AutoMeter BATTERY EXTENDER 9201-12V Bedienungsanleitung

FOR SERVICE OR REPLACEMENT PARTS CONTACT: AUTO METER PRODUCTS Inc. 413 W. Elm St. Sycamore, IL 60178 USA (866) 248-6357

Email us at [email protected] 2650-772X-10 Rev. D 5/19/09

LIMITED WARRANTY (12 MONTHS FROM DATE OF PURCHASE)

Auto Meter warrants to the original retail purchaser that this product will be free from defects in material or workmanship for a period of twelve (12) months from the date

of original retail purchase. When Auto Meter determines a product failed due to defects in material or workmanship within this 12 month warranty period, the product

will be repaired or replaced for the original retail purchaser only. This warranty is limited to the repair or replacement of parts in the Battery Extender and the necessary

labor by Auto Meter to effect the repair or replacement of the Battery Extender. In no event shall Auto Meter be responsible for special, incidental or consequential

damages or costs incurred due to the failure of this product. Improper use, accident, water damage, abuse, unauthorized repairs or alterations, but not limited to these

acts, voids this warranty. Auto Meter disclaims any liability or consequential damages due to breach of any written or implied warranty on the Battery Extender, or any

attempted service done by anyone other than Auto Meter.

WARRANTY AND SERVICE INFORMATION

Warranty and service claims sent to the Auto Meter service department must be transportation prepaid and accompanied with dated proof of purchase. This warranty

applies only to the original retail purchaser and is non-transferable. Damage incurred during return shipments are not covered under this warranty. It is the responsibility

of the shipper (the original retail purchaser returning the Battery Extender) to package the tester properly to prevent any damage during return shipment. Repair costs

for such damages will be charged back to shipper (original retail purchaser returning Battery Extender). Protect the product and add plenty of packing/cushioning such

as crumpled up newspaper.

MOUNTING

Mounting key holes are provided on both end caps of the unit. It is

recommended that you mount the Battery Extender to a wall or other

secure surface. This will keep it out of the way and prevent damage

due to accidents. You may leave the screws slightly loose to allow easy

removal through the key hole slot.

IMPORTANT!

A clean battery and battery terminals insure proper operation of the

Battery Extender and the vehicle charging system. Dirty terminals may

put a constant slow drain on the battery. If your battery and terminals

have a white or blueish crust on them, your charging system may be

having problems. Have the vehicle electrical system checked by a

qualified automotive service technician.

MAINTENANCE AND CLEANING

Always keep your Battery Extender clean and looking like new! Unplug

the Battery Extender, and use a slightly dampened cloth to clean the

housing and lead sets. Use no solvents or soaps.

OVERLOAD AND PROTECTIVE DEVICES

The Battery Extender is equipped with two overload protectors. In the

event of minor overloads, power will be reduced to a safe level to allow

continued use in maintenance mode only. The second protector will

activate in the event of major overload and completely turn the unit

off. The second protector is permanent and must be repaired at the

factory.

WHAT TO EXPECT FROM YOUR BATTERY EXTENDER!

MAXIMIZES BATTERY LIFE

The Battery Extender is designed to maximize the life of a serviceable

lead acid battery. A serviceable battery is a battery that is not defective

or damaged. This means a vehicle battery will not give you the annual

dead battery surprise when it comes out of storage!

PREVENTS PREMATURE BATTERY FAILURE

The Battery Extender keeps your battery at full charge on a

continuous basis. Batteries not kept at a full charge become sulfated,

which is the main reason for premature battery failure.

MAINTAINS STORED BATTERIES AT FULL CHARGE

The Battery Extender should be used to charge and maintain all

starting and deep cycle batteries in storage or that don’t receive daily

use. Some examples are: automobiles, boats, race cars, campers,

RV’s, 4 wheelers, motorcycles, personal water craft, farm machinery

(tractors, combines, etc.), heavy equipment, rental equipment (trucks,

compressors, portable signs, bulldozers, stationary pumps, etc.),

and any equipment that receives occasional use or is in storage.

