Atlona JunoX 451 HDBT Bedienungsanleitung

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

4K HDR Fout-Input HDMI Switcher with Auto-Switching and

Return Optical Audio

AT-JUNO-451 / AT-JUNO-451-HDBT

1 x AT-JUNO-451

1 x 4-pin captive screw block

2 x Mounting plates

4 x Rubber feet

4 x Screws

1 x IR remote control

1 x DC 5V power supply

1 x IEC cord

1 x Installation Guide

1 x AT-JUNO-451-HDBT

1 x 4-pin captive screw block

2 x Mounting plates

4 x Rubber feet

4 x Screws

1 x IR remote control

1 x DC 5V power supply

1 x IEC cord

1 x Installation Guide

Package Contents

The Atlona JunoX™451 HDBT (AT-JUNO-451-HDBT) is a 4x1 switcher for high dynamic range

(HDR) formats. The JunoX 451 HDBT features three HDMI inputs, plus an HDBaseT input for

receiving video, embedded audio, and Ethernet over distances up to 330 feet (100 meters).

It is HDCP 2.2 compliant and supports 4K/UHD video @ 60 Hz with 4:4:4 chroma sampling,

as well as HDMI data rates up to 18 Gbps. The JunoX 451 HDBT is ideal for receiving 4K HDR

over HDBaseT from an Atlona Opus™ Series matrix switcher, and is also compatible with the

Atlona UHD-PRO3, UHD-CAT, and SW Series for data rates up to 10 Gbps. It includes EDID

management features and automatic input switching. The JunoX 451 HDBT also supports

the HDMI Audio Return Channel for receiving digital audio from a television,and includes a

TOSLINK digital audio output for sending this audio to an AV receiver or soundbar. This JunoX

Series switcher can be controlled via Ethernet, RS-232, and IR. A handheld IR remote control is

included.

The Atlona JunoX™ 451 (AT-JUNO-451) provides the same features at the AT-JUNO-451-HDBT,

except that the HDBaseT input is replaced with an HDMI port.

IMPORTANT: Visit http://www.atlona.com/product/AT-JUNO-451-HDBT and

http://www.atlona.com/product/AT-JUNO-451 for the latest rmware updates

and User Manual.

AT-JUNO-451 AT-JUNO-451-HDBT

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

HDMI OUT LANOPTICAL RS-232

RX TX S

IR IN DC 5V

AT-JUNO-451-HDBT

INPUT

1 2 34

POWER INPUT FW

1 2 3 4

INPUT

AT-JUNO-451-HDBT

JUNOXTM

HDMI OUT LANOPTICAL RS-232

RX TX S

IR IN DC 5V

AT-JUNO-451-HDBT

INPUT

1 2 34

POWER INPUT FW

1 2 3 4

INPUT

AT-JUNO-451-HDBT

JUNOXTM

1 IR Window

Receives IR signals from the included IR

remote. Refer to RS-232 / IR Connector

(page 3) for wiring information.

2 Input Indicators

These LED indicators glow solid blue to

indicate the active input.

3 POWER

Press this button to power-on or power-

o the unit.

4 INPUT

Press and release this button to cycle

through each of the inputs.

5 FW

Connect a mini USB cable to this port to

update the rmware.

6 HDBaseT Input

This port is only available on the AT-

JUNO-451-HDBT: Connect a transmitter,

such as the AT-UHD-PRO3-44M, to this

port using an Ethernet cable.

The AT-JUNO-451 replaces this port with

an HDMI input.

7 HDMI Inputs

Connect an HD/UHD source to each of

these HDMI ports.

8 HDMI OUT

Connect an HDMI cable from this port to

a display or other sink device. This output

supports multichannel audio.

9 OPTICAL

Connect an optical audio cable from this

TOSLINK port to an audio output device.

This port is part of the Audio Return

Channel (ARC): audio from the display

is routed upstream, back to the switcher

over HDMI, to this port.

10 RS-232 / IR IN

Connect the included 4-pin captive

screw block to this port. Refer to RS-232

/ IR Connector (page 3) for wiring

information.

11 LAN

Connect an Ethernet cable from this port

to a Local Area Network (LAN).

12 DC 5V

Connect the included 5 V DC power

supply to this power receptacle.

Panel Descriptions (AT-JUNO-451-HDBT shown)

9 10 11

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

RS-232 / IR Connector

Both the AT-JUNO-451 and AT-JUNO-451-HDBT both provide RS-232 and IR control, using the

included four-pin captive screw block. IR or RS-232 can be connected to a control system when

using external control.

