Asus IPIBL-LA Berkeley-GL8E Bedienungsanleitung

Motherboard

IPIBL-LA

(Berkeley-GL8E)

E3188

First Edition V1

April 2007

IPIBL-LA (Berkeley-GL8E) specications summary................................ iii

1. Motherboard layout......................................................................... 1

2. Central Processing Unit (CPU) ...................................................... 2

2.1 Overview ............................................................................ 2

2.2 Installing the CPU .............................................................. 2

3. System memory .............................................................................. 5

3.1 Memorycongurations....................................................... 5

3.2 Installing a DDR2 DIMM .................................................... 7

3.3 Removing a DDR2 DIMM .................................................. 7

4. Expansion slots .............................................................................. 8

4.1 Installing an expansion card .............................................. 8

4.2 Conguringanexpansioncard .......................................... 8

4.3 Interruptassignments ........................................................ 9

4.4 PCI Express x16 slot........................................................ 10

4.5 PCI Express x1 slot.......................................................... 10

4.6 PCI slots........................................................................... 10

5. Jumpers ..........................................................................................11

6. Connectors .................................................................................... 12

6.1 Rear panel connectors..................................................... 12

6.2 Internal connectors .......................................................... 14

Contents

iii

IPIBL-LA (Berkeley-GL8E) specications

summary

(continued on the next page)

CPU LGA775 socket for the Intel®Conroe//Kentseld

processor

Chipset Northbridge: Intel®G33MemoryControllerHub(MCH)

Southbridge:Intel®ICH9R

Front Side Bus(FSB) 1066 MHz/800MHz/533MHz

Memory Dual-channelmemoryarchitecture

4x240-pinDIMMsocketssupportunbufferednon-ECC

 8GB800/667MHzDDR2memorymodules

Expansion slots 1 x PCI Express x16 slot for discrete graphics card

2 x PCI Express x1 slot

1 x PCI slots

Rear panel 1 x PS/2 keyboard port

1xPS/2mouseport

1 x IEEE 1394a port

1xLAN(RJ-45)port

1 x VGA Connector

6xaudioportssupport8-channelsaudioconguration

4xUSB2.0portssupporthot-plugfunction

1xCoaxialSPDIFoutport

1 x Coaxial SPDIF in port

Internal connectors 1 x Floppy connector

1x24-pinATXpowerconnector

1x4-pinATX12Vpowerconnector

6xSerialATAconnectors

1 x IEEE 1394a connector

4 x USB 2.0 connectors

1 x CPU fan connector

1 x System fan connectors

1 x HDMI connector

1xDigitalaudioconnector

1xFrontpanelaudioconnector

1 x System panel connector

Storage Southbridgesupports:

6xSerialATAharddiskdriveswithhot-swapfunction

Audio Southbridgesupports8-channelaudiocongurationwith

Realtek®ALC888SHighDenitionAudioCODEC

LAN Intel® 82566DC 10/100/1000 Mbps Fast Ethernet LAN

PHY

IPIBL-LA (Berkeley-GL8E)-LA specications

summary

IEEE 1394 AgereLFW3227supportstwoIEEE1394aports

PC health monitoring ASUS F8000 for CPU, system, chassis fan control,

 motherboard,andCPUtemperature

BIOS features 8MbSPIashROM

HP BIOS with enhanced ACPI, DMI, Green, and PnP

 FeaturesPlus

Form factor Micro-ATXformfactor:9.6inx9.6in

*Specicationsaresubjecttochangewithoutnotice.

IPIBL-LA(Berkeley-GL8E) 1

1. Motherboard layout

PCIEX1_2

IPIBL-LA

PS/2KBMS

T: Mouse

B: Keyboard

ALC888S

FLOPPY

DDR2 XMM1 (64 bit,240-pin module)

SYS_FAN1

FRONT_USB6

24.5cm (9.6in)

PCI

Intel

ICH9R

Intel

Bearlake

GMCH

BUZZ1 F_PANEL1

ATX12V

CPU_FAN1

CLEAR CMOS

CLEAR PWD

ASUS

F8000

FRONT_1394

Below:Mic In

Center:Line Out

Top:Line In

PCIEX16

SPDIF2

DDR2 XMM2 (64 bit,240-pin module)

DDR2 XMM3 (64 bit,240-pin module)

DDR2 XMM4 (64 bit,240-pin module)

SATA1

SATA2

FRONT_USB1

24.5cm (9.6in)

Agere

LFW3227

Intel

82566DC

LGA775

SPDIF1

I_1394

USB

LAN+USB

BIOS

HDMI_HEADER1

PCIEX1_1

CR2032 3V

Lithium Cell

CMOS Power

FRONT_USB2

ATXPWR

Top:

Subwoofer Speaker Out

Center

Rear Speaker Out

Below

Side Speaker Out

VGA

FRONT_USB5

FRONT_USB4FRONT_USB3

SATA3

SATA4

SATA5

SATA6

IPIBL-LA(Berkeley-GL8E)2

2. Central Processing Unit (CPU)

2.1 Overview

ThemotherboardcomeswithasurfacemountLGA775socketdesignedforthe

Intel®Mainstream/ValueFMBprocessorinthe775-landpackage.

