SMART ARM-based Microcontrollers

OLED1 Xplained Pro

USER GUIDE

Preface

Atmel® OLED1 Xplained Pro is an extension board to the Atmel Xplained Pro

evaluation platform. The board enables the user to experiment with user

interface applications with buttons, LEDs, and a display.

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

Table of Contents

Preface............................................................................................................................ 1

1. Introduction................................................................................................................3

1.1. Features....................................................................................................................................... 3

1.2. Kit Overview................................................................................................................................. 3

2. Getting Started...........................................................................................................4

2.1. Xplained Pro Quick Start.............................................................................................................. 4

2.2. Design Documentation and Relevant Links................................................................................. 4

3. Xplained Pro.............................................................................................................. 5

3.1. Hardware Identification System....................................................................................................5

3.2. Xplained Pro Headers and Connectors........................................................................................5

3.2.1. Xplained Pro Standard Extension Header..................................................................... 5

4. Hardware User Guide................................................................................................7

4.1. Electrical Characteristics.............................................................................................................. 7

4.2. Headers and Connectors..............................................................................................................7

4.2.1. OLED1 Xplained Pro Extension Header........................................................................7

4.3. Peripherals................................................................................................................................... 8

4.3.1. LEDs.............................................................................................................................. 8

4.3.2. Push Buttons................................................................................................................. 8

4.3.3. OLED Display................................................................................................................ 9

5. Hardware Revision History and Known Issues........................................................10

5.1. Identifying Product ID and Revision........................................................................................... 10

5.2. Revision 3...................................................................................................................................10

6. Document Revision History......................................................................................11

7. Evaluation Board/Kit Important Notice.....................................................................12

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

1. Introduction

1.1. Features

•UG-2832HSWEG04 monochrome OLED display

–128 x 32 Pixels

–Controlled by 4-wire SPI interface, up to 100MHz

•Three LEDs

•Three Mechanical push buttons

•Xplained Pro hardware identification system

1.2. Kit Overview

OLED1 Xplained Pro is a basic extension board for the Xplained Pro platform with three LEDs, three push

buttons, and an OLED display. The OLED display is controlled via a SPI interface up to 100MHz. OLED1

Xplained Pro connects to any Xplained Pro standard extension header on any Xplained Pro MCU board.

Figure 1-1. OLED1 Xplained Pro Top Overview

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

2. Getting Started

2.1. Xplained Pro Quick Start

Steps to start exploring the Atmel Xplained Pro platform:

1. Download Atmel Studio.

2. Launch Atmel Studio.

3. Connect OLED1 Xplained Pro to an Xplained Pro MCU board and connect a USB cable to the

DEBUG USB port on the Xplained Pro MCU board.

When the Xplained Pro MCU kit is connected to your computer for the first time, the operating system will

perform a driver software installation. The driver file supports both 32- and 64-bit versions of Microsoft®

Windows® XP, Windows Vista®, Windows 7, Windows 8, Windows 10, and Windows Server 2012.

Once the Xplained Pro MCU board is powered the green power LED will be lit and Atmel Studio will auto

detect which Xplained Pro MCU- and extension board(s) are connected. Atmel Studio will present

relevant information like datasheets and kit documentation. The kit landing page in Atmel Studio also has

the option to launch Atmel Software Framework (ASF) example applications for the kit. The target device

is programmed and debugged by the on-board Embedded Debugger and therefore no external

programmer or debugger tool is needed.

2.2. Design Documentation and Relevant Links

The following list contains links to the most relevant documents and software for OLED1 Xplained Pro:

•Xplained products - Atmel Xplained evaluation kits are a series of easy-to-use evaluation kits for

Atmel microcontrollers and other Atmel products. For low pin-count devices the Xplained Nano

series provides a minimalistic solution with access to all I/O pins of the target microcontroller.

Xplained Mini kits are for medium pin-count devices and adds Arduino Uno compatible header

footprint and a prototyping area. Xplained Pro kits are for medium to high pin-count devices, they

features advanced debugging and standardized extensions for peripheral functions. All these kits

have on board programmers/debuggers which creates a set of low-cost boards for evaluation and

demonstration of features and capabilities of different Atmel products.

•Atmel Studio - Free Atmel IDE for development of C/C++ and assembler code for Atmel

microcontrollers.

•Atmel Data Visualizer - Atmel Data Visualizer is a program used for processing and visualizing

data. Data Visualizer can receive data from various sources such as the Embedded Debugger Data

Gateway Interface found on Xplained Pro boards and COM ports.

•Hardware Users Guide in PDF format - PDF version of this User Guide.

•Design Documentation - Package containing CAD source, schematics, BOM, assembly drawings,

3D plots, layer plots, etc.

