MMDV7OC / MMDV7OC B

7” LCD OVERHEAD MONITOR

WITH DVD PLAYER

OPERATION MANUAL

TOP EJECT

DO M E LIGHT

ON OFF AU TO

POW ER PLAY

OFF ON

POWER

IMPORTANT

AnLCDpaneland/orvideomonitormaybeinstalledinamotorvehicleandvisibleto thedriverif

the LCD panel or video monitor is used for vehicle information, system control, rear or side

observationornavigation.IftheLCDpanelorvideomonitorisusedfortelevisionreception,video

or DVD play, the LCD panel or video monitor must be installed so that these features will only

functionwhenthevehicleisin‘park’orwhenthevehicle’sparkingbrakeisapplied.

An LCD panel or video monitor used for television reception, video or DVD play that operates

whenthevehicle isingearorwhentheparkingbrakeisnotapplied,mustbeinstalledtotherear

of the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor

vehicle. Warnings

♦Do not use any solvents or cleaning materials when cleaning the video system.

♦Do not use any abrasive cleaners, they may scratch the screen. Use only a lightly

dampened lint free cloth to wipe the screen if it is dirty.

♦Lock the LCD screen in the fully closed position when not in use.

♦Beforeputtingonheadphonesalwaysadjustthe volumesetting tothelowestposition.

♦Remember to leave the dome light switch in the off or auto positions when the

vehicle is unattended, as the dome lights, if left on, can drain the vehicle’s battery.

♦Do not put pressure on the screen.

♦Caution children to avoid touching or scratching the screen, as it may become dirty

or damaged. Safety Precaution

For safety reasons, when changing video tapes it is recommended that the vehicle is not in

motion, and that you do not allow children to unfasten seatbelts to change tapes or make any

adjustmentstothesystem. Systemadjustmentscanbeaccomplishedusingtheremotecontrol

unit,whileseatbeltsremainfastened. EnjoyyourMovies2Goentertainmentsystembutremember-

safety of all passengers remains the number one priority.

Congratulations on your purchase of the Movies 2 Go MMDV7OC / MMDV7OC B

drop-down Video Monitor with DVD player. The MMDV7OC / MMDV7OC B has been

designed to give you and your family many years of video entertainment in the mobile

environment. Please read the directions that follow to familiarize yourself with the

product and to ensure that you obtain the best results from your equipment.

NOTE: Installation options vary, see the individual owner’s manuals for each

component in your system to obtain a full understanding of each component’s

operation.

FEATURES

♦7”TFT(ThinFilmTransistor)ActiveMatrixLCD(LiquidCrystal

Display)MonitorwithDVDplayer

♦OSD(OnScreenDisplay)forControlofPictureQualityand

Functions

♦DVD/CD/MP3 compatible

♦Infrared Transmitter for the included IR Wireless

Headphones

♦Two Audio / Video Source Inputs (One is for internal

DVD player)

♦Power ON/OFF Switch

♦RemoteRepeaterSensor

♦DomeLightswithBuilt-inThreeWaySwitch

♦VideoDisplayON/OFFControl(whenLCDPanelisOpened

andClosed)

CONTROLS AND INDICATORS DIAGRAM

POWER PLAY STO P EJECT

DOM E LIG H T

ON OFF AUTO

OFF ON

POW ER

MENU DOWN UP

MAINFUNCTIONDESCRIPTIONS

1. DVD disc insertion slot.

2. Power Button – For internal DVD player

3. Play Button

4. Eject Button

5. Stop Button

6. MMDV7OC / MMDV7OC B Ventilation opening

7. Infrared Transmitter – Used to transmit audio to wireless headphones.

8. Dome Lights – Provide additional interior illumination.

9. Power ON/OFF Select Switch – For LCD monitor.

10. Select Up Button

11. Select Down Button

12. Menu button – Display MENU, PICTURE, SOURCE and DISPLAY OFF.

13. LCD Panel

14. Screen Release – Slides in the direction of the arrow to release the drop

down screen.

15. Three Position Dome Light Switch

• Auto – Automatically switches on the dome lights in conjunction with the

vehicle’sinterior illumination.

• Off – The Dome lights will not turn on in this position.

• On – Turns on the Dome lights.

16. Remote Sensor – For remote repeater.

17. Remote Sensor – For remote internal DVD player.

BATTERY INSTALLATION

Before attempting to operate your

RemoteControl,installthebatteriesas

described below.

1) TurntheRemote Control facedown.

Using a fingernail, lift the battery

cover off.

2) Installtwo“AAA”batteries asshown.

Makesurethatproperpolarity(+or

–) is observed.

3) Align the cover tabs with he remote

control and press down until the

cover clicks.

