AT&T OneVision DEFINITY G3 Guide Leitfaden

585-229-107

Issue 2

April, 1996

OneVision DEFINITY G3

Proxy Agent Installation and

Connectivity

Graphics © AT&T 1988

Table of

Contents

Issue 2 April 1996 iii

About This Book xiii

Book Overview xiii

Intended Audiences xiv

Typographical Conventions xvi

■Keyboard conventions xvii

Your Proxy Agent Package xix

Trademarks xxi

Related Resources xxii

Reader Comments xxiv

1 Before You Begin 1-1

Chapter Overview 1-1

■About theProxy Agent 1-2

Section Overview 1-2

Stages of Translating PBX Data 1-3

Supported PBXs 1-4

■Requirements 1-5

Section Overview 1-5

PC Requirements 1-6

To Check Disk Space 1-7

Recommended Hardware 1-9

Recommended Software 1-10

■About Installations 1-11

Section Overview 1-11

Contents

iv Issue 2 April 1996

UnixWare Methodology 1-12

Installation and Setup Task List 1-13

2 PC Hardware Installation 2-1

Chapter Overview 2-1

PC Setup Checklist 2-2

3 UnixWare Installation 3-1

Chapter Overview 3-1

■Installation Procedures 3-2

Section Overview 3-2

New Installations 3-3

UnixWare 2.01 Upgrades 3-6

To Set System and Node Names 3-9

■TCP/IP Administration 3-11

Section Overview 3-11

To Configure the Ethernet Interface 3-12

To Set the Hosts File 3-14

To Test the TCP/IP Connection 3-16

To Troubleshoot the TCP/IP Connection 3-17

Contents

Issue 2 April 1996 v

4 UnixWare Administration 4-1

Chapter Overview 4-1

■Login Administration 4-2

Section Overview 4-2

About Logins 4-3

To Add New Logins: UNIX Shell 4-4

To Add New Logins: OA&M 4-6

To Add New Logins: Desktop 4-9

To Verify Group Assignments 4-11

■Maintenance Administration 4-13

Section Overview 4-13

About Port Monitors 4-14

To Assign Devices to Ports 4-15

To Back Up andRestore 4-17

5 Planning Connectivity 6-1

Chapter Overview 6-1

■About Connectivity 6-2

Section Overview 6-2

Proxy Agent Connectivity 6-3

Communications Hardware 6-5

■Data Communications Hardware 6-6

Section Overview 6-6

To Choose the Hardware 6-8

Proxy Agent and Modem Connections 6-9

Proxy Agent and Data Module Connections 6-10

Contents

vi Issue 2 April 1996

Proxy Agent and ADU Connections 6-11

To Choose Circuit Packs 6-12

PBX and Modem Connections 6-13

PBX and Data Module Connections 6-14

PBX and ADU Connections 6-15

Cables for Modems 6-16

Cables for Data Modules 6-19

Cables for ADUs 6-21

■PC Hardware Connections 6-23

Section Overview 6-23

PC Hardware Connections 6-24

Cables and Connectors 6-25

To Validate Dial Strings 6-27

To Set the Dip Switch 6-28

■Alarm Stream 6-31

Section Overview 6-31

To Connect the Modem to thePC 6-32

Alarm Path 6-33

6 Connectivity 7-1

Chapter Overview 7-1

■Dial-Up Connections 7-2

Section Overview 7-2

Port Terminations 7-3

Analog Connections 7-4

Digital Connections 7-7

Contents

Issue 2 April 1996 vii

To Program PBX Ports 7-9

Site-Specific Connections 7-13

Multiple Connections 7-14

■Direct Connections 7-15

Section Overview 7-15

Requirements 7-16

Procedural Overview 7-18

To Install the Hardware 7-18

To Configure Data Modules 7-19

To Set Data Module Extensions 7-22

To Update the Abbreviated Dialing List 7-24

To Edit the Devices File 7-26

To Set Up a Hotline Connection 7-27

To Administer the Proxy Agent 7-28

7 Serial I/O Cards 8-1

Chapter Overview 8-1

■Installation Procedures 8-2

Section Overview 8-2

DigiBoard Xem 8-3

Equinox SST 8-6

Equinox XP 8-7

Specialix XIO 8-10

■Administration Procedures 8-11

Section Overview 8-11

To Assign Devices to the Proxy Agent 8-12

Contents

viii Issue 2 April 1996

To Verify Device Types 8-14

To Verify Dial Strings 8-15

To Create Port Monitor Entries 8-17

8 Proxy Agent Installation 9-1

Chapter Overview 9-1

About the Proxy Agent 9-2

Making Preparations 9-3

To Verify Hardware Connections 9-4

To Verify Installed Software 9-5

Proxy Agent Installation 9-6

9 Proxy Agent Administration 10-1

Chapter Overview 10-1

■Maintenance 10-2

Section Overview 10-2

UNIX Permissions 10-3

Printers 10-4

Back Up Your System 10-5

Remove the Software 10-6

■Proxy Agent Configuration 10-7

Section Overview 10-7

To Verify the Installation 10-8

Contents

Issue 2 April 1996 ix

To Change Hardware Configuration 10-10

To Change the User Interface 10-13

■Proxy Agent Connectivity 10-17

Section Overview 10-17

To Define External Systems 10-18

To Connect to aPBX 10-20

To Disconnect from a PBX 10-22

■Proxy Agent Customization 10-23

Section Overview 10-23

ToStart the Proxy Agent 10-24

The Online Guide 10-25

To Check the Proxy Agent Status 10-26

To Change Clients 10-27

To Change Managers 10-28

10 Alarms 11-1

Chapter Overview 11-1

■Alarm Reception 11-2

Section Overview 11-2

Program the Alarm Receiver Port 11-3

Set Modem Options for Alarm Reception 11-9

■Alarm Forwarding 11-12

Section Overview 11-12

Program the Alarm Sender Port 11-13

Edit the Dialers File 11-14

Set the Modem Options for Alarm Forwarding 11-15

Contents

xIssue 2 April 1996

■Program the Proxy Agent 11-16

Section Overview 11-16

Change Alarm Forwarding 11-17

11 Post-Installation Tests 12-1

Chapter Overview 12-1

Technician Checklist 12-2

Customer Checklist 12-3

A PA001 Form A-1

Appendix Overview A-1

PA001 Administration Request Form A-2

B Design Configuration B-1

Appendix Overview B-1

■Proxy Agent Network B-2

Digital Switch On-Network B-2

Analog On-Network B-4

“Other” On-Network B-6

Customer-Provided Multiplexor Data Networks B-8

Contents

Issue 2 April 1996 xi

■Proxy Agent Connectivity B-11

Local Connection: 2000’ or Less

Sys75 R1V3; G1; G3iV1, V2, V3; G3vsV1, V2, V3 B-12

Local Connection: 2000’ or Less

G3rV1, V2, V3 B-13

Local Connection: 2000’ or Less

Sys75 R1V3; G1; G3iV1, V2, V3; G3vsV1, V2, V3 B-14

Local Connection: 5000’ or Less

G3rV1, V2, V3 B-15

Remote Connection:

Sys75 R1V3; G1; G3iV1, V2, V3; G3vsV1, V2, V3 B-16

Remote Connection:

G3rV1, V2, V3 B-17

C Basic vi C-1

Appendix Overview C-1

vi Editor C-2

D Proxy Agent Quick Reference D-1

Appendix Overview D-1

Hotkeys D-2

Commands D-3
