Auslock T11 Bedienungsanleitung
Special Attention:
1. Mechanical keys please keep outdoor, just in case keys lock in doors.
2. Please replace for the battery when low wattage alarm.
3.Reading this manual carefully before installation, and keep it for future reference.
Smart Dead Lock
User Manual
1
1. Introduction
1.1. Lock structure
1.2. Packing List
Check the following drawing to check whether the package contains all the parts
NO
Name
Qty
NO
Name
Qty
1
Front Panel
1
9
Screw Stubs:M4*30mm
3
2
Back Panel
1
10
Screw Stubs:M4*40mm
3
3
Mortise
1
11
Mortise Screws:M4*25mm
(For Wooden Door)
4
4
Card
3
12
Mortise Screws:M5*10mm
(For Aluminum Door)
4
5
Mechanical Key
2
13
M4*10mm Screws
For Fixing Back Panel
4
6
Waterproof Rubber Plate
2
14
M4*30mm Screw
3
7
User Manual
1
15
M4*50mm Screw
3
8
Strike&Strike Box
1+1
16
Sucker
1
Introduction
Operation
F&Q
Installation
2
1.3. Specifications
Suitable for
Models
T11
Doors Applicable
Aluminum door
Wooden door
Materials
Handle：Zinc Alloy
Working Voltage
6V/4x AA Batteries
Lock Weight
2.0KG
Door Thickness to Fit
35-60mm
Unlocking Way
Bluetooth
Fingerprint(option)
Password
Card
Mechanical key
Data Capacity
Fingerprint：200
Password：150
Card：200
Color
Silver
Black
Working Temperature
-10℃-55℃
Low Wattage
Alarm
Less than 4.8V
Working Humidity
0-95%
Introduction
Operation
F&Q
Installation
3
1.4. Initialization
Tip: How to open the key cover?
2.Installation
2.1Confirm opening direction
Use a suction cup to suck on the key
cover for easier opening
Long press the reset button on the back of the
front panel for about 3s, input “000#”, the
initialization is successful when the buzzer short
beep twice.
Reset Button
Introduction
Introduction
Operation
F&Q
Installation
4
Set The Left Open
Set The Right Open
1
Spindle always keep
horizontal
2
Deadbolt always
keep pull in
3
What is left open?
This we called "left
open"(show as
image)
4
Change to "L" or “R”
position in the PCB
of back panel
5
Deadbolt knob
Attention：Any of above is improper set, will cause problem！！！
2.2. Installation Diagram
Step1 Install Mortise
Step2 Install Screws Casing and Water Rubber Plate
5
Step3 Install Front Panel
Step4 Fixed Front Panel and Water Rubber Plate
Step5 Connecting Front and Back Panels
Step6 Fixed Back Panel
Step7 Install Batteries
Step8 Cover the battery box
3.Operation
Introduction
Operation
F&Q
Installation
Spindle always
keep horizontal
The deadbolt
always keep
PULL IN
6
3.1. Registration
3.2. Connect lock to the phone
1) please scan the QR code to download the app
2) You can also search for AUSLOCK in the APP store (Google Play) to download
4) Register a new account (phone number or email) or login with an existing account.
5) Touch the lock screen to light, click "+ Add Lock”
6) The lock nearby will appear on the phone screen, Click "+"
7) Re-name the lock
8) The lock added successfully
3.3.Add locks
Auslock supports multiple types of lock devices. The lock needs to be added by the app after
entering the add mode. Generally, a lock that has not been added, as long as the lock keyboard is
touched, it will enter the add mode. The default password is 123456 if not added by the phone
H11
The software (iOS version) can be
downloaded from the app store, and
the Android version can be
downloaded from the application
store of Google play, Yingyongbao,
Baidu, Ali, 360, Huawei, and
Xiaomi.
AUSLOCK users can register the account by
mobile phone and Email which currently support
200 countries and regions on the world. The
verification code will be sent to user’s mobile
phone or email, and the registration will be
successful after the verification.
7
3.4. User Management
3.4.1. Bluetooth management
Make sure there is no problem with Bluetooth communication. After connecting the phone to the door
lock as above, Click " "to unlock.(the phone is within 5meters from the door lock)
3.4.2. Setting Passcode
Passcodes are also a way to unlock.After entering the passcode on the locked keyboard, press the unlock
button in the lower right corner to unlock. Passcodes are divided into permanent, time-limited, single, clear,
cycle, and custom. (You can share the Passcode to other user via WeChat、SMS、Email、
Messenger、WhatsApp)
3.4.3. Send e-Key
Click on the " " as shown in figure, you can send the eKey to other users of Auslock to
authorize the unlock(the receiver must be download the APP and set up an account)→ Select e-key
format (Timed, permanent, One-time, Recurring) → Enter recipient's account of Auslock ,set the
name and effective time of the eKey, Can choose to allow remote unlocking or disallowing,
authorized administrator or not authorized, as shown in figure →Send→The recipient's account has
Bluetooth unlock permission
Introduction
Operation
F&Q
Installation
8
3.4.4.Add card
Supports opening doors through various IC cards. Before an IC card is used to open the door, i
t needs to be added first. The adding process needs to be performed by the app beside the lock.
The validity period of the IC can be set, it can be permanent, or it can be limited in time.
3.4.5. Add fingerprint
The premise that a fingerprint can be used to open a door is that it needs to be added first. The
adding process needs to be performed by theAPP beside the lock. The fingerprint expiration data can
be set, it can be permanent, or it can be limited. After setting, you can modify its validity period.
3.4.6. e-Key management
Click “ “ The manager can delete ekey, reset ekey, send and adjust the ekey, meanwhile he
can search the lock record.
3.4.7. Passcode management
Click " “. All generated passwords can be viewed and managed in the password
management module. This includes a password change, password deletion, password reset, and
password unlock record.
3.4.8. Unlock records
Click " "you can query your unlock record as shown in figure
Introduction
Operation
F&Q
Installation
9
3.5. Gateway management(Optional)
The Auslock is directly connected via Bluetooth, that is why it is not attacked by the network.
The gateway is a bridge between smart locks and home WIFI networks. Through the gateway, the
user can remotely view and calibrate the lock clock, read the unlock record. Meanwhile, it can
remotely delete and modify the password.
3.5.1. Add Gateway
3.6.Electronic Locking Button
Introduction
Operation
F&Q
Installation
1.If you want to have the Electronic Locking function,
first turn on "privacy lock" on the app 2. When the button
is in the red state, it is in the locked state and can only be
unlocked through the administrator app or mechanical
key.