The Battery Extender is also fully compatible with gelled electrolyte

(gel-cell) batteries (sometimes used in place of liquid electrolyte

batteries in many heavy duty applications). (DO NOT USE WITH DRY

CELL, NICKLE CADMIUM, NICKLE METAL HYDRIDE OR SIMILAR

BATTERIES. Refer to the enclosed instructions.)

NOTE: Never use the Battery Extender in a boat or water craft.

Always remove the battery from the boat or water craft and

use the Battery Extender on shore.

VALUABLE PROTECTION

The Battery Extender provides full off-season protection for seasonally

used batteries. It keeps your stored batteries ready for their next use.

This means a serviceable battery will not give the annual dead battery

surprise when it comes out of storage!

PROTECTION FROM COMPUTER DRAIN

Cars are often equipped with computers that require continuous

battery power to maintain data in memory. The Battery Extender’s

superior circuitry automatically delivers the correct charge to

compensate.

LONG LASTING PERFORMANCE

The Battery Extender has been designed and manufactured in America

to provide superior performance from the High Tech housing to the

last internal detail. Quality is built in and assured with circuit burn-in,

computerized testing and inspection. Care in handling and occasional

cleaning of the leads and housing will help keep it looking like new, and

give you many years of satisfaction.

Checks Each Battery’s Condition

The Battery Extender will determine the worst batteries that are

sulfated and that have bad cells. The battery can be replaced without

unnecessary charging.

Battery Warmer

The Battery Extender will keep a battery warm and ready for full use on

cold days.

2650-772X-10 Rev. D

OPERATING INSTRUCTIONS

BATTERY EXTENDER™

MODELS 9201-12V, 9202 12-16V

1. Before operating your Battery Extender, read and follow all instructions,

cautions, procedures, and warnings shown or printed on:

• Thisinstructionmanual

• YourBatteryExtender

• Thebatterytobechargedormaintained

• TheVehicleorunitabatteryisusedorinstalledin

Consult Auto Meter if you need more information.

2. Use the Battery Extender only on LEAD ACID AND GELLED

ELECTROLYTE (GEL-SELL) BATTERIES that match the voltage

printed on the front label of the Battery Extender. DO NOT attempt

use on other types of batteries (Dry Cell, Nickel Cadmium, Nickel

Metal Hydride, etc.) commonly found in small home appliances.

This may cause the batteries to burst, resulting in damage or injury

to people and property.

3. DO NOT use your Battery Extender on batteries that are in use. Use

it only on batteries or vehicles that are in storage.

4. DO NOT use attachments with your Battery Extender that are not

recommended or sold by Auto Meter. Non-recommended attachments

may result in injury, electric shock, or fire and voids the warranty.

5. To connect or disconnect the Battery Extender from a battery

always use the square 2 pin connector. When disconnecting from

the battery or unplugging from the wall, use the plug to pull on.

Never pull the cord, it may damage the plug or the cord.

6. Place the power cords in a location where they will not be stepped

on, tripped over, or subjected to stress or abuse of any kind.

7. Never operate your Battery Extender if any portion of it’s housing,

cords, or attachments appear to be damaged in any way. Have it

inspected and serviced by Auto Meter.

8. If your Battery Extender has been dropped, received a sharp blow,

or abused in any way, have it inspected and repaired by Auto Meter

if necessary.

9. Use of an extension cord is not recommended. An inadequate

extension cord could result in fire or electric shock. If you must use

one, make sure the following conditions are met:

A.Useathreepronggroundedextensioncord.

B.Thecordendsarewiredcorrectlyandingoodcondition.

C.Thecorditselfisingoodcondition.

D.Insure that all pins on the extension cord are identical in size,

shapeandnumberastheplugontheBatteryExtender.

E.Make sure the extension cord is large enough to carry the AC

amperageratingofyourBatteryExtender.Seechartbelow:

10. NEVER open the housing of the Battery Extender or attempt to

repair it yourself. It must be repaired by Auto Meter. Their are no

user serviceable parts inside. Any tampering or incorrect assembly

may result in fire or electric shock and voids the warranty.

