Audiovox VM9413 Bedienungsanleitung
Featuring:
DVD, CD, MP3, WMA, USB and SD Playback
Touch Screen Interface
4
MediaLink A/V Input
Front Panel SD input
Composite Video Out
Remote Control
Navigation Ready (NAV102 Only)
Bluetooth Ready (Requires BTM10)
VM9413 Quick
Reference Guide
Press Audio
VM9413
Enter
MUTE NAV INT RPT
BAND ASOPEN DISP
Navigation operation requires NAV102
installation
Bluetooth operation requires BTM10
installation
Rear Camera operation requires rear camera
installation
Anti-Theft Feature
Entering the Default Password
The VM9413 is equipped with an anti-theft feature requiring the user to enter a
password upon initial power on.
The default user password is 012345 (6 digits). Enter the password using the on-
screen keypad and then press the Enter (arrow) button. You can also use the remote
control keypad to enter the password.
123
456
789
0
Enter Password:
Changing the Password
To change the anti-theft and RATINGS protection password,perform the following
steps:
1. Press the SETUP button on the remote control or touch the button on the
screen to enter the “SETUP” menu.
2. Touch RATING to view the “RATING” sub-menu. An open lock icon to the right of
the “Password” field indicates that a user password had not yet been entered.
3. Touch the keypad icon next to the blue box in the “Password” field to open the
on-screen keypad.
4. Enter a new 6-digit password and press the Enter (arrow) button.
The "lock" icon will now appear closed and the new anti-theft password will be
set, as well as the password for RATING protection.
NOTE: If you forget your password, contact Customer Service at 1-800-323-4815 for
assistance.
RADIO
SETUP
RDS
Rating
Hardware
P.VOL
TS Cal
General Language Audio Back
Password
Rating 8. Adult
Load Factory Reset
Speaker
Demo
Bluetooth
02:40 AM
123
456
789
0
Clear
Controls and Indicators
1. Press to turn the unit on. Press and hold to turn the unit off.
Press repeatedly to select playing mode.
2. Turn to adjust the volume.
Press and hold to access audio menu. While in menu, press repeatedly to view
audio settings.
3. Press to mute audio. Press again to resume previous volume.
4. Insert disc for automatic playback.
5. Press to eject disc.
Press and hold to reset core mechanism position.
6. Press to change the AM, FM or SAT band.
7. Press to play the previous chapter/track or auto-search the previous available
radio station. In menu mode, press to move the cursor to the left.
8. Press to access the next chapter or track or auto-search the next available radio
station. In menu mode, press to move the cursor to the right.
9. Press to cycle through information available on the LCD or TFT screen. In DVD
Mode, press to view the top and bottom information bars. Press again to turn
“Display Off”.
16
8
15
19
5
3
120
11
s Audio Enter
2
Pre s
13
717
OPEN DISP
BAND
AS
10
43
6
14 9
18 12
NAV INT
VM9413
10. View playback information on secondary LCD.
11. Point remote control at IR Receiver to control functions.
12. Insert SD card for playback of media files through the radio.
13. Use thin metallic object to depress RESET button and restore factory default
settings.
14. Press to open TFT screen.
15. Press to pause or resume playback or to confirm current selection.
16. Press to fast forward/fast reverse disc or tune up one frequency step in tuner
mode. In menu mode, press to move the cursor up.
17. Press to slow forward/slow reverse disc or tune down one frequency step in tuner
mode. In menu mode, press to move the cursor down.
18. When the NAV102 is connected to the head unit, press to display the navigation
user interface. The TFT screen must be open for this function to operate.
19. Press to control intro playback function.
20. Press to control repeat playback function.
Controls and Indicators (continued)
BAND
CLOSE ASDISP Multimedia Receiver
21
22
24
25
23
s Audio Enter
Pres
VM9413
ANGLE / TILT PICTURE
NAV INT
21. Touch the TFT screen to control head unit functions.
22. Press to close the TFT screen.
23. Press once to adjust the downward tilt angle of the screen one step at a time or
press and hold to adjust the angle in a continuous motion.
24. Press once to adjust the upward tilt angle of the screen one step at a time or
press and hold to adjust the angle in a continuous motion.
25. Press to adjust the display aspect ratio of the picture to one of three settings:
Full, Normal or Standby.
Press and hold to adjust the Brightness and Contrast. Press the volume control
to move between Brightness and Contrast. Turn the rotary encoder to adjust the
setting for the selected option.
Common User Settings
Audio Control Menu
Touch the EQ button on the left side of the screen to access the Audio Control Menu,
shown below.
1. Use the touchscreen or the left/right joystick buttons on the unit or remote control
to highlight the audio feature to be adjusted.
2. Touch the screen or press the joystick enter button to select the highlighted
option.
3. Touch the +/– buttons on the screen or use the joystick to adjust the selected
feature to the desired setting.
Touch the "FAD-BAL"
button to access a
second screen with the
Balance/Fader
settings.
Use the arrows on
either side of the box
where "User" is
selected, to choose a
preset equalizer level.
NOTE
The EQ mode will automatically change to “USER” when individual
audio functions are adjusted.
EQ: User
E
Q
T
A
G
+12 —
0 —
–12 —
80 250 600 1k 4k 10k 16k
FAD-BAL EQ USER BACK
