AC-R2-001 Page 2
IMPORTANT
Read the following instructions carefully and be sure your appliance is properly installed, assembled and
cared for. Failure to follow these instructions may result in serious bodily injury and/or property damage.
This appliance is intended for commercial use only.
This appliance is adjusted to operate on the gas specified on the gas type label and on the data label.
The gas type label is located front of the appliance and data label RH side front of the appliance. If in
doubt as to the type of gas available contact the network operator or gas supplier for confirmation of gas
type.
It is the operator’s responsibility to check the appliance is properly assembled and maintained
The heat shield located beneath the burner must always be in place during burner operation.
Do not lay the gas cylinder down – cylinder should be stored / used in the upright position
Hazardous fire or explosion may result if instructions are ignored.
Leak test all connections before use and after each cylinder refill
Never check for leaks with a match or naked flame
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
Use only in well ventilated areas, but not facing against any draught.
WARNING! Carbon monoxide hazard – this appliance can produce carbon monoxide which has no
odour. Using the appliance in an enclosed space (for example, boats, caravan, tent, car, and mobile
home) may cause death.
Do not move the appliance during operation
Avoid twisting or kinking of the flexible gas hose
Do not use the appliance near any air opening(s) into buildings (i.e. windows, doorways, ventilation ducts
etc.)
Leak test all connections before use and after each cylinder refill – refer “How to Check for Gas Leaks” in
this manual.
An LP gas cylinder not connected for use in this appliance shall not be stored near this appliance.
Ensure the gas hose is not placed under the appliance or allowed to contact any hot surfaces of the
appliance
This appliance must not be modified or changed in any way.
Disconnect the gas cylinder from the burner prior to storage. It is also recommended that the gas
cylinder be stored outdoors in a well-ventilated area.
Do not use any other gas type except the one specified on the label/data plate.
Use only the gas regulator and hose supplied with this appliance. An inferior or a damaged regulator
could cause an incomplete combustion or other troubles with the burner.
Do not leave the burner unattended when in use. Always turn off the burner and the main gas valve after
each use.
Do not use the burner as a space heater under any circumstance.
Do not cover or blow off the flames. This could cause gas leaking.
Always keep inflammable materials away from the burner.
Make sure that you use cooking woks, pots or pans that sit firmly on the trivet. Do not use pots that are
too small / large for the burner size, as they could be unstable on the trivet.
If abnormal combustion is observed when in use, turn off the main gas valve and examine the burner
(Refer to Trouble-Shooting Guide).
Do not attempt to repair the burner yourself.
Do not install into a marine environment.
This appliance is suitably protected while it is on its way to you. All materials used for packaging are
suitable for recycling. Please make a contribution to protecting the environment by disposing of the
packaging appropriately
HOW TO CHECK FOR GAS LEAKS
To check for leaks, turn on gas supply with the appliance gas valves in the OFF position (DO NOT
IGNIGHT) Check for leakage by brushing a solution of soapy detergent and water onto the connection
points at the bottle and the appliance. If bubbling is evident (it may take more than 30 seconds to
appear) this indicates a gas leak is present. If disassembling, cleaning, reassembling and tightening the
connection does not rectify the leak you should close the gas cylinder valve and consult the place of
purchase for assistance.