11. To prevent injury during cleaning or maintenance, always:

• UnplugtheBatteryExtenderfromthewalloutletfirst(usingtheplug).

• DisconnecttheBatteryExtenderfromthebattery.

12. ALWAYS disconnect the Battery Extender from a stored vehicle or

battery before operation.

13. NEVER attempt to charge a frozen battery. Allow the battery to

return to room temperature before connection.

14. ALWAYS use the Battery Extender in an open and well ventilated area.

The area should be dry and free of trash, debris, and combustibles.

WARNING: Explosive Hydrogen gas may be present around batteries.

15. DO NOT use the Battery Extender in direct sun light or adverse

weather conditions such as rain or snow.

16. Never place your Battery Extender above or below the battery.

Locate it as far to the side of the battery as the leads permit. This

prevents acid drips and spills from landing on the Battery Extender

during battery filling or specific gravity testing. This also prevents

battery fumes from reaching the Battery Extender.

17. DO NOT place a battery on the Battery Extender.

18. DO NOT touch the charging clips together when the Battery

Extender is plugged in.

19. DO NOT attempt to open or modify the unit. DO NOT insert any

object into ventilation holes. DO NOT cover ventilation holes on

unit.

20. NEVER use the Battery Extender in or on any boat or water craft.

You must remove the battery from the boat or water craft and charge

on dry land. DO NOT use the Battery Extender where it will be

exposed to moisture or inclement weather, or around combustibles

like trash, flammable liquids and vapors.

GENERAL SAFETY RULES FOR SAFE OPERATION

PERSONAL SAFETY PRECAUTIONS

1. Wear protective goggles or a full face shield.

2. Wear protective clothing. Leave no exposed skin.

3. Have plenty of fresh water and hand soap available for use if acid

should contact your eyes, skin or clothing.

4. Have someone close by in the event you need emergency

assistance when working with a battery.

5. Remove all metal objects (pens, tools, jewelry etc.) from your body.

These items can create a direct short between the battery terminals

and can cause serious burns.

6. DO NOT carry tools or metal objects in the vicinity of a battery.

These items can fall on the battery terminals creating a high current

short. This could result in a fire, burns, explosion, etc.

7. DO NOT touch your face, eyes or other body parts without first washing

your hands. Battery acid can burn and irritate eye and skin tissue.

8. DO NOT allow any source of ignition in the area of a battery. Keep

all flame and spark producing devices out of the area and NEVER

SMOKE near a battery.

9. Use the one hand rule! Keep one hand in your pocket whenever

you make an electrical connection. This reduces the risk of electric

shock to the user.

10. DO NOT attempt to open or modify the unit. DO NOT insert any

object into ventilation holes. DO NOT cover ventilation holes on

unit.

Length of cord (feet): 25 50 100 150

AWG size of cord: 18 18 18 16

Lead acid batteries are dangerous! During use and charging they may generate EXPLOSIVE hydrogen gas. This means

YOU MUST carefully read and follow these instructions before each use of your Battery Extender.

WARNING:

DO NOT use on 6 volt batteries. This instruction applies to 9201 and 9202 only.

IMPORTANT: This product is not a charger. It is designed to maintain a charged battery at full charge during storage.

It is normal for case to be hot to the touch in charge mode. Thermal protective circuitry provides for safe, unattended operation.

NOTE:

Two Pin Connector

BATTERY

Red (+)

Spring

Clip

Larger

Positive (+)

Post

Smaller

Negative (-)

Post

Black (-)

Spring

Clip

For uninstalled batteries we have supplied a lead set with spring clips.

Follow these steps for connection and operation (see illustration to

right):

1. Make sure the Battery Extender is NOT plugged in to an AC outlet

before connecting the clips to the battery.

2. (Model 9202 only.) Set the 12/16 volt switch to the voltage of the

battery you are connecting to.

3. Locate the positive (+) terminal post of the battery, it is usually larger

than the negative (-) terminal post. Connect the RED spring clip to

this battery terminal post. It’s a good idea to wiggle the clip on the

battery post to insure a good connection.

