ATEN Master View CS-82A Bedienungsanleitung

2 Port KVM Switch

User Manual

CS-82A

Read this guide thoroughly and follow the installation and operation proce-

dures carefully in order to prevent any damage to the units and/or any de-

vices that connect to them.

This package contains:

M1 Master View CS-82A KVM Switch

M1 User Manual

If anything is damaged or missing, contact your dealer.

Manual Part No. PAPE - 1217-1AT

Printed in Taiwan 09/2002

All brand names and trademarks are the registered property of their respective owners.

2002-09-19

Note: This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy, and if not installed and used in

accordance with the instruction manual, may cause

interference to radio communications. However, there is

no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

MReorient or relocate the receiving antenna;

MIncrease the separation between the equipment and

receiver;

MConnect the equipment into an outlet on a circuit different

from that which the receiver is connected;

MConsult the dealer or an experienced radio/television

technician for help.

2002-09-19

Overview

The Master View CS-82A 4 Port KVM (Keyboard, Video,

Mouse), Switch is a control unit that allows access to two

computers from a single console (keyboard, monitor and

mouse). Before the development of the Master View, the only

way to control multiple computer configurations from a single

console was through a complex and costly network system.

Now, with the Master View CS-82A, you can easily access two

computers in a cost effective manner.

Setup is fast and easy; plugging cables into their appropriate

ports is all that is entailed. There is no software to configure;

there are no installation routines, and no incompatibility

problems. Since the Master View CS-82A intercepts keyboard

input directly, it works on any hardware platform and with all

operating systems.

The Master View CS-82A provides two convenient methods to

access the computers connected to the system: 1) push button

Port Selection Switches located on the unit’s front panel; and 2)

Hotkey combinations entered from the keyboard.

There is no better way to save time and money than with a

Master View CS-82A installation. Since a single console

manages all of the computers, the CS-82A setup: 1) eliminates

the expense of having to purchase a separate keyboard,

monitor, and mouse for each computer; 2) saves all the space

those extra components would take up; 3) saves on energy

costs; and 4) eliminates the inconvenience and wasted effort

involved in constantly moving around from one computer to

another.

- 1 -

2002-09-19

Features

MSupports Microsoft Intellimouse and the Scrolling Wheel on

Most Mice

MKeyboard and Mouse Emulation For Error Free Booting

MEasy to Install - No Software Required - Standard Cables to

Connect to the Computers Is All It Takes

MEasy to Operate - Computer Selection Via Push Button

Switches or Hotkeys - Auto Scan Function to Monitor

Computer Operation

MLED Display for Easy Status Monitoring

MCompatible With All Operating Platforms

MCaps Lock, Num Lock, and Scroll Lock, States are Saved

and Restored When Switching

MSuperior Video Quality - Up To 1920x1440; DDC; DDC2;

DDC2B

MCompact, Sturdy, Durable Metal Housing

MEfficient, Ergonomic Design; Logical Connector Layout

MFollows PC 99 Color Specifications

MStandard Cables for Computer Connections

MSaves Time, Space, Power, and Equipment Costs

MNon-Powered Operation

- 2 -

2002-09-19

Hardware Requirements

Console

MA VGA, SVGA, or Multisync monitor capable of the highest

resolution that you will be using on any computer in the

installation

MA PS/2 Style Mouse

MA PS/2 Style Keyboard

Computers

The following equipment must be installed on each computer

that is to be connected to the system:

MA VGA, SVGA or Multisync card.

MA 6-pin mini-DIN (PS/2 style) mouse port.

MEither a 6-pin mini-DIN (PS/2 Style) keyboard port with +5V

DC on pin 4 and Ground on pin 3, or a 5-pin DIN (AT Style)

keyboard port with +5V DC on pin 5 and ground on pin 4.*

*See the note under Cables in the next section.

