Asus ROG Vulcan ANC Bedienungsanleitung

ROG Vulcan ANC

Active Noise-Canceling Gaming Headset

U7449 / First Edition / May 2012

Quick Start Guide

English...........................................2

French............................................5

German .........................................8

Italian .............................................11

Russian ..........................................14

Czech .............................................17

Danish............................................20

Dutch .............................................23

Finnish ...........................................26

Greek..............................................29

Hungarian ....................................32

Norwegian ...................................35

Polish..............................................38

Portuguese ..................................41

Romanian .....................................44

Slovenian......................................47

Slovensky......................................50

Spanish..........................................53

Swedish.........................................56

Ukrainian ......................................59

Türkçe............................................62

U7449_Vulcan_ANC_QSG.indb 1 5/23/12 1:41:55 PM

Quick Start Guide2

English

ASUS ROG Vulcan ANC

Package contents

• 1 x ROG Vulcan ANC headset

• 1 x Audio cable

• 1 x AAA battery

Getting to know your headset

1. Adjustable headband

Allows you to adjust the headset for a snug ﬁt on your head.

2. Ear cups

Provides you with an enhanced audio experience.

3. Battery cover

Contains the battery slot.

4. Battery cover button

Push this button to open the battery cover.

5. ANC activity LED

A red LED indicates that the active noise cancelation control function is

turned on.

6. ANC switch

Allows you to turn on/off the active noise cancelation control function.

7. Audio port

Insert the audio cable into this port.

8. Microphone port

Insert the microphone into this port.

9. In-line microphone jack storage clip

Allows you to clip the headset adapter on your pocket.

10. Volume control

Allows you to increase/decrease the volume.

11. Mute control

Allows you to put the microphone on mute mode.

12. Microphone

Insert the microphone into the microphone port for a two-way

communication.

To wear your headset

• Adjust the headband so it ﬁts snugly on your head.

• Adjust the ear cups so it ﬁts comfortably around your ears.

• Move the volume control to increase/decrease the volume.

Wearing your headset

NOTE: There are L and R markings on the ear cups.

• 1 x Microphone

• 1 x Quick Start Guide

• 1 x Protective case

Speciﬁcation summary

Driver: 40mm

Impedance: 32 ohms

Frequency range: 10~20 Khz

ANC (Active noise cancelation) performance: Maximum >15dB

Effective Bandwidth >600MHz

PNC (Passive noise cancelation) performance: Maximum >30dB

Battery life: Up to 40 hours (with one AAA battery)

Dimension (mm): 206mm x 196mm x 80mm (L x W x H)

Weight: 325g

U7449_Vulcan_ANC_QSG.indb 2 5/23/12 1:42:00 PM

Quick Start Guide

ASUS ROG Vulcan ANC 3

English

Getting to know your headset

1. Adjustable headband

Allows you to adjust the headset for a snug ﬁt on your head.

2. Ear cups

Provides you with an enhanced audio experience.

3. Battery cover

Contains the battery slot.

4. Battery cover button

Push this button to open the battery cover.

5. ANC activity LED

A red LED indicates that the active noise cancelation control function is

turned on.

6. ANC switch

Allows you to turn on/off the active noise cancelation control function.

7. Audio port

Insert the audio cable into this port.

8. Microphone port

Insert the microphone into this port.

9. In-line microphone jack storage clip

Allows you to clip the headset adapter on your pocket.

10. Volume control

Allows you to increase/decrease the volume.

11. Mute control

Allows you to put the microphone on mute mode.

12. Microphone

Insert the microphone into the microphone port for a two-way

communication.

To wear your headset

• Adjust the headband so it ﬁts snugly on your head.

• Adjust the ear cups so it ﬁts comfortably around your ears.

• Move the volume control to increase/decrease the volume.

Wearing your headset

NOTE: There are L and R markings on the ear cups.

• 1 x Microphone

• 1 x Quick Start Guide

• 1 x Protective case

Speciﬁcation summary

Driver: 40mm

Impedance: 32 ohms

Frequency range: 10~20 Khz

ANC (Active noise cancelation) performance: Maximum >15dB

Effective Bandwidth >600MHz

PNC (Passive noise cancelation) performance: Maximum >30dB

Battery life: Up to 40 hours (with one AAA battery)

Dimension (mm): 206mm x 196mm x 80mm (L x W x H)

Weight: 325g

U7449_Vulcan_ANC_QSG.indb 3 5/23/12 1:42:01 PM

Quick Start Guide4

English

Installing the battery

To install the battery

1. Turn off the ANC switch.

2. Push the battery cover button to open

and remove the battery cover.

3. Install one AAA battery in the battery slot.

4. Replace the battery cover.

NOTE: Remove the battery if you are not going to use your headset

for a long time.

Connecting the microphone and the audio cable

To connect the microphone

Connect the microphone to the headset’s microphone port.

To connect the audio cable

1. Connect the audio cable to the headset’s audio port.

2. Connect the audio cable’s headphone and microphone connectors to

your computer’s headphone and microphone ports.

Activating the noise-canceling function

The noise-canceling function removes ambient noise such as background

noise for a clearer sound quality.

To activate the noise-canceling function

Slide the ANC switch to the right to activate the noise-canceling function.

The activity LED turns red.

Storing your headset

To store your headset

1. Fold one side,then the other, ensuring that

pressure is applied to the hinges and not on the

ear cups.

2. Put your headset and its accessories in the

protective case.

U7449_Vulcan_ANC_QSG.indb 4 5/23/12 1:42:03 PM