4. Connect the BLACK spring clip to the negative (-) battery terminal post.

5. Double check that the square two pin connector on the lead set is firmly

plugged into the square output connector of the Battery Extender.

6. Make sure the Battery Extender is safely located away from the

battery and in a non hazardous location.

7. Plug the AC cord in to a grounded outlet.

8. (Model 9202 only.) For 16V batteries, the red 16V light should be

ON. If the light is OFF, check that the 12/16V switch is in the correct

position.

FOR USE WITH SPRING CLIPS

NOTE: The Battery Extender may switch back into full

charge mode (Amber light ON) as required by

your battery, this is normal.

BATTERY EXTENDER OPERATING INSTRUCTIONS

No Lights:Means one of the following:

• You reversed the connections by connecting the red spring clip to the

negative (-) battery post and the black spring clip to the positive (+)

batterypost.

•Youhaveapoorconnectionatthebattery.

•ThereisnoACpower.

Check all three!

Amber light (Charge): The Battery Extender is delivering up to a 1 Amp

charge.

Green light (Maintain): The Battery Extender is safely maintaining your

battery at a full charge. Your battery is ready to go when you need it!

Amber Flashing Light = Defective Battery:The Battery Extender is

designed to detect either sulfated battery or dead cell. Make sure that the

battery post and clamp are clean. If the amber light continues to flash the

battery should be replaced.

Your Battery Extender is equipped with sophisticated circuitry that

will safely charge and maintain both 12 and 16 Volt batteries without

MaintainCharge

Auto Meter Products, Inc.

413 W.Elm St., Sycamore, IL 60178

Battery Extender

12V Battery Charger/Maintainer

Extends Battery Life

Model 9201

16 Volt

When Lit

Green Light

(Maintenance Mode)

Amber Light

(1 Amp Charge)

overcharging. Make sure you read and follow the “General Safety Rules

for Safe Operation” before proceeding with this operating instruction.

BATTERY EXTENDER INDICATOR LIGHTS

WARNING: Do not close hood, doors, or covers when using spring

clips on installed batteries. This can cause dangerous

high current shorting across the battery terminals.

FOR USE WITH BATTERY CLIPS ON INSTALLED BATTERIES

You may use the spring clip lead set for installed batteries on a

temporary basis. However we do not recommend doing this for long

term connections. The clips can accidentally come in contact with

compartment covers, hoods and other items that may cause dangerous

high current shorts across the battery terminals. To temporarily connect

the spring clips to an installed battery, follow these steps:

1. Check that the Battery Extender is NOT plugged in to an AC outlet

before connecting the spring clips to the battery.

2. (Model 9202 only.) Set the 12/16 volt switch to the voltage rating of

the battery you are connecting to.

3. Locate the positive (+) terminal post of the battery, it is usually larger

than the negative (-) terminal post. Connect the RED (+) spring clip

to this battery terminal post.

4. Connect the BLACK (-) spring clip to a bolt or screw on the chassis

or engine block. These should be heavy steel parts not sheet metal.

Do not connect to fuel lines, carburetor, or moving parts. Make the

connection as far from the battery as the leads allow.

5. Plug in the AC cord, and observe the indicator lights for operation.

6. (Model 9202 only.) For 16V batteries, the red 16V light should be

ON. If the light is OFF, check that the 12/16V switch is in the correct

position.

Red Light

(16 Volt Operation)

Model 9202 only

For batteries installed in vehicles or other equipment we have provided

a lead set with ring terminals. Since many installed batteries are in

space-restricted locations or compartments, these ring terminals (see

illustration to left) have been designed to provide a safe and convenient

connection. Follow these steps for connection and operation:

1. Check that the Battery Extender is NOT plugged in to an AC outlet

before connecting the ring terminals to the battery.

2. (Model 9202 only.) Set the 12/16 volt switch to the voltage rating of

the battery you are connecting to.

3. Locate the positive (+) terminal post of the battery, it is usually larger

than the negative (-) terminal post. Connect the RED (+) ring terminal

to this battery terminal.