•OLED1 Xplained Pro on Atmel web page - Atmel website link.

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

3. Xplained Pro

Xplained Pro is an evaluation platform that provides the full Atmel microcontroller experience. The

platform consists of a series of Microcontroller (MCU) boards and extension boards, which are integrated

with Atmel Studio, have Atmel Software Framework (ASF) drivers and demo code, support data

streaming, and more. Xplained Pro MCU boards support a wide range of Xplained Pro extension boards,

which are connected through a set of standardized headers and connectors. Each extension board has

an identification (ID) chip to uniquely identify which boards are connected to an Xplained Pro MCU board.

This information is used to present relevant user guides, application notes, datasheets, and example

code through Atmel Studio.

3.1. Hardware Identification System

All Xplained Pro compatible extension boards have an Atmel ATSHA204 CryptoAuthentication™ chip

mounted. This chip contains information that identifies the extension with its name and some extra data.

When an Xplained Pro extension is connected to an Xplained Pro MCU board the information is read and

sent to Atmel Studio. The Atmel Kits extension, installed with Atmel Studio, will give relevant information,

code examples, and links to relevant documents. The table below shows the data fields stored in the ID

chip with example content.

Table 3-1. Xplained Pro ID Chip Content

Data field Data type Example content

Manufacturer ASCII string Atmel'\0'

Product Name ASCII string Segment LCD1 Xplained Pro'\0'

Product Revision ASCII string 02'\0'

Product Serial Number ASCII string 1774020200000010’\0’

Minimum Voltage [mV] uint16_t 3000

Maximum Voltage [mV] uint16_t 3600

Maximum Current [mA] uint16_t 30

3.2. Xplained Pro Headers and Connectors

3.2.1. Xplained Pro Standard Extension Header

All Xplained Pro kits have one or more dual row, 20-pin, 100mil extension header. Xplained Pro MCU

boards have male headers, while Xplained Pro extensions have their female counterparts. Note that all

pins are not always connected. All connected pins follow the defined pin-out description in the table

below.

The extension headers can be used to connect a variety of Xplained Pro extensions to Xplained Pro MCU

boards or to access the pins of the target MCU on Xplained Pro MCU boards directly.

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

Table 3-2. Xplained Pro Standard Extension Header

Pin number Name Description

1 ID Communication line to the ID chip on an extension board

2 GND Ground

3 ADC(+) Analog to digital converter, alternatively positive part of differential

ADC

4 ADC(-) Analog to digital converter, alternatively negative part of differential

ADC

5 GPIO1 General purpose I/O

6 GPIO2 General purpose I/O

7 PWM(+) Pulse width modulation, alternatively positive part of differential

PWM

8 PWM(-) Pulse width modulation, alternatively negative part of differential

PWM

9 IRQ/GPIO Interrupt request line and/or general purpose I/O

10 SPI_SS_B/

GPIO

Slave select for SPI and/or general purpose I/O

11 I2C_SDA Data line for I2C interface. Always implemented, bus type.

12 I2C_SCL Clock line for I2C interface. Always implemented, bus type.

13 UART_RX Receiver line of target device UART

14 UART_TX Transmitter line of target device UART

15 SPI_SS_A Slave select for SPI. Should preferably be unique.

16 SPI_MOSI Master out slave in line of serial peripheral interface. Always

implemented, bus type.

17 SPI_MISO Master in slave out line of serial peripheral interface. Always

implemented, bus type.

18 SPI_SCK Clock for serial peripheral interface. Always implemented, bus type.

19 GND Ground

20 VCC Power for extension board

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

4. Hardware User Guide

4.1. Electrical Characteristics

OLED1 Xplained Pro can be connected to several Xplained Pro MCU boards and manually connected to

other hardware. Xplained Pro MCU board(s) that does not have 3.3V as its primary target voltage will

read all ID devices on connected extensions to check if they support the target voltage before enabling it

to the extension headers. The table below shows the static content written in the ID chip.

Table 4-1. OLED1 Xplained Pro ID Chip Content

Data field Content

Product name OLED1 Xplained Pro

Minimum operation voltage 3.0V

Maximum operation voltage 3.6V

Maximum current 10mA

Related Links

Xplained Pro Standard Extension Header on page 5

4.3. Peripherals

4.3.1. LEDs

There are three yellow LEDs available on OLED1 Xplained Pro. The LEDs can be activated by driving the

connected I/O line low.

Table 4-3. LED Connections

Pin on EXT connector Silk screen marking

7 LED1

8 LED2

6 LED3

4.3.2. Push Buttons

There are three push buttons available on OLED1 Xplained Pro. When a button is pushed the

corresponding I/O pin is connected to ground. There are no external pull-up resistors on OLED1 Xplained

Pro, so internal pull-up resistors have to be enabled in the target microcontroller.

