8X.51.15.00 / 09.18 Changes reserved . Wijzigingen voorbehouden . Modi ications réservée . Änderungen und Irrtümer vorbehalten . Modi icazione riservato.

Installation manual / Installatie handleiding

Manuel d'installation / Installationsanleitung

Manuale di installazione

Cube

GB / NL / F / D / I

2 - GB

safety regulations

SYMBOL LEGEND:

Failure to comply with this warning may

result in personal injury or even death.

Failure to comply with this warning may

result in serious damage to property,

plants or animals.

Do not perform operations that involve

removing the appliance from its instal-

lation location.

Damage to the device.

Do not climb onto chairs, stools, lad-

ders or unstable supports to clean the

device.

Personal injury caused by falling from a

height or shearing (stepladders shutting

accidentally).

Do not use any insecticides, solvents

or aggressive detergents to clean the

appliance.

Damage to plastic or painted parts.

Do not use the appliance for any pur-

pose other than normal domestic use.

Damage to the device caused by opera-

tion overload.

Damage to objects caused by improper

use.

Do not allow children or inexperienced

people to operate the appliance.

Damage to the appliance caused by im-

proper use.

ATTENTION!

The appliance can be used by children old-

er than 8 years and by people with reduced

physical, sensory or mental abilities, or who

lack adequate experience and the neces-

sary knowledge, provided they are super-

vised or have been instructed on the safe

use of the appliance and on the potential

risks connected with it.

Children must not play with the appliance.

Any cleaning and maintenance performed

by the user must not be eected by unsu-

pervised children.

PRODUCT CONFORMING TO EU

DIRECTIVE 2012/19/EU

The barred wheeled bin symbol appearing

on the appliance or on its packaging indi-

cates that the product must be collected

separately from other waste at the end of

its useful life.

The user must therefore deliver the decom-

missioned product to an appropriate local

facility for separate collection of electro-

technical and electronic waste.

Alternatively, the appliance to be scrapped

can be delivered to the dealer when pur-

chasing a new equivalent appliance.

Electronic products for disposal measuring

less than 25cm can also be delivered free

of charge to electronic equipment dealers

having a surface area of at least 400 m2,

without having to purchase other products.

Proper separated collection of the decom-

missioned appliance for its subsequent

recycling, treatment and eco-compatible

disposal helps to prevent negative eects

on the environment and human health, be-

sides encouraging reuse and/or recycling

of its constituent materials.

GB - 3

Technical data

Power supply BUS 8 to 24V max / Limited Power Source

complies

Electrical uptake

6 mA

Operating temperature

0 to 40°C

Storage temperature

-10 to 70°C

Dimensions

93 x 88 x 24 mm

Bus wire length and cross-sectional area

NOTE:

IN ORDER TO AVOID INTERFERENCE PROBLEMS, USE A

SHIELDED CABLE OR TWISTED PAIR CABLE.

max. 50 m - min. 0,6 mm²

Insulation class

III

Protection rating

IP30 (when installed as speciﬁed)

Temperature sensor

±1%

technical features

Product Technical Sheet

Supplier name ATAG

Manufacturer's model ID

Cube

Temperature control class V

Energy eciency contribution (%) for space heating +3%

If an Atag external sensor is added:

Temperature control class VI

Energy eciency contribution (%) for space heating +4%

In a system with 3 zones with 1 ATAG Oz and 1 ATAG Cube:

Temperature control class VIII

Energy eciency contribution (%) for space heating +5%

D E

F H

4 - GB

technical features

Room controller:

1. display

2. keys

Display:

A. Detected room temperature

B. WiFi device detected on bus

C. Heating/cooling mode indication

D. Fault

E. Cooling/anti-freeze mode in con-

trolled zone

F. Heat request

G. Timer-based modiﬁcation of

room temperature set-point in the

schedule programming (when ena-

bled)

H. Manual mode active

I. Programmed mode active

(heating/cooling as scheduled on a

device capable of setting schedule)

L. Controlled zone OFF

M. Battery low charge

N. Mode key (“MODE”)

O. Conﬁrm key (OK)

P. Increase temperature setting key (+)

Q. Decrease temperature setting key (-)

Set mode to heating (HEAT) or cool-

ing (COOL).

x 5s

GB - 5

operating mode

The system's operating mode can be set

to heating or cooling when the device is

connected to a product which supports

both modes (such as a heat pump).

Press the “MODE” key (Fig. 1) to display:

“”.

Press “MODE” again (Fig. 2) for 5 sec-

onds.

“ ” will display next to the key.

Now press the key to select the mode

(Fig. 3)

The display will show:

- “HEAT” heating

- “COOL” cooling.

Press the OK button to conﬁrm the selec-

tion.

NOTE:

The heating/cooling mode selection ap-

plies to the entire system.

Fig. 1

Fig. 2

Fig. 3

6 - GB

manual operation

Manual operation heats or cools the zone

in which the thermostat is installed, and

maintains the manual temperature set-

ting throughout the day (time scheduling

is disabled).

Press the "MODE" button until the display

shows “ ” (Fig. 4).

