Atmos Multi Mk2 Bedienungsanleitung

APPENDIX

ATMOS MULTI Mk2 version 2004 Appendix Page 1

APPENDIX 1. Spare Parts List

Atmos Multi Mk 2 Parts List

Atmos Multi 24/80

Atmos Multi 24/80 PLUS

Atmos Multi 32/80 PLUS

Drg Ref Description Part Ref.

1 Wall bracket *** 07.98.37.043

2 Bracket fixing kit *** 07.95.82.006

3 Rear casing *** 07.90.22.080

3.1 AAV Grommet 15 mm red/brown *** 07.98.68.026

3.2 Casing latches kit *** 07.90.82.009

4 Securing bolt *** 07.98.44.075

5 Air intake pipe *** 07.98.74.298

6 Automatic closing device 3/8" *** 75.06.65.001

7 Automatic air vent 3/8" *** 79.40.26.001

8 Flue gas pipe *** 07.98.74.295

8 Flue gas temp measuring point *** 07.95.15.002

9 Flue pipe *** 07.98.74.286

10 Gas pipe *** 07.98.74.282

11 Gas valve & fittings set *** 07.95.00.002

11.1 Gas valve *** 07.98.78.003

11.2 O-Ring 26,57x3,53 *** 07.98.83.190

11.3 Bolt M5x8 *** 82.27.02.908

11.4 Nipple 1/2" *** 07.98.74.312

12 Sealing washer *** 07.98.83.189

13 Connecting tube - 24 Model ** 07.95.74.024

13 Connecting tube - 32 Model * 07.95.74.025

14 Fixing nut M6 *** 07.98.82.120

15 Flow pipe set *** 07.95.00.003

15.1 Flow pipe *** 07.98.74.283

15.2 (deleted) *** 75.66.99.027

15.3 Tightening ring 22 mm *** 07.98.74.155

15.4 Tightening nut M27x1,5 *** 07.98.82.119

15.5 CH Temperature sensor *** 07.98.63.042

15.6 Plug 1/2"+ O-Ring *** 74.53.80.016

16 Tank set * 07.95.05.008

16 Tank set - Plus Version * * 07.95.05.009

16.1 Tank frame *** 07.98.30.006

16.2 Earthing washer M8 *** 07.98.82.114

16.3 Hex bolt M8x12 *** 07.98.82.112

16.4 Sealing washer M8 *** 82.74.06.903

16.5 Pump/heat exchanger pipe *** 07.98.74.285

16.6 Union nut 1" *** 07.98.82.113

16.7 O-Ring 22x3.0 *** 07.98.83.227

16.8 Bracket bolt *** 07.98.43.017

16.9 Silicone sealing ring *** 07.98.83.231

16.10 Adjusting screw M6x25 *** 07.98.82.117

16.11 Support collar 22 mm * * 07.98.74.206

16.12 Earthing tab 6,3 mm 45° *** 68.31.12.828

16.13 Screw M4x8 self tap *** 82.08.93.046

ATMOS MULTI Mk2 version 2004 Appendix Page 2

Atmos Multi Mk 2 Parts List

Atmos Multi 24/80

Atmos Multi 24/80 PLUS

Atmos Multi 32/80 PLUS

Drg Ref Description Part Ref.

