Autel MaxiProgrammer 201 Bedienungsanleitung

Trademarks

MaxiSys®, MaxiDAS®, MaxiScan®, MaxiRecorder®, MaxiTPMS®, and

MaxiCheck®are trademarks of Autel Intelligent Technology Corp., Ltd.,

registered in China, the United States and other countries. All other marks are

trademarks or registered trademarks of their respective holders.

No part of this manual may be reproduced, stored in a retrieval system or

transmitted, in any form or by any means, electronic, mechanical, photocopying,

recording, or otherwise, without the prior written permission of Auteltech.

Disclaimer of Warranties and Limitation of Liabilities

All information, specifications and illustrations in this manual are based on the

latest information available at the time of printing. Auteltech reserves the right to

make changes at any time without notice. While information of this manual has

been carefully checked for accuracy, no guarantee is given to the completeness

and correctness of the contents, including but not limited to the product

specifications, functions, and illustrations.

Auteltech will not be liable for any direct damages or for any special, incidental,

or indirect damages or for any economic consequential damages (including lost

profits).

IMPORTANT

Before operating or maintaining this unit, please read this manual carefully,

paying attention to the safety warnings and precautions.

For Services and Support:

http://pro.auteltech.com

www.auteltech.com

1-855-288-3587 (North America)

0086-755-86147779 (China)

Support@auteltech.com

For technical assistance in all other markets, please contact your local selling

agent.

Contents

1SAFETY PRECAUTIONS................................................................ 1

2INTRODUCTION ............................................................................ 2

SPECIFICATIONS................................................................................ 2

ACCESSORIES INCLUDED .................................................................... 3

COMPONENTS AND PORTS .................................................................. 4

3PRODUCT TROUBLESHOOTING .................................................13

4UPDATE........................................................................................14

SOFTWARE UPDATE..........................................................................14

5COMPLIANCE INFORMATION......................................................16

6WARRANTY AND SERVICE..........................................................18

LIMITED ONE YEAR WARRANTY ..........................................................18

SERVICE INFORMATION......................................................................19

1 Safety Precautions

The AUTELTECH MaxiProgrammer 201 (XP201 for short) has been

carefully designed to help automotive technicians maintaining and

servicing modern vehicles.

To avoid personal injury or damage to vehicles, please read this

manual first and observe the following safety precautions whenever

working on a vehicle.

Make sure:

The diagnosis or service is performed in a safe environment.

The vehicle is operated in a well-ventilated work area.

The vehicle parts and XP201 components are welded at a

constant temperature.

The vehicle and XP201 are powered off and grounded.

The XP201 is dry, clean, and free from oil, water, grease and dust.

Electrostatic interference is avoided during operation. If a failure

occurs due to electrostatic interference, please try to operate

again.

2 Introduction

The MaxiProgrammer 201 is specially designed to read Volkswagen

vehicle key chip data, clone and generate exclusive keys, read/write

on-board EEPROM data, and read/write Freescale 9S12 MCUs. By

working with diagnostic tool and PC that are both loaded with

programmer software, the MaxiProgrammer 201 can read/write key

chip data quickly and accurately.

Specifications

Table 2-1 Specifications

Item

Description

Operating Temperature

-10℃~ 85℃(14℉~ 185℉)

Storage Temperature

-20℃~ 85℃(-4℉~ 185℉)

Port

Mini USB, VGA_DB15

Input Voltage

5 VDC

Operating Current

< 250 mA

Maximum Consumption

1 W

Device Dimensions (L*W*H)

130 mm * 68 mm * 28 mm

Package Dimensions (L*W*H)

201 mm * 167 mm * 75 mm

Net Weight

466 g

Gross Weight

11 kg (20 pcs)

Accessories Included

APB001 –EEPROMAdaptor

APA002 –EEPROM Socket

APA001 –EEPROM Clamp Integrated

MC9S12 Cable

User’s Manual

APC001 –USB Cable (Standard USB –

Mini USB)

APC002 –USB Cable (Mini USB –Mini

USB) (Optional)

The two types of USB cables work with

different products, please choose the

corresponding USB cable for the product

you use.

Components and Ports

Figure 2-1 MaxiProgrammer 201 Views

1. Vehicle Key Chip Slot –holds the vehicle key chip.

2. Vehicle Key Slot –holds the vehicle key.

3. Status LED Light –indicates the current operating status.

4. Connection Port –connects EEPROM Adaptor and EEPROM

Clamp Integrated MC9S12 Cable.

5. USB Port –provides data communication and power supply.

Vehicle Key Slot

Holds the Vehicle Key to read and write vehicle key information.

Vehicle Key Chip Slot

Holds the Vehicle Key Chip to read and write vehicle key chip

information.

Status LED Light

The status LED of the XP201 indicates the operating status of the

device. See Table 2-2 for detailed description.

Table 2-2 Status LED Light on the Front Panel

LED Light

Color/Status

Description

Power

Solid Green

Powered on and Default Status

Flashing Green

Communication Status

Solid Red

Error Status

Connection Port

There are two accessories that can be paired with the connection port:

EEPROM Clamp Integrated MC9S12 Cable and EEPROM Adaptor.

EEPROM Clamp Integrated MC9S12 Cable

Figure 2-2 EEPROM Clamp Integrated MC9S12 Cable

1. MC9S12 Cable

Table 2-3 Definitions of MC9S12 Cable

No.

Color

Definition

Pin correspond

to DB15

Note

Green

TXCLKS

Black

GND

Shielded line

White

TOSC

Shielded line

Blue

TSW

Brown

GND

Yellow

TRESET

Red

VDD

2. EEPROM Clamp Cable

Table 2-4 Definitions of EEPROM Clamp Cable

No.

Color

Definition

Pin correspond

to DB15

Note

White and

Red

Pin 1 is red

White and

Purple

White and

Blue

Grey

White and

Brown

White and

Green

White and

Orange

White and

Black

Pin 8 is

black

Here are the possible causes for EEPROM read/write failure and data

error when connecting the clamp to the test board for EEPROM

read/write:

A. EEPROM read/write operations are affected by the circuit of the

connected test board;

B. EEPROM read/write operations of the test board are affected by

the read/write operations of the clamp;

C. The signal is damaged by large resistance. Alarge resistance will

be generated when connecting the clamp to a fast communicating

EEPROM or using a long cable for connection.

Therefore, it is recommended to dismantle the chip on the EEPROM,

weld the EEPROM to the EEPROM adaptor or place in the EEPROM

socket, and then insert it in the EEPROM adaptor.

18. EEPROM Clamp

19. DB15 VGA Port

EEPROM Adaptor

The EEPROM adaptor is compatible with three 8-pin packaging

TSSOP, SOP, DIP connections, and each packaging reserves three

same ports, so the device will function properly when one port is

damaged. For SOP8 packaging, the EEPROM adaptor can also work

with the EEPROM socket. To do this, place the pins of the SOP8

EEPROM into the EEPROM accordingly and then insert them into the

EEPROM adaptor.

USB Port

The USB port is used for the data communication between the XP201
