Auto-Trail Cheyenne Benutzerhandbuch
OWNERS HANDBOOK
Cheyenne & Frontier
www.auto-trail.co.uk
AT Cheyenne-Frontier Owners Handbook v3:Layout 1 12/11/08 16:21 Page 2
TAKE YOURS ON AN ADVENTURE
1
Important
Your motorhome makes use of many complex
systems and services. Please ensure that you
have read all instruction manuals carefully,
and fully understand all aspects of your
vehicle, before driving it on the open road.
If you have any queries on the operation of
any part of your motorhome please contact
your supplying dealer.
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 1
2
www.auto-trail.co.uk
Useful Information
: Owner’s Handbook
Complete the details below:
Model:
Date Purchased:
Supplying Dealer:
Sales Person:
Telephone Number:
Tyre Pressure:
Radio Code:
Exterior Door Key Number:
Water Filter Key Number:
Vehicle Build Number:
Name: Telephone:
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 2
TAKE YOURS ON AN ADVENTURE
3
Useful Information
Auto-Trail VR Limited.
Trigano House, Genesis Way, Europarc,
Grimsby, North East Lincolnshire, DN37 9TU.
Tel: +44(0) 1472 571000 Fax: +44(0) 1472 571001
e-mail: [email protected]
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 3
4
www.auto-trail.co.uk
Contents
: Owner’s Handbook
Useful information..................................................2-3
Introduction............................................................5-6
Preparing for the road............................................7-8
External features..................................................9-10
Driving your motorhome ........................................11
Selecting a pitch......................................................12
Gas services ......................................................13-14
Electrical services ..............................................15-16
Leisure battery ........................................................17
EC325 power supply unit ..................................17-18
EC325 control panel ..........................................19-20
Mains lights ............................................................21
Entertainment system........................................21-22
Spinflo Caprice oven ........................................23-24
Dometic RM7361 refrigerator ................................25
Thetford N150 & N180 fridge/freezer......................26
Truma S3002 vehicle space heater ..................27-28
Truma Combi 4E/6E ..........................................29-30
Truma Ultrastore water heater ................................31
Exterior BBQ ..........................................................32
Flue covers ..............................................................33
Water services ........................................................34
Thetford cassette toilet ..........................................35
Exterior shower ......................................................36
Windows & skylights..........................................37-38
Wind-out awning ....................................................39
Security & ventilation ........................................40-41
Habitation door ......................................................42
Central locking ........................................................43
Entrance step ..........................................................44
General care ......................................................45-46
Winter laying up ................................................47-48
Good neighbour guide ......................................49-50
Annual check list................................................51-54
Guarantee ..........................................................55-56
Cable colour chart ..................................................57
Vehicle specifications..............................................58
Power circuits..........................................................59
230v circuits ............................................................60
Cheyenne circuits - road lighting ............................61
Frontier circuits - road lighting ................................62
Consumer circuits - floor ........................................63
Consumer circuits - roof ........................................64
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 4
TAKE YOURS ON AN ADVENTURE
5
Introduction
Auto-Trail welcomes you to the ranks of
Auto-Trail owners.
This handbook has been designed to enable
you to derive the maximum benefit and
enjoyment from your motorhome;
its information will be beneficial to
experienced and new motorhomers alike.
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 5
6
www.auto-trail.co.uk
Introduction
: Owner’s Handbook
This handbook is intended to give a brief overview
of your motorhome and its appliances.
You are advised to read all of the individual
appliance instructions which will be found in
the information wallet supplied with your vehicle.
Please note that every effort is made within this
handbook to accurately reflect and describe our
motorhomes.
However, our policy of continued improvements,
and change in market supply conditions means
that we reserve the right to alter specifications
without prior notice.
It is important that this handbook accompanies
the motorhome so that any future owner has
the benefit of the relevant information.
Your motorhome is designed to give many years
of use. Regular maintenance is however necessary
to ensure trouble free service.
Your supplying dealer is responsible for all aspects
of customer care.
All vehicles are supplied with a comprehensive
warranty, please ensure that the dealer has fully
explained all aspects of your motorhomes
operational systems and the necessary servicing
requirements.
Should you require assistance your supplying dealer
is fully conversant with the correct procedures that
you should follow to get any issues dealt with in a
timely manner.
Modifications To Your Vehicle
Please check with your supplying dealer before
carrying out any modifications to your vehicle.
Any unauthorised modifications carried out by a
third party could effect the terms of your warranty
agreement.
We would always advise that you consult your
dealer before any additional equipment is fitted
to your vehicle to ensure the appropriate fixing
support is available.
Appliance Maintenance
In the interest of safety, replacement parts for
an appliance shall conform to the appliance
manufacturers specifications, and should
be fitted by him or his authorised agent.
Base Vehicle
Please make reference to the base vehicle
handbook for matters relating to the motorhome
as a road vehicle (e.g. tyre pressures, etc).
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 6
TAKE YOURS ON AN ADVENTURE
Preparing for the Road
Loading Your Vehicle
All models manufactured by Auto-Trail are of
a well balanced design, the most common
causes of poor stability include:
• Poor weight distribution of the weight inside
the vehicle.
• Incorrect tyre pressure (always adhere to
the tyre pressures stated in the chassis
manufacturers handbook. Always inflate
to the ‘fully laden’ condition).
Try to load heavy items down near the floor of
the vehicle, between the axles and as evenly
as possible side to side.
We would recommend that the table is stored
on the floor between the beds if there is no
dedicated storage position.