17 Thermostat *** 78.76.54.981

18 Rear insulation *** 07.98.83.229

19 Burner/fan assembly - 24 Model ** 07.95.25.003

19 Burner/fan assembly - 32 Model * 07.95.25.004

19.1 Burner casting *** 07.95.07.002

19.2 Fan casing *** 07.98.83.185

19.3 Fan *** 07.98.36.003

19.4 Nut M4 *** 07.98.82.080

19.5 Viewing glass set *** 07.95.26.003

19.6 Burner set *** 07.95.25.002

19.7 Ionisation probe set *** 07.95.78.004

19.8 Ignition electrode set *** 07.95.70.006

19.9 O-Ring 80x2 *** 07.98.83.184

19.10 Mixing chamber 25 mm - 24 Model ** 07.98.16.002

19.10 Mixing chamber 28 mm - 32 Model * 07.98.16.001

19.11 Screw M6x8 *** 07.98.82.082

19.12 Grommet 15 mm *** 07.98.68.041

19.13 Nipple cover Ø 6 mm *** 07.98.15.092

20 Ceramic core *** 07.98.27.001

21 Mid baffle *** 07.98.41.027

22 Lower baffle *** 07.98.41.016

23 Condensate collector *** 07.98.07.007

24 Siphon 32x140 mm *** 07.90.74.200

25 Sealing washer 60 mm *** 07.98.83.233

26 Lifting bar set *** 07.95.74.023

27 CH pump (inc. cable loom K5) *** 07.95.36.002

28 3 Port valve (inc. cable loom K7) *** 75.83.01.004

29 Return pipe for CH pump *** 07.98.74.284

30 Pressure sensor *** 07.98.78.004

31 Pump seal 30 mm *** 07.98.83.230

32 Union nut 1" *** 07.98.82.113

33 Short pipe for pump *** 07.98.74.288

34 T-piece 22x22x22 mm *** 07.98.74.304

35 Pipe with bend - pump * 07.98.74.296

35 Pipe with bend – helix coil * * 07.98.74.287

36 Elbow connection 22x22 mm * * 74.64.30.958

37 Front insulation *** 07.98.83.228

38 Flow pipe *** 07.98.74.308

39 Bracket *** 07.98.37.042

40 Ignition transformer *** 07.98.61.001

41 Screw M4x8 self tap *** 82.08.93.046

42 Hex bolt M8x12 *** 07.98.82.112

43 Controller mounting plate *** 07.95.30.001

44 Controller *** 07.95.64.001

45 Controller front plate *** 07.98.35.288

46 Front case set *** 07.95.22.004

47 Data Plate 24 Model * 07.98.35.294

47 Data Plate 24 Plus Model * 07.98.35.295

ATMOS MULTI Mk2 version 2004 Appendix Page 3

Atmos Multi Mk 2 Parts List

Atmos Multi 24/80

Atmos Multi 24/80 PLUS

Atmos Multi 32/80 PLUS

Drg Ref Description Part Ref.

47 Data Plate 07.98.35.296

47 Data Plate 32 Plus Model * 07.98.35.297

48 Screw M3x 25 *** 07.98.82.115

100 Cable loom K1 (room thermostat) *** 07.98.66.122

101 Cable loom K2 (pressure sensor) *** 07.98.66.206

102 Cable loom K4 *** 07.98.66.212

(CH flow & tank temp sensors)

103 Appliance selection 24 Model * 07.98.63.043

103 Appliance selection 24 Plus Model * 07.98.63.044

103 Appliance selection 07.98.63.045

103 Appliance selection 32 Plus Model * 07.98.63.046

104 Tank temperature sensor *** 07.98.63.047

105 Cable loom K5 (CH pump) *** 07.98.66.208

106 Cable loom K6 *** 07.98.66.202

(Gas valve, max. thermostat,

Ionisation/ Ignition electrode)

107 Cable loom K7 (3 port valve) *** -

108 Cable loom K8 (fan) *** 07.98.66.201

109 Cable K11 (main boiler earth) *** 07.98.66.207

110 Cable loom K12 (ignition earth) *** 07.98.66.204

111 Cable loom K13 (ignition) *** 07.98.66.210

112 Mains lead *** 07.98.66.120

Note 1 Temp. & pressure relief valve *** ?

Note 1 – This part is not shown in the diagrams. Please refer to the Boiler Schematic (Section 4).

ATMOS MULTI Mk2 version 2004 Appendix Page 4

ATMOS MULTI Mk2 version 2004 Appendix Page 5

ATMOS MULTI Mk2 version 2004 Appendix Page 6

ATMOS MULTI Mk2 version 2004 Appendix Page 7

ATMOS MULTI Mk2 version 2004 Appendix Page 8

ATMOS MULTI Mk2 version 2004 Appendix Page 9

APPENDIX 2. Fault Finding

1. GENERAL

The Atmos Multi has 3 types of error messages:-

1. Warning messages

In this case, instead of the status message, a letter appears on the diagnostic display for one second, once every 5

seconds.

2. Blocking messages

A permanently illuminated letter appears on the diagnostic display.

3. Malfunction messages

A flashing letter or number appears on the diagnostic display.

In the event of a warning message, the function to which the message applies will be switched off while the appliance

continues to operate.

In the event of a malfunction message, the entire appliance will be shut down requiring manually resetting before the

boiler will continue operation.

OPERATING CODES ON ATMOS MULTI

See also Table 1 in Section 5 of the Manual. The following appear on the status display:-

1 Hot water heating operating

2 Central heating operating

3 Hot water and central heating – priority to hot water

4 Hot water and central heating - supply to both

The dot in the bottom right hand corner of the diagnostic display indicates the following burner function:-

No dot No burner

Slow flashing dot Minimum fire

Increasingly fast flashing dot Higher & higher firing

Constant dot Burner on maximum output

The dot in the bottom right hand corner of the central heating display: -

Dot Motorised valve energised to send

water to the central heating circuit
