Hardware Installation Manual

AudioCodes Gateway & Session Border Controller Series

Mediant 1000 Gateway

and E-SBC

Notice Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

Notice

Information contained in this document is believed to be accurate and reliable at the time

of printing. However, due to ongoing product improvements and revisions, AudioCodes

cannot guarantee accuracy of printed material after the Date Published nor can it accept

responsibility for errors or omissions. Updates to this document can be downloaded

from https://www.audiocodes.com/library/technical-documents.

This document is subject to change without notice.

Date Published: July-21-2021

WEEE EU Directive

Pursuant to the WEEE EU Directive, electronic and electrical waste must not be disposed of with

unsorted waste. Please contact your local recycling authority for disposal of this product.

Customer Support

Customer technical support and services are provided by AudioCodes or by an authorized

AudioCodes Service Partner. For more information on how to buy technical support for

AudioCodes products and for contact information, please visit our website at

https://www.audiocodes.com/services-support/maintenance-and-support.

Documentation Feedback

AudioCodes continually strives to produce high quality documentation. If you have any

comments (suggestions or errors) regarding this document, please fill out the Documentation

Feedback form on our website at https://online.audiocodes.com/documentation-feedback.

Stay in the Loop with AudioCodes

Notes and Warnings

Read and adhere to all warning statements in this document before installing the

device.

The device is an INDOOR unit and must be installed only indoors.

- ii -

Notice Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

(French) Avertissement: L’appareil est une unité d’INTERIEUR et doit donc

obligatoirement être installé en intérieur.

Ethernet port interface cabling must be routed only indoors and must not exit the

building.

(French) Avertissement: Le câblage de l’interface du port Ethernet doit être acheminé

uniquement en intérieur et ne doit pas sortir du bâtiment.

FXS indoor module: FXS port interface cabling must be routed only indoors and must

not exit the building.

(French) Avertissement: FXS module intérieur: le câblage de l’interface du port FXS

doit être acheminé uniquement en intérieur et ne doit pas sortir du bâtiment.

The device is supplied as a sealed unit and must be installed and serviced only by

qualified service personnel.

(French) Avertissement: L’appareil doit obligatoirement être installé et entretenu par

un agent de service qualifié.

Disconnect the device from the mains and Energy Source (ES) before servicing.

(French) Avertissement: Débranchez l’appareil du secteur et de la Energy Source

(ES) avant toute réparation.

Caution Electrical Shock: Do not open or disassemble this device. The device carries

high voltage and contact with internal components may expose you to electrical

shock and bodily harm.

(French) Attention életrocution: Ne tentez pas d’ouvrir ni de démonter l’appareil.

L’appareil transporte une haute tension et son contact avec des composants internes

risque de vous exposer à l’électrocution et à des lésions corporelles.

Open source software may have been added and/or amended for this product. For

more information, please visit our website at https://www.audiocodes.com/services-

support/open-source or contact your AudioCodes sales representative.

Regulatory Information

VoIP Gateway

1. This equipment complies with Part 68 of the FCC Rules and the requirements adopted

by the ACTA. On the bottom of the unit or on the Interface card of this equipment is a

label that contains among other information, a product identifier in the format

- iii -

Notice Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

US:AC1IS00BM1KMIX or US:AC1ISNANM1000 and ringer equivalence. If requested, this

number must be provided to the telephone company.

2. This equipment is designed to be connected to the telephone network using an RJ-48C

and/or RJ-11C connector, which is Part 68 compliant. The service order codes (SOC) are

6.0F for digital interfaces and 9.0Y for analog interfaces and the Facility interface codes

(FIC) are: 04DU9.1SN, 04DU9.1KN, 04DU9.BN, 04DU9.DN, 02LS2, O2GS2.

3. For FXO Only: The REN is used to determine the number of devices that may be con-

nected to a telephone line. Excessive RENs on a telephone line may result in the devices

not ringing in response to an incoming call. In most but not all areas, the sum of RENs

should not exceed five (5.0). To be certain of the number of devices that may be con-

nected to a line, as determined by the total RENs, contact the local telephone company.

The REN for this product is 0.5.

4. Should the product cause harm to the telephone network, the telephone company will

notify you in advance that temporary discontinuance of service may be required. If

advance notice is not practical, you will be notified as soon as possible. In addition, you

will be advised of your right to file a complaint with the FCC if it is necessary.

5. The telephone company may make changes in its facilities, equipment, operations or

procedures that could affect the operation of the equipment. If this happens, the tele-

phone company will provide advance notice in order for you to make necessary modi-

fications to maintain uninterrupted service.