1. Use wire strippers to remove a portion of the cable jacket.

2. Remove at least 3/16” (5 mm) from the insulation of each wire.

3. Insert the wires into the correct terminal on the included captive screw block, as shown

below.

4. Tighten the screws to secure the wires. Do not use high-torque devices as this may

damage the screws and/or connector block.

Both the AT-JUNO-451 and AT-JUNO-451-HDBT include an

IR remote control that can be used to operate the unit from

a remote location.

GND

to control system

or AT-VCC-IR-KIT

GND

IR Remote Control

SW-R1

Video 1

Video

Video 2

All On

Power

Vol +

Vol

Mute

Input Audio

On Off

1 On / O buttons

Press the On button to power-on the unit. Press the

O button to power-o the unit.

2 Input

Press these buttons (1- 4) to select the desired input.

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

• AT-JUNO-451-HDBT:

1. Connect a transmitter, such as the AT-UHD-PRO3-44M, to the HDBaseT (INPUT 1) port on

the AT-JUNO-451-HDBT.

2. Connect a HD/UHD source to each of the three HDMI inputs (INPUT 2 - INPUT 4).

• AT-JUNO-451:

3. Connect a HD/UHD source to each of the four HDMI inputs (INPUT 1 - INPUT 4).

• AT-JUNO-451 / AT-JUNO-451-HDBT:

4. Connect an optical audio cable from the OPTICAL port to a sound bar or other audio output

device.

5. Connect an Ethernet cable from the LAN port to the Local Area Network (LAN).

6. Connect the included 4-pin captive screw block to the RS-232 /IR IN port.

Refer to RS-232 / IR Connector (page 3) for wiring information.

7. Connect the included 5 V DC power supply to the DC 5V power receptacle.

8. Connect the power supply to an available electrical outlet.

For easy conguration of Atlona devices, AMS 2.0 is available from https://atlona.com/AMS for

free. Two options can be used for installation: The free Linux-based software download or the

easy-to-install server hardware (AT-AMS-HW).

Once AMS has been set up:

1. Open a browser on the same network as AMS 2.0 and go to the IP of AMS 2.0. View the

AMS 2.0 installation instructions on how to nd the IP of the software, if necessary.

2. Enter the login information on the AMS 2.0 web page, then click the Login button.

3. View the AT-JUNO-451 or AT-JUNO-451-HDBT manual for routing and conguration.

Installation

AMS 2.0

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

Web GUI

Both the AT-JUNO-451 and AT-JUNO-451-HDBT include a built-in web GUI, which allows easy

management and control of all features. Follow the instructions below to access the web GUI.

1. Set the IP mode of the AT-JUNO-451. By default, the AT-JUNO-451 is set to DHCP mode.

• Static IP mode: Press and hold the recessed button, with the tip of a pencil or

paper clip, until the PWR indicator blinks twice. The default static IP address is

192.168.1.254.

• DHCP mode: Press and hold the button until the PWR indicator blinks four times.

2. Connect an Ethernet cable from the LAN port on the AT-JUNO-451, to the Local Area

Network (LAN).

3. Use an IP scanner to determine the IP address of the AT-JUNO-451.

4. Launch a web browser and enter the IP address of the unit.

5. The AT-JUNO-451 Login page will be displayed.

6. Enter the following information on the Login page.

Password: Atlona

7. Click the Login button.

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

Connection Diagrams

LAN

AV Receiver

Media Player

media4

Display

SOURCE: DVD

AAX DEC

BNE XOR

Video

HDBaseT

Video

Audio

AT-UHD-PRO3-44M

Blu-ray Player

Media Player

EDID

POWER ENTER

FNC CANCEL INFO

12 3

AT-UHD-PRO3-44M

POWER INPUT FW

1 2 3 4

INPUT

AT-JUNO-451-HDBT

UNO

LAN

AV Receiver

UHD Blu-ray Player

Media Player

Laptop

media4

UHD Display

SOURCE: DVD

AAX DEC

BNE XOR

Video

Video Video

Video

Audio

AT-JUNO-451

POWER

UNO

1 2 3 4

INPUT INPUT FW

AT-JUNO-451

AT-JUNO-451-HDBT

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

Both the AT-JUNO-451 and AT-JUNO-451-

HDBT include two mounting brackets, which

can be used to attach the unit to any at

surface. Use the two enclosure screws, on

the sides of the unit to attach the mounting

brackets.