Modifying the room temperature

In manual mode, the set-point tempera-

ture (default value 20°C) can be modiﬁed.

Press the temperature adjustment keys

“+” and “-” to set the room temperature

(Fig. 5). Press “OK” to conﬁrm.

The set value will ﬂash on the display for

a few seconds, after which the display

will once again show the detected room

temperature.

Disabling

heating/cooling

You can disable heating/cooling in the

zone in which the thermostat is installed.

Press the "MODE" button until the display

shows: “ ”.

When heating is o, the anti-freeze func-

tion is enabled.

Anti-freeze function

When the anti-freeze function is enabled,

the display shows: “ ”.

In this mode, central heating will only ac-

tivate if the room temperature falls below

5°C, to protect the pipes against freezing

up.

Fig. 4

Fig. 5

Fig. 6

GB - 7

programmed operation

Programmed operation is controlled by

the heating/cooling schedule set on a

device capable of setting schedules.

Press the "MODE" button until the display

shows “ ” (Fig. 7).

Timed adjustment

room temperature

In programmed mode, you can temporar-

ily modify the set-point temperature set

on a device capable of setting schedule.

Press the temperature adjustment keys

“+” and “-” to set the room temperature

(Fig. 8).

Press “OK” to conﬁrm the temporary set-

ting.

The display will now show “ ” and the

time for which the changed setting ap-

plies will ﬂash (3h default) (Fig. 9).

Press “+” and “-“ to set the duration of the

modiﬁcation, which can vary between 0

hour (minimum) and 24 hours (maximum).

Press "OK" to conﬁrm the modiﬁed set-

ting.

The display will now show the detected

room temperature again.

When the temporary setting times out,

the display will again show the set-point

temperature set with a device capable of

setting schedule.

To cancel the modiﬁed setting, press

“MODE” and select manual mode.

Press the "MODE" button until the display

shows “ ” to return to programmed

operation.

Fig. 7

Fig. 8

Fig. 9

BUS

T B

8 - GB

installing

Positioning

The device detects the room tempera-

ture, therefore several factors should be

taken into account when choosing an in-

stallation site. Position the device far from

heat sources (radiators, sunlight, ﬁreplac-

es, etc.) and from draughts, doorways

and windows which could aect the tem-

perature readings. It should be installed

approximately 1.5 metres above the ﬂoor

level.

ATTENTION!

Installation should be performed by a quali-

ﬁed technician. Before making any connec-

tions, shut o electrical power to the heat

generator with its external two-position

switch. Power supply of the device must be-

connected to a circuit breaker.

Wall installation

- If necessary, install the mounting plate

to the electrical box included in the kit

(Fig. 10).

- Detach the thermostat's base by press-

ing down the tab at the bottom (Fig. 11).

- Fix the base to the wall at the chosen

position, using the plugs and screws

supplied with the kit (Fig. 12).

Electrical connection to the heat gen-

erator.

IN ORDER TO AVOID INTERFERENCE

PROBLEMS, USE A SHIELDED CABLE

OR TWISTED PAIR CABLE.

- Route the wires through the slot and con-

nect them to terminals B and T.

- Once the wires have been connected, re-

store the thermostat by ﬁrst inserting the

top and then rotating it downwards while

pressing it gently in towards the wall.

- Connect the thermostat wire to the BUS

terminal on the heat generator's terminal

board (Fig. 13).

- Power up the heat generator

heat generator terminal

board

Fig. 11

Fig. 10

Fig. 12

Fig. 13

x 5s

GB - 9

installing

Associating the zone

- Check that the thermostat is powered

up and properly hooked up

- Hold the “+”key on the thermostat

down for 5 seconds (Fig. 14).

The display will alternate between the

software version and modiﬁcation in-

dex.

- Hold the “+”key on the thermostat

down for 5 seconds.

The display will show the parameter

“nr02” (Fig. 15).

- Press “OK” to enter the zone associa-

tion menu; the display will show the ﬁrst

available zone.

- Press “+” and “-”to select the zone you

wish to associate (Fig. 16).

- Press ‘OK’ to conﬁrm.

- Press “MODE” to return to the main

screen.

Fig. 14

Fig. 15

Fig. 16

10 - GB

technical adjustments

TABLE OF PARAMETERS

ATAG Cube

- Hold “+”down for 5 seconds. The display will alternate between the software version and

modiﬁcation index.

- Press “OK” to enter the settings menu.

- Press “+” and “-” to scroll through the parameters.

- Press "OK" button to select a parameter.

Par. Description Default

CF01 Room temperature correction (range +/-5°C) 0°C

CF11 0: Display OFF after 10s

1: Display always on 1

CF12 0: Backlight o

1: Backlight OFF after 5s of inactivity 1

TABLE OF ERRORS

Error Cause Solution

Err – Ebus

Zone association error: the

zone associated with the

device is already assigned

Check the installed thermostats. Assign a

dierent zone.

- - -

Err The thermostat is damaged Replace it

Inhaltsverzeichnis

Sprachen:

Andere Atag Controller Handbücher

Atag

Atag One Zone Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