6. If trouble is experienced with this equipment, for repair or warranty information please

contact AudioCodes Inc. 200 Cottontail Lane, Suite A101E, Somerset NJ 08873, USA; Tel:

+1-732-469-0880, Fax: +1-732-469-2298. If the equipment is causing harm to the tele-

phone network, the telephone company may request to disconnect the equipment until

the problem is resolved.

7. Connection to Telephone Company Provided coin service is prohibited. Connection to

party lines service is subject to state tariffs.

Related Documentation

Document Name

Mediant 1000 Datasheet

SBC-Gateway Series Release Notes

Mediant 1000B Gateway & E-SBC SIP User's Manual

- iv -

Notice Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

Document Revision Record

LTRT Description

41414 New warning bulletin regarding plastic sticker covering spare AC power socket;

New section for replacing Power Supply module; new drawings for replacing

modules.

41415 Installing operating system (OS) on OSN was modified (OS is not installed by

default).

41417 FXO warning statement added.

41418 Hardware Maintenance chapter was updated (rear-panel slot assignment

section added; front-panel module replacement updated; OSN server module

replacement updated).

41420 Correction to SWX module port labels; chassis weight.

41422 Fan Tray module replacement procedure added.

41424 MPM module slot assignment; BRI/PRI Fallback section updated.

41426 RS-232 cable adapter ordering information modified.

41427 Power surge protection warnings.

41430 HDMI connector.

41431 Power Supply module replacement update; physical dimensions; miscellaneous

formatting.

41432 Module slot assignment update.

41433 FXS outdoor module added and relevant cabling instructions (for power surge

protection); OSN 3/4 reset button described; HDMX module LED description

typo; AC power cable note added (Japanese).