4. Connect BLACK (-) ring terminal to negative (-) battery terminal.

5. Double check that the square two pin connector on the lead set

is firmly plugged into the square out put connector of the Battery

Extender (see illustration in “FOR USE WITH SPRING CLIPS”).

6. Secure the lead set out of the way of fan blades, belts, pulleys, and hot

items like exhaust manifolds. Nylon ties work great in this situation.

7. Make sure the Battery Extender is safely located away from the

battery and in a nonhazardous location.

8. Plug the AC cord in to a grounded outlet.

9. (Model 9202 only.) For 16V batteries, the red 16V light should be

ON. If the light is OFF, check that the 12/16V switch is in the correct

position.

BATTERY

SMALL

SCREW

TERMINAL

BATTERY

Red (+)

Ring Terminal

Smaller

Negative (-)

Post

Larger

Positive (+)

Post

Black (-)

Ring Terminal

Red (+)

Battery Cable Black (-)

Battery Cable

Red (+)

Ring Terminal

Larger

Positive (+)

Post

Smaller

Negative (-)

Post

Black (-)

Ring Terminal

Red (+)

Battery Cable

Black (-)

Battery Cable

2 Pin Connector

NOTE: Smaller batteries may have screws for terminals (see

illustration to right). You may need to purchase smaller ring

terminals for these applications. Do not connect ring terminals

to anything but the battery. Other locations are hazardous.

WARNING: Do not use in 16V mode on a 12V battery.

Damage to your battery will occur.

FOR USE WITH PERMANENT RING TERMINALS

Connect the Battery Extender to

a grounded 120 Volt AC power

receptacle (left) that is wired in

compliance with local electrical code.

A grounded receptacle will receive a

plug with a round ground pin and two

blade terminals.

PROPER AC POWER CONNECTIONS

WARNING: Do not alter the plug or cord on your Battery Extender. To do

so is a serious safety risk. You must have a proper ground.

If you do not know how to test an outlet for ground, have a

qualified electrician test it for you.

If your outlet will not receive a plug with a

ground pin, you will need a temporary ground

adapter (3 prong adapter, shown to the right). Be

sure the metal ground tab is securely screwed

into the face plate as shown. You may need

a longer screw than the screw in the outlet.

Use this adapter only as a temporary means of

connection. Have a qualified electrician install a

proper receptacle as soon as possible.

Metal

Grounding Tab

3. If you accidentally disconnect

the Battery Extender from

the battery while it is in

operation, it will shut itself off

in approximately one second.

You must complete the

disconnection procedure after

this happens by performing

steps 1 and 2.

PROPER DISCONNECT PROCEDURE

2. a) Disconnect the square

two pin output connector

for the ring terminal lead

set as shown.

b) For the spring clip lead

set, always disconnect

the BLACK (-) spring

clip first and the RED (+)

spring clip second.

1. Always disconnect the

AC extension cord first

(if used). Then unplug

the AC power cord of

the Battery Extender.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere AutoMeter Stromversorgung Handbücher

AutoMeter

AutoMeter CLEAN POWER CPS-55 Bedienungsanleitung

Beliebte Stromversorgung Handbücher anderer Marken

Monacor

Monacor PS-12CCD Bedienungsanleitung

VOLTIMA

VOLTIMA MagicBox 15 Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6032A Bedienungsanleitung

Miller

Miller Auto Deltaweld 452 Bedienungsanleitung

BCP

BCP PUOUBK Merkblatt

HC 2210 Bedienungsanleitung

Puls

Puls CT5.241 Bedienungsanleitung

OCZ

OCZ ZX1250W Bedienungsanleitung

iseg

iseg ECH 238 Bedienungsanleitung

Power

Power XXL A Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6631B Bedienungsanleitung

Renogy

Renogy PHOENIX 300 Bedienungsanleitung

HP 6200B Service-Handbuch

Epson

Epson Stylus Scan 2500 Betriebsanleitung

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Bedienungsanleitung

Puls

Puls MiniLine ML50.100 Bedienungsanleitung

Puls

Puls AS-Interface SLA4.100 Bedienungsanleitung

Kenwood

Kenwood PS-60 Bedienungsanleitung