1. Using a small Phillips screwdriver, remove

the two screws from the left side of the

enclosure.

2. Position one of the mounting brackets, as

shown below, aligning the holes on the

side of the enclosure with one set of holes

on the mounting bracket.

3. Use the screws from Step 1 to attach the

mounting bracket.

4. Repeat steps 1 and 2 to attach the

second mounting bracket to the opposite

side of the unit.

5. Mount the unit to a at surface using the

oval-shaped holes, on each mounting

bracket. If using a drywall surface, a #6

drywall screw is recommended.

POWER INPUT FW

1 2 3 4

INPUT

AT-JUNO-451-HDBT

UNO

POWER INPUT FW

1 2 3 4

INPUT

AT-JUNO-451-HDBT

UNO

POWER INPUT FW

1 2 3 4

INPUT

AT-JUNO-451-HDBT

UNO

NOTE: Mounting brackets can

also be inverted to mount the

unit under a table or other at

surface.

Mounting Instructions

Installation Guide

AT-JUNO-451 / AT-JUNO-451-HDBT

Troubleshooting

Problem Solution

How do I update the

rmware?

• Firmware and instructions can be found and downloaded

from the rmware tab at http://www.atlona.com/product/

AT-JUNO-451 and http://www.atlona.com/product/AT-

JUNO-451-HDBT.

RS-232 and/or IR control

is not working.

• Verify that the 4-pin captive screw block is wired

correctly. Refer to RS-232 / IR Connector (page 3) for

wiring instructions.

• Check that the included power supply is connect to an

active AC electrical outlet.

What type of control can

be used with the AT-

JUNO-451 and AT-JUNO-

451-HDBT?

• The AT-JUNO-451 can be controlled using RS-232, TCP/

IP, the web GUI, or AMS.

Auto-switching is not

working.

• The AT-JUNO-451 and AT-JUNO-451-HDBT both come

with auto-switching disabled. Auto-switching can

be enabled through AMS, the web GUI, or using the

AutoSW command. Refer to the User Manual for more

information.

trademarks are the property of their respective owners. Pricing, specications and availability subject to change without notice. Actual products, product images, and

online product images may vary from images shown here.

atlona.com •408.962.0515 •877.536.3976

Version 1

Andere Handbücher für JunoX 451 HDBT

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Atlona Schalten Handbücher

Atlona

Atlona AT-HDMI-24M Bedienungsanleitung

Atlona

Atlona AT-PC81A Bedienungsanleitung

Atlona

Atlona AT-HDKVM-V21 Bedienungsanleitung

Atlona

Atlona AT-UHD-SW-510W Bedienungsanleitung

Atlona

Atlona Omega AT-OME-ST31A Bedienungsanleitung

Atlona

Atlona JunoX 451 HDBT Bedienungsanleitung

Atlona

Atlona AT-HD-SC-500 Bedienungsanleitung

Atlona

Atlona junox AT-JUNO-451 Bedienungsanleitung

Atlona

Atlona AT-HDR-H2H-88MA Bedienungsanleitung

Atlona

Atlona AT-VGA0801 TO AT-VGA9601 Bedienungsanleitung

Atlona

Atlona AT-LINE-EX Bedienungsanleitung

Atlona

Atlona AT-UHD-SW-52 Bedienungsanleitung

Atlona

Atlona AT-LINE-PRO5 Bedienungsanleitung

Atlona

Atlona AT-HDVS-150-TX Bedienungsanleitung

Atlona

Atlona AT-HDVS-150-KIT Bedienungsanleitung

Atlona

Atlona AT-HDVS-150-TX Technisches Handbuch

Atlona

Atlona AT-HDVS-210H-TX-WP Bedienungsanleitung

Atlona

Atlona AT-HDVS-150-TX Bedienungsanleitung

Atlona

Atlona AT-HDVS-150-TX Bedienungsanleitung

Atlona

Atlona AT-HDVS-200-TX-PSK Bedienungsanleitung

Atlona

Atlona AT-APC21A Bedienungsanleitung

Atlona

Atlona ATL-ATAPC21A Bedienungsanleitung

Atlona

Atlona AT-MDP21 Bedienungsanleitung

Atlona

Atlona AT-OPUS-RX41 Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