The remote control will operate the

MMDV7OC/ MMDV7OCBDVDplayer

only. Itisnot a universal remotecontrol

and will not control equipment from

other manufacturers.

REMOTECONTROLOPERATION

–

RETURN

A-B

REPEAT

SETUP

EJECT

DISPLAY

ANGLE

AUDIO

ZO O M

Enter

13 14

16 17

20 21

DVD FUNCTION DESCRIPTIONS

1. DISPLAYButton

Press to display DVD Disc current information.

2. ANGLE Button

Allows the user to select the DVD angle if the DVD contains this feature.

3. SUBTITLE Button*

Allows the user to select the DVD subtitle feature. Use cursor keys to highlight desired

item, use ENTER to switch.

4. AUDIO Button*

Allowsthe user to entertheAudio menu features (languagespokenetc.). Use the ( )

buttons to highlight desired item, use the ( ) buttons to switch.

5. ZOOM Button

Press this button to zoom the picture.

Press ZOOM button O SD DVD PlayerPerform

Once ZOOM x2 ZOOM picture 2 times

Tw ice ZOOM x3 ZOOM picture 3 times

3 times ZOOM x4 ZOOM picture 4 times

4 times ZOOM x1/2 Reduced picture to 1/2

5 times ZOOM x1/3 Reduced picture to 1/3

6 times ZOOM x1/4 Reduced picture to1/4

7 times ZOOM OFF NormalDisplay

Press DISPLAY button DVD PlayerPerform

Once Display currentTITLE & CHAPTER

Tw ice D isplay currentSUBTITLE

3 times Display currentAUDIO language & channel

4 times Display currentANGLE

5 times Display A-B curre n t status

6 times Display REPEAT currentstatus

7 times Display is turned off

*NOTE: Some DVDS only allow access to these functions through the root menu.

6. UP ( ) Button

Allows the user to scroll upwards in the menu options.

7. LEFT ( ) Button

Allows the user to shift left in the menu options.

8. MENU Button

Allows the user to access the main DVD menu.

9. RETURN Button

Allows the user to exit the set up menu.

10.NEXT ( )Button

Allows the user to skip to the next chapter or track.

11. PREVIOUS ( ) Button

Allows the user to return to the previous chapter or track.

12.SCANBACKWARD ( ) Button

Allows the user to search in a backward direction at 2,4,6,8,16 and 32 times the normal

speed.

13.SCAN FORWARD ( ) Button

Allows the user to search in a forward direction at 2,4,6,8,16 and 32 times the normal

speed.

14.SLOW Button

The DVD viewing speed will be reduced to 1/2, 1/4, 1/8 and 1/16 times of the normal

speed.

15. STOP ( ) Button

DVD disc play will be stopped.

16.PLAY( ) Button

Pressthisbuttontoactivatetheplaymodewhileadiscisloadedintothedisccompartment.

17.PAUSE ( ) Button

Allows the user to pause the playback.

18.A–B REPEAT Button

Allows the user to repeat play of a DVD or CD from pointAto point B.

21.SETUP Button

Allows the user to select the DVD options (Display, OSD Language, Default, Parental

Control,Password,ExitSetup). Thesetupdisplaycanbeviewedonlywhentheplayeris

in stop mode.

22.RIGHT ( ) Button

Allows the user to shift to the right in the menu options.

23.ENTERButton

Used to select or switch a highlighted selection.

24.NUMBERS Buttons

Allows the user to enter the number 0 to 9 for selection of CD tracks, dvd chapters and

passwordsetting.

25.EJECT ( ) Button

The disc will be ejected from the disc compartment.

19.REPEAT Button

Allows the user to repeat various titles, chapters or tracks of a DVD,CD or MP3 and

displaysthe repeat menu.

20.DOWN ( ) Button

Allows the user to scroll downward in the menu options.

TURNINGTHEMMDV7OC/MMDV7OCBONOROFF

(LCDDISPLAYUNIT&INTERNALDVDPLAYER)

1. Sliding the screen release lock forward will unlock the LCD screen and drop

downslightly. Movethescreen downwardand pivotituntilacomfortableviewing

angle is reached. The internal friction detent will hold the screen in position

while the system is in use.

2. Slide the POWER switch to the ON position on the monitor.

3. Press the POWER Button to switch on the Internal DVD source.

4. Select AV1 from the menu options (see page 14 for details).

5. After the unit is turned ON and begins to display a picture, adjust the viewing

angle by pivoting the screen to optimize the picture quality.

6. Remember to turn the unit OFF and pivot the LCD to the locked position when

not in use.

TOP EJECT

DOM E LIGHT

ON OFF AUTO

POW ER PLAY

OFF ON

POW ER

Power

ON/OFF

Switch

Power

Button
