Asus RT-N56U Bedienungsanleitung

HKBN_SETUP_ROUTER_ASUS_ENG_230315

ASUS Wireless Router

(RT-N56U) Setup User’s Guide

HKBN_SETUP_ROUTER_ASUS_ENG_230315

1 Get to know the ASUS router..............................................................................................2

A. Tech Specs - Connections and Expansion .................................................................2

B. Minimum System Requirements (bb500/ FibreHome500/ bb1000/ FibreHome1000).2

2 Connecting to ASUS router.................................................................................................3

3 Switching your broadband Internet service to HKBN..........................................................6

4 Tips on Internet Connection................................................................................................7

HKBN_SETUP_ROUTER_ASUS_ENG_230315

Get to know the ASUS Router

1 Get to know the ASUS router

A. Tech Specs - Connections and Expansion

B. Minimum System Requirements (bb500/ FibreHome500/ bb1000/ FibreHome1000)

To ensure that you have a fast and stable network, please refer to the following as a

recommended minimum system requirement.

Central Processing Unit (CPU)

Intel Core2 Duo P8700/2.5 (3 GHz or above)

System Memory

4GB or above

Hard disk

64GB SATA II SSD (Min. I/O speed of 200MB/s)

Network Adaptor

100/1000M Network Adaptor

USB LED

LAN LED

WAN LED

5GHz LED

2.4GHz LED

Power LED

USB Port

LAN Port

WAN Port

AC Socket

HKBN_SETUP_ROUTER_ASUS_ENG_230315

Connecting to ASUS Router

2 Connecting to ASUS router

Make sure you have a LAN cable connected from the HKBN wall plate/ONT to the WAN port

of your ASUS Router (RT-N56U). Using a second LAN cable, connect it from the Router LAN

port to the computer LAN port. Once finished, switch on the power supply for the router and

turn on the computer.

Open your Internet browser, and input [http://192.168.1.1] into the address-bar then press

[Enter]. Enter [admin] as the default user name and password, click [OK].

After login, press [Go] to start the setup.

HKBN_SETUP_ROUTER_ASUS_ENG_230315

Connecting to ASUS Router

2Connecting to ASUS router

Create a [Router Login Name] and [Password] then press [Next] to continue to the connection

setup.

ASUS Wireless Router (RT-N56U) supports both 2.4GHz and 5GHz wireless connections.

After creating the network name (SSID) and security key, it is recommended that you choose

[Copy 2.4GHz to 5GHz settings], then click [Apply] to finish.

HKBN_SETUP_ROUTER_ASUS_ENG_230315

Connecting to ASUS Router

2Connecting to ASUS router

Confirm all settings displayed are correct in the Network Configuration Summary then click

[Next].

Before the new settings can be applied, the router will again ask for an authentication done

by entering your new Login name and Password.

HKBN_SETUP_ROUTER_ASUS_ENG_230315

Switching your broadband

Internet service to HKBN

3 Switching your broadband Internet service to HKBN

After logging in to the router through your browser, select [WAN] under [Advanced Settings]

of router settings page. Choose [Automatic IP] under [WAN Connection Type], then click

[Apply] to update the setting.

HKBN_SETUP_ROUTER_ASUS_ENG_230315

Tips on Internet Connection

Factory default reset of

ASUS router

4 Factory default reset of ASUS Router

If the device is not accessible from the router setting page, you can reset to the factory default

setting by pressing the reset button.

1. 1. Confirm your TP-LINK router is switched on.

2. Press and hold the [Reset] button with a sharp object for 5 seconds, then release the

[Reset] button and wait the router to reboot to its factory default settings.

3. Default Setting：

IP Address

SSID

admin / admin

192.168.1.1

ASUS

ASUS Wireless Router (RT-N56U) - The Reset Button is located to the next to USB port

Reset Button