Where a dedicated storage position is available,
the table should be retained in this position
whilst the vehicle is in motion.
Roof Rack (If Fitted)
Please be advised that the maximum
recommended weight that should be carried
on the roof rack is 40kg.
Please be aware that in certain conditions the
fibreglass roof may become very slippery,
please take extreme care should you choose
to walk on the vehicle roof.
Bicycle Carrier (If Fitted)
Auto-Trail recommends that if a bicycle carrier
is fitted to your vehicle it should be capable of
carrying no more than two cycles.
The Frontier model is designed to accept a
specific model of cycle carrier details of which
are available through your supplying dealer.
Never exceed the maximum authorised weight
that should be specified on the carrier.
Tow Bars
Various suppliers manufacture tow bars that can
be fitted to your Auto-Trail vehicle. Please check
with your tow bar supplier that the tow ball fitted
to your vehicle fits your requirements exactly
and does not contravene any road traffic
regulations.
7
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 7
8
www.auto-trail.co.uk
Preparing for the Road
: Owner’s Handbook
Maximum Loading Of Your Vehicle
The weights of your vehicle are stated in the back of
this handbook and on the secondary weight plate
located in the engine bay of your vehicle.
The secondary weight plate gives the following
information.
The serial number of your vehicle which should
be quoted in any correspondence with your
supplying dealer.
• ‘MAW’ is the maximum authorised weight of your
vehicle which must never be exceeded when the
vehicle is loaded and in use.
• ‘GTW’ is the gross train weight of your vehicle.
This is the maximum combined weight of the
actual motorhome fully loaded to its maximum
authorised weight, plus the allowance for a trailer.
The weight of the loaded motorhome and trailer
must never exceed the gross train weight quoted
on the weight plate.
• ‘1’ is the maximum authorised weight for the
individual front axle
• ‘2’ is the maximum authorised weight for the
individual rear axle.
• ‘3’ is the maximum authorised weight of the
individual third axle (only used on twin rear
axle models).
Please note that if you add both maximum
authorised axle weights together it will normally
give you a larger figure than the maximum
authorised weight (MAW) – please be aware that
the Maximum authorised weight (MAW) must
never be exceeded.
Please take care to ensure that you have allowed
for the masses of all items you intend to carry in
the Motorhome. e.g. passengers, optional
equipment, essential habitation equipment and
personal effects such as clothing, food, pets,
bicycles, sailboards, sports equipment, etc.
Before You Set Off In Your Motorhome
• Ensure all articles are stowed securely.
Do not store tins, bottles or heavy items in
overhead lockers.
• Close and secure all lockers and cupboard doors.
• Secure all bunks.
• Close and secure all roof lights.
• Store main table in transit position.
• Ensure fridge is on 12V operation and set
door lock.
• Close and latch all windows (never drive with
windows on night settings).
• Leave all curtains and blinds open to aide visibility.
• Ensure leisure battery is secure.
• Ensure all gas appliances are turned off, that the
gas bottles are correctly positioned, secured and
turned off.
• Ensure that seat swivels (if fitted) are locked in
the forward facing position.
• Ensure entrance step is retracted
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 8
TAKE YOURS ON AN ADVENTURE
9
External Features
F
D
B
C
A
A Exterior door retaining catch when open
B Folding step
C Fridge vents
D Awning light (where fitted)
E Status T.V. aerial
(omni directional, where fitted)
F Front marker lights
E
2090 AT Cheyenne-Frontier Owners Handbook REPRO 2:Layout 1 18/11/08 14:40 Page 9
Dieses Handbuch passt für folgende Modelle
8
Inhaltsverzeichnis
Andere Auto-Trail Wohnmobil Handbücher
Auto-Trail
Auto-Trail FRONTIER Benutzerhandbuch
Auto-Trail
Auto-Trail Tracker Benutzerhandbuch
Auto-Trail
Auto-Trail Motorhome Installationsanleitung
Auto-Trail
Auto-Trail V LINE 540 SE 2020 Benutzerhandbuch
Auto-Trail
Auto-Trail Excel Benutzerhandbuch
Auto-Trail
Auto-Trail 2015 V-Line Benutzerhandbuch
Auto-Trail
Auto-Trail Tribute Series Benutzerhandbuch
Auto-Trail
Auto-Trail Motorhome Bedienungsanleitung
Auto-Trail
Auto-Trail 2006 Benutzerhandbuch
Beliebte Wohnmobil Handbücher anderer Marken
Jayco
Jayco Kiwi Travel Trailer 2003 Bedienungsanleitung
Fleetwood
Fleetwood 1999 Discovery Kurzanleitung
Bush Palace
Bush Palace STARCRAFT TOO Bedienungsanleitung
Fleetwood
Fleetwood Jamboree Searcher 1993 Bedienungsanleitung
Winnebago
Winnebago Journey Bedienungsanleitung
Tiffin Motorhomes
Tiffin Motorhomes 2017 Allegro Breeze Bedienungsanleitung
Winnebago
Winnebago 2009 Spirit Bedienungsanleitung
Lunar Caravans
Lunar Caravans Venus Bedienungsanleitung
Triple E
Triple E Free Spirit 2012 Bedienungsanleitung
Winnebago
Winnebago 2014 Adventurer Bedienungsanleitung
NewMar
NewMar Dutch Star 1999 Bedienungsanleitung
Winnebago
Winnebago 1996 Brave Bedienungsanleitung