41434 REN for FXO.

41435 FXS outdoor limitation for simultaneous ring and off-hook long haul.

41436 FXS outdoor-routing warning bulletin updated.

41437 Ethernet port 0/3 added to CRMX.

41438 Dry-contact relay interface added.

-v-

Notice Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

LTRT Description

41439 FXS module part numbers updated.

41441 Logo updated; fallback updated.

41443 OSN3C and OSN4B modules added; HDMI cable connector updated with figure;

FXS module for indoor-and-outdoor updated

41444 Duration of press for reset to defaults; trademarks.

41445 New CRMX module; regulations updated; only OSN4B kept in document

41446 Replacing CRMX module and faulty device

- vi -

Content Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

Table of Contents

1 Introduction 1

2 Unpacking the Device 2

3 Physical Description 3

Physical Dimensions and Operating Environment 3

Front Panel Description 3

FXS Module 5

Ports Description 5

LED Description 5

FXO Module 6

Ports Description 6

LED Description 6

BRI Module 7

Ports Description 7

LED Description 7

TRUNKS (E1/T1) Module 8

Ports Description 8

LED Description 8

Media Processing Module (MPM) 9

CRMX Module 10

Ports Description 10

LED Description 12

SWX LAN Expansion Module 14

Ports Description 14

LED Description 15

Fan Tray Module 15

Power Supply Module and LED Description 16

Rear Panel Description 17

OSN Server Modules 18

OSN4B Module 18

HDMX Module 22

4 Mounting the Device 24

Desktop Mounting 24

19-inch Rack Mounting 24

Mounting in a 19-inch Rack using a Pre-Installed Shelf 25

Mounting in a 19-inch Rack using Front-Mounting Brackets Only 26

Mounting in a 19-inch Rack using Front and Rear Mounting Brackets 26

5 Cabling the Device 33

Earth Grounding and Power Surge Protection 33

Connecting to LAN with Port-Pair Redundancy 34

Analog Interfaces 36

Connecting to FXS Interfaces 36

- vii -

Content Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

Indoor FXS Cabling 37

Outdoor FXS Cabling 38

Connecting to FXO Interfaces 40

Indoor FXO Cabling 41

Outdoor FXO Cabling 41

Connecting the FXS Analog Lifeline Phone 43

ISDN BRI Interfaces 45

Connecting to BRI Lines 45

Connecting the PSTN Fallback for BRI Lines 46

ISDN E1/T1 Interfaces 47

Connecting to E1/T1 Trunks 47

Connecting the PSTN Fallback for E1/T1 Trunks 48

Connecting the RS-232 Serial Interface 49

Connecting a Dry-Contact Relay Alarm System 50

Cabling and Installing OSN Server Platform 52

Connecting to Power 54

6 Hardware Maintenance 57

Chassis Slot Assignment for Modules 57

Front-Panel Module Slot Assignment 57

Module Slot Assignment on Rear Panel 58

Installing and Replacing Modules 58

Front-Panel I/O Modules 58

Replacing Blank-Panel Slot Covers with I/O Modules 59

Replacing I/O Modules 60

OSN Server Modules 64

Replacing Blank-Panel Slot Covers with OSN Server Modules 64

Replacing OSN Server Modules 66

Replacing the Fan Tray Module 68

Power Supply Module 69

Installing an Optional, Secondary Power Supply Module 70

Replacing a Power Supply Module 71

Replacing a Faulty Device 72

7 Module Hardware Revision Compatibility 74

- viii -

CHAPTER1 Introduction Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

1 Introduction

This document provides a hardware description of the Mediant 1000B Gateway & E- SBC

(hereafter referred to as device) and step-by-step procedures for cabling the device.

The device is a 19-inch industrial platform chassis, 1U high and 13.8 inch deep. The chassis'

modular hardware design allows scalability to capacity demands and optional telephony

interfaces to suite your requirements.

The device supports the following interfaces:

■Analog and Digital Telephony (Separate orderable item):

●Up to four digital trunks modules, supporting up to 6 x E1 / 8 x T1 (1, 2, or 4 E1/T1/J1

PRI spans per module)

●Up to five BRI modules, where each module provides four BRI ports

●Up to six FXO modules, where each module provides four FXO ports

●Up to six FXS modules, where each module provides four FXS ports

■(Separate orderable item) Up to four Media Processing modules (MPM), providing

additional DSP resources for SBC transcoding and/or three-way conferencing

■Up to seven LAN Ethernet interfaces:

●Three interfaces on the CRMX module

●(Separate orderable item) Four interfaces provided by a LAN Expansion module (SWX)

■(Separate orderable item) Open Solution Network (OSN) server modules for hosting third-

party applications (such as an IP PBX)

■Dry-contact alarm relays for connection to an external audible or visual alarm system (e.g.,

bell)

■Fan Tray module

■Up to two Power Supply modules

●Hardware configurations may change without notice. Currently available

hardware configurations are listed in AudioCodes Price Book. For further

enquiries, please contact your AudioCodes sales representative.

●For information on configuring the device, refer to the device's User’s Manual.

-1-

CHAPTER2 Unpacking the Device Mediant 1000 Gateway & E-SBC | Hardware Installation Manual

2 Unpacking the Device

Follow the procedure below for unpacking the carton in which the device is shipped.

➢To unpack the device:

1. Open the carton and remove the packing materials.

2. Remove the chassis from the carton.

3. Check that there is no equipment damage.

4. Ensure that in addition to the chassis, the package contains the following items:

●One or two AC power cables (depending on customer order)

●Four anti-slide bumpers for desktop installation

5. Check, retain and process any documents.

If there are any damaged or missing items, notify your AudioCodes sales representative.

-2-

Andere Handbücher für Mediant 1000

Inhaltsverzeichnis

Andere AudioCodes Tor Handbücher

AudioCodes

AudioCodes Mediant 1000 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 800 MSBG Bedienungsanleitung

AudioCodes

AudioCodes Gateway & Session Border Controller Series Montageanleitung

AudioCodes

AudioCodes Mediant 1000B Montageanleitung

AudioCodes

AudioCodes Mediant 3000 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 800 MSBG Bedienungsanleitung

AudioCodes

AudioCodes MP-100 Bedienungsanleitung

AudioCodes

AudioCodes Media Pack MP-11x Montageanleitung

AudioCodes

AudioCodes MediaPack MP-124 Bedienungsanleitung

AudioCodes

AudioCodes MediaPack MP-263 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 1000 Bedienungsanleitung

AudioCodes

AudioCodes MediaPack 1288 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 1000 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 3000 Bedienungsanleitung

AudioCodes

AudioCodes MP-104 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 8000 Gebrauchsanweisung

AudioCodes

AudioCodes Mediant Series Kurzanleitung

AudioCodes

AudioCodes MediaPack 1 Series Montageanleitung

AudioCodes

AudioCodes MediaPack MP-124 Bedienungsanleitung

AudioCodes

AudioCodes MediaPack MP-124 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 2000 Montageanleitung

AudioCodes

AudioCodes Mediant 600 Bedienungsanleitung

AudioCodes

AudioCodes Mediant 500 Bedienungsanleitung

AudioCodes

AudioCodes Commander MP264DB Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

Huawei

Huawei EchoLife HG620 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung
