Asus E9022 Bedienungsanleitung

USER GUIDE

E9022

ASUS Tablet

First Edition

March 2014

E9022_FE170CG_User_Guide.indd 1 2014/3/26 �� 02:25:02

Charging your device

Ensure to fully charge your ASUS Tablet before using it in

battery mode for extended periods. Remember that the power

adapter charges your ASUS Tablet as long as it is plugged into

an AC power source. Be aware that it takes much longer to

charge the ASUS Tablet when it is in use.

IMPORTANT! Do not leave the ASUS Tablet connected to

the power supply once it is fully charged. ASUS Tablet is not

designed to be left connected to the power supply for extended

periods of time.

Airplane precautions

Contact your airline provider to learn about related inight

services that can be used and restrictions that must be followed

when using your ASUS Tablet in-ight.

IMPORTANT! You can send your ASUS Tablet through x-ray

machines (used on items placed on conveyor belts), but do not

expose them from magnetic detectors and wands.

Safety precautions

This ASUS Tablet should only be used in enviroments with

ambient temperatures between 0°C to 35°C (32°F to 95°F).

Long time exposure to extremely high or low temperature

may quickly deplete and shorten the battery life. To ensure the

battery’s optimal performance, ensure that it is exposed within

the recommended environment temperature.

E9022_FE170CG_User_Guide.indd 2 2014/3/26 �� 02:25:02

ASUS Tablet

Package contents

NOTES:

• Ifanyoftheitemsisdamagedormissing,contactyour

retailer.

• *Thesecontentsvarywithcountryorregion.

Powercharger* Poweradapter*

ASUS Tablet

USER GUIDE

ASUS Tablet

Technical

documentations and

warranty card

MicroUSBcable*

E9022_FE170CG_User_Guide.indd 3 2014/3/26 �� 02:25:03

ASUS Tablet

Touch screen panel

Your ASUS Tablet

Front view

Front camera

Audio speaker/

Earpiece receiver

E9022_FE170CG_User_Guide.indd 4 2014/3/26 �� 02:25:03

ASUS Tablet

Rear view

Micro USB 2.0 port

Volume button

Power button

Speaker/Headset port Rear camera

Side compartment

E9022_FE170CG_User_Guide.indd 5 2014/3/26 �� 02:25:03

ASUS Tablet

Inside the side compartment

microSIMcardslots**

microSDcardslot*

* ThemicroSDcardslotsupportsmicroSDandmicroSDHCcardformats.

** ThemicroSIMcardslotssupportWCDMAandEDGE/GSMnetworkbands.

NOTE: ThenumberofmicroSIMcardslotsvarybycountryor

region.

E9022_FE170CG_User_Guide.indd 6 2014/3/26 �� 02:25:03

ASUS Tablet

Charging your ASUS Tablet

Using the power adapter and micro USB cable

To charge your ASUS Tablet:

Connect the micro USB cable to the power adapter.

Plug the micro USB connector into your ASUS Tablet.

Plug the power adapter into a grounded power outlet.

Charge your ASUS Tablet for eight (8) hours before

using it in battery mode for the rst time.

E9022_FE170CG_User_Guide.indd 7 2014/3/26 �� 02:25:03

ASUS Tablet

Using the power charger

To charge your ASUS Tablet:

Plug the micro USB connector into your ASUS Tablet.

Plug the power charger into a grounded power outlet.

Charge your ASUS Tablet for eight (8) hours before

using it in battery mode for the rst time.

E9022_FE170CG_User_Guide.indd 8 2014/3/26 �� 02:25:04

ASUS Tablet

IMPORTANT!

• UseonlythebundledpoweradapterandmicroUSBcable

to charge your ASUS Tablet. Using a dierent power adapter

may damage your ASUS Tablet.

• Peeltheprotectivelmofromthepoweradapterandmicro

USB cable before charging the ASUS Tablet to prevent risk or

injury.

• Ensuretoplugthepoweradaptertothecorrectpoweroutlet

with the correct input rating. The output voltage of this

adapter is DC 5 V, 1 A.

• WhenusingyourASUSTabletwhileplugged-intoapower

outlet, the grounded power outlet must be near the unit and

easily accessible.

• DonotplaceobjectsontopofyourASUSTablet.

NOTES:

• YourASUSTabletcanbechargedviatheUSBportona

computer only when it is in sleep mode (screen o) or turned

o.

• ChargingthroughaUSBportofacomputermaytakelonger

time to complete.

• Ifyourcomputerdoesnotprovideenoughpowerfor

charging your ASUS Tablet, charge your ASUS Tablet via the

grounded power outlet instead.

E9022_FE170CG_User_Guide.indd 9 2014/3/26 �� 02:25:04

ASUS Tablet

Installing a micro SIM card

Before you can make calls, send text messages, or connect to a

mobile broadband network using your ASUS Tablet, you need

toinstallamicroSIM(SubscriberIdentityModule)card.

NOTE: ThenumberofmicroSIMcardslotsvarybycountryor

region.

ToinstallamicroSIMcard:

1. Open the side compartment cover of your ASUS Tablet.

E9022_FE170CG_User_Guide.indd 10 2014/3/26 �� 02:25:04
