The information within this guide must be used in conjunction with the information in the Audi Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.
By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this
information to augment that material.
LEARN MORE AT
auditechnology.com
Audi Explore
Welcome
Your new A7 is equipped with many features designed to accentuate
your driving experience and create an environment that is refined,
elegant and supremely functional. This guide will assist you in better
understanding some of the features of your A7 and provide you with
the knowledge needed to enjoy your new Audi to its fullest.
When you see this symbol, you can
discover more with your smart phone
by texting the letter keys to the code
provided. A video tutorial will be sent
to further explain the topic.
Standard messaging and data rates charged by your phone
service provider will apply.
MMI® Controls
The MMI® system consists of the MMI® display screen and the
MMI® control panel. This panel is composed of a control knob,
control buttons and function buttons.
Pressing one of the six “function buttons” such as
“RADIO” or “NAV” (Navigation) displays that feature’s
options in each corner of the MMI® screen. For instance,
after pressing the “RADIO” function button, the four
corners of the MMI® screen read “Presets”, “Band”,
“Functions” and “Settings”.
To select one of these options, use one of the four corresponding
buttons, known as the “control buttons,” surrounding the “control
knob.” While operating the function options, you can return to a
previous screen by pressing the “BACK” button.
You can access sub-menus and lists by turning the control knob, which
scrolls through the listings on the MMI® screen. To make a selection,
simply press the control knob.
The MMI® Touch can be used to write letters and numbers or
access Preset Radio stations. To enter a space, drag your finger
from left to right. While in Navigation mode, after pressing
the control knob, the touch pad can be used to move along the
map in the desired direction.
Do not text and drive. Message and data rates may apply.
TEXT A7NAV1 to 38981
Audio & Navigation
MMI® Controls
Media Function Button
7YY[iiWlW_bWXb[c[Z_W\hecYedd[Yj[ZiekhY[i
8BK;JEEJ>7kZ_e"I:YWhZ":L:"@ka[Xen"
and Audi Media Interface (AMI).
Volume/Track Advance Buttons
The knob to the upper right of the control knob is the volume dial.
Fh[ii_d]edY[m_bbckj[j^[WkZ_e$>ebZ_d]_jZemdm_bbjkhdj^[
system off. The arrow buttons allow you to move through the
audio tracks and radio stations.
MMI® Controls
cont.
Steering Wheel Controls
In addition to the MMI® control
panel you can use the multifunction
steering wheel controls to display
specific MMI® features in the
Driver Information System. Simply
press the “ARROW” buttons to
display the MMI® modes. Press the
“MENU” button to display
submenu options for that mode.
The thumbwheel can be used to
scroll through the options. Press it
to make a selection.
The “TALK” button is used to
activate Voice Recognition.
The volume thumbwheel is
used to adjust the volume,
pressing it will mute audio.
Pressing the “iNAV” button
will repeat the last Navigation
announcement when
navigation is active.
The is used to access
a programmable stored
function.
MMI® Controls
You can set any mix of up to 50 Presets from FM, AM or Sirius options.
Setting Station Presets
cont.
1. Press the “RADIO” function
button multiple times to
toggle between FM, AM
ehI?H?KI$
Do not text and drive. Message and data rates may apply.
TEXT A7NAV6 to 38981
*$Ehfh[iiWdZ^ebZj^[Y[dj[h
control knob until the
Presets screen shows
the Preset list.
2. Tune to the desired
station using the control
knob and pressing
to select.
3. Press and hold the desired
number on the touchpad
until you hear the tone that
the station has been stored.
MMI® Controls
To access your Presets:
Fh[iij^[“RADIO” function button
then the Presets control button.
Ki[j^[CC?YedjhebadeXjeiYhebb
through your Presets.
Fh[iij^[Y[dj[hXkjjede\j^[Yedjheb
knob to select a Preset.
EYYWi_edWbbo"jWbbXk_bZ_d]iWdZjkdd[bicWo_dj[hhkfjj^[iWj[bb_j[i_]dWb$<ehceh[_d\ehcWj_ed"fb[Wi[h[\[hjej^[I_h_kiNCXheY^kh[_doekh]bel[Xen$
5. Scroll to the numbered list position
where you want to save your selection.
6. Press the center control knob again;
the station is saved to this position.
MMI® Controls
BLUETOOTH® Pairing MMI®
Initial Setup
3. Select Audi MMI® when it
appears on the phone’s
screen.
