5422

Shock

fluid

89278

2.5mm

piston

washer

89353

Shock piston

set (1.3, blank)

89215

Locknut

(piston)

89352

O-Ring

89352

Bottom

nut

89358

Upper

shock

tool

Shock

fluid

One drop of

shock

fluid on

threads.

89261

Shock shaft,

38mm (rear)

89260

Shock shaft,

29mm, (front)

:: Shock Assembly - (cont.)

:: Chassis Assembly

:: Steering Assembly

89258

Front

chassis

brace

25215

locknut

89455

3x22mm

fhcs

89010

Top plate

(lower)

3 dot down

hinge pin

bushing

89476

RC8B

+3mm

chassis

89552

Side guards

(left & right)

25201

3x8mm

fhcs

89293

Front spring,

silver (3.9lbs)

(short spring)

89348

Rear spring,

silver (3.3lbs)

(long spring) 89354

16mm

shock

spring cup

Build two

front and

two rear

shocks!

89396

Shock

pre-load

clips

89396

Shock

pre-load

clips

Front shock: 7mm

Rear shock: 2mm

10mm

5mm

3mm

2mm

1mm

89552

Side guards

(left & right)

25201

3x8mm

fhcs

x4x4

Side guards

25215

locknut

25203

3x12mm

fhcs

25202

3x10mm

fhcs

25202

3x10mm

fhcs

89010

Top plate

(upper)

89011

Top plate

(upper)

89039

Hinge pin

bushing

(3 dot down)

Andere Handbücher für RC82

Inhaltsverzeichnis

Andere Associated Electrics Motorisiertes Spielzeugauto Handbücher

Associated Electrics

Associated Electrics T4.1 Bedienungsanleitung

Associated Electrics

Associated Electrics 8400 Bedienungsanleitung

Associated Electrics

Associated Electrics RC10B5M Factory Lite Team Kit Bedienungsanleitung

Associated Electrics

Associated Electrics 12R5.1 FactoryTeam Bedienungsanleitung

Associated Electrics

Associated Electrics Element RC Enduro Bushido RTR Handbuch

Associated Electrics

Associated Electrics RC10L-Graphite Bedienungsanleitung

Associated Electrics

Associated Electrics RC19T Bedienungsanleitung

Associated Electrics

Associated Electrics SC10 4x4 Bedienungsanleitung

Associated Electrics

Associated Electrics RC10 SC5m Bedienungsanleitung

Associated Electrics

Associated Electrics RC10GT Bedienungsanleitung

Associated Electrics

Associated Electrics RC10GT Bedienungsanleitung

Associated Electrics

Associated Electrics RC10TC6 Factory Team Bedienungsanleitung

Associated Electrics

Associated Electrics RC8B3.1 Bedienungsanleitung

Associated Electrics

Associated Electrics TEAM ASSOCIATED RC10B4 Bedienungsanleitung

Associated Electrics

Associated Electrics ELEMENT RC ENDURO GATEKEEPER KIT 40110 Handbuch

Associated Electrics

Associated Electrics RC18 Bedienungsanleitung

Associated Electrics

Associated Electrics RC10T Bedienungsanleitung

Associated Electrics

Associated Electrics Rival MT10 Bedienungsanleitung

Associated Electrics

Associated Electrics TEAM ASSOCIATED RC10B4 B4 Bedienungsanleitung

Associated Electrics

Associated Electrics Element RC Enduro Bedienungsanleitung

Associated Electrics

Associated Electrics Monster MGT8.0 Bedienungsanleitung

Associated Electrics

Associated Electrics RC10 T4.2 Bedienungsanleitung

Associated Electrics

Associated Electrics RC10L2 Road Series Bedienungsanleitung

Associated Electrics

Associated Electrics Mini MGT 3.0 Bedienungsanleitung

Beliebte Motorisiertes Spielzeugauto Handbücher anderer Marken

Eduard

Eduard Humber Scout Car Mk.I exterior Bedienungsanleitung

Traxxas

Traxxas 4995X Bedienungsanleitung

Jamara

Jamara VW T1 Bus Bedienungsanleitung

REVELL

REVELL 68 CHEVY CHEVELLE SS 396 Bedienungsanleitung

Schumacher

Schumacher Pro Cat Bedienungsanleitung

Tamiya

Tamiya TT-01 TYPE E Bedienungsanleitung

Eduard

Eduard Krupp Protze 6x4 1/48 Bedienungsanleitung

New Bright

New Bright 61072UEP Bedienungsanleitung

Team Durango

Team Durango DEX410v5 Bedienungsanleitung

Jamara

Jamara Mercedes Actros Muldenkipper 2,4 GHz Bedienungsanleitung

PLAYMOBIL

PLAYMOBIL 9536 Bedienungsanleitung

Atomic

Atomic BZ3 Bedienungsanleitung

Aiyaplay

Aiyaplay 370-290V00 Bedienungsanleitung

Power Wheels

Power Wheels GRJ53 Bedienungsanleitung

ZEROTRIBE

ZEROTRIBE Zetricks ZT1144 Bedienungsanleitung

INJUSA

INJUSA 412 Bedienungsanleitung

Maverick

Maverick MSC-30BR-WP Bedienungsanleitung

Land of B.

Land of B. Rollin' Riders Bedienungsanleitung
