Atari RetroBLE2P Bedienungsanleitung



1|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER



BluetoothWirelessAtariRetroJoystickandPaddleAdapter



User’sManual





2|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

SafetyInstructions

Alwaysreadthesafetyinstructionscarefully:

 KeepthisUser’sManualforfuturereference.

 Keepthisequipmentawayfromhumidity.

 Ifanyofthefollowingsituationarises,gettheequipmentcheckedbyaservicetechnician:

o Theequipmenthasbeenexposedtomoisture.

o Theequipmenthasbeendroppedanddamaged.

o Theequipmenthasobvioussignofbreakage.

o TheequipmenthasnotbeenworkingwelloryoucannotgetitworkaccordingtoUser’s

Manual.



Nopartofthispublicationmaybereproducedinanyformbyanymeanswithoutthepriorwritten

permission.Othertrademarksorbrandnamesmentionedhereinaretrademarksorregistered

trademarksoftheirrespectivecompanies.



Disclaimer

Informationinthisdocumentissubjecttochangewithoutnotice.Themanufacturerdoesnotmakeany

representationsorwarranties(impliedorotherwise)regardingtheaccuracyandcompletenessofthis

documentandshallinnoeventbeliableforanylossofprofitoranycommercialdamage,includingbut

notlimitedtospecial,incidental,consequential,orotherdamage.





3|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

Introduction

Thisadapterallowsyoutoconnect2AtariJoysticksor2PaddlesandpairthedevicetoyourPCor

phone.YoursystemwillrecognizeyourAtarijoysticksandpaddlesasstandardgamepadsreadyforyou

tousewithyouremulatorsandgames.

ExtrasharedbuttononthedevicewillshowupasbuttonsonthePCgamepadandtheycanbemapped

toothercapabilitiesinyouremulator.

InadditiontostandardsinglebuttonAtariJoystick,thisdevicealsosupportsFlashbackAtarijoysticks

thathave5buttons,Atarisingleordualpaddles,7800joysticks(bothbuttonsonthe7800willtriggera

singlefirebutton).

Features

 Built‐inRechargeableBatteryviaUSB

 ConnectsWirelesslyviaBluetooth

 Dualportsallowing2JoyticksorPaddles

 ScreendisplayprovidesdeviceoperationsandJoystick/Paddlefeedbackinreal‐time

 5Buttonsonthedeviceprovideadditionaloptionsforgamepaduse

 Nodriversneeded

 CompatiblewithWindows,Linux,Mac,andPhones

PackageContents

 User’sManual

 BluetoothWirelessAtariRetroJoystickandPaddleAdapter



SystemRequirements

 PC,Laptop,Pi3or4,SmartPhone

 Bluetoothconnectivity

 Oneofthefollowingoperatingsystems(nodriversneeded):

o Windows10

o MacOS,

o LinuxOS(includingRetroPie)

o AndroidoriOS



4|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

InstallationVerification

Afteryouturnonthedevice,ifyouhavenotpairedthedeviceyet,youwillseeablueblinkingConthe

devicessmallscreen.BlinkingCindicatesthedeviceisdisconnectedandreadyforpairingprocess.

TopairwithyourPC,Laptop,Pi,orPhone,simplyfollowyouroperatingsystemsnormalBluetooth

connectionprocess.BelowisanexampleprocessonWindows10.

Windows10

GotoWindowsControlPanelandclickon“ViewDevicesandprinter”



ClickonAddadeviceontopleftcorner



SelectRetroJoysticksandclickNext



5|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

Oncethedeviceispairedyouwillseeitonyourdeviceslist.RightclickontheshownRetroJoystick

deviceandselectGamecontrollersettings



Youwillseethedevicestwoportslisted.Theybothwillhavethesamename.Selectthetoponeforthe

rightportlabeled1onthedevice.Selectthebottomonefortheleftportlabeled2onthedevice.

Thenclickproperties



SeeOperationsectionformoreinformationonhowyourjoysticks/paddlesandbuttonsonthedevice

aremappedtogamepadcontrollersonyourPC.



Asyoumoveyourjoystick/paddles,youwillseetheappropriateaxisandbuttonsupdateaccordingly.

NotetheZaxesandRotationandbutton7,8arereceivingdatafromthealternatejoystickport.Having

datafrombothportscombinedishelpfulforsomeemulatorsandoperatingsystems.



6|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

Operation

MakesuretoconnectyourPaddleorJoysticksbeforeyouturnonthedevice.Thesystemwilldetectthe

typeofdeviceyouconnectedatstartup.