BLUETOOTH® pairing is a one-time procedure. Once paired via BLUETOOTH®, your phone will
automatically connect when you start your vehicle and your phone’s contacts automatically
synchronize, allowing you to retrieve contacts and make and receive calls through the infotainment
system. For more information regarding phone compatibility visit audiusa.com/bluetooth.
To pair a phone:
1. Switch ignition to accessories mode.
2. Activate your phone’s BLUETOOTH® function
and set to Pairing or Search mode.
Do not text and drive. Message and data rates may apply.
See your phone’s owner manual for specific pairing instructions. Vehicle should be stationary with the parking brake engaged while performing this operation.
TEXT A7NAV2 to 38981
4. The Audi MMI® system
will indicate a PIN number
is required and ask, Would
you like to connect? Use
the MMI® control knob to
select Yes.
5. Confirm the six-digit PIN
displayed matches the PIN
displayed on your phone
and select Yes using the
control knob.
Note: Once paired, the BLUETOOTH® symbol appears in the MMI® screen along with network strength bars and it will be displayed whenever a paired phone is connected to the infotainment system.
6. Select Pair on your phone
to complete the pairing
process.
-$9edjWYjiiodY^hed_p_d]$
8BK;JEEJ>WYj_l[WdZ
network strength bars.
BLUETOOTH®
Pairing
Call By Name
Do not text and drive. Message and data rates may apply.
Voice Recognition: MMI®
TEXT A7NAV3 to 38981
1. Press the “TALK” button.
A beep will sound.
2. Say, “Call” <Name from directory>
(e.g., “Call John Smith”).
3. To confirm the request, say “Yes”.
The number will be dialed.
Note: If multiple numbers are stored for a given contact, the
system will ask which number you wish to dial. When calling by
name using voice recognition, you must say the name as it is
stored in your phone book.
BLUETOOTH®
Pairing
Voice Recognition: MMI®
cont.
Name Tags
You may attach your own specific verbal Name Tags to stored Contacts, such as nicknames or other words that are not in the directory listing.
You may use any short verbal command.
TEXT A7NAV3 to 38981
Do not text and drive. Message and data rates may apply.
3. Select contact’s name and press MMI®
control knob to open contact’s information.
2. From the telephone menu,
select Directory.
1. Press the “TEL” function button.
4. Press the “TALK” button. After the beep, say “Store Name”.
5. When prompted, say <name>. When prompted,
repeat <name>.
6. The system will confirm, “The name <name> has been stored.”
7. To call this contact, refer to call by name using voice
recognition instructions.
Important Warnings and Safety Information, which you must read, are listed on the last panel under
Voice Recognition.
BLUETOOTH®
Pairing
Audi connect®can provide you with Google Earth™, Google Voice™
Local Search, Wi-Fi Hotspot, Online Services (fuel prices, weather
information, travel information, news feeds) and myAudi
Destinations.
TEXT A7ACT1 to 38981
Do not text and drive. Message and data rates may apply.
1. Ensure SIM card (provided by dealer) is
present in the SIM slot.
2. Press the “TEL” function button.
3. Press the “Settings” control button.
Initial Setup
Note: Vehicle should be stationary with the parking brake set before
performing these operations.
Audi connect®
Audi connect®
Configuration:
Audi connect®
4. Scroll to Connections and press
the control knob once to select. Wi-Fi Configuration
5. Select Data connection. 6. Then, select Set up
connection, scroll to
without request and select.
7. Press the “BACK” function
button and select Network
connection (Wi-Fi).
8. Ensure that Wi-Fi active is
on as notated by a check
mark.
Audi connect®
cont.
9. Scroll to Wi-Fi settings
and select.
11. Select Apply settings to
save your password.
10. Select Password and
enter a password at least
eight characters long and
select OK.
*Most devices use Encryption type
WPA2 as the default.
12. On your device, search for
Wi-Fi Networks select
the SSID and enter your
password to establish
a connection.
Note: You may connect up to eight wireless
devices at one time.
Always pay careful attention to the road, and do not drive while distracted. The features and technologies discussed are optional, may
require an additional subscription with separate terms and conditions, and should be used only when it is safe and appropriate.
The Wi-Fi hotspot feature is intended for passenger use only.
Audi connect® services are only available where there is mobile network coverage. You can obtain more information from your current service provider.
Audi connect®