Cables

Use of substandard cables may damage the connected devices or

degrade overall performance. For optimum signal integrity and to

simplify the layout, we strongly recommend that you use ATEN

high quality CS Custom Cable sets: 2L-1001P/C (1.8 m) and

2L-1003P/C (3 m).

Note: 1. If your computer uses a standard AT style keyboard

socket you will need to purchase a PS/2-to-AT

keyboard adapter (Part No. 2A-106, or any standard

keyboard adapter).

2. The CS-82A does not support serial mice.

- 3 -

2002-09-19

Introduction

Front View

1. Port Selection Switches

Press a switch to access the computer attached to the

corresponding port.

2. Port LEDs:

The Port LEDs are built into the Port Selection Switches.

The upper ones are the On Line LEDs; the lower ones are

the Selected Port LEDs:

MThe On Line LEDs lights ORANGE to indicate that the

computer attached to the corresponding port is up and

running.

MThe Selected LED lights GREEN to indicate that the

computer attached to its corresponding port is the one

that has the KVM focus. Depending on the port’s status,

the LED may flash according to a specific pattern (see the

LED Display table in the Appendix for details).

3. Console Keyboard and Mouse Ports

The cables from your keyboard and mouse plug in here.

Each port is identified by an appropriate icon.

- 4 -

1 & 2 3

2002-09-19

Rear View

1. Console Video Connector

The cable from your monitor plugs in here.

2. CPU Port Connectors

The KVM cables that connect to the computer’s monitor,

keyboard and mouse ports plug in here. Each port is

identified by an appropriate icon.

Note: 1. In order to have the console’s keyboard and mouse

control notebook computers that only have one

PS/2 port, you can use a two PS/2 port to USB

adapter, such as the ATEN UC-100KM. Simply

plug the KVM cable’s keyboard and mouse

connectors into the adapter, then plug the adapter

into the computer’s USB port.

2. Ordinary PS/2 to USB changers commonly sold in

computer shops will not work with the CS-82A.

- 5 -

2002-09-19

Installation

Refer to the diagram on the next page as you perform the

following steps:

1. Plug the monitor, keyboard, and mouse into the Console

port connectors of the Master View CS-82A unit. Each port

is labeled with an appropriate icon to indicate itself.

2. Use KVM cables (see the Hardware Requirements section),

to connect the keyboard, monitor, and mouse ports from any

available CPU Port (1 - 2), to the keyboard, monitor, and

mouse ports of the computers you are connecting up (see

the diagram on p. 7).

Note: If your computers use AT style connectors for the

keyboard, and/or standard serial connectors for the

mouse, refer back to the note in the Cables section

on p. 3.

3. If you choose to use external power (optional) plug the

power adapter into an external AC source; plug the power

adapter cable into the unit s power jack as shown in the

diagram on p. 7.

4. Turn on the power to the connected computers.

Note: The CS-82A’s Power On default is to link to the first

computer you turn on.

- 6 -

1. Before you begin, make sure that power to all the

devices you will be connecting up have been

turned off. You must unplug the power cords of

any computers that have the Keyboard Power On

function. Otherwise, the switch will receive power

from the computer.

2. To prevent damage to your installation due to ground

potential difference, make sure that all devices on

the installation are properly grounded. Consult your

dealer for technical details, if necessary.

2002-09-19

- 7 -

2002-09-19

Operation

Controlling all the computers in your CS-82A installation from a

single console could not be easier. Two port selection methods

that provide instant access to the computers are available:

MManual Port Selection

MHotkey Port Selection

Manual Port Selection

With Manual Port Selection you simply press the Port Selection

switch that corresponds to the port that the computer you want

to access is attached to. The Selected LED lights to indicate

which port is active.

Hotkey Port Selection

Hotkey Port Selection allows you to select the active computer

directly from the keyboard. The Master View CS-82A provides

the following Hotkey Port Selection features:

MSelecting the Active Port

MAuto Scan Mode

- 8 -

2002-09-19