2.2 Installing the CPU

ToinstallaCPU:

1. Locate the CPU socket on the motherboard.

BeforeinstallingtheCPU,makesurethatthesocketboxisfacingtowardsyou

andtheloadleverisonyourleft.

IPIBL-LA

IPIBL-LA(Berkeley-GL8E)

CPU Socket 775

2. Presstheloadleverwithyourthumb(A),thenmoveittotheleft(B)untilitis

released from the retention tab.

Retention tab

Load lever

This side of the socket box

should face you.

PnP cap

Topreventdamagetothesocketpins,donotremovethePnPcapunlessyou

are installing a CPU.

IPIBL-LA(Berkeley-GL8E) 3

3. Lift the load lever in the direction of

the arrow to a 135º angle.

5. Position the CPU over the

socket,makingsurethat

the gold triangle is on the

bottom-leftcornerofthe

socketthentthesocket

alignment key into the

CPU notch.

Alignment key

Gold triangle mark

4. Lifttheloadplatewithyourthumb

andforengertoa100ºangle(A),

thenpushthePnPcapfromtheload

platewindowtoremove(B).

Load plate

CPU notch

TheCPUtsinonlyonecorrectorientation.DONOTforcetheCPUintothe

socket to prevent bending the connectors on the socket and damaging the CPU!

IPIBL-LA(Berkeley-GL8E)4

• Thismotherboard supportsIntel® Mainstream/ValueFMB processorin the

775-landpackagewithHyper-ThreadingTechnology.

• Hyper-ThreadingTechnologyissupportedunderWindows®XP/2003Server/

VistaandLinux2.4.x(kernel)andlaterversionsonly.UnderLinux,usethe

Hyper-Threadingcompilertocompilethe code.Ifyouareusing anyother

operating systems, disable the Hyper-Threading Techonology item in the

BIOStoensuresystemstabilityandperformance.

• Installing Windows®XPServicePack1orlaterversionisrecommended.

• MakesuretoenabletheHyper-ThreadingTechnologyiteminBIOSbefore

installingasupportedoperatingsystem.

• FormoreinformationonHyper-ThreadingTechnology,visitwww.intel.com/

info/hyperthreading.

TousetheHyper-ThreadingTechnologyonthismotherboard:

1. Install an Intel®Intel®Mainstream/ValueFMBprocessorthatsupportsHyper-

ThreadingTechnology.

2. PowerupthesystemandentertheBIOSSetup.UndertheAdvancedMenu,

makesurethattheitemHyper-ThreadingTechnologyissetto[Enabled].

TheitemappearsonlyifyouinstalledaCPUthatsupportsHyper-Threading

Techonology.

3. Rebootthecomputer.

6. Closetheloadplate(A),then

pushtheloadlever(B)untilit

snaps into the retention tab.

7. Ifinstallingadual-coreCPU,

connect the chassis fan cable

to the CHA_FAN1 connector to

ensuresystemstability.

Notes on Intel® Hyper-Threading Technology

IPIBL-LA(Berkeley-GL8E) 5

3. System memory

ThemotherboardcomeswithfourDoubleDataRate2(DDR2)DualInlineMemory

Module(DIMM)sockets.

ADDR2modulehasthesamephysicaldimensionsasaDDRDIMMbuthasa

240-pinfootprintcomparedtothe184-pinDDRDIMM.DDR2DIMMsarenotched

differently to prevent installation on a DDR DIMM socket.

ThefollowinggureillustratesthelocationoftheDDR2DIMMsockets.

3.1 Memory congurations

Youcaninstall512MB,1GB,and2GBDDR2SDRAMDIMMsintotheDIMM

socketsusingthememorycongurationsinthissection.

• InstallingDDR2DIMMsotherthantherecommendedcongurations

maycausememorysizingerrororsystembootfailure.Useanyofthe

recommendedcongurationsonthenextpage.

• Install only identical(thesametypeandsize)DDR2DIMMpairsusingthe

recommendedcongurations.

• MakesurethatthememoryfrequencymatchestheCPUFSB(FrontSide

Bus).RefertotheMemoryfrequency/CPUFSBsynchronizationtableon

the next page.

• Thismotherboarddoesnotsupportdouble-sided16-bitDDRDIMMs.

• Donotcreateathree-DIMMcongurationindual-channelmode.Thethird

DIMMisignoredinthedual-channeloperation.

IPIBL-LA

IPIBL-LA(Berkeley-GL8E)

240-pin DDR2 DIMM sockets

XMM1

XMM2

XMM3

XMM4

IPIBL-LA(Berkeley-GL8E)6

Recommended memory congurations

* Use only identical DDR2 DIMM pairs.

Memory frequency/CPU FSB synchronization

Sockets

Mode DIMM1 DIMM2 DIMM3 DIMM4

Single-channel

(1) Installed – – –

(2) – Installed – –

(3) – – Installed –

(4) – – – Installed

Dual-channel*

(1) Installed – Installed –

(2) – Installed – Installed

(3) Installed Installed Installed Installed

CPU FSB DDR DIMM Type Memory Frequency

1066MHz PC2-6400/PC2-5300/PC2-4200 800/667/553 MHz

800MHz PC2-6400/PC2-5300/PC2-4200 667/533 MHz

533MHz PC2-5300/PC2-4200 667/533 MHz
