ATEN CS692 Bedienungsanleitung

CS692

USER MANUAL

USB HD Audio/Video KVM Switch

FCC Information

Federal Communication Commission Interference Statement: This

equipment has been tested and found to comply with the limits for a

Class B digital service, pursuant to Part 15 of the FCC rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. Any changes or modifications

made to this equipment may void the user’s authority to operate this

equipment. This equipment generates, uses, and can radiate radio

frequency energy. If not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna;

Increase the separation between the equipment and receiver;

Connect the equipment into an outlet on a circuit different from

that which the receiver is connected;

Consult the dealer or an experienced radio/television technician

for help.

FCC Caution: Any changes or modifications not expressly approved

by the party responsible for compliance could void the user's authority

to operate this equipment.

RoHS

This product is RoHS compliant.

SJ/T 11364-2006

The following contains information that relates to China.

- 3 -

CS692 User Manual

Online Registration

Telephone Support

Technical Support

For international online technical support – including

troubleshooting, documentation, and software updates:

http://eservice.aten.com

For North American technical support:

International http://eservice.aten.com

International 886-2-8692-6959

China 86-10-5255-0110

Japan 81-3-5323-7178

Korea 82-2-467-6789

North America 1-888-999-ATEN ext 4988

United Kingdom 44-8448-158923

Email Support [email protected]

Online

Technical

Support

Troubleshooting

Documentation

Software Updates

http://www.aten-usa.com/support

Telephone Support 1-888-999-ATEN ext 4998

- 4 -

Package Contents

The CS692 USB HD Audio/Video KVM Switch package contains

the following items:

1 CS692 USB HD Audio/Video KVM Switch with Remote

Port Selector

2 Hotkey Stickers

1 User Manual*

1 Quick Start Guide

Check to make sure that all the components are present and that

nothing got damaged in shipping. If you encounter a problem,

contact your dealer.

Read this manual thoroughly and follow the installation and

operation procedures carefully to prevent any damage to the unit,

and/or any of the devices connected to it.

*Features may have been added to the CS692 since this

manual was printed. Please visit our website to download the

most up-to-date version of the manual.

Manual Date: 2013-12-02 - Manual Part No. PAPE-1349-AT3G

ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights

reserved. All other trademarks are the property of their respective owners.

- 5 -

Overview

The CS692 USB HD Audio/Video KVM Switch links two HD

audio/video-enabled PCs or devices to a single USB keyboard,

USB mouse, and HD audio/video display console. The CS692

Switch takes a giant step forward from prior cable KVM models in

the Petite series, by offering full HD audio/video functionality,

USB 2.0 peripheral sharing (via a USB hub attached to the USB

mouse port), and a firmware upgrade function that allows you to

keep up with latest available versions.

Another new feature of the CS692 is the implementation of a

remote port selector. This means that you can now control port

switching from the desktop while the switch itself can be placed

in a convenient, out-of-the-way, location. Also, in addition to new

hotkeys, the CS692 offers the latest mouse port-switching

function – simply double-click on the scroll wheel of a USB mouse

to change ports.

Furthermore, the CS692 features ATEN’s patented Video

DynaSync technology, which eliminates boot-up display

problems and optimizes resolution when switching between

ports.

Finally, the CS692's new Power on detection feature means that

if one of the computers is powered off, switch will automatically

switch to the other powered-on computer.

Featuring an unbeatable combination of HD audio/video

functionality, USB 2.0 peripheral sharing convenience, gaming

keyboard support, and enhanced user-friendly operations, the

CS692 allows users to keep up with the latest innovations in

desktop multimedia applications.

- 6 -

Features

One HD audio/video console controls two USB computers

Computer selection via remote port selector, hotkeys, and

USB mouse

Audio-enabled – full bass response provides a rich

experience for 2.1 channel surround sound systems

Independent switching of the KVM and Audio focus – one

computer has the KVM focus and the other the Audio focus*

Multiplatform support – Windows 2000 / XP / Vista / 7, Mac,

Linux

Compact design, built-in all-in-one cables (2 x 1.2 m)

Superior video quality – up to 1920 x 1200

Compatible with widescreen LCD monitors

Video DynaSync – exclusive ATEN technology eliminates

boot-up display problems and optimizes resolution when

switching between ports

Power on detection – if one computer is powered off, the

CS692 will automatically switch to the other computer

Supports gaming and multimedia keyboards

Supports multifunction and wireless keyboards and mice

Console mouse port emulation/bypass feature supports most

mouse drivers and multifunction mice

Mac keyboard support and emulation**

USB 2.0 mouse port can be used for USB hub and USB

peripheral sharing***

Non-Powered

Firmware upgradable

Note: 1. HD audio through the monitor’s built-in speakers cannot be switched

independently.

2. PC keyboard combinations emulate Mac keyboards. Mac keyboards

work only with their own computers.

3. May require an additional power adapter.

4. To use the USB 2.0 mouse port as a USB hub, you must first disable

mouse emulation mode. See Hotkey Summary Table, page 15 for

information.

- 7 -

System Requirements

Console

An HD audio/video monitor

A USB keyboard and a USB mouse

Speakers and microphone (optional)

Computers

The following equipment must be installed on each computer that

is to be connected to the system:

An HD audio/video port

USB Type A port

Speaker and microphone ports (optional)

Cables

The CS692’s innovative design features built-in KVM and audio

cables for extra convenience. No further cables are necessary.

- 8 -

Operating Systems

Supported operating systems are shown in the table, below:

OS Version

Windows 2000 / XP / 2003 / 2008 / Vista / 7

Linux RedHat 9.0, Fedora and higher

SuSE 10 / 11.1 and higher

Debian 3.1 / 4.0

Ubuntu 7.04 / 7.10

UNIX FreeBSD 5.5 / 6.1 / 6.2

Novell Netware 6.0 / 6.5

Mac OS 9 and higher

DOS 6.2 and higher

- 9 -

Components

CS692

Remote Port Selector

- 10 -

*If your console monitor has built-in speakers and supports

audio through its HD audio/video interface, separate speakers

are not needed.

No. Component Description

1 Port LEDs The LED lights on to indicate that the

computer attached to its

corresponding port is selected and

has the KVM focus.

The LED flashes to indicate that the

computer attached to its

corresponding port is being scanned

by the Auto Scan function.

The LED is off to indicate the port is

not selected.

2 Console Keyboard

Port

Your USB console keyboard plugs in

here.

3 Console Monitor Port Your HD audio/video console monitor

plugs in here.

4 Console Mouse Port Your USB console mouse plugs in

here.

5 KVM Cables The connectors at the end of these

built-in KVM cables attach to the two

HD audio/video computers/devices in

your CS692 installation. See the

diagram on page 12 for further details.

6 Console Audio Ports Your console speakers* and

microphone plug in here.

7 Port Selection

Pushbutton

Press the Port Selection Pushbutton

to toggle the KVM and Audio focus

between the two computers/devices.