WorkingwithPaddlesvsJoysticks

Eachtimeyouswitchfrompaddlestojoystickorviceversa,youmusteitherresetorturnoff/onthe

deviceforthesystemtoreinitializesoitcandetectthechange.Toresetthedevicewhilethedeviceis

on,pressandholdtheRed+Green+Blue+Yellowbuttonsimultaneously(allbuttonsexceptwhite).You

willseethescreendisplayRESETandbegincheckingall4portsforpaddles.Note:Whileyoucan

connect4paddlestothedeviceandsystemwillgenerallyworkfine,only2paddlesareofficially

supported.Paddle3hasaslightlysmallerrangein4‐paddleconfigurationduetolimitationofhardware.

SinglevsDoubleModeofOperation

Whenyoufirstturnonthedevice,itwillautomaticallybeinDoublemode.InDoublemodethedevice

willsendinformationbacktothePCtobothgamepadsshownonthePC.InSinglemodethedevicewill

sendinformationfrombothportsconnectedonlytoasinglegamepadonyourPC.

YoucantogglethemodeofthedevicebypressingGreen+Blue+Yellow+Whitesimultaneously.The

devicewillchangemodesandthescreenwilldisplaythemodeyouchangedto;either“Mode:Single”or

“Mode:Double”.

SingleMode

SinglemodeisneededforsomeoperatingsystemssuchasLinuxorRetroPieastheydonotproperly

handlemulti‐hidconnectionsviaasingleBluetoothconnection.IfyoustayinDoublemode,yourOSwill

getconfusedanddatefromyourjoystickswillgetintermingled.Makesuretoswitchtosinglemodeif

youhavetroublewithoperatingsystemsotherthanwindows.

InSinglemode,youcanstilluse2joysticksor4paddlesbecausethedevicewillsendbothportsdatato

asinglegamepadshownonyourPC/Linux/Mac.

ForbothportsasJoysticksthedevicewillsenddataofthe2Joysticksconnectedtothesystemssingle

gamepadasfollows:

‐ X/Yaxisandbutton1willbeJoystick1onthedevice

‐ Zaxis,rotation,andbutton6willbeJoystick2onthedevice

Ifyouconnect4paddles(2onPort1,and2onPort2)thedevicewillsenddataofall4paddlestothe

systemssinglegamepadasfollows:

‐ Xaxisandbutton1forpaddle1

‐ Yaxisandbutton2forpaddle2.

‐ Zaxisandbutton7forpaddle3

‐ Zrotationandbutton8forpaddle4.





7|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

DoubleMode

DoublemodeismainlysupportedforWindowsOSbecauseitdoesproperlyhandlemulti‐hid

connectionsviaasingleBluetoothconnection.

Indoublemode,bothgamepadsshownonyourPCwillworkcorrectly.Asanaddedbonus,thedevice

willdevicewillsenddataoffrombothportstoeachgamepadshownonyourPC.

2Joysticksconnectedtothesystemsaremappedasfollows:

OnyourPCGamepad1:

‐ X/Yaxisandbutton1willbeJoystick1onthedevice

‐ Zaxis,rotation,andbutton6willbeJoystick2onthedevice

OnyourPCGamepad2:

‐ X/Yaxisandbutton1willbeJoystick2onthedevice

‐ Zaxis,rotation,andbutton6willbeJoystick1onthedevice

Ifyouconnect4paddles(2onPort1,and2onPort2)thedevicewillsenddataofall4paddlesto

gamepadsonyourPCasfollows:

OnyourPCGamepad1:

‐ Xaxisandbutton1forpaddle1

‐ Yaxisandbutton2forpaddle2

‐ Zaxisandbutton7forpaddle3

‐ Zrotationandbutton8forpaddle4

OnyourPCGamepad2:

‐ Xaxisandbutton1forpaddle3

‐ Yaxisandbutton2forpaddle4

‐ Zaxisandbutton7forpaddle1

‐ Zrotationandbutton8forpaddle2

ButtonsontheDevice

Herearehowthebuttonsonthedevicemapped:

‐ Red–Button1(Commonfirebuttononallgamepads)

‐ Green–Button2

‐ Blue–Button3

‐ Yellow–Button4

‐ White–Button5



Pleasenote,thesebuttonsareconsideredCommonButtons,thustheywillshowupasbutton2‐5

pressedonyourgamepadshownonyourPC.



8|Page



BLUETOOTHWIRELESSATARIRETROJOYSTICKANDPADDLEADAPTER

ChargingtheDevice

Thedevicewilldisplaythebatterystatusonthescreen.IfyouconnectedthedevicetoaUSBcharger,

thedisplaywouldlikelyshow100%.Thisdoesnotmeanbatteryisfullycharged.Thebatterystatus

displaycurrentlyisonlyforwhenyoudonothavethedevicepluggedin.

Tocharge,simplyplugthedeviceintoaUSBchargeranditwillchargeautomatically.Itcantake1‐2

hoursforafullchargedependingontypeofchargeryouhave.Toseethestatusofbattery,unplugfrom

chargerandthenturnonthedeviceandwait10seconds.