Info: Remember to enable internal pull-up resistors in the target device to get a defined

electrical level on the I/O lines connected to the buttons.

Table 4-4. Push Buttons Connections

Pin on EXT connector Silk screen marking

9 BUTTON1

3 BUTTON2

4 BUTTON3

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

4.3.3. OLED Display

OLED1 Xplained Pro features a 128 x 32 pixel white monochrome OLED display, UG-2832HSWEG04

from WiseChip Semiconductor Inc. The display has a SSD1306 display controller by Solomon Systech

built in and is controlled via a 4-wire SPI interface + reset with the signals described in the table below.

The datasheets for the display module or the display controller is not publicly available and has to be

acquired from the respective manufacturers.

Info:

Note that the OLED display does not have a SPI MISO signal. That means that data can only

be written to the display, not read.

Table 4-5. OLED Display Connections

Pin on EXT

connector

Signal Name Description

16 SPI_MOSI SPI master out, slave in signal. Used to write data to the

display.

18 SPI_SCK SPI clock signal, generated by the master.

5 DATA_CMD_SEL Data/command select. Used to choose whether the

communication is data to the display memory or a command to

the LCD controller.

15 DISPLAY_SS SPI slave select signal, must be held low during SPI

communication.

10 DISPLAY_RESET Reset signal to the OLED display, active low. Used during

initialization of the display.

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

5. Hardware Revision History and Known Issues

5.1. Identifying Product ID and Revision

The revision and product identifier of Xplained Pro boards can be found in two ways; either through Atmel

Studio or by looking at the sticker on the bottom side of the PCB.

By connecting an Xplained Pro MCU board to a computer with Atmel Studio running, an information

window will pop up. The first six digits of the serial number, which is listed under kit details, contain the

product identifier and revision. Information about connected Xplained Pro extension boards will also

appear in the Atmel Kit's window.

The same information can be found on the sticker on the bottom side of the PCB. Most kits will print the

identifier and revision in plain text as A09-nnnn\rr, where nnnn is the identifier and rr is the revision.

Boards with limited space have a sticker with only a QR-code, which contains a serial number string.

The serial number string has the following format:

"nnnnrrssssssssss"

n = product identifier

r = revision

s = serial number

The product identifier for OLED1 Xplained Pro is A09-1769.

5.2. Revision 3

Revision 3 of OLED1 Xplained Pro is the initial released version.

OLED1 Xplained Pro boards with a serial number that ends with a number lower than 11148 may have a

wrong revision programmed into the Xplained Pro ID chip. This will only affect the information displayed

by the Atmel Kits extension in Atmel Studio. It will not affect the operation of the board.

Atmel OLED1 Xplained Pro [USER GUIDE]

Atmel-42077C-OLED1-Xplained-Pro-Hardware_User Guide-03/2016

Inhaltsverzeichnis

Andere Atmel Hauptplatine Handbücher

Atmel

Atmel AVR ATasicICE POD Bedienungsanleitung

Atmel

Atmel QT5 Xplained Pro Bedienungsanleitung

Atmel

Atmel AT91SAM9263-EK Bedienungsanleitung

Atmel

Atmel STK526 Installationshandbuch

Atmel

Atmel AT91SAM7S-EK Bedienungsanleitung

Atmel

Atmel SAM4E-EK Bedienungsanleitung

Atmel

Atmel AT91SAM7SE-EK Bedienungsanleitung

Atmel

Atmel ATSAMD10 Xplained Mini Bedienungsanleitung

Atmel

Atmel SAM4L8 Xplained Pro Bedienungsanleitung

Atmel

Atmel AT90USB162 Bedienungsanleitung

Atmel

Atmel ATSAM4C-EK Bedienungsanleitung

Atmel

Atmel SAM9N12/CN11-EK Bedienungsanleitung

Atmel

Atmel SAM4N Xplained Pro Bedienungsanleitung

Atmel

Atmel AVR910 Montage- und Bedienungsanleitung

Atmel

Atmel AT32UC3L-EK Bedienungsanleitung

Atmel

Atmel AT85DVK-07 Installationshandbuch

Atmel

Atmel AT91SAM9G10-EK Bedienungsanleitung

Atmel

Atmel maXTouch Xplained Pro Bedienungsanleitung

Atmel

Atmel AT91SAM9261-EK Bedienungsanleitung

Atmel

Atmel AT91SAM9M10-G45-EK Bedienungsanleitung

Atmel

Atmel ATMEGA256RFR2-ZUR Bedienungsanleitung

Atmel

Atmel AT91SAM9G20-EK Bedienungsanleitung

Atmel

Atmel AT88CK9000 Bedienungsanleitung

Atmel

Atmel AT73C239-EK1 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
